LEXUS LS600H 2015 Owners Manual

3895-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■Manual setting
The strength of the seat heater and seat cooler can be adjusted to 3
levels each.
Seat heater
*1: When the system is off, pressing “ ” turns the seat
heater on.
Pressing “ ” increases the level and pressing “ ” lowers the level.
Seat cooler*2: When the system is off, pressing “ ” turns the seat
cooler on.
Pressing “ ” increases the level and pressing “ ” lowers the level.
*1: The indicator illuminates in amber.
*2: The indicator illuminates in blue.
OFF
Seat heater*1
Low
Mid
HiSeat cooler
*2
Low
Mid
Hi1
2
3
4
5
6

3905-6. Other interior features
LS600hL_U(OM50E41U)
■Operating condition
The power switch is in ON mode.
■Climate control seat operation
Depending on the outside temperature and the temperature of the seat surface,
there are cases when heating operation is stronger than usual.
■Operating the rear climate control seats from the front seats
 P. 3 4 3
■Disabling the switches on the rear controller
P. 3 4 5
■Replacing the air filters
Filters are installed in the climate control seats. For replacement of the filters, contact
your Lexus dealer.
■Customization
Automatic operation settings can be customized. (Customizable features P. 5 6 4 )

3915-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
CAUTION
■Burns/excessive cooling
●Use caution when seating the following persons in a seat to avoid the possibility of
burns or excessive cooling:
• Babies, small children, elderly persons, sick persons and persons with a physi-
cal disability
• Persons who have sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs which induce sleep, such as sleeping drugs and cold remedies
●Do not cover the seat with anything when using the climate control seat. Using
the climate control seat with a blanket or cushion may increase or decrease the
temperature of the seat, resulting in overheating or overcooling.
●Do not use the climate control seat more than necessary. Doing so may cool the
occupants excessively or may cause minor burns or overheating.
NOTICE
■To prevent damage to the climate control seat
Do not put heavy objects that have an unev en surface on the seat and do not stick
sharp objects, such as needle s and nails, into the seat.
■To prevent the 12-volt battery from being discharged
Do not leave the system on longer than necessary when the hybrid system is off.

3925-6. Other interior features
LS600hL_U(OM50E41U)
Pull the armrest down for use.
Armrest (5-seat models)
NOTICE
■To prevent damage to the armrest
Do not place too much strain on the armrest.

3935-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Slide the lever to raise the table.
Pull the table up and pull down
the table.
The position of the table can be
changed. Before using the table,
make sure that the table is securely
locked.
When the table is in use, the front
seats will stop if they are going to
contact the table. ( P. 160, 176)
When returning the table, pull it up
while pulling the lock release lever.
Retractable table (4-seat models)
1
2

3945-6. Other interior features
LS600hL_U(OM50E41U)
CAUTION
■When not in use
To avoid injury, return the table.
■Caution while driving
Keep the table stowed properly in its place. In the event of an accident, contact
with the table may result in death or serious injury.
■When using the table
Observe the following precautions. Failure to do so may result in death or serious
injury.
●Make sure the table is securely locked.
●Do not lean on the table.
●Do not put anything heavier than 22 lb. (10 kg) on the table.
NOTICE
■To prevent damage to the table
Do not place too much strain on the table.

3955-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■From front seat
5-seat models
Extend/retract
4-seat models
Extend/retract
Rear sunshade
The rear sunshade can be raised and lowered by operating any of the
buttons shown below.

3965-6. Other interior features
LS600hL_U(OM50E41U)
■From rear seat
5-seat models
Extend/retract
4-seat models
Extend/retract
■The rear sunshade can be used when
The power switch is in ON mode.
■Operating the rear sunshade after turning the hybrid system off
The rear sunshade can be operated for approximately 60 seconds even after the
power switch is switched to ACCESSORY mode or turned off.

3975-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■Reverse operation feature
To ensure adequate rear visibility, the rear sunshade automatically lowers when the
shift lever is shifted to R.
However, the rear sunshade is raised again if any of the following occurs:
●The button is pressed again.
●The shift lever is shifted to P.
●The shift lever is shifted out of P and R, and the vehicle reaches a speed of 9 mph
(15 km/h).
If the hybrid system is turned off when the rear sunshade has been lowered due to
the reverse operation feature, it will not be raised even when the hybrid system is
turned on again and the vehicle reaches a speed of 9 mph (15 km/h). To raise the
sunshade again, press the button.
■Button lock function
To prevent inadvertent operation, some butt ons on the rear controller can be locked.
(  P. 3 5 7 )
CAUTION
■When the rear sunshade is being raised or lowered
Do not place fingers or other objects in the shade mechanism or in the opening as
injury may result.
NOTICE
■To prevent the 12-volt battery from being discharged
Do not operate the rear sunshade when the hybrid system is off.
■To ensure normal operation of the sunshade
Observe the following precautions:
●Do not place excessive load on the motor or other components.
●Do not place objects where they may hinder opening and closing operations.
●Do not attach items to the rear sunshade.
●Keep the opening clean and clear of obstructions.
●Do not operate the rear sunshade cont inuously for long periods of time.

3985-6. Other interior features
LS600hL_U(OM50E41U)
■From front seat
5-seat models
Extend/retract
4-seat models
Extend/retract
■From rear seat
5-seat models
Extend/retract
Rear door sunshades
The rear door sunshades can be extended and retracted by operating
any of the buttons shown below.
