key LEXUS LX470 2006 User Guide

KEYS AND DOORS
15
Sounding an alarm*
11X015d
When you push the “P ANIC” button for about 1 second, an
alarm sounds to deter any person trying to break into or
damage your vehicle.
If you want to stop the alarm, push “LOCK”, “UNLOCK” or
“PANIC” button for about 1 second.
This function does not work when the ignition key is in the “ON”
position.
NOTE: *The alarm can be set not to sound. Ask your Lexus
dealer for details.
Operating the windows and moon roof
The windows and moon roof can be operated using a
wireless remote control key from outside the vehicle.*NOTE: *The windows and moon roof can be deactivated.
The moon roof can be set to slide open or tilt up or
deactivated. Ask your Lexus dealer for details.
11x500d
Push the “UNLOCK” button until the windows and moon roof
start to move. At this time one beep sounds. When you
release the button, the windows and moon roof stop operating.
This function will work even with the window lock switch
pressed in.

KEYS AND DOORS
16For vehicles sold in U.S.A.
This device complies with
Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
NOTICE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
 Consult the dealer or an experienced radio / TV techni-
cian for help.
FCC WARNING:
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.
For vehicles sold in Canada
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.

KEYS AND DOORS
17
Replacing the battery
When you replace the battery, prepare a lithium battery
CR2016 or equivalent and a special screwdriver.
CAUTION
Special care should be taken to prevent small children
from swallowing the removed battery or components.
NOTICE
When replacing the battery, be careful not to lose the
components.
 Replace only with the same or equivalent type
recommended by a Lexus dealer.
 Dispose of used battery according to the local laws.
11L0281
1. Remove the screw, and then the cover while pushing it in the
arrow direction.
11x602
2. Remove the module from the key frame.

KEYS AND DOORS
18
11x603
3. Open and remove the battery case cover using a coin.
4. Remove the discharged battery and put in a new battery
with the positive side up.
NOTICE
Make sure the positive side and negative side of the
battery are faced correctly.
 Do not replace the battery with wet hands. Water may
cause unexpected rust.
 Do not touch or move any components inside the
transmitter, or it may interfere with proper operation.
 Be careful not to bend the electrode when inserting
the battery and that dust or oils do not adhere to the
inside of the module.
 Take care not to lose the screws.
5. Replace the battery case cover. 6. Install the module into the key frame and secure the cover
with the screw.
7. When pushing any switch on the wireless key, make sure
the indicator light comes on.

KEYS AND DOORS
19
SIDE DOORS
Locking with key
11X001b
 1Lock 2Unlock
Turn the key towards the front of the vehicle to lock and
towards the back to unlock.
All the side doors and back door lock and unlock
simultaneously with either front door. In the driver’s door lock,
turning the key once will unlock the driver’s door and twice in
succession will unlock all th e side doors and back door
simultaneously. In the passenger’s door lock, turning the key
once will unlock all the side doors and back door
simultaneously.*
NOTE: *The 2step unlocking function can be changed.
Ask your Lexus dealer for details. Together with the activation of
unlocking, the interior light
comes on for 15 seconds if the interior light switch is in “DOOR”
position. However, this function does not work when the
ignition key is in the “ON” position. For further information, see
“Interior lights” on page 69.

KEYS AND DOORS
20
Locking with inside lock button
11X002a
 1Lock 2Unlock
Push in the lock button to lock and unlock the door.
The front doors can be opened by pulling the inside handles
even if the lock buttons are in the locked position.
CAUTION
Do not pull the inside handle of the front doors while
driving. The doors will open and an accident may occur.
Lexus strongly recommends that all children be placed
in the rear seat of the vehicle.
Closing the door with the lock button pushed in will also lock
the door. Be careful not to lock your keys in the vehicle. With
the key in the ignition switch and the front door open, the lock
knob cannot be moved in the lock position.
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle in an accident. It also
helps prevent the doors from being opened
unintentionally.

KEYS AND DOORS
21
Locking with power door lock switch
11X003e
 1Lock 2Unlock
To lock all the side doors and back door simultaneously,
push the power door lock switch down on the front side.
Pushing down on the rear side will unlock them.
The same switch is also found on the front passenger’s side.
When the front doors are locked from the outside or locked with
the wireless remote control transmitter, the power door lock
switch will not work until either front door is unlocked with the
key, lock button or wireless remote control transmitter.
Automatic door locking and unlocking
functions
AUTOMATIC DOOR LOCKING
You can select the following functions:
 Locking linked with the shift position
All doors are automatically locked when the selector lever is
moved out of “P” position.
 Locking linked with vehicle speed
All doors are automatically locked when the vehicle speed
goes above about 20 km/h (12 mph).
You can set or cancel the automatic door locking
functions:
Be sure to apply the parking brake when performing the
following operations.
To select the locking linked with the shift position:
1. Close all doors and turn the ignition switch to the “ON”
position.
2. Shift the selector lever to the “P” position.
3. Within 10 seconds of turning the ignition switch to the “ON”
position, press and hold the driver’s side power door lock
switch in the lock position for 5 seconds and then release.
The doors will be locked and unlocked to indicate that the
function is set.
To cancel the function, do the above operation again.

KEYS AND DOORS
22To select the locking linked with the vehicle speed:
1. Close all doors and turn the ignition switch to the “ON”
position.
2. Shift the selector lever from “P” to the “N” position.
3. Within 10
seconds of turning the ignition switch to the “ON”
position, press and hold the driver’s side power door lock
switch in the lock position for 5 seconds and then release.
The doors will be locked and unlocked to indicate that the
function is set.
To cancel the function, do the above operation again.
AUTOMATIC DOOR UNLOCKING
You can select the following functions:
 Unlocking linked with the shift position
All doors are automatically unlocked when the selector lever
is moved to “P” position.
 Unlocking linked with the ignition switch
All doors are automatically unlocked when the the driver’s door
is opened within 10 seconds after the ignition switch is turned
to the “ACC” or “LOCK” position, or the key is removed.
You can set or cancel the automatic unlocking functions:
Be sure to apply the parking brake when performing the
following operations.
To select the unlocking linked with the shift position:
1. Close all doors and turn the ignition switch to the “ON”
position. 2. Shift the selector lever to the “P” position.
3. Within 10
seconds of turning the ignition switch to the “ON”
position, press and hold the driver’s side power door lock
switch in the unlock position for 5 seconds and then release.
The doors will be locked and unlocked to indicate that the
function is set.
To cancel the function, do the above operation again.
To select the unlocking linked with the ignition switch:
1. Close all doors and turn the ignition switch to the “ON”
position.
2. Shift the selector lever from “P” to the “N” position.
3. Within 10 seconds of turning the ignition switch to the “ON”
position, press and hold the driver’s side power door lock
switch in the unlock position for 5 seconds and then release.
The doors will be locked and unlocked to indicate that the
function is set.
To cancel the function, do the above operation again.

KEYS AND DOORS
23
Locking with rear door childprotector
11X004e
 1Lock 2Unlock
Whenever small children are in the vehicle, lock the rear
door so that it does not open by the inside door handle.
To do this, move the lever to the “LOCK” position as
shown and then close the door.
BACK DOOR
Opening and closing
11X007g
 Opening from outside 1
Unlock 2Lock 3Open
All the doors lock and unlock simultaneously with the back
door.

KEYS AND DOORS
24
11X008d
Opening from inside 1
Unlock 2Lock 3Open
The back door can be opened as shown. See “Cargo and luggage” on page 329 for precautions to
observe in loading luggage.
After closing the back door, try pulling it up to make sure it is
securely closed.
Closing the back door with the lock button pushed in will also
lock the back door. Be careful not to lock your keys in the
vehicle.
The back door lock will be controlled with the power door lock
switch. (For instructions, see “Side doors” on page 19.)
CAUTION
Keep the back
door closed while driving. This not only
keeps the luggage from being thrown out but also
prevents exhaust gases from entering the vehicle.
