359
6-1. Specifications
6
Vehicle specifications
■Engine number
The engine number is stamped on
the bottom of the engine block as
shown.

360
6-1. Specifications
Engine
Fuel
Model1LR-GUE
Ty p e10-cylinder V type, 4-cycle, gasoline
Bore and stroke3.50 3.10 in. (88.0  79.0 mm)
Displacement 293.2 cu.in. (4805 cm3)
Drive belt tensionAutomatic adjustment
Fuel typeUnleaded gasoline only
Octane rating91 (Research octane number 96) or higher
Fuel tank capacity
(Reference)19.3 gal. (73 L, 16.1 Imp. gal.)
NOTICE
■Fuel precaution
Do not use any fuel other than that specified above. Doing so may cause engine
damage.

361
6-1. Specifications
6
Vehicle specifications
Lubrication system■ Specified engine oil for the LFA
*1: The oil filters used are exclusive to the LFA. When the oil is changed, the oil fil-
ters should also be replaced.
*
2: The lifetime of the vehicle depends greatly on the quality of oil used. The use of “Mobil 1 5W-50” is most suitable for your vehicle and is recommended.
Oil capacity*1
(Amount of oil required
for an oil change 
reference) With twin air-cooled oil cooler
18.0 qt. (17.0 L, 15.0 Imp. qt.)
With single air-cooled oil cooler
16.9 qt. (16.0 L, 14.1 Imp. qt.)
Oil brand*2“Mobil 1 5W-50”
Recommended API
grade
SM or SN
■Engine oil viscosity
●The 5W portion of the oil viscosity rating
indicates the characteristic of the oil
which allows cold startability. Oils with a lower value before the W allow for eas-
ier starting of the engine in cold weather.
●The 50 in 5W-50 indicates the oil viscosit y when the oil is at its operating tem-
perature. An oil with a higher viscosity may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.
NOTICE
■To prevent engine damage
If “Mobil 1 5W-50” is not available, another oil of equivalent quality to “Mobil 1
5W-50” may be used. In this case, do not start the engine if the engine coolant or
oil temperature is below 5 F (-15C), and do not drive the vehicle under extreme
load conditions.

362
6-1. Specifications
Cooling system
Ignition system
Capacity26.9 qt. (25.5 L, 22.4 Imp. qt.)
Coolant typeUse either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili- cate, non-amine, non-nitrite, and non-borate cool-
ant with long-life hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
Gap DENSO PK22HTBR-L8
0.032 in. (0.8 mm)
NOTICE
■Platinum-tipped spark plugs
Use specified spark pl
ugs mentioned above. Do not adjust gap when tuning engine.

363
6-1. Specifications
6
Vehicle specifications
Electrical system
Front counter gear
Rear transaxle
Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the fac-
tory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent
of matching quality that satisfies the above specifications. Please contact your
Lexus dealer for further details.
Clutch & Shift Hydraulic System Fluid
Battery
Open voltage* at
68 F (20 C): 12.6
12.8 V Fully charged
12.2 
12.4 V Half charged
11.8 
12.0 V Discharged
(*: Voltage checked 20 minutes after the
engine and all the lights are turned off)
Charging rates 5 A max.
Engine oil
Oil brand“Mobil 1 5W-50” (also used for the engine)
Oil capacity5.6 qt. (5.3 L, 4.7 Imp. qt.)
Oil type and viscosity“Toyota Genuine Differential Gear Oil LT
75W-85 GL-5” or equivalent
Fluid type“Toyota Genuine Brake Fluid 2500H”
(change not needed)

364
6-1. Specifications
Brakes
*1: Minimum horizontal distance between and when the pedal is depressedwith a force of 45 lbf (200 N, 20 kgf) while the engine is idling.
*2: Upper side of pedal cover
Pedal clearance*14.0 in. (102 mm) Min.
Floor (firewall)
Brake pedal
Pe d a l c o ve r
Pedal free play 0.04  0.08 in. (1.0  2.0 mm)
Brake pad wear limit0.08 in. (2.0 mm)
Parking brake pad wear limit0.06 in. (1.5 mm)
Fluid typeFMVSS No.116 DOT 3 or SAE J1703
4.0 in. (102 mm) Min. 0.20 in. (5 mm) or less*2

365
6-1. Specifications
6
Vehicle specifications
Steering
NOTICE
■Precaution for CCM (Carbon Ceramic Material) brake discs
Be careful not to subject the CCM brake discs to any kind of strong impact.
Even if there is no obvious damage, in the following situations, have the vehicle
inspected by your Lexus dealer:
●If the vehicle is involved in an accident that may affect the suspension and wheels
●If a CCM brake disc sustains an impact during the removal or installation of the
wheels
●If the brake pads have worn out and the metal part of the pad is in contact with the
CCM brake disc surface
Free playLess than 0.6 in. (15 mm)

366
6-1. Specifications
Tires and wheels
Ti r e s i z e265/35ZR20 (95Y), 305/30ZR20 (99Y)
Front and rear tire inflation pres-
sure
(Recommended cold tire inflation
pressure) Front:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear: 33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Driving at high speeds (above 155 mph [250
km/h]) (in countries where such speeds are
permitted by law) Add 8 psi (50 kPa, 0.5 kgf/cm
2 or bar) to the
front tires and rear tires. Never exceed the
maximum cold tire inflation pressure indicated
on the tire sidewall.
Wheel size Front: 20 
9 1 /2J
Rear: 20  11 1 /2J
Wheel bolt torque 81 ft•lbf (110 N•m, 11.2 kgf•m)

367
6-1. Specifications
6
Vehicle specifications
Light bulbs
A: D4S discharge bulbs
B: Wedge base bulbs (amber)
C: Wedge base bulbs (clear)
D: Single end bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlight low/high beams
35 A
Front turn signal lights 21 B
Front side marker lights 194 3.8 C
Rear turn signal lights 7440 21 C
Rear side marker lights 5C
Back-up lights 21 D
License plate lights 5C
InteriorLuggage compartment light
3.8 C
Door courtesy lights 3.8 C

368
6-1. Specifications
Fuel information
Your vehicle must use only unleaded gasoline.
Premium unleaded gasoline with an octane rating of 91 (Research Octane
Number 96) or higher is required for optimum engine performance.
At minimum, the gasoline you use should meet the specifications of
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada.
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehicle has a fuel tank opening that only
accommodates the special nozzle on unleaded fuel pumps.
■Gasoline quality
In very few cases, driveability problems may be caused by the brand of gasoline you
are using. If driveability problems persist, try changing the brand of gasoline. If this
does not correct the problem, consult your Lexus dealer.
■Gasoline quality standards
●Automotive manufacturers in the U.S.A., Europe and Japan have developed a
specification for fuel quality called the World-Wide Fuel Charter (WWFC),
which is expected to be applied worldwide.
●The WWFC consists of four categories that are based on required emission
levels. In the U.S., category 4 has been adopted.
●The WWFC improves air quality by lowering emissions in vehicle fleets, and
improves customer satisfaction through better performance.
■Recommendation of the use of gasoline containing detergent additives
●Lexus recommends the use of gasoline that contains detergent additives to
avoid the build-up of engine deposits.
●All gasoline sold in the U.S.A. contains detergent additives to clean and/or keep
clean intake systems.
