key LEXUS LX570 2014 Owners Manual

TABLE OF CONTENTS Index
2
LX570_OM_OM60L21U_(U) 1-1. Key information
Keys ..................................................... 30
1-2. Opening, closing and
locking the doors
Smart access system with
push-button start .......................... 35
Wireless remote control .............. 48
Side doors ........................................... 51
Back door ........................................... 56
1-3. Adjustable components
(seats, mirrors, steering
wheel)
Front seats .......................................... 67
Rear seats ............................................. 71
Driving position memory
system .............................................. 83
Head restraints................................. 87
Seat belts ............................................. 91
Steering wheel................................ 100
Anti-glare inside rear view
mirror .............................................. 102
Outside rear view mirrors ......... 104 1-4. Opening and closing the
windows and moon roof
Power windows.............................. 107
Moon roof ......................................... 110
1-5. Refueling
Opening the fuel tank cap........... 114
1-6. Theft deterrent system
Engine immobilizer system ......... 117
Alarm.................................................... 119
1-7. Safety information
Correct driving posture ............. 122
SRS airbags ..................................... 124
Front passenger occupant
classification system .................. 138
Child restraint sy stems ............... 144
Installing child restraints ............. 1491
Before drivingFor information regarding the navigation system, refer to the “Navigation System
Owner’s Manual”.

TABLE OF CONTENTS Index
6
LX570_OM_OM60L21U_(U) 4-2. Maintenance
Maintenance
requirements............................... 736
General maintenance ................ 739
Emission inspection and
maintenance (I/M)
programs ...................................... 742
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions .................................. 743
Hood.................................................. 746
Engine compartment.................. 747
Tires ................................................... 762
Tire inflation pressure ................... 771
Wheels.............................................. 775
Air conditioning filter .................. 777
Electronic key battery ............... 780
Checking and replacing
fuses ................................................ 782
Light bulbs ....................................... 799 5-1. Essential information
Emergency flashers...................... 812
If your vehicle needs to be
towed............................................... 813
If you think something is
wrong .............................................. 819
Fuel pump shut off system ....... 820
5-2. Steps to take in an emergency
If a warning light turns on or a
warning buzzer sounds... ....... 821
If a warning message is
displayed ...................................... 832
If you have a flat tire.................... 849
If the engine will not start ......... 863
If the shift lever cannot be
shifted from “P” ......................... 865
If you lose your keys ................... 866
If the electronic key does not
operate properly ....................... 867
If the battery is discharged ...... 870
If your vehicle overheats ........... 873
If the vehicle becomes
stuck................................................ 876
If your vehicle has to
be stopped in an
emergency .................................. 8785
When trouble arises

27
LX570_OM_OM60L21U_(U) CAUTION■
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol
and certain drugs delay reaction time, impair judgment and reduce coordination,
which could lead to an accident that co uld result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers
or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full at tention to driving. Anything that distracts
the driver, such as adjusting controls, ta lking on a cellular phone or reading can
result in a collision with resulting death or serious injury to you, your occupants or
others. ■
General precautions regarding children’s safety
Never leave children unattended in the vehi cle, and never allow children to have or
use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is
also a danger that children may injure themselves by playing with the cigarette
lighter, the windows, the moon roof, or othe r features of the vehicle. In addition, heat
build-up or extremely cold temperatures inside the vehicle can be fatal to children.

Before driving
1
29
LX570_OM_OM60L21U_(U) 1-1. Key information
Keys .............................................. 30
1-2. Opening, closing and
locking the doors
Smart access system with
push-button start .................... 35
Wireless remote control ........ 48
Side doors..................................... 51
Back door .................................... 56
1-3. Adjustable components
(seats, mirrors, steering
wheel)
Front seats ................................... 67
Rear seats ..................................... 71
Driving position memory
system ....................................... 83
Head restraints .......................... 87
Seat belts ...................................... 91
Steering wheel ......................... 100
Anti-glare inside rear view
mirror ....................................... 102
Outside rear view
mirrors ..................................... 104 1-4. Opening and closing the
windows and moon roof
Power windows ........................ 107
Moon roof .................................. 110
1-5. Refueling
Opening the fuel tank
cap ............................................. 114
1-6. Theft deterrent system
Engine immobilizer
system........................................ 117
Alarm........................................... 119
1-7. Safety information
Correct driving posture ....... 122
SRS airbags .............................. 124
Front passenger occupant
classification system............ 138
Child restraint systems ......... 144
Installing child restraints....... 149

30
LX570_OM_OM60L21U_(U) 1-1. Key information
Keys The following keys are provided with the vehicle.
Electronic keys • Operating the smart access
system with push-button start
(  P. 3 5 )
• Operating the wireless
remote control function
(  P. 4 8 )
Mechanical keys
Key number plate
■ Card key (if equipped)
Electronic key Operating the smart access sys-
tem with push-button start
(  P. 3 5 )
Mechanical key

311-1. Key information
1
Before driving
LX570_OM_OM60L21U_(U) Using the mechanical key
Take out the mechanical key. The mechanical key can only be
inserted in one direction, as the key
only has grooves on one side. If the
key cannot be inserted in a look
cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the smart
access system with push-button
start does not operate properly,
you will need the mechanical key.
(  P. 8 6 7 )

321-1. Key information
LX570_OM_OM60L21U_(U) ■
Card key ●
The mechanical key that is stored inside the card key should be used only in an
emergency, such as when the key does not operate properly. ●
If it is difficult to take out the mechanical key, push down the lock release button
using a pen tip etc. If it is difficult to pull it out, use a coin etc.
●
The card key is not waterproof.■
When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. (  P. 6 8 7 )
Remove the mechanical key for your own use and provide the attendant with the
electronic key only. ●
To store the mechanical key in the card key,
insert it inside while pressing the lock
release button.
●
If the battery cover is not installed and the
battery falls out or if the battery was
removed because the key got wet, reinstall
the battery with the po sitive terminal facing
the Lexus emblem.

331-1. Key information
1
Before driving
LX570_OM_OM60L21U_(U) ■
Key number plate
Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that
a key is lost, a new mechanical key can be made by your Lexus dealer, using the key
number plate. (  P. 8 6 6 )■
When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any
buttons on the electronic key while inside the aircraft cabin. If you are carrying an
electronic key in your bag etc., ensure that the buttons are not li kely to be pressed
accidentally. Pressing a button may cause the electronic key to emit radio waves
that could interfere with the operation of the aircraft.
NOTICE■
To prevent key damage
Observe the following: ●
Do not drop the keys, subject them to strong shocks or bend them.●
Do not expose the keys to high temperatures for a long period of time. ●
Do not get the keys wet or wash them in a ultrasonic washer etc. ●
Do not attach metallic or magnetic materials to the keys or place the keys close to
such materials. ●
Do not disassemble the keys. ●
Do not place the key near objects that produce magnetic fields, such as TVs,
audio systems, induction cookers, or medi cal electrical equipment, such as low-
frequency therapy equipment.

341-1. Key information
LX570_OM_OM60L21U_(U) NOTICE■
Precautions for handling the card keys ●
Do not apply excess force when insertin g the mechanical key to the card key.
Doing so may damage the card key. ●
If the battery or card key terminals get wet, the battery may corrode and the card
key may stop working.
If the key is dropped into water, or if drinking water etc. is spilled on the key,
immediately remove the battery cover and wipe the battery and terminals.
(To remove the battery cover, lightly grasp it and pull.) If the battery is corroded,
have your Lexus dealer replace the battery. ●
Do not crush the battery cover or use a screwdriver to remove the battery cover.
Forcibly removing the battery co ver may bend or damage the key.●
If the battery cover is frequently removed, the cover may become loose. ●
When installing the battery, make sure to check the direct ion of the battery.
Installing the battery in the wrong direction may cause the battery to deplete rap-
idly. ●
The surface of the card key may be damage d, or its coating may peel off in the
following situations:
• The card key is carried together with hard objects, such as coins or keys.
• The card key is scraped with a sharp object, such as a tip of mechanical pencil.
• The surface of the card key is wiped with thinners or benzene.

351
Before driving
LX570_OM_OM60L21U_(U) 1-2. Opening, closing and locking the doors
Smart access system with push-button start The following operations can be performed simply by carrying the elec-
tronic key on your person, for example in your pocket.
(The driver should always carry the electronic key.)
Locks and unlocks the doors (  P. 36)
Locks and unlocks the doors (  P. 36)
Starts and stops the engine (  P. 175)
