LEXUS LS600H 2015 Owners Manual

891-3. Theft deterrent system
1
For safety and security
LS600hL_U(OM50E41U)
■Certifications for the immobilizer system
For vehicles sold in the U.S.A.
FCC ID: NI4TMIMB-1
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesire d operation.
FCC WARNING:
Changes or modifications not expressly ap proved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.
For vehicles sold in Canada
This device complies with Industry Cana da licence-exempt RSS standard(s). Oper-
ation is subject to the following two conditio ns: (1) this device may not cause interfer-
ence, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation
of the system cannot be guaranteed.

901-3. Theft deterrent system
LS600hL_U(OM50E41U)
The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the alarm is set:
●A locked door or trunk is unlocked or opened in any way other than
using the entry function, wireless remote control or mechanical key.
(The doors will lock again automatically.)
●The hood is opened.
Close the doors, trunk and hood,
and lock all the doors. The system
will be set automatically after 30
seconds.
The indicator light changes from
being on to flashing when the system
is set.
Do one of the following to deactivate or stop the alarms:
●Unlock the doors or open the trunk.
●Turn the power switch to ACCESS ORY or ON mode, or start the
hybrid system. (The alarm will be deactivated or stopped after a few
seconds.)
Alarm
The alarm
Setting the alarm system
Deactivating or stopping the alarm

911-3. Theft deterrent system
1
For safety and security
LS600hL_U(OM50E41U)
■System maintenance
The vehicle has a maintenance-free type alarm system.
■Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the fol-
lowing:
●Nobody is in the vehicle.
●The windows and moon roof are closed before the alarm is set.
●No valuables or other personal items are left in the vehicle.
■Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
■Alarm-operated door lock
●When the alarm is operating, the doors ar e locked automatically to prevent intrud-
ers.
●Do not leave the key inside the vehicle when the alarm is operating, and make sure
the key is not inside the vehicle when rech arging or replacing the 12-volt battery.
●A person inside the vehicle opens a door,
the trunk or hood.
●The 12-volt battery is recharged or replaced
when the vehicle is locked. (P. 5 2 8 )
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation
of the system cannot be guaranteed.

921-3. Theft deterrent system
LS600hL_U(OM50E41U)

93
Instrument cluster2
LS600hL_U(OM50E41U)2. Instrument cluster
Warning lights and indicators ....................................... 94
Gauges and meters ..................... 99
Multi-information display ........ 105
Energy monitor/ consumption screen ................. 112

94
LS600hL_U(OM50E41U)
2. Instrument cluster
◆Instrument cluster
The units used on the speedometer, the tachometer and some indicators may dif-
fer depending on the target region.
◆Center panel
Warning lights and indicators
The warning lights and indicators on the instrument cluster, center
panel and outside rear view mirrors inform the driver of the status of
the vehicle’s various systems.
For the purpose of explanation, the following illustration displays all
warning lights and indicators illuminated.

952. Instrument cluster
2
Instrument cluster
LS600hL_U(OM50E41U)
◆Outside rear view mirrors (vehicles with BSM)
Warning lights inform the driver of ma lfunctions in the indicated vehicle’s
systems.
Warning lights
*1
(U.S.A.)
Brake system warning light
(  P. 4 9 3 )*1
Slip indicator ( P. 4 9 5 )
*1
(Canada)
Brake system warning light
( P. 4 9 3 )*1, 2Brake hold operated
indicator ( P. 495)
*1Charging system warning
light ( P. 4 9 4 )*1, 2
(U.S.A.)
Parking brake indicator
( P. 495)
*1
(U.S.A.)
Malfunction indicator
lamp ( P. 4 9 4 )*1, 2
(Canada)
Parking brake indicator
( P. 495)
*1
(Canada)
Malfunction indicator
lamp ( P. 4 9 4 )*1Brake system warning light
( P. 495)
*1SRS warning light
( P. 4 9 4 )Open door warning light
( P. 4 9 6 )

962. Instrument cluster
LS600hL_U(OM50E41U)
*1: These lights come on when the power switch is turned to ON mode to indicatethat a system check is being performed. They will go off after the hybrid system is
on, or after a few seconds. There may be a malfunction in a system if the lights do
not come on, or go off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
*1
(U.S.A.)
ABS warning light
( P. 4 9 4 )Low fuel level warning light
( P. 4 9 6 )
*1
(Canada)
ABS warning light
( P. 4 9 4 )Seat belt reminder light
( P. 4 9 6 )
*1Electric power steering
system warning light
( P. 4 9 4 )*1Master warning light
( P. 4 9 6 )
*1, 2
(if equipped)
Pre-collision system warn-
ing light ( P. 495)*1
Tire pressure warning light
( P. 4 9 7 )

972. Instrument cluster
2
Instrument cluster
LS600hL_U(OM50E41U)
The indicators inform the driver of the operating state of the vehicle’s vari-
ous systems.
Indicators
Turn signal indicator
(  P. 2 2 7 )*1Brake hold standby indica-
tor ( P. 2 3 1 )
(U.S.A.)
Headlight indicator
( P. 2 3 4 )*1Brake hold operated indi-
cator ( P. 2 3 1 )
(Canada)
Tail light indicator
( P. 2 3 4 ) Cruise control “SET” indi-
cator (
P. 2 5 3 , 2 5 7 )
Headlight high beam indi-
cator ( P. 235) Cruise control indicator
(
 P. 2 5 3 , 2 5 7 )
Automatic High Beam
indicator ( P. 2 3 8 )
(if equipped)
Radar cruise control indi-
cator ( P. 2 5 7 )
Front fog light indicator
(  P. 2 4 3 )
(if equipped)
LKA (Lane-Keeping
Assist) indicator
( P. 2 7 3 )
“READY” indicator
(  P. 2 1 6 )
*1“HEIGHT HIGH” indica-
tor ( P. 2 8 7 )
EV indicator ( P. 7 8 )
*1, 2
Slip indicator ( P. 2 9 1 )
EV drive mode indicator
(  P. 2 2 1 )
*1VSC (Vehicle Stability
Control) OFF indicator
( P. 2 9 1 )
Snow mode indicator
(  225)
*1, 3
(if equipped)
Pre-collision system warn-
ing light ( P. 2 9 8 )

982. Instrument cluster
LS600hL_U(OM50E41U)
*1: These lights come on when the power switch is turned to ON mode to indicatethat a system check is being performed. They will go off after the hybrid system is
on, or after a few seconds. There may be a malfunction in a system if the lights do
not come on, or go off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster than
usual to indicate that the system is operating.
*4: In order to confirm operation, the BSM ou tside rear view mirror indicators illumi-
nate in the following situations:
• When the power switch is turned to ON mode while the BSM main switch is set to ON.
• When the BSM main switch is set to ON while the power switch is in ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators
will turn off after a few seconds.
If the BSM outside rear view mirror indicato rs do not illuminate or do not turn off,
there may be a malfunction with the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
*1
(U.S.A.)
Parking brake indicator
(  P. 2 2 8 )
*4
(if equipped)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators ( P. 3 0 8 )
*1
(Canada)
Parking brake indicator
( P. 2 2 8 )*1“A I R B A G O N /
OFF” indicator
( P. 5 5 )
CAUTION
■If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not come on
when you start the hybrid system, this co uld mean that these systems are not avail-
able to help protect you in an accident, wh ich could result in death or serious injury.
Have the vehicle inspected by your Lexus dealer immediately if this occurs.
