engine LEXUS LX570 2014 Owners Manual

3952-5. Driving information
2
When driving
LX570_OM_OM60L21U_(U) ■
AVS (adaptive variable suspension system)
The suspension can be switched for improvement in driveability. (  P. 3 2 9 )■
Break-in schedule
If your vehicle is new or equipped with any new power train components (such as
an engine, transmission, differential or wheel bearing), Lexus recommends that you
do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
After the vehicle has been driven for over 500 miles (800 km), you can start tow-
ing. However, for the next 500 miles (800 km), drive the vehicle at a speed of less
than 50 mph (80 km/h) when towing a traile r, and avoid full throttle acceleration.■
Maintenance ●
If you tow a trailer, your vehicle will require more frequent maintenance due to
the additional load. (See “Owner’s Guide”, “Warranty and Services Guide”,
“Owner’s Manual Supplement” or “Warranty Booklet”.) ●
Retighten the fixing bolts of the towing ball and bracket after approximately
600 miles (1000 km) of trailer towing.■
If trailer sway occurs
One or more factors (crosswinds, passing vehicles, rough roads, etc.) can adversely
affect handling of your vehicle and trailer, causing instability. ●
If trailer swaying occurs:
• Firmly grip the steering wheel. Steer straight ahead.
Do not try to control trailer swaying by turning the steering wheel.
• Begin releasing the accelerator peda l immediately but very gradually to
reduce speed.
Do not increase speed. Do not apply vehicle brakes.
If you make no extreme correction with the steering or brakes, your vehicle and
trailer should stabilize. (if enabled, Trailer Sway Control can also help to stabilize the
vehicle and trailer.)

4033-1. Using the touch screen
3
Interior features
LX570_OM_OM60L21U_(U) Initial screen
When the “ENGINE START
STOP” switch is turned to
ACCESSORY or IGNITION ON
mode, the initial screen will be dis-
played for a few seconds as the
system starts up. Images shown on the initial screen
can be changed to suit individual
preferences. (  P. 4 1 7 )
Adjusting the display
The contrast and brightness of the screen display and the image the cam-
era displays can be adjusted. (For information regarding audio/video
screen adjustment:  P. 5 1 8 )
Press the “SETUP” button and the touch “Display” on the “Setup”
screen. STEP 1

4063-1. Using the touch screen
LX570_OM_OM60L21U_(U) ■
Changing between day mode and night mode
In the following conditions, the displays condition is not changed to night mode
even if the headlight switch is turned on:
• The instrument panel light control switch is turned fully to the right.
• The vehicle is in a bright area, such as outside in direct sunlight. ■
To turn off the display
The display goes off when “Screen Off” is touched. To turn the screen back on,
press any button. The sele cted screen appears.
NOTICE■
To avoid damaging the touch screen ●
To prevent damaging the screen, lightly touch the screen buttons with your finger. ●
Do not operate or rub the screen with a ballpoint pen, a mechanical pencil, finger
nail, a pointy and/or hard object be cause this will damage the screen.●
Do not use objects other than yo ur finger to touch the screen.●
Wipe off fingerprints using a glass cleaning cloth. Do not use chemical cleaners
to clean the screen, as they may damage the touch screen. To display the screen in day mode, even with
the headlight switch on, touch “Day Mode”
for brightness and contrast control.
If the screen is set to day mode with the
headlight switch turned on, this condition is
memorized even with the engine turned
off.

4483-2. Using the air conditio ning system and defogger
LX570_OM_OM60L21U_(U) ■
Using the automatic mode
Fan speed is adjusted automatically in accordance with the temperature setting and
ambient conditions. As a result, the following may occur: ●
Immediately after the “AUTO” button is pressed, the fan may stop for a while
until warm or cool air is ready to flow. ●
Cool air may flow to the area around the upper body when the heater is on.■
Using the system in recirculated air mode
The windows will fog up more easily if the recirculated air mode is used for an
extended period. ■
Switching between outside air and recirculated air modes
Recirculated air mode or outside air mode may be automatically switched in accor-
dance with the temperature setting and the inside temperature. ■
When the outside temperature exceeds 75°F (24°C) and the air conditioning
system is on ●
In order to reduce the air conditioning power consumption, the air conditioning
system may switch to recirculated air mode automatically. This may also reduce
fuel consumption. ●
Recirculated air mode is selected as a default mode when the “ENGINE START
STOP” switch is turned to IGNITION ON mode. ●
It is possible to switch to outside air mode at any time by pressing .■
Window defogger feature
Recirculated air mode may automatically switch to
(outside air) mode in situ-
ations where the windows need to be defogged. ■
Automatic mode for air intake control
In automatic mode, the system detects exhaust gas and other pollutants and auto-
matically switches between outside air and recirculated air modes.
When the air conditioning is off, and the fan is operating, turning the “AUTO” mode
on will activate the air conditioning system. ■
When outside temperature approaches 32°F (0°C)
The air conditioning system may not operate even when “A/C” is touched.

4503-2. Using the air conditio ning system and defogger
LX570_OM_OM60L21U_(U) CAUTION■
To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather. The differ-
ence between the temperature of the outside air and that of the windshield can
cause the outer surface of the windshield to fog up, blocking your vision.
NOTICE■
To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine
is stopped.

4513-2. Using the air conditio ning system and defogger
3
Interior features
LX570_OM_OM60L21U_(U) Outside temperature display
Outside temperature is displayed in the screen.
The displayed temperature ranges from -40  F (-40  C) up to 122  F
(50  C).
■
The outside temperature is displayed when
The “ENGINE START STOP” switch is in IGNITION ON mode. ■
When “— —” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Lexus dealer■
Display
In the following situations, the correct outside temperature may not be displayed, or
the display may take longer than normal to change. ●
When stopped, or driving at low speeds (less than 12 mph [20 km/h]) ●
When the outside temperature has changed suddenly (at the entrance/exit of a
garage, tunnel, etc.)

4553-2. Using the air conditio ning system and defogger
3
Interior features
LX570_OM_OM60L21U_(U) Adjusting the position and opening and closing the air outlets
Direct air flow to the left or right,
up or down.
Turn the knob fully to the back of
the vehicle to close the vent.
NOTICE■
To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine
is stopped.

4563-2. Using the air conditio ning system and defogger
LX570_OM_OM60L21U_(U) Rear window and outside rear view mirror defoggers ■
The rear window and outside rear view mirror defoggers can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
CAUTION■
When the outside rear view mirror defoggers are on
Do not touch the rear view mirror surfac es, as they can become very hot and burn
you.These features are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
On/off The operation time changes
according to the ambient tem-
perature and vehicle speed.
Pressing the button again also
turns the defoggers off.

4573-2. Using the air conditio ning system and defogger
3
Interior features
LX570_OM_OM60L21U_(U) Windshield wiper de-icer
■
The windshield wiper de-icer can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
CAUTION■
When the windshield wiper de-icer is on
Do not touch the glass at the lower part of the windshield or the side of the front pil-
lars as the surfaces can become very hot and burn you.This feature is used to prevent ice fr om building up on the windshield and
wiper blades.
Press the “CLIMATE” button.
On/off The windshield wiper de-icer
will automatically turn off after
approximately 15 minutes.
Touching the switch again also
turns the de-icer off.STEP 1
STEP 2

4613-3. Using the audio system
3
Interior features
LX570_OM_OM60L21U_(U) CAUTION■
For vehicles sold in U.S.A. and Canada ●
Pa r t 1 5 o f t h e F CC Ru l e s
FCC Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. ●
Laser products
• USE OF CONTROL OR ADJUSTMENT OR PERFORMANCE OF PRO-
CEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
• THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL
INCREASE EYE HAZARD.
NOTICE■
To prevent battery discharge
Do not leave the audio system on longer than necessary when the engine is off. ■
To avoid damaging the audio system
Take care not to spill drinks or other fluids on the audio system.
