lexus LFA 2012 Owner's Manual / LEXUS 2012 LFA OWNERS MANUAL (OM77006U)

5
When trouble arises
329
5-2. Steps to take in an emergency
Indicates that the washer
fluid level is low.Add washer fluid.
(
 P. 2 6 4 )
Indicates that engine oil
level is low. Check the level of engine
oil (
P. 132), and add if
necessary ( P. 2 5 7 ) .
Indicates that the engine
oil needs to be changed. Have the engine oil
changed at your Lexus
dealer. (Also have the oil
maintenance function
reset.)
Indicates that the engine
coolant temperature or
engine oil temperature is
below -13 F (-25 C). Start the engine when the
engine coolant or engine
oil temperature reaches
-1 1
F (-24 C) or higher.
Indicates that the battery
voltage is low. Start the engine.
Indicates that the spark
plugs are dirty or carbon
fouled. Drive the vehicle at 2400
rpm or higher for a total
duration of several min-
utes.
MessageDetailsCorrection procedure

330
5-2. Steps to take in an emergency
Indicates that gear shift-
ing is restrained tempo-
rarily (due to overheating
of the transmission
pump).Gear shifting is not pos-
sible while this message
is displayed. Refrain from operating the
paddle shift switches for 5
or more seconds.
Indicates that gear shift-
ing is restrained (due to
low transmission fluid
temperature). Gear shifting is not pos-
sible while this message
is displayed. Warm up the vehicle by
driving it.
Indicates that the clutch
has temporarily over-
heated. Stop the vehicle in a safe
place and select Neutral.
Allow the clutch to cool
down by allowing the
vehicle to idle for
approximately 15 min-
utes.
MessageDetailsCorrection procedure

5
When trouble arises
331
5-2. Steps to take in an emergency
■To prevent the clutch from overheating
●Do not use the accelerator pedal to hold the vehicle on uphill inclines in an
attempt to prevent the vehicle from moving backward.
●On uphill inclines, observe the following whenever possible:
• Maintain a safe distance from the vehicle ahead and avoid frequent starts.
• Avoid using AUTO driving mode on uphill inclines. This will help to avoidunnecessary gear changes.
■If “Battery low Electric al equipment operation is limited” is displayed
The battery voltage is low. The operation of the air conditioning system, transmis-
sion pump and other power-consuming components may be temporarily limited
until the battery is recharged.

332
5-2. Steps to take in an emergency
If you have a flat tire
The LFA is equipped with an emergency tire puncture repair kit, not a spare
tire.
A puncture caused by a nail or screw passing through the tire tread can be
repaired temporarily with the emerge ncy tire puncture repair kit. When
replacing the repaired tire, consult your Lexus dealer or tire dealer.
■Before repairing the tire
●Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Select 1st gear or Reverse.
● Stop the engine.
● Turn on the emergency flashers.
■ Contents
Compressor
Sealant
Injection hose
Extension hose (for extracting
the sealant) Valve core tool
Valve core (spare)
Stickers

5
When trouble arises
333
5-2. Steps to take in an emergency
Taking out the emergency tire puncture repair kitOpen the rear hatch and remove
the cover.
Release the belt and take out the
tool bag.
Take the emergency tire puncture
repair kit out of the tool bag.
STEP1
STEP2

334
5-2. Steps to take in an emergency
Before putting the sealant into useCheck the degree of tire damage befo re making use of the sealant in the
emergency tire puncture repair kit.
A tire should only be repaired if the
damage is caused by a nail or
screw passing through the tire
tread.
Do not remove the nail or screw
from the tire.
Move the vehicle until the area of
the puncture, if known, is posi-
tioned at the bottom, in contact
with the ground. This allows the
sealant to plug the damaged area
more effectively.
Emergency repair with the sealant in the kit is not possible in the following
cases. Contact your Lexus dealer.
● When the wheel is damaged
● When two or more tires have been punctured
● When the tire is damage d due to driving without sufficient tire inflation
pressure
● When the tire is visibly disengaged from the wheel
● When the tire lost air pressure due to a crack or damage in the tire
sidewall
● When the cut or piercing to the tread is 0.16 in. (4 mm) or more

5
When trouble arises
335
5-2. Steps to take in an emergency
Emergency repair methodRemove the cap from the valve.
Bring the protruding part of the
valve core tool into contact with
the valve and fully discharge the
air.
Pull out the valve core by turning it
counterclockwise using the valve
core tool.
Shake the sealant bottle several
times and remove the cap of the
sealant bottle.
STEP1
STEP2
STEP3
STEP4

336
5-2. Steps to take in an emergency
Connect the injection hose by
screwing it onto the bottle. As it is
screwed in, the aluminum seal on
the bottle will be torn.
Remove the plug from the injection
hose.
Connect the injection hose to the
valve.
Inject the sealant that is in the bot-
tle. Hold and tilt the bottle, then
squeeze sealant out of the bottle
as shown.STEP5
STEP6
STEP7
STEP8

5
When trouble arises
337
5-2. Steps to take in an emergency
Attach the sticker as shown.
Remove the injection hose from
the valve and screw the valve core
into the valve securely by turning it
clockwise with the valve core tool.
Connect the air compressor hose
by threading it onto the valve.
Connect the compressor power
plug to the power outlet in the
glove box.
Turn the ignition switch to the “ACC” position.STEP9
STEP10
STEP 11
STEP 12
STEP 13

338
5-2. Steps to take in an emergency
Check the specified inflation pressure. (P. 366)
Turn the compressor switch “ON”
and fill the tire with air until the
specified inflation pressure is
reached.
Turn the switch “OFF” when the
pressure gauge connected to the
hose reads the specified pressure.
If the inflation pressure is not
attained within 8 minutes, emer-
gency repair is not possible due to
severe damage. Contact your
Lexus dealer.
After completely filling the tire with air, disconnect the hose from
the tire valve and the compress or power plug from the power
outlet.
To spread the liquid sealant ev enly in the tire, immediately drive
for about 3 miles (5 km) or 10 minutes.
Drive cautiously at a moderate speed, avoiding sudden starts, sudden
braking, and abrupt steering maneuvers.
After driving about 3 miles (5 km)
or 10 minutes, stop your vehicle in
a safe place and reconnect the
compressor.
STEP 14
STEP 15
STEP 16
STEP 17
STEP 18
STEP 19
