OCCUPANT RESTRAINT SYSTEMS
176Install the child restraint system on the front passenger seat
only when it is unavoidable. Your vehicle is equipped with a
front passenger occupant classification system. In order to
activate
the occupant classification system correctly, install the
forward−facing child restraint system on the front passenger
seat in the following order:
1. Turn the ignition key to the “ON” position.
2. Move the front passenger seat to the rearward position.
3. Put the child restraint system on the front passenger seat
without putting your weight on the front passenger seat.
4. Insert the seat belt tab into the seat belt buckle.
5. Fully extend the shoulder belt to put it in the lock mode.
When the belt is then retrac ted even slightly, it cannot be
extended. To hold the seat securely, make sure the belt is in the
lock mode before letting the belt retract.
6. While pressing the convertible seat firmly against the seat
cushion and seatback, let the shoulder belt retract as far as it
will go to hold the convertible seat securely.
CAUTION
Push and pull the child r estraint system in different
directions to be sure it is secure. Follow all the
installation instructions pr ovided by its manufacturer.
7. Put a child on the child restraint system and secure the child,
complying with the instructions provided by the child restraint
system manufacturer. The occupant classification indicator light should indicate
“OFF”
when the ignition key is in the “ON” position and the child
is in the child restraint system after following these procedures.
The “OFF” indicator indicates the SRS front passenger airbag
will not deploy. If the indicator light indicates “ON”, remove the
child restraint system and reinstall it with the ignition key in the
“ACC” or “LOCK” position. If the indicator light still indicates
“ON” when the ignition key is turned to the “ON” position, then
the SRS front passenger airbag may deploy in an accident. Do
not drive the vehicle in this condition. Remove the child
restraint system and contact your Lexus dealer.
CAUTION
Never install a rearfacing child restraint system on
the front passenger seat. A forwardfacing child
restraint system should only be installed on the front
passenger seat when unavoidable. If you must install
the child restraint system on the front passenger
seat, put the seat in its mo st rearward position, and
install the forwardfacing child restraint system in
the proper order. Otherw ise, the front passenger
occupant classification system cannot detect the
presence of the child rest raint system and the front
passenger airbag could deploy.

OCCUPANT RESTRAINT SYSTEMS
189
DRIVING POSITION MEMORYSYSTEM
A microcomputer will memorize the position of the driver’s
seat, and the positions of the tilt and telescopic steering, and
outside rear view mirrors. Two different driving position
profiles can be entered into the computer’s memory.
Recording the driving position in the computer’s memory can
only be done when the ignition key is in the “ON” position and
the selector lever is in the “P” position.
Setting the driving position
16X162
1. Adjust the driver’s seat, tilt and telescopic steering and
outside rear view mirrors to the desired position.
2. While pushing the “SET” button, push button “1” or “2”
until the signal beeps. The beep sound means that the positions are recorded in the
computer’s memory.
By repeating these two steps
and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
16X163
When you push button “1” or “2”, the driving position will
be automatically adjusted to the position recorded for that
button.

OCCUPANT RESTRAINT SYSTEMS
190Conditions for memorized position activation

Ignition key “ON” and selector lever in “P” position.
All parts of the memorized positions can be activated.
 Key not in ignition switch and within 30 seconds of opening
driver’s door.
The memorized position can be activated, except for the tilt
and telescopic steering.
If any driving position memory switch is pushed while one of
the memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (“1” or “2”)\
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory w ill be erased and the memorized positions will have
to be set again.
CAUTION
 Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch.

STEERING WHEEL AND MIRRORS
193
Automatic tiltaway*
16X100f
When the ignition key is removed, the steering column
moves forward away from the driver and also tilts up for
easy exit and entry.
When the key is inserted in the ignition switch, the steering
column returns to the previously set position.NOTE: *This feature can be deactivated. Ask your Lexus
dealer for details.
OUTSIDE REAR VIEW MIRRORS
16X013a
Adjust the mirror so that you can just see the side of your
vehicle in the mirror.
Be careful when judging the size or distance of any object seen
in the outside rear view mirror on the passenger’s side
because it is a convex mirror. Any object seen in a convex
mirror will look smaller and farther away than if seen in a normal
flat mirror.
When the inside rear view mirror darkens in “AUTO” mode, the
outside rear view mirrors also darken to reduce the reflection
of the headlights of the following vehicle. For details, see
“Inside rear view mirror” on page 196.
When you push the outside rear view mirror defogger switch,
the heater panels in the outside rear view mirrors will quickly
clear the mirror surface. (See “Outside rear view mirror
defogger switch” on page 38.)

STEERING WHEEL AND MIRRORS
194
CAUTION
Do not adjust the mirror while the vehicle is moving.
Doing so may cause the driver to mishandle the
vehicle and an accident may occur , resulting in death
or serious injuries.
 Since the mirror surfaces can get hot, do not touch
them when the outside rear view mirror defogger
switch is on.
Power rear view mirror control
16X014f
 1
Control switch 2Master switch
To adjust the power rear view mirror, first place the master
switch at “L” (left) or “R” (right), and push the contro\
l
switch on the desired side.
The power rear view mirrors can be adjusted when the key is
in the “ACC” or “ON” position.

STEERING WHEEL AND MIRRORS
195
When you are backing up,
you can adjust the mirrors
down quickly by the following operations with the ignition
on.
 Put the selector lever in the “R” position.
 Place the master switch at “L” (left) or “R” (right).
The mirrors return to the previous position by any of the
following operations.
 Put the selector lever in a position other than “R”.
 Place the master switch in the neutral position.
 Turn the ignition key to the “ACC” position.
NOTICE
If ice should jam the mirror, do not operate the control
or scrape the mirror face. Use a spray deicer to free the
mirror.
Folding rear view mirrors
16X015f
To fold the rear view mirrors, push the switch. To return
to their original position, push the switch again.
The rear view mirrors can be folded backward for parking in
compact areas.
CAUTION
To avoid personal injury and any mirror malfunction,
do not touch the mirror while it is moving.
 Do not drive with the mirrors folded backward. Both
the driver and passenger side rear view mirrors must
be extended and properly adjusted before driving.

STEERING WHEEL AND MIRRORS
196
INSIDE REAR VIEW MIRROR
16X016e
Adjust the mirror so that you can just see the rear of your
vehicle in the mirror.
Pushing the switch changes the mode between “AUTO”
and “DAY”.
The indicator comes on when the “AUTO” mode is selected.
“DAY” mode: The mirror surface is normal.
“AUTO” mode: If the mirror detects light from the
headlights of the vehicle behind you, the mirror surface
darkens slightly to reduce the reflected light.
When the inside rear view mirror surface changes, the outside
rear view mirror surfaces will also become darker.
When the ignition key is inserted and turned on, the inside rear
view mirror always turns on in the “AUTO” mode. When
the inside air temperature is low, it may take a little longer
for the mirror to darken in response to the detection of
headlights.
CAUTION
Do not adjust the mirror while the vehicle is moving.
Doing so may cause the driver to mishandle the vehicle
and an accident may occur resulting in death or serious
injuries.
16x658b
To ensure correct functioning of antiglare mirror sensors
located on both sides of the mirror, do not touch or cover
the sensors with your finger or a piece of cloth, etc.

AIR CONDITIONING
202
AUTOMATIC AIR CONDITIONING CONTROLS
20X017e
You can adjust the brightness of the display. See
“Instrument panel light control” on page 66 for details.
The automatic air conditioning automatically maintains
the set temperature.
This air conditioning features automatic fan speed and air flow
control which automatically se lects the most suitable fan
speed and air flow to control the temperature. The ignition key
must be in the “ON” position.NOTICE
To prevent the battery from being discharged, do not
leave the air conditioning on longer than necessary
when the engine is not running.

AIR CONDITIONING
213
REAR AIR CONDITIONINGCONTROLS
20X054b
The control panel is located in the roof panel above the
second seat.
1 Automatic control button
2 Air flow control buttons
3 OFF button
4 Temperature control lever
5 Fan speed control buttons
The automatic air conditioning automatically maintains the set
temperature.
This air conditioning features automatic fan speed and air flow
control which automatically se lects the most suitable fan
speed and air flow to control the temperature. The ignition key
must be in the “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave the air conditioning on longer than necessary
when the engine is not running.

AUDIO
220
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some informat ion may not pertain to your
system.
Your audio system works when the ignition key is in the “ACC”
or “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave the audio system on longer than necessary when
the engine is not running.
(a) Turning the system on and off
21X506b
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.
21X507a
Push “AM·SAT”, “FM”, “TAPE” or “DISC” to turn on that
mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or CD is not set, the cassette player or CD player
does not turn on.
You can turn off the cassette player by ejecting the cassette
tape. If the audio system was previously off, then the entire
audio system will be turned off when you eject the cassette
tape. If another function was previously playing, it will come on
again.
