display LEXUS LX570 2014 Owners Manual

4353-1. Using the touch screen
3
Interior features
LX570_OM_OM60L21U_(U) ■ Playing a music
* 1
: Say the desired artist name or album name in the place of the “<>”.
* 2
: To use this function, say “Main menu” and then “Play music” while the
“Shortcut Menu” screen is being displayed. Command
Action Shortcut
Menu
“Play Artist ” Plays tracks by the selected artist.
For example: Say “Play artist
”
* 1
O
“Play Album ” Plays tracks from the selected album.
For example: Say “Play album
”
* 1
O
“Play Song ”
* 2
Plays the selected track.
For example: Say “Play song Summer-
time”, “Play song Concerto in A
Major” etc. —
“Play Playlist
”
* 2
Plays tracks from the selected playlist.
For example: Say “Play playlist My
Favorite Songs”, “Play Playlist Classic
Hits” etc. —

4373-1. Using the touch screen
3
Interior features
LX570_OM_OM60L21U_(U) ■ Air conditioning system command
When expanded voice commands are turned “On”. (  P. 433)Command
Action Shortcut
Menu
“Automatic climate
control” Turns air conditioni ng system on and
off. O
“Warmer” Turns temperature up. O
“Cooler ” Turns temperature down. O■
Voice command system ●
Commands that are not displayed in the “Shortcut Menu” screen can be oper-
ated from the “Main Menu” screen. ●
If the system does not respond or the confirmation screen does not disappear,
press
or
and try again.●
Voice guidance can be canceled by setting voice prompts to off. Use this setting
when it is desirable to say a co mmand immediately after pressing
or
and hearing a beep.■
If a voice command cannot be recognized ●
If a voice command cannot be recognized within 6 seconds, voice guidance will
say “Pardon?” (“Command not recognized.” will be displayed on the screen)
and voice command reception will restart. ●
If a voice command cannot be recognized 2 consecutive times, the voice com-
mand guidance system will say “Paused. To restart voice recognition, push the
talk switch. To cancel voice recognition, push and hold the talk switch.”. Then
voice recognition will be suspended.■
When touching “Voice Prompts” ●
The voice recognition prompt can be set to on or off. This setting can also be
changed on the “Voice Settings” screen. (  P. 4 2 3 )●
Voice recognition will be temporarily suspended. Press
or
again.

4383-1. Using the touch screen
LX570_OM_OM60L21U_(U) ■
When using the microphone ●
It is unnecessary to speak directly into the microphone when giving a command. ●
Wait for the confirmation beep before speaking a command. ●
Voice commands may not be recognized if:
• Spoken too quickly.
• Spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while voice commands are spoken.
• The air conditioning speed is set high.
• The air conditioning vents are turned towards the microphone. ●
In the following conditions, the system may not recognize the command prop-
erly and using voice commands may not be possible:
• The command is incorrect or unclear. Note that certain words, accents or
speech patterns may be difficul t for the system to recognize.
• There is excessive background noise, such as wind noise.■
When searching for a track ●
A USB memory or iPod must be connected to enable track searching and play-
back. (  P. 5 4 8 , 5 5 8 )●
When a USB memory or iPod is connec ted, recognition data is created so
tracks can be searched using voice commands. ●
Recognition data is updated under the following conditions:
• When the USB memory or iPod data has changed.
• When the voice recognition language is changed. (  P. 4 1 5 )●
While the recognition data is being cr eated or being updated, a track search
cannot be performed using a voice command. ●
While “Play Music” is displayed in the “Shortcut Menu” screen, say “Play music”
to display the music screen from which searching for a track using a voice com-
mand can be performed. ●
When “Play Music” is dimmed in the “Shortcut Menu” screen, it is not possible
to search for a track using a voice command. In this situation, reduce the
amount of music data in the USB memory or iPod and update the recognition
data to enable searching by voice command.

4393-1. Using the touch screen
3
Interior features
LX570_OM_OM60L21U_(U) ■
Natural speech information ●
The “Use the Phone” and “Play Music” commands displayed on the “Shortcut
Menu” screen can be operated using natural language speech recognition
technology. ●
If the command cannot be recognized completely, the command input screen
will be displayed. (Search results will be shown based on the part of the com-
mand that was recognized.)■
When turning the audio or air conditioning system on ●
Commands relating to operation of the audio/video and air conditioning sys-
tems can only be performed when the au dio/video and air conditioning systems
are turned on. ●
Expanded voice commands can be recognized when the “Shortcut Menu”
screen is displayed.■
The Gracenote ®
media database
Music recognition technology and related data are provided by Gracenote ®
.
Gracenote is the industry standard in music recognition technology and related
content delivery. For more information visit www.gracenote.com .

440
LX570_OM_OM60L21U_(U) 3-2. Using the air conditio ning system and defogger
Front air conditioning system Airflow and outlets are automatically adjusted according to the tempera-
ture setting.
Press the “CLIMATE” button to display the air conditioning operation
screen.
* : The front air conditioning system cannot be switched off while the cool
box is on. (  P. 6 9 5 ) Air conditioning
on/off switch
Fan speed display Rear air conditioning operation
screen display switch
Outside temperature display
Airflow display
4-zone operation
switch
Passenger’s side
temperature control
Outside air or
recirculated air mode
Passenger’s side
temperature display
Rear air conditioning
operation modeMicro dust and
pollen filterWindshield
defoggerOff
* Driver’s side
temperature displayAutomatic modeDriver’s side
temperature controlAir conditioning
operation screen
display button

4413-2. Using the air conditio ning system and defogger
3
Interior features
LX570_OM_OM60L21U_(U) Using the voice command system
Press or to operate
the voice command system.
(  P. 429/“Navigation System
Owner’s Manual”)
Without dynamic radar cruise
control
With dynamic radar cruise con-
trol
Using the automatic mode
Press the “AUTO” button.
The air conditioning system will begin to operate. Air outlets
and fan speed are automatically adjusted according to the
temperature setting. “AUTO” will be displayed on the touch screen.
Press to switch to automatic air intake mode.
The air conditioning system au tomatically switches between
outside air and recirculated air modes.
Press to increase the temperature and to decrease
the temperature. The temperature for the driver’s and front passenger’s seats can be set
separately. A
B
STEP 1
STEP 2
STEP 3

4513-2. Using the air conditio ning system and defogger
3
Interior features
LX570_OM_OM60L21U_(U) Outside temperature display
Outside temperature is displayed in the screen.
The displayed temperature ranges from -40  F (-40  C) up to 122  F
(50  C).
■
The outside temperature is displayed when
The “ENGINE START STOP” switch is in IGNITION ON mode. ■
When “— —” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Lexus dealer■
Display
In the following situations, the correct outside temperature may not be displayed, or
the display may take longer than normal to change. ●
When stopped, or driving at low speeds (less than 12 mph [20 km/h]) ●
When the outside temperature has changed suddenly (at the entrance/exit of a
garage, tunnel, etc.)

4523-2. Using the air conditio ning system and defogger
LX570_OM_OM60L21U_(U) Rear air conditioning system Airflow and outlets are automatically adjusted according to the tempera-
ture setting. Left side temperature control
Automatic mode
Fan speed OffLeft side temperature setting display Fan speed display Airflow display
Right side temperature controlRight side temperature setting display
Changes the air outlets used

4533-2. Using the air conditio ning system and defogger
3
Interior features
LX570_OM_OM60L21U_(U) Using the automatic mode
Press the “AUTO” button.
The air conditioning system will begin to operate. Air outlets
and fan speed are automatically adjusted according to the
temperature setting.
Press “  ” on the “TEMP” button to in crease the temperature and
“  ” to decrease the temperature. The temperature for the right-hand an d left-hand rear seats can be set
separately.
Adjusting the settings
■ Adjusting the temperature setting
Press “  ” on the “TEMP” button to increase the temperature and “  ”
to decrease the temperature. The temperature for the right-hand and left-hand rear seats can be set sep-
arately.
■ Adjusting the fan speed
Press “  ” (increase) or “  ”  (decrease) on .The fan speed is shown on the display. (7 levels)
Press to turn the fan off.
■ Changing the air outlets
Press the “MODE” button. The air outlets switch each time the button is pressed. STEP 1
STEP 2

458
LX570_OM_OM60L21U_(U) 3-3. Using the audio system
Audio system type CD and DVD player with AM/FM radio
Press “AUDIO” and touch each tab to display the audio control screen.
