IN CASE OF AN EMERGENCY
351
IF YOUR VEHICLE WILL NOTSTART
(a) Simple checks
Before making these checks, make sure you have
followed the correct starting procedure instructions in
ºHow to start the engineº on page 288 and that you have
sufficient fuel. Since your vehicle is equipped with the
engine immobiliser system, also check whether the
other keys will start the engine. If they work, your key
may be broken. Have the key checked at your Lexus
dealer. If none of your keys work, the system is possibly
broken. Call your Lexus dealer. See ºKeysº on page 9.
If the engine is not turning over or is turning over too
slowly ±
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior
light.
3. If the light is out, dim or goes out when the starter is
cranked, the battery is discharged. You may try jump
starting. See º(c) Jump startingº for further instruction.
If the light is O.K., but the engine still will not start, it
needs adjustment or repair. Call a Lexus dealer,
Roadside Assistance or Customer Service Assistance.
(See ºForewordº.)
NOTICE
Do not pull± or push±start the vehicle. It may damage the vehicle or cause a collision when theengine starts. Also the three±way catalyticconverter may overheat and become a fire hazard.
If the engine turns over at its normal speed but will
not start ±
1. The engine may be flooded because of repeated
cranking. See º(b) Starting a flooded engineº for further
instructions.
2. If the engine still will not start, it needs adjustment or
repair. Call a Lexus dealer, Roadside Assistance or
Customer Service Assistance. (See ºForewordº.)

IN CASE OF AN EMERGENCY
352
(b) Starting a flooded engine
If the engine will not start, your engine may be
flooded because of repeated cranking.
If this happens, turn the key to ºSTARTº with the
accelerator pedal held down. Continue this operation for
30 seconds and then stop cranking. Then try starting the
engine with your foot off the accelerator pedal.
If the engine does not start after 30 seconds of cranking,
release the key, wait a few minutes and try again.
If the engine still will not start, it needs adjustment or
repair. Call a Lexus dealer, Roadside Assistance or
Customer Service Assistance. (See ºForewordº.)
NOTICE
Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.

IN CASE OF AN EMERGENCY
355


5Discharged battery 6Booster battery
JUMP STARTING PROCEDURE
1. If the booster battery is installed in another vehicle,
make sure the vehicles are not touching. Turn off all
unnecessary lights and accessories.
2. If required, remove all the vent plugs from the booster
battery. Lay a cloth over the open vents on the booster
battery. (This helps reduce the explosion hazard,
personal injuries and burns.)
If the booster battery is an extended maintenance
interval battery, it is not necessary to remove the vent
plugs.
3. If the engine in the vehicle with the booster battery is
not running, start it and let it run for about 5 minutes.
During jump starting, run the engine at about 2000 rpm
with the accelerator pedal lightly depressed.
4. Locate po
sitive (+) and negative (±) terminals of each
battery. Connect the jumper cables in the exact order
(
1 2 3 4) shown in the illustration.
1 Connect a positive (red) jumper cable clamp to the
positive (+) terminal of the discharged battery.
2 Connect the clamp at the other end of the positive
(red) cable to the positive (+) terminal of the booster
battery.
3 Connect a negative (black) cable clamp to the
negative (±) terminal of the booster battery.
4Connect the clamp at the other end of the negative
(black) cable to a solid, stationary, unpainted
metallic point (such as shown in the illustration)
away from the battery. Do not connect it to or near
any part that moves when the engine is cranked.

IN CASE OF AN EMERGENCY
356
CAUTION
When making the connections, to avoid serious injury,
do not lean over the battery or accidentally let the
jumper cables or clamps touch anything except the
correct battery terminals or the ground.
5. Start your engine in the normal way. After starting,
run it at about 2000 rpm for several minutes with the
accelerator pedal lightly depressed.
6. Carefully disconnect the cables in the exact reverse
order: the negative cable and then the positive cable.
7. Carefully dispose of the battery cover cloths which
may now contain sulfuric acid.
8. If removed, replace all the battery vent plugs.
If the cause of your battery discharging is not apparent
(for example, lights left on), you should have it checked.IF YOUR VEHICLE OVERHEATS
If your engine coolant temperature gauge indicates
overheating, if you experience a loss of power, or if
you hear a loud knocking or pinging noise, the
engine has probably overheated.

IN CASE OF AN EMERGENCY
357
When the engine overheats
Pull safely off the road, stop the vehicle and turn on your
emergency flashers. Put the transmission in ºPº and
apply the parking brake.
A: If steam is coming from your engine:
Turn off the engine. Leave the hood closed until there
is no sign of steam or coolant. Your engine could have
been seriously damaged already. Call your Lexus
dealer for assistance.
CAUTION
To help avoid personal injury, keep the hood closed until
there is no steam. Escaping steam or coolant is sign of
very high pressure.

IN CASE OF AN EMERGENCY
358B: If no steam is coming from your engine:
Leave the engine running and turn off the air
conditioning. Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in
the acceptable range, turn off the engine and call your
Lexus dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or
your vehicle overheats again, have it checked as soon
as possible by your Lexus dealer.IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place ± well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the pa rking brake and put the transmission
in ºPº.
4. Have everyone get out of the vehicle on the side away

IN CASE OF AN EMERGENCY
359
from traffic.
5. Read the following instructions thoroughly.
NOTICE
For vehicles equipped with the height control
switch, be sure to turn the ignition switch offbefore jacking. If this is not done, the vehicleheight adjustment function will operate, whichmay cause body damage.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Follow jacking instructions.
 Do not put any part of your body under a
vehicle supported by a jack. Personal injury
may occur.
Do not start or run the engine while your
vehicle is supported by the jack.
 Stop the vehicle on a level firm ground, firmly
set the parking brake and put the transmission
in ºPº. Block the wheel diagonally opposite to
the one being changed if necessary.
 Make sure to set the jack properly in the jack
point. Raising the vehicle with jack improperly
positioned will damage the vehicle or may
allow the vehicle to fall off the jack and cause
personal injury.
 Never get under the vehicle when the vehicle is
supported by the jack alone.
 Use the jack only for lifting your vehicle during
wheel changing.
 Do not raise the vehicle with someone in the
vehicle.
 When raising the vehicle, do not put an object
on or under the jack.
 Raise the vehicle only high enough to remove
and change the tire.
NOTICE

IN CASE OF AN EMERGENCY
383
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing eyelet
and towing cable or chain. The eyelet and towing cable
or chain may break and cause serious injury or damage.
NOTICE
Use only a cable or chain specifically intended for use in towing vehicles. Securely fasten the cableor chain to the towing eyelet provided.
Before towing, release the parking brake and put the
transmission in ºNº. The ignition key must be in ºACCº
(engine off) or ºONº (engine running).
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.

IN CASE OF AN EMERGENCY
386
IF YOU LOSE YOUR KEYS ORLOCK YOURSELF OUT
You can purchase a new key at your Lexus dealer if
you can give them the key number and master key.
Even if you lose only one key, contact your Lexus dealer
to make a new key. If you lose all your master keys, you
cannot make new keys; the whole engine immobiliser
system must be replaced.
See the suggestion given in ªKeysº on page 9.
You can use the wireless remote control system with the
new key. Contact your Lexus dealer for detailed
information.
If your keys are locked in the vehicle and you cannot get
a duplicate, many Lexus dealers can still open the door
for you, using their special tools. If you must break a
window to get in, we suggest breaking the smallest side
window because it is the least expensive to replace. Be
extremely cautious to avoid cuts from the glass.

MAINTENANCE
390
GENERAL MAINTENANCE
Listed below are the general maintenance items that
should be performed at the intervals specified. It is
recommended that any problem you notice be brought
to the attention of your Lexus dealer or qualified service
shop for their advice.
CAUTION
Make these checks only where adequate ventilation can
be obtained if you run the engine.
Vehicle exterior
Items listed below should be performed from time to
time, unless otherwise specified.
Tire pressure
Check the pressure with a gauge every two weeks, or at
least once a month and adjust as shown on the tire
pressure label. See page 431 for a dditional information.
Tire surface
Check the tires carefully for cuts, damage or excessive
wear. See page 435 for additional information.
Wheel nuts
When checking the tires, make sure to check the nuts for
looseness. Tighten them if necessary. Tire rotation
Rotate
the tires every 12000 km (7500 miles). See page
433 for additional information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other
fluid after the vehicle has been parked for a while. If you
smell fuel fumes or notice any leak, have the cause
found and corrected immediately.
Doors and engine hood
Check that all doors, including trunk lid, operate
smoothly and all latches lock securely. Make sure the
engine hood secondary latch secures the hood when the
primary latch is released.
