LEXUS LS600H 2015 Owners Manual

3795-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Open the ashtray lid.
To remove the ashtray, pull the ashtray
lid upwards.
Ashtrays
: If equipped
CAUTION
■When not in use
Keep the ashtray closed. In the event of sudden braking or sudden swerving, an
accident may occur due to an occupant being struck by the open ashtray or ash
flying out.
■To prevent fire
●Fully extinguish matches and cigarettes be fore putting them in the ashtray, then
make sure the ashtray is fully closed.
●Do not place paper or any other type of flammable object in the ashtray.

3805-6. Other interior features
LS600hL_U(OM50E41U)
Front
Push the back part of the lid to open,
and push the cigarette lighter down.
The cigarette lighter will pop up when
it is ready for use.
Rear (5-seat models)
Push the cigarette lighter.
The cigarette lighter will pop out when
it is ready for use.
Rear (4-seat models)
Open the auxiliary box and push the
cigarette lighter.
The cigarette lighter will pop out when
it is ready for use.
Cigarette lighters
: If equipped

3815-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■The cigarette lighter can be used when
The power switch is in ACCESSORY or ON mode.
CAUTION
■To avoid burns or fires
●Do not touch the metal parts of the cigarette lighter.
●Do not hold the cigarette lighter down. It could overheat and cause a fire.
●Do not insert anything other than the cigarette lighter into the outlet.
■When not in use
Keep the ashtray closed.
Injuries may result in the event of an accident or sudden braking.

3825-6. Other interior features
LS600hL_U(OM50E41U)
■12 V
Front*
Push the back part of the lid to
open, and open the lid.
Console box
Open the console box and open
the lid.
Power outlets
The power outlet can be used for the following components: 12 V: Accessories that run on less than 10 A.
120 VAC: Accessories that use less than 100 W.

3835-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Rear (5-seat models)*
Open the lid.
Rear (4-seat models)*
Open the auxiliary box and open
the lid.
*: If equipped
■120 VAC*
Open the lid.
*: If equipped

3845-6. Other interior features
LS600hL_U(OM50E41U)
■The power outlet can be used when
12 V
The power switch is in ACCESSORY or ON mode.
120 VAC
The power switch is in ON mode.
NOTICE
■To avoid damaging the power outlet
Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter th e power outlet may cause a short circuit.
■To prevent the fuse from being blown
12 V
Do not use an accessory that uses more than 12 V 10 A.
120 VAC
Do not use a 120 VAC appliance that requires more than 100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protection
circuit will cut the power supply.
■To prevent the 12-volt battery from being discharged
Do not use the power outlet longer than necessary when the hybrid system is off.
■Appliances that may not operate properly (120 VAC)
The following 120 VAC appliances may not operate properly even if their power
consumption is under 100 W.
●Appliances with high initial peak wattage
●Measuring devices that process precise data
●Other appliances that require an extremely stable power supply

3855-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Automatic operation
Operates automatically according
to the outside and cabin tempera-
ture when the power switch is
turned to ON mode. Automatic
operation can be turned off using
the switch.
The indicator light comes on when the
heater is operating.
Manual operation
Turns the heated steering wheel on/
off.
The indicator light comes on when the
heater is operating.
■Operating condition
The power switch is in ON mode.
■Timer function
Manual operation: Turns off after approximately 30 minutes.
Automatic operation: Operates for a maximum of 30 minutes. (Turns off according
to outside and cabin temperature.)
■If the indicator light does not come on
If the indicator light does not come on when the switch is pressed, a malfunction may
have occurred in the system. Have the vehicle inspected by your Lexus dealer.
■Customization
The automatic turning on/off of the heated steering wheel can be customized.
(Customizable features P. 5 6 4 )
Heated steering wheel
The left and right grip portions of the steering wheel can be heated.

3865-6. Other interior features
LS600hL_U(OM50E41U)
CAUTION
■Burns
Only appropriately qualified and capable non-impaired persons should operate
the vehicle. However, care should be taken to prevent injury if anyone in the follow-
ing categories comes into contact with the steering wheel when the heated steer-
ing wheel is on:
●Babies, small children, the elderly, the sick and the disabled
●Persons with sensitive skin
●Persons who are fatigued
●Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold
remedies, etc.)
NOTICE
■To prevent the 12-volt battery from being discharged
Turn the switch off when the hybrid system is off.

3875-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Press the knob to release the
lock.
Press the knob to lock it when not in
use.
AUTO setting
Turn the knob to the “AUTO”
position.
When set to “AUTO” mode, seat
heater, off, ventilation or seat cooler is
automatically selected according to
the set temperature of the air condi-
tioning system, outside temperature,
etc.
Climate control seats
The seats can be heated or cooled. When set to “AUTO” mode, the cli-
mate control seats/seat heaters are linked to the air conditioning set-
tings and automatically adjusted.
Front climate control seats
1
2

3885-6. Other interior features
LS600hL_U(OM50E41U)
Manual setting
Set the temperature by turning
the knob to the left or right.Off
Seat heater
Ventilation
Seat cooler
■AUTO setting
The switch turned on/off.
When set to “AUTO” mode, the
indicator illuminates.
When set to “AUTO” mode, seat
heater, off, ventilation or seat
cooler is automatically selected
according to the set temperature of
the air conditioning system, outside
temperature, etc.
2
1
2
3
4
Rear climate control seats
5-seat models4-seat models
