239
4-1. Maintenance and care
4
Maintenance and care
NOTICE
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the rear window, as this may cause damage to
the rear window defogger heater wires or antenna. Use a cloth dampened with
lukewarm water to gently wipe the window clean. Wipe the window in strokes
running parallel to the heater wires or antenna.
●Be careful not to scratch or damage the heater wires or antenna.

240
4-2.Maintenance
Maintenance requirements
To ensure safe and economical driving, day-to-day care and regular mainte-
nance are essential. It is the owner’s re sponsibility to perform regular checks.
Lexus recommends performing the following maintenance:
■ General maintenance
General maintenance should be pe rformed on a daily basis. This can
be done by yourself or by a Lexus dealer.
■ Scheduled maintenance
Scheduled maintenance should be performed at specified intervals
according to the ma intenance schedule.
For details about maintenance items and schedules, refer to the “Warranty
and Service Guide”, “Owner’s Manual Supplement” or “Scheduled Mainte-
nance”.
■ Do-it-yourself maintenance
You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty
coverage.
The use of Lexus repair manuals is recommended.
For details about warranty coverage, refer to the separate “Owner’s
Guide”, “Warranty and Service Guide” , “Owner’s Manual Supplement” or
“Warranty Booklet”.
■Repair and replacement
It is recommended that genuine Lexus parts be used for repairs to ensure perfor-
mance of each system. If non-Lexus parts are used in replacement or if a repair
shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
■Allow inspection and repairs to be performed by a Lexus dealer
●Lexus technicians are well-trained speciali sts and are kept up to date with the
latest service information. They are well informed about the operation of all sys-
tems on your vehicle.
●Keep a copy of the repair order. It proves that the maintenance that has been
performed is under warranty coverage. If any problem should arise while your
vehicle is under warranty, your Lexus de aler will promptly take care of it.

241
4-2. Maintenance
4
Maintenance and care
CAUTION
■If your vehicle is not properly maintained
Improper maintenance could result in serious damage to the vehicle and possible
serious injury or death.
■Handling of the battery
●Engine exhaust, some of its constituents, and a wide variety of automobile com-
ponents contain or emit chemicals known to the State of California to cause can-
cer and birth defects and other reproductive harm. Work in a well ventilated area.
●Oils, fuels and fluids contained in vehicles as well as waste produced by compo-
nent wear contain or emit chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm. Avoid exposure and wash
any affected area immediately.
●Battery posts, terminals and related accessories contain lead and lead com-
pounds which are known to cause brai n damage. Wash your hands after han-
dling. ( P. 2 6 5 )

242
4-2. Maintenance
General maintenance
Listed below are the general maintenance items that should be performed at
the intervals specified in the “Warranty and Services Guide” or “Owners
Manual Supplement”. It is recommended that any problem you notice should
be brought to the attention of your Lexu s dealer or qualified service shop for
advice.
Engine compartment
Luggage compartment
ItemsCheck points
Brake fluid Is the brake fluid at the correct level?
(P. 2 6 2 )
Engine coolant Is the engine coolant at the correct
level? (
P. 2 6 0 )
Engine oil Is the engine oil at the correct level?
(P. 1 3 2 )
Exhaust system There should not be any fumes or
strange sounds.
Condenser The condenser should be free from
foreign objects. (
P. 2 6 1 )
ItemsCheck points
Battery Check the connections. ( P. 2 6 5 )

243
4-2. Maintenance
4
Maintenance and care
Vehicle interior
ItemsCheck points
Accelerator pedal • The accelerator pedal should move
smoothly (without uneven pedal
effort or catching).
Brake pedal • Does the brake pedal move
smoothly?
• Does the brake pedal have appro- priate clearance from the floor?
( P. 3 6 4 )
• Does the brake pedal have the cor- rect amount of free play?
( P. 3 6 4 )
Brakes • The vehicle should not pull to one
side when the brakes are applied.
• The brakes should work effectively.
• The brake pedal should not feel
spongy.
• The brake pedal should not get too close to the floor when the brakes
are applied.
Indicators/buzzers • Do the indicators and buzzers
function properly?
Lights • Do all the lights come on?
Pa r k i n g b r a ke • When parked on a slope and the
parking brake is on, is the vehicle
securely stopped?
Seat belts • Do the seat belts operate
smoothly?
• The seat belts should not be dam- aged.

244
4-2. Maintenance
Vehicle exterior
Seats• Do the seat controls operate prop-
erly?
Steering wheel • Does the steering wheel rotate
smoothly?
• Does the steering wheel have the
correct amount of free play?
• There should not be any strange sounds coming from the steering
wheel.
ItemsCheck points
Doors • Do the doors operate smoothly?
Engine hood • Does the engine hood lock system
work properly?
Fluid leaks • There should not be any signs of
fluid leakage after the vehicle has
been parked.
Ti r e s • Is the tire inflation pressure cor-
rect?
• The tires should not be damaged or excessively worn.
• The wheel bolts should not be loose.
Wa s h e r f l u i d • Is there sufficient washer fluid?
( P. 2 6 4 )
ItemsCheck points

245
4-2. Maintenance
4
Maintenance and care
CAUTION
■If the engine is running
Turn the engine off and ensure that there is adequate ventilation before performing
maintenance checks.

246
4-2. Maintenance
Emission inspection and maintenance (I/M) programs
Some states have vehicle emission in spection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
■ If the malfunction indicator lamp comes on
The OBD system determines that a problem exists somewhere in the
emission control system. Your vehicle may not pass the I/M test and
may need to be repaired. Contact your Lexus dealer to service the
vehicle.
■ Your vehicle may not pass the I/M test:
●When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may not
be completely set.
● When the fuel tank cap is loose
The malfunction indicator lamp comes on as a temporary malfunc-
tion and your vehicle may not pass the I/M test.
■ When the malfunction indicator lamp goes off after several driving
trips
The error code in the OBD system will not be cleared unless the vehi-
cle is driven 40 or more times.
■ If your vehicle does not pass the I/M test
Contact your Lexus dealer to prepare the vehicle for re-testing.

247
4
Maintenance and care
4-3.Do-it-yourself maintenance
Do-it-yourself service precautions
If you perform maintenance yourself, be sure to follow the correct proce-
dures as given in these sections.
ItemsParts and tools
Battery condition ( P. 2 6 5 ) •Warm water
•Baking soda
•Grease
• Conventional wrench
(for the positive terminal clamp
bolt)
Brake fluid level ( P. 2 6 2 ) • FMVSS No.116 DOT 3 or SAE
J1703 brake fluid
•Rag or paper towel
•Funnel (used only for adding brake fluid)
Condenser ( P. 2 6 1 )

Engine coolant level ( P. 2 6 0 ) • “Toyota Super Long Life Coolant”
or similar high-quality ethylene gly-
col-based non-silicate, non-amine,
non-nitrite and non-borate coolant
with long-life hybrid organic acid
technology. “Toyota Super Long
Life Coolant” is pre-mixed with
50% coolant and 50% deionized
water.
•Funnel (used only for adding engine cool-
ant)
Engine oil level ( P. 2 5 7 ) • “Mobil 1 5W-50”
•Funnel
(used only for adding engine oil)
Fuses ( P. 2 8 7 ) • Fuse with same amperage rating as
original

248
4-3. Do-it-yourself maintenance
Tire inflation pressure (P. 2 7 7 ) • Tire pressure gauge
• Compressed air source
Wa s h e r f l u i d ( P. 2 6 4 ) • Water or washer fluid containing
antifreeze (for winter use)
•Funnel
(used only for adding water or
washer fluid)
ItemsParts and tools
