lexus LS400 2000 Engine / LEXUS 2000 LS400 OWNER'S MANUAL (OM50533U)

AUDIO
244program
(See page 261 for details.)
CD mode: Direct access to a desired
program (See page 270 for details.)
Using your audio system: some basics
This section describes some of the basic features of the
Lexus audio system. Some information may not pertain
to your system.
Your audio system works when the ignition key is in the
ºACCº or ºONº position.
NOTICE
To prevent the battery from being discharged, do not leave the car audio on longer than necessarywhen the engine is not running.
(a) Turning the system on and off

AUDIO
245
20L002a
Push this knob to turn the audio system on and off.
Turn this knob to adjust the volume.
The system turns on in the last mode used.
20L042a

AUDIO
246Push
ºAMº, ºFM1/2º, ºTAPEº or ºCDº to turn on that
mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode
to another.
If the tape or disc is not set, the cassette player or
compact disc player does not turn on.
You can turn off the cassette player by ejecting the
cassette tape. If the audio system was previously off,
then the entire audio system will be turned off when you
eject the cassette tape. If another function was
previously playing, it will come on again.
20L043

AUDIO
247
In the ºTAPEº or ºCDº mode, the applicable
functions
are shown in the lowest part of the display.
Push the switch just below to turn on each function.
(b) Tone and balance
How good an audio program sounds to you is largely
determined by the mix of the treble, mid±range, and
bass levels. In fact, different kinds of music and vocal
programs usually sound better with different mixes of
treble, mid±range, and bass.
A good balance of the left and right stereo channels and
of the front and rear sound levels is also important.
Keep in mind that if you are listening to a stereo
recording or broadcast, changing the right/left balance
will increase the volume of one group of sounds while
decreasing the volume of another.
20L044-2

AUDIO
248ºBASSº knob: Use this knob to adjust low±pitched
tones.
ºMIDº
knob: Use this knob to adjust mid±pitched tones.
ºTREBLEº knob: Use this knob to adjust high±pitched
tones.
ºBALANCEº knob: Use this knob to adjust the sound
balance between the right and left speakers.
ºFADERº knob: Use this knob to adjust the sound
balance between the front and rear speakers. (c) Automatic sound levelizer (Except Nakamichi
model)
20L111
When
the audio sound becomes difficult to be heard due
to road noise, wind noise, etc. during driving, the system
adjusts to the optimum volume and tone quality
according to the noise level.

AUDIO
249
(d) Your radio antenna
The wire antenna is mounted inside the rear window.
NOTICE
When
cleaning the inside of the rear window, be
careful not to scratch or damage the wire antenna.
Putting a window tint (especially, conductive ormetallic type) on the rear window may affect thereception of radio or m obile telephone. For the
installation of the window tint, consult with your Lexus dealer.
(e) Your cassette player
When you insert a cassette, the exposed tape should be
to the right.
NOTICE
Do not oil any part of the cassette player, and do not insert anything except a cassette tape into theslot.
(f) Your automatic changer

AUDIO
250
20L006-2
If your Lexus is equipped with an automatic changer, it
can play selected discs or continuously play all the discs
set in the magazine.
When you set discs into the magazine, make sure they
face the correct way. If not, the player will display ºERRº
and the disc number.
NOTICE
Never try to disassemble or oil any part of the compact disc player. Do not insert anythingexcept a compact disc into the magazine.
The player is intended for use with 12 cm (4.7 in.) discs
only.

AUDIO
251
Radio operation
(a) Listening to the radio
20L045a
Push these buttons to choose either an AM or FM
station.
ºAMº, ºFM1º or ºFM2º appears on the display.

AUDIO
252
20L046±1
Push this button on the upper side to step up the
station band or on the lower side to step down.
Your radio automatically changes to stereo reception
when a stereo broadcast is received. ºSTº appears on
the display. If the signal becomes weak, the radio
reduces the amount of channel separation to prevent the
weak signal from creating noise. If the signal becomes
extremely weak, the radio switches from stereo to mono
reception. In this case, ºSTº disappears from the
display. (b) Presetting a station

AUDIO
253
20L047a
1. Tune in the desired station.
2. Push one of the station selector buttons ( 1±6 )
and hold it until a beep is heard. This sets the station
to the button and the button number ( 1±6 ) appears
on the display.
Each button can store one AM station and two FM
stations. To change the preset station to a different one,
follow the same procedure.
The preset station memory is cancelled when the power
source is interrupted by battery disconnection or a blown
fuse. (c) Selecting a station
Your Lexus has an electronic tuning radio ( ETR ). Tune
in the desired station using one of the following methods.
