5
When trouble arises
309
5-1. Essential information
Fuel pump shut off system
To minimize the risk of fuel leakage when the engine stalls or when an airbag
inflates upon collision, the fuel pump shut off system stops the supply of fuel to
the engine.
Follow the procedure below to restart the engine after the system is acti-
vated.
Turn the ignition switch to the “ACC” or “LOCK” position.
Restart the engine.
NOTICE
■Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the ground, the fuel system has been damaged
and is in need of repair. Do not restart the engine.
STEP1
STEP2

310
5-1. Essential information
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main purpose
of an EDR is to record, in certain crash or near crash-like situations, such as an
airbag deployment or hitting a road obstacle, data that will assist in under-
standing how a vehicle's systems perf ormed. The EDR is designed to record
data related to vehicle dynamics and safe ty systems for a short period of time,
typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
● How various systems in your vehicle were operating;
● Whether or not the driver and passenger safety belts (seat belts) were
buckled/fastened;
● How far (if at all) th e driver was depressing the accelerator and/or
brake pedal; and,
● How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances
in which crashes and injuries occur.
NOTE:
EDR data are recorded by your vehicl e only if a non-trivial crash situation
occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., na me, gender, age, and crash location)
are recorded. However, other parties, such as law enforcement, could
combine the EDR data with the type of personally identifying data rou-
tinely acquired during a crash investigation.

5
When trouble arises
311
5-1. Essential information
To read data recorded by an EDR, special equipment is required, and
access to the vehicle or the EDR is needed. In addition to the vehicle
manufacturer, other parties, such as law enforcement, that have the spe-
cial equipment, can read the information if they have access to the vehicle
or the EDR.

312
5-2.Steps to take in an emergency
If a warning light turns on or a warning buzzer sounds...
Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by your Lexus dealer.
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
The following warning indicates a possible problem in the brake system.
Immediately stop the vehi cle in a safe place and contact your Lexus
dealer.
Warning lightWarning light/Details
(U.S.A.)
(Canada)
Brake system warning light (warning buzzer) •Low brake fluid
• Malfunction in the brake system

5
When trouble arises
313
5-2. Steps to take in an emergency
Stop the vehicle immediately.The following warnings indicate the possibility of damage to the vehicle
that may lead to an ac cident. Immediately stop the vehicle in a safe place
and contact your Lexus dealer.
Warning lightWarning light/Details
Charging system warning light Indicates a malfunction in the vehicle’s charging system.
(Flashes) Engine oil temperature warning light (warning buzzer)
Indicates that the engine oil temperature is too high.
(Flashes) Engine coolant temperature warning light (warning
buzzer)
Indicates that the engine coolant temperature is too high.
( P. 3 5 1 )
(Flashes)

314
5-2. Steps to take in an emergency
Have the vehicle inspected by your Lexus dealer immediately.
Failing to investigate the cause of the following warnings may lead to the
system operating abnormally and possibly cause an accident. Have the
vehicle inspected by your Lexus dealer immediately.
Warning lightWarning light/Details
(U.S.A.)
(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic transmission control system.
SRS warning light Indicates a malfunction in:
• The SRS airbag system; or
• The seat belt pretensioner system.
(U.S.A.)
(Canada)
ABS warning light Indicates a malfunction in:
•The ABS; or
• The brake assist system.
Brake system warning light Indicates a malfunction in:
• The electronically controlled brake system; or
• The electric parking brake.
Electric power steering system warning light (warning
buzzer) Indicates a malfunction in the EPS system.
(Comes on) Slip indicator
Indicates a malfunction in:
• The VSC system;
•The TRAC system; or
• The hill-start assist control system.

5
When trouble arises
315
5-2. Steps to take in an emergency
Follow the correction procedures.After taking the specified steps to co rrect the suspected problem, check
that the warning light goes off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
Indicates that a door is not
fully closed. Check that both side doors
are closed.
Low fuel level warning light Indicates remaining fuel is
approximately 2.9 gal. (11 L,
2.4 Imp. gal.) or less Refuel the vehicle.
(On the instru- ment cluster) Driver’s seat belt reminder
light (warning buzzer)
*2
Warns the driver to fasten
their seat belt.
Fasten the seat belt.
(On the center panel) Passenger’s seat belt
reminder light
(warning buzzer)
*2
Warns the passenger to fas-
ten their seat belt.
Fasten the seat belt.

316
5-2. Steps to take in an emergency
*1: Open door warning buzzer
P. 3 2 7
*2: Driver’s and passenger’s seat belt reminders buzzer
The driver’s and passenger’s seat belt reminders sound to alert the driver and
passenger that their seat belt is not fa stened. The buzzer sounds intermittently
for 10 seconds after the vehicle has reached a speed of 12 mph (20 km/h).
Then, if the seat belt is still unfastened , the buzzer will sound in a different tone
for 20 more seconds. Tire pressure warning light
When the light comes on:
Low tire inflation pressure
Adjust the tire inflation pres-
sure to the specified level. The
light will turn off after a few
minutes. In case the light does
not turn off even if the tire infla-
tion pressure is adjusted, have
the vehicle checked by your
Lexus dealer.
When the light comes on after
blinking for 1 minute:
Malfunction in the tire pres-
sure warning system Have the system checked by
your Lexus dealer.
Master warning light A buzzer sounds and the
warning light comes on and
flashes to indicate that the
master warning system has
detected a malfunction. 
P. 3 2 2
Warning lightWarning light/DetailsCorrection procedure

5
When trouble arises
317
5-2. Steps to take in an emergency
■If the malfunction indicator lamp comes on while driving
First check the following:
●Is the fuel tank empty?
If it is, fill the fuel tank immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Lexus dealer as soon
as possible.
■Electric power steering system warning light
When the battery is low or when the voltage drops temporarily, the electric power
steering system warnin g light may come on.
■Passenger detection sensor and passenger seat belt reminder
●If luggage is placed on the passenger seat, the passenger detection sensor may
cause the warning light to flash even if a passenger is not sitting in the seat.
●If a cushion is placed on the seat, the sensor may not detect a passenger, and the
warning light may not operate properly.
■When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level. Pushing the tire
pressure warning reset switch will not turn off the tire pressure warning light. After
the tire inflation pressure is adjusted, it may take a few minutes for the tire pressure
warning light to go off.
■The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such as natural
air leaks or tire inflation pressure changes caused by temperature. In this case,
adjusting the tire inflation pressure will turn off the warning light (after a few min-
utes).

318
5-2. Steps to take in an emergency
■If the tire pressure warning system is not functioning
The tire pressure warning system will be disabled in the following conditions:
(When the condition becomes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmitters are used
●If the ID code on the tire pressure warning valves and transmitters is not regis-
tered in the tire pressure warning computer
●If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm2 or bar) or higher
The tire pressure warning system may be disabled in the following conditions:
(When the condition becomes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies are nearby
●If a radio set at similar frequencies is in use in the vehicle
●If there is a lot of snow or ice on the vehicle, particularly around the wheels or
wheel housings
●If non-genuine Lexus wheels are used (Even if you use Lexus wheels, the tire
pressure warning system may not work properly with some types of tires.)
●If a tire is repaired with the emergency tire puncture repair kit
■If the tire pressure warning light comes on after flashing frequently for 1 minute
If the tire pressure warning light comes on after flashing frequently for 1 minute
when the ignition switch is turned to th e “ON” position, have it checked by your
Lexus dealer.
■Customization that can be configured at Lexus dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features P. 383)
