sensor Lexus IS300h 2013 Owner's Guide

191
4Driving
IS300h_EE(OM53B95E)
4-1. Before driving
Driving the vehicle............ 192
Cargo and luggage ............ 200
Trailer towing.................... 201
4-2. Driving procedures
Power (ignition) switch ..... 209
EV drive mode .................. 214
Hybrid transmission .......... 216
Turn signal lever ............... 222
Parking brake .................... 224
ASC
(Active Sound Control)... 225
4-3. Operating the lights and
wipers
Headlight switch............... 226
Automatic High Beam ...... 229
Fog light switch ................ 233
Windshield wipers and
washer ............................. 235
4-4. Refueling
Opening the fuel tank cap . 2414-5. Using the driving
support systems
Cruise control ................... 245
Dynamic radar cruise
control ............................. 249
LDA
(Lane Departure Alert) ... 261
Lexus parking
assist-sensor .................... 267
Rear view monitor system 274
Driving mode select
switch.............................. 283
Driving assist systems ...... 286
PCS (Pre-Crash Safety
system)............................ 292
BSM
(Blind Spot Monitor) ...... 299
• The Blind Spot Monitor
function......................... 304
• The Rear Crossing
Traffic Alert function ... 306
4-6. Driving tips
Hybrid vehicle driving tips 309
Winter driving tips .............311

2274-3. Operating the lights and wipers
4
Driving
IS300h_EE(OM53B95E)
This system allows the headlights and front position lights to be turned on
for 30 seconds when the power switch is off.
Pull the lever toward you and
release it with the light switch is in
or after turning the power
switch off.
Pull the lever toward you and release
it again to turn off the lights.
Daytime running light system
To make your vehicle more visible to other drivers, the front position lights turn
on automatically (at an increased intensity) whenever the hybrid system is started
and the parking brake is released. Daytime running lights are not designed for
use at night.
Headlight control sensor
Automatic light off system
When the light switch is in or : The headlights and front fog lights turn
off automatically if the power switch is turned to ACCESSORY mode or turned
off.
When the light switch is in : The headlights and all lights turn off automati-
cally if the power switch is turned to ACCESSORY mode or turned off.
To turn the lights on again, turn the power switch to ON mode, or turn the light
switch off once and then back to or .
If any of the doors or trunk lid is left open, the lights automatically turn off after
20 minutes.
Follow me home system
The sensor may not function properly if an
object is placed on the sensor, or anything
that blocks the sensor is affixed to the wind-
shield.
Doing so interferes with the sensor detect-
ing the level of ambient light and may cause
the automatic headlight system to malfunc-
tion.

2284-3. Operating the lights and wipers
IS300h_EE(OM53B95E)
Light reminder buzzer
A buzzer sounds when the power switch is turned off or turned to ACCESSORY
mode and the driver’s door is opened while the lights are turned on.
Automatic headlight leveling system
The level of the headlights is automatically adjusted according to the number of
passengers and the loading condition of the vehicle to ensure that the headlights
do not interfere with other road users.
Operation guide display (vehicles with rain-sensing windshield wipers only)
When the headlight switch is operated to and from the “AUTO” position, the cur-
rent status is displayed on the meters for a few seconds to show that AUTO mode
is activated/deactivated. (P. 1 1 9 )
Customization
Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features: P. 581)
NOTICE
To prevent 12-volt battery discharge
Do not leave the lights on longer than necessary when the hybrid system is off.

2294-3. Operating the lights and wipers
4
Driving
IS300h_EE(OM53B95E)
Push the lever away from you
with the headlight switch in the
or position.
Press the Automatic High Beam
switch.
The Automatic High Beam indicator
will come on when the headlights
are turned on automatically to indi-
cate that the system is active.
Automatic High Beam

: If equipped
The Automatic High Beam uses an in-vehicle camera sensor to assess the
brightness of streetlights, the lights of oncoming and preceding vehicles,
etc., and automatically turns the high beam on or off as necessary.
Activating the Automatic High Beam system
1
2

2314-3. Operating the lights and wipers
4
Driving
IS300h_EE(OM53B95E)
The Automatic High Beam can be operated when
The power switch is in ON mode.
Camera sensor detection information
High beam may not be automatically turned off in the following situations:
• When oncoming vehicles suddenly appear from a curve
• When the vehicle is cut in front of by another vehicle
• When oncoming or preceding vehicles are hidden from sight due to repeated
curves, road dividers or roadside trees
High beam may be turned off if an oncoming vehicle that is using fog lights
without using the headlights is detected.
House lights, street lights, red traffic signals, and illuminated billboards or signs
may cause the high beam to turn off.
The following factors may affect the amount of time taken to turn high beam on
or off:
• The brightness of headlights, fog lights, and tail lights of oncoming and pre-
ceding vehicles
• The movement and direction of oncoming and preceding vehicles
• When an oncoming or preceding vehicle only has operational lights on one
side
• When an oncoming or preceding vehicle is a two-wheeled vehicle
• The condition of the road (gradient, curve, condition of the road surface etc.)
• The number of passengers and amount of luggage
High beam may be turned on or off when unexpected by the driver.
Small vehicles, such as bicycles, may not be detected.
In the situations below, the system may not be able to correctly detect the sur-
rounding brightness levels, and may flash or expose nearby pedestrians to the
high beam. Therefore, you should consider turning the high beams on or off
manually rather than relying on the Automatic High Beam system.
• In bad weather (rain, snow, fog, sandstorms etc.)
• The windshield is obscured by fog, mist, ice, dirt etc.
• The windshield is cracked or damaged.
• The camera sensor is deformed or dirty.
• Surrounding brightness levels are equal to those of headlights, tail lights or
fog lights.
• Vehicles ahead have headlights or tail lights that are either switched off,
dirty, changing color, or have improperly adjusted aim.
• When driving through an area of intermittently changing brightness and
darkness.
• When frequently and repeatedly driving ascending/descending roads, or
roads with rough, bumpy or uneven surfaces (such as stone-paved roads,
gravel tracks etc.).
• When frequently and repeatedly taking curves or driving on a winding road.
• There is a highly reflective object ahead of the vehicle, such as a sign or a
mirror.
• The vehicle’s headlights are damaged or dirty.
• The vehicle is listing or titling, due to a flat tire, a trailer being towed etc.
• The driver believes that the high beam may be causing problems or distress
to other drivers or pedestrians nearby.

2324-3. Operating the lights and wipers
IS300h_EE(OM53B95E)• The vehicle is used in a territory in which vehicles travel on the opposite side
of the road of the country for which the vehicle is approved, for example
using a vehicle designed for right-hand traffic in a left-hand traffic territory,
or vice versa.
CAUTION
Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turning high beam on or off manually if neces-
sary.
NOTICE
Notes when using the Automatic High Beam system
Do not touch the camera sensor.
Do not subject the camera sensor to a strong impact.
Do not disassemble the camera sensor.
Do not spill liquid onto the camera sensor.
Do not apply window tinting or stickers to the camera sensor or the area of
windshield near the camera sensor.
Do not place items on the dashboard. There is a possibility that the camera
sensor will mistake items reflected in the windshield for streetlights, the head-
lights of other vehicles, etc.
Do not install a parking tag or any other accessories near or around the cam-
era sensor.
Do not overload the vehicle.
Do not modify the vehicle.
Do not replace windshield with non-genuine windshield.
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Observe the following to ensure that the
Automatic High Beam functions correctly.

2374-3. Operating the lights and wipers
4
Driving
IS300h_EE(OM53B95E)
Rain-sensing windshield wipers
Move the lever up by 2 lev-
els
Move the lever up by 1 level
Move the lever down by 1
level
Move the lever down by 2
levels
AUTO mode on/off switch
With AUTO mode selected, the wip-
ers will operate automatically when
the sensor detects falling rain. The
system automatically adjusts wiper
timing in accordance with rain vol-
ume and vehicle speed.
The AUTO mode indicator will turn
on when AUTO mode is selected.
*1: After temporary operation, the mode will return to AUTO mode.
*2: AUTO mode will be canceled.
AUTO mode
indicator
1
2
3
4
5
OffTemporary
operationTemporary
operationLow speed
operationHigh speed
operation
Low speed
operationOffOffHigh speed
operationHigh speed
operation
High speed
operationOffLow speed
operationNo changeNo change
AUTO
mode
Intermittent
operation
Off
Temporary
operation
*1Low speed
operation
*2High speed
operation
*2Continu-
ouslyNo change
Operation
Status
before
operation

2384-3. Operating the lights and wipers
IS300h_EE(OM53B95E)
When AUTO mode is selected, the sensor sensitivity can be adjusted by
turning the switch ring.
Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
The wipers will automatically oper-
ate a couple of times after the washer
squirts.
When the headlights are on and the
lever is pulled and held, the head-
light cleaners will operate once.
After this, the headlight cleaners will
operate every 5th time the lever is
pulled.
The wipers can be used as intermittent windshield wipers, which operate
regardless of vehicle speed or amount of raindrops. The intermittent
windshield wiper operation can be switched when the vehicle is stopped
and the wiper is off. The wiper operation cannot be switched during
AUTO mode or while the intermittent windshield wipers are operating.
Press and hold until the AUTO
mode indicator stops flashing.
If is pressed and held until the
AUTO mode indicator stops flashing
again, it will return to its previous
state.
The wiper can be switched when the
vehicle is stopped and the wipers are
off.
6
7
8
Switching between the intermittent windshield wipers and rain-
sensing windshield wipers (vehicles with rain-sensing windshield
wipers)

2394-3. Operating the lights and wipers
4
Driving
IS300h_EE(OM53B95E)
The windshield wiper and washer can be operated when
The power switch is in ON mode.
Dripping prevention wiper sweep
After performing a washing and wiping operation several times, the wipers oper-
ate one more time after a short delay to prevent dripping.
However, the last sweep will not happen if the vehicle is traveling above 170 km/
h (106 mph).
Effects of vehicle speed on wiper operation (vehicles with rain-sensing wind-
shield wipers)
Vehicle speed affects the following even when the wipers are not in AUTO
mode.
Intermittent wiper interval
Wiper operation when the washer is being used (delay until drip prevention
wiper sweep occurs)
With low speed windshield wiper operation selected, wiper operation will be
switched from low speed to intermittent wiper operation only when the vehicle is
stationary.
Raindrop sensor (vehicles with rain-sensing windshield wipers)
If the wiper is turned to AUTO mode while the power switch is in ON mode,
the wipers will operate once to show that AUTO mode is activated.
If the temperature of the raindrop sensor is 85°C (185°F) or higher, or -30°C (-
22°F) or lower, automatic operation may not occur. In this case, operate the
wipers in any mode other than AUTO mode.
When the windshield wipers are in temporary operation (vehicles with rain-sens-
ing windshield wipers)
AUTO mode cannot be activated even if is pressed.
If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the
windshield washer fluid reservoir.
Operation guide display (vehicles with rain-sensing windshield wipers only)
When the windshield wiper switch is operated to activate AUTO mode or when
the rain-sensing level is adjusted, the current status is displayed on the meters for
a few seconds. (P. 1 1 9 )
The raindrop sensor judges the amount of
raindrops.
An optical sensor is adopted. It may not
operate properly when sunlight from the
rising or setting of the sun intermittently
strikes the windshield, or if bugs etc. are
present on the windshield.

2404-3. Operating the lights and wipers
IS300h_EE(OM53B95E)
CAUTION
Caution regarding the use of windshield wipers in AUTO mode
The windshield wipers may operate unexpectedly if the sensor is touched or the
windshield is subject to vibration in AUTO mode. Take care that your fingers
or anything else do not become caught in the windshield wipers.
Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility. This
may lead to an accident, resulting in death or serious injury.
NOTICE
When the windshield is dry
Do not use the wipers, as they may damage the windshield.
When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled toward
you and held continually.
When a nozzle becomes blocked
In this case, contact any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
Do not try to clear it with a pin or other object. The nozzle will be damaged.
