GAUGES, METERS AND SERVICE REMINDER INDICATORS
58
(g) “ABS” Warning Light
The light comes on when the ignition key is turned to the “ON”
position. If the anti−lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti−lock brake system, the brake
assist system, the active traction control system and/or the
vehicle stability control system do/does not operate, but the
brake system still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti−lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer
as soon as possible to service the vehicle.
 The light does not come on when the ignition key is turned
to the “ON” position or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.CAUTION
If the “ABS” warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Either of the following conditions may occur, but do not
indicate the malfunction:
 The light may stay on for about 60 seconds after the ignition
key is turned to the “ON” position. It is normal if it turns off
after a while.
 Depressing the brake pedal repeatedly may turn on the
light. It is normal if it turns off after a few seconds.
(h) Open Door Warning Light
This light remains on until all the side doors and back door are
completely closed.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
59
(i) Tire Pressure Warning Light
This light comes on when the ignition key is turned to the “ON”
position. If the tire pressure warning system works properly
and tire inflation pressure is appropriate, the light goes off after
a few seconds.
This light comes on or flashes in the following cases when the
ignition key is turned to the “ON” position.
 When the low tire inflation pressure is detected while
driving...
If any tire has low inflation pressure, the light comes on.
The light goes off after the tire inflation pressure is adjusted
to a specified level.
 When initializing the system...
If initialization is completed, the light blinks three times.
 When the system malfunctions...
If the system malfunctions, the light blinks.
Although it is no problem to continue driving, have your
vehicle checked by your Lexus dealer as soon as possible.
(j) Unengaged “Park” Warning Light
This light warns that the transmission “Park” mechanism is not
engaged. If the four −wheel drive control is in the “N” position
while the selector lever is in the “P” position, the transmission
will disengage and the wheels will not lock.
CAUTION
To restore the park function, shift the fourwheel drive
control out of “N”.
(k) Automatic Transmission Fluid Temperature Warning Light
This light warns that the automatic transmission fluid
temperature is too high.
If this light comes on while you are driving, slow down and pull
off the road. Stop the vehicle at a safe place and put the
selector lever in “P” and leave the engine idling until the light
goes off. If the light goes off, you can start the vehicle again.
If the light does not go of f, call a Lexus dealer or qualified repair
shop for assistance.
NOTICE
Continued driving with the warning light on may
damage the automatic transmission.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
60
(l) Vehicle Stability Control System andActive Traction Control System Warning
Light
This light warns that there is a problem somewhere in the
vehicle stability control system and active traction control
system.
If the “VSC/TRAC” warning light and “VSC OFF” indicator light
come on, have your vehicle checked by Lexus dealer as soon
as possible. However, it is no problem that the “VSC/TRAC”
warning light comes on when the brake actuator temperature
becomes high. (For details, see “Active traction control
system” on page 288.)
The lights will stay on with the ignition key turned to “ON”, and
will go off after about a few seconds.
The lights may stay on for 60 seconds after the ignition key is
turned to the “ON” position. It is normal if they go out after a
while.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
When the “VSC/TRAC” warning light and “VSC OFF” indicator
light come on, the vehicle stability control system and/or active
traction control system do not operate, but there is no problem
to continue your driving.
(m) Variable Gear Ratio Steering System Warning Light
This light warns that there is a problem somewhere in the
variable gear ratio steering system.
The light will come on when the ignition key is turned to “ON”
and will go off after a few seconds.
If the light comes on while driving, the system is not working.
Although conventional steering operates when maneuvered,
a larger degree of wheel maneuvering (than at the time when
the system is functioning properly) is needed when driving at
low speed. At this time, the center position of the steering
wheel could be changed. Although it is no problem to continue
driving, have your vehicle repaired at your Lexus dealer.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
The light will flash if you disconnect and reconnect the battery
terminal. This is because the system is reset temporarily.
However, it is no problem to drive. To turn off the light, drive for
a short while. The system will be set automatically and return
to normal.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
61
(n) Lexus Night View System Warning Light
When this light comes on, the bulb for the near−infrared
floodlight (night view projector) is burned out. Have it replaced
at Lexus dealer.
(o) Charging System Warning Light
This warning light comes on when the ignition switch is turned
to the “ON” position, and goes off when the engine is started.
When there are problems in the charging system while the
engine is running, the warning light comes on.
NOTICE
When the charging system warning light comes on
while the engine is running, malfunctions such as the
engine drive belt being broken may have occurred. If
the warning light comes on, immediately stop the
vehicle in a safe place and contact your Lexus dealer.
(p) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(q) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(r) Key Reminder Buzzer
This buzzer acts as a reminder to remove the key when you
open the driver’s door with the ignition key in the “ACC” or
“LOCK” position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
62
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Place the four−wheel drive control lever in “N” position and
the selector lever in “P” position and turn the ignition key to
“ACC”.
The following service reminder indicator should come on. It
goes off when you place the four −wheel drive control lever in
“H” or “L” position.
4. Turn the ignition key to “ON”.
The following service reminder indicators should come on.
222
w73

w72a
214
218


wtracorw227
orw16
or

or

222
GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
The following service reminder indicators go off after a few
seconds.

w73

w72a

218
214 wtracorw227
or

The following service reminder indicat
or goes off after about 6
seconds.
The anti −lock brake system warning light, vehicle stability
control system off indicator light and vehicle stability control
system and active traction control system warning light may
stay on for about 60 seconds after the ignition key is turned to
the “ON” position. It is normal if they go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.
TRIP INFORMATION DISPLAY (Vehicles without navigation system)
13x541z
The following information is shown with the ignition
switch turned on. Each time you push the “MODE” button,
the displayed information is changed.
 Average vehicle speed
 Driving distance after engine starting
 Available driving range
 Average fuel consumption after being refueled
 Current fuel consumption
The displayed trip information values indicate the general
driving condition and may not always reflect precise and actual
conditions.

INTERIOR EQUIPMENT
69
INTERIOR LIGHTS
Front
14X081
To turn on the interior light, slide the switch.
With the switch in the “DOOR” position, the light comes on
when any door is opened or when the ignition key is turned to
“LOCK”. After all the doors are closed, the light remains on for
about 15 seconds and then goes out.*
However, in the following cases, the light goes out
immediately:
1. All the doors are closed when the ignition key is in “ACC” or
“ON” position.
2. The ignition key is turned to “ACC” or “ON” when the light
is still on.
3. All the doors are locked when the light is still on. 4. One door is closed with the lock button pushed in while the
other doors are locked.
NOTE: * The interior lights can be set not to come on or the
duration of lighting can be changed. Ask your Lexus dealer
for details.
Rear
14X002
To turn on the interior light, slide the switch.
With the switch in the “DOOR” position, the light comes on
when the rear door or back door is opened. The light goes out
immediately when the rear door and back door are closed.

INTERIOR EQUIPMENT
71
IGNITION SWITCH LIGHT
14X004a
For easy access to the ignition switch, the ignition switch
light comes on when any of the doors are opened.
The light remains on for about 15 seconds and goes out after
all the doors are closed. However, the light goes out
immediately when all the doors are locked or the ignition key
is in the “ACC” or “ON” position.
CLOCK
14X500
The digital clock indicates the time when the ignition key
is at the “ACC” or “ON” position. To reset the hour, press
the “H” button. To reset the minutes, press the “M”
button. To adjust the time to the nearest hour, press the
“:00” button.
For example, if the “:00” button is pressed when the time is
between 9:30 − 9:59 or between 10:01 − 10:29, the time will
change to 10:00.
If the electrical power source has been disconnected from the
clock, the time display will automatically be set to 1:00.
When the headlight switch is in the first or second click stop,
you can also adjust the brightness of the display using the
instrument panel light control dial.

INTERIOR EQUIPMENT
72
OUTSIDE TEMPERATURE DISPLAY
14X501
This display shows the outside temperature when the
ignition switch is on.
The displayed temperature ranges from −30C (− 22F) up to
50 C (122F). If the temperature does not appear on the
display or it shows “− − ”, take your vehicle to your Lexus dealer.
When the headlight switch is in the first or second click stop,
you can also adjust the brightness of the display using the
instrument panel light control dial.
The unit shown on the display can be changed. For details,
see “Trip information display” on page 63.
CIGARETTE LIGHTER AND ASHTRAY
Front
14X006c
To use the cigarette lighter, press in the cigarette lighter.
After it finishes heating up, it automatically pops out ready
for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in the
“ACC” position to use the lighter.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, close the lid completely.
To remove the ashtray, press down on the lock spring plate and
pull out.
Use a Lexus genuine cigarette lighter or equivalent for
replacement.

INTERIOR EQUIPMENT
75
Rear
14X603
The power outlets are designed for power supply for car
accessories.
The ignition key must be in the “ACC” or “ON” position for t\
he
power outlets to be used.
NOTICE
To prevent the fuse from being blown, do not use the
electricity over the total vehicle capacity of 12V/120W
(front and rear outlets together).
 To prevent the battery from being discharged, do not
use the power outlets longer than necessary when
the engine is not running.
Close the power outlet lids when the power outlets
are not in use. Inserting anything other than an
appropriate plug that fits the outlet, or allowing any
liquid to get into the outlet may cause electrical
failure or short circuits.
REAR CONSOLE BOX
14X074
 1
For upper box 2For lower box
To use the rear console box, open as shown in the
illustration.
