display LEXUS LX570 2014 Owners Manual

5033-3. Using the audio system
3
Interior features
LX570_OM_OM60L21U_(U) Using the CD/DVD player Press the “AUDIO” button if a disc has already been loaded in the disc slot.
Touch the “DISC” tab or press the “AUDIO” button repeatedly until the
“DISC” tab is selected.
Disc slotDisc eject
Play/pauseAudio control screen display button
Pow e r Vo l u m e
Track, file and chapter
selection/fast forward/rewind Track/file/
chapter
selection Setting the
sound
(  P. 5 6 8
)

5043-3. Using the audio system
LX570_OM_OM60L21U_(U) Inserting a disc
Insert a disc into the disc slot.
Ejecting a disc
Press and remove the disc.
Playing and pausing a track/file/chapter
To play or pause a track/file/chapter, press . ■
Using the display ●
Under extremely cold conditions, the screen may react slowly or operation
sound may become louder. ●
If a disc is inserted with the labe l facing down, it cannot be played.

5063-3. Using the audio system
LX570_OM_OM60L21U_(U) Selecting, fast forwarding or rewinding a track (Audio CD)
■ Selecting a track
Press “  ” or “  ” on the “PRST•TRACK” button or turn the
“TUNE•SCROLL” knob to select the desired track number.
■ Selecting a track from the track list
Touch the track name on the screen to display the CD’s track list.
Touch the desired track number.
, : Touch to move the list up or
down by 5 track groups.
“PRST•TRACK” button: Press “  ”
or “  ” on the “PRST•TRACK” but-
ton to scroll through the track list
one by one.
“TUNE•SCROLL” knob: Turn the
knob clockwise or counterclock-
wise to quickly scroll up or down
the track list.
, : If appears to the right of
an item name, the com-
plete name is too long for
the screen. Touch to
scroll to the end of the
name. Touch to move to
the beginning of the name.
■ Fast forwarding or rewinding a track
To fast forward or rewind, press and hold “  ” or “  ” on the
“PRST•TRACK” button. STEP 1
STEP 2

5073-3. Using the audio system
3
Interior features
LX570_OM_OM60L21U_(U) Selecting a folder (MP3/WMA discs)
■ Selecting a folder
To u c h “ >
” or “ <
” on the screen to select the next/previous folder.
■ Selecting a folder from the folder list
Touch the folder name on the sc reen to display the following
folder list screen.
Touch the desired folder number
to display the folder’s file list. From
the file list, select the desired file
number.
, : Touch to move the list up or
down by 5 folder groups.
“TUNE•SCROLL” knob: Turn the
knob clockwise or counterclock-
wise to quickly scroll up or down
the folder list.
, : If appears to the right of
an item name, the com-
plete name is too long for
the screen. Touch to
scroll to the end of the
name. Touch to move to
the beginning of the name.STEP 1
STEP 2

5083-3. Using the audio system
LX570_OM_OM60L21U_(U) Selecting, fast forwarding or rewinding a file (MP3/WMA discs)
■ Selecting a file
Press “  ” or “  ” on the “PRST•TRACK” button or turn the
“TUNE•SCROLL” knob to select the desired file number.
■ Selecting a file from the file list
Touch the file name on the screen to display the following file list
screen.
Touch the desired file number.
, : Touch to move the list up or
down by 5 file groups.
“PRST•TRACK” button: Press “  ”
or “  ” on the “PRST•TRACK” but-
ton to scroll through the file list one
by one.
“TUNE•SCROLL” knob: Turn the
knob clockwise or counterclock-
wise to quickly scroll up or down
the file list.
, : If appears to the right of
an item name, the com-
plete name is too long for
the screen. Touch to
scroll to the end of the
name. Touch to move to
the beginning of the name.
■ Fast forwarding or rewinding a file
To fast forward or rewind, press and hold “  ” or “  ” on the
“PRST•TRACK” button. STEP 1
STEP 2

5103-3. Using the audio system
LX570_OM_OM60L21U_(U) Repeat play
Audio CD
Touch “RPT” on the screen. “RPT” appears on the screen.
To cancel, touch “RPT” again.
MP3/WMA disc
■ Repeating a file
Touch “RPT” on the screen.
Each time is “RPT” touched, th e mode changes as follows:
• When “RAND” is off
file repeat  folder repeat  off
• When “RAND” is on
file repeat  repeat off
■ Repeating all of the files in a folder
Touch “RPT” repeatedly until “F LD.RPT” appears on the screen.To cancel, touch “RPT” again.■
If you touch
The display returns to the previous screen. ■
Displaying the title and artist name (Audio CD)
If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. Up to
32 characters can be displayed. ■
Error messages
 P. 5 2 5

5123-3. Using the audio system
LX570_OM_OM60L21U_(U) ■ Control icon screen
Menu screen appears
Option screen appears
(  P. 513)
Display menu control key
(  P. 5 1 4 )
Vehicle is completely
stopped and the parking
brake is applied, the video
screen returns
Rewind
Stop
Pa u s e
Touch to play
Fast forward
Setting the sound (  P. 5 6 8 )If is touched, while watching a DVD, the DVD controls will appear.
If appears on the screen when a control is touched the operation
relevant to the control is not permitted.

5133-3. Using the audio system
3
Interior features
LX570_OM_OM60L21U_(U) ■ DVD options screen
Touch “Options” on “DVD” screen, the following screen appears.
Returns to the full screen
(only when the vehicle is
completely stopped and the
parking brake is applied)
Search by title number
Change audio language
Change angle
Display the predetermined
scene and start playing from
there
Change subtitle language
Change screen size
Display the image quality
adjustment screen
Change initial setting
If appears on the screen when a control is touched the operation
relevant to the control is not permitted.

5173-3. Using the audio system
3
Interior features
LX570_OM_OM60L21U_(U) Changing the angle (if the angle option is available)
Touch “Angle” on the “DVD Options” screen.
Each time you touc h “Change”, the
next available angle is selected. The angles available are restricted
to those available on the DVD disc.
: Returns to the previous
screen
Changing screen size
Touch “Wide” on the “DVD Options” screen.
Touch the desired display. After
setting, touch “Save”.
Displays a 3 : 4 screen, with
either side in black
Widens the 3 : 4 screen hori-
zontally to fill the screen
Widens the 3 : 4 screen verti-
cally and horizontally, in the
same ratio, to fill the screen : Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

5183-3. Using the audio system
LX570_OM_OM60L21U_(U) Adjusting the screen
Touch “Display” on the “DVD Options” screen.
Touch “<” or “>” to display the
desired item to be adjusted, and
then touch “OK”. The screen goes off when “Screen
Off” is touched. To turn the screen
back on, press any button. The
selected screen appears.STEP 1
STEP 2
R G
Color Red Green
- +
To n e Lighter Darker
Contrast We a k e r Stronger
Brightness Darker Brighter
