display LEXUS LX570 2014 Owners Manual

6753-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) ■
Editing the “Device Name”
If you change a device name, the name registered in your cellular phone is not
changed. ■
About “Device Address”
The address peculiar to the system. It cannot be changed. If you have registered two
Bluetooth ®
phones with the same device name and you cannot distinguish one
from the other, refer to this address. ■
“My Phone Number”:
The phone number of the Bluetooth ®
phone is displayed on the screen. Depending
on the type of phone, the phone number may not be displayed. ■
“Profiles”:
The compatibility profile of the Bluetooth ®
device is displayed on the screen.■
“Connect Portable Player from”:
There are 2 portable player connection settings available; “Vehicle” and “Portable
Player”. ■
When you delete a Bluetooth ®
phone
The phonebook data will be deleted at the same time.

6763-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) Selecting a Bluetooth ®
phone
If multiple Bluetooth ®
phones are registered, follow the procedure below
to select the Bluetooth ®
phone to be used. You can only use one phone
at a time.
Display the “Bluetooth
* ” screen. ( 
P. 6 6 9 )
Touch “Connect Phone” on the “Bluetooth
* ” screen.
Choose the phone to be con-
nected. The Bluetooth ®
mark is displayed
when you connect the phone.
If a completion message is dis-
played, connection is complete.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
■
When another Bluetooth ®
device is connected during registering or selecting a
phone ●
When another Bluetooth ®
device is connected, a confirmation message will be
displayed. If you want to disconnect it, touch “Yes”. ●
The currently connected Bluetooth ®
phone’s screen button will have a Blue-
tooth ®
mark displayed on it. If the currently connected Bluetooth ®
phone’s
screen button is touched, the Bluetooth ®
phone can be disconnected. Touch
“Yes” to disconnect.■
Connecting the phone while Bluetooth ®
audio is playing
Bluetooth ®
audio will stop temporarily.

6773-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) Selecting a portable player
If multiple portable players are reg istered, follow the procedure below to
select the portable player phone to be used. You can only use one porta-
ble player at a time.
Display the “Bluetooth
* ” screen. ( 
P. 6 6 9 )
Touch “Connect Portable Player” on the “Bluetooth
* ” screen.
Choose the portab le player to be
used. The Bluetooth ®
mark is displayed
when you connect the portable
player.
If a completion message is dis-
played, connection is complete.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc. STEP 1
STEP 2
STEP 3
■
When another Bluetooth ®
device is connected during registering or selecting a
portable player ●
When another Bluetooth ®
device is connected, a confirmation message will be
displayed. If you want to disconnect it, touch “Yes”. ●
The currently connected portable player’s screen button will have a Bluetooth ®
mark displayed on it. If the currently co nnected portable player’s screen button
is touched, the portable player can be disconnected. Touch “Yes” to disconnect.

6783-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) Detailed Bluetooth ®
settings
You can confirm and change the Bluetooth ®
settings.
Pa g e 1
Changing the device connec-
tion status
Changing the name of the con-
nected device.
Changing the passcode that
you registered your Bluetooth ®
device in the system
The address peculiar to the sys-
tem You cannot change this address. If
the same device name is displayed
on the screen of your device, refer
to it.
Pa g e 2
The compatibility profile of the
Bluetooth ®
device
To display the screen above, follow the steps below.
Press the “SETUP” button, and touch “Bluetooth
* ” on the “Setup”
screen.
Touch “Detailed Bluetooth* Settings” on the “Bluetooth
* ” screen.
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.STEP 1
STEP 2

6793-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L21U_(U) ■ Changing Bluetooth
* power
The Bluetooth
* device is automatically co nnected when you turn the
“ENGINE START STOP” switch to ACCESSORY or IGNITION ON
mode. You can change between “On” or “Off”.
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 6 7 8 )
Touch “Bluetooth
* Power” on the “Detailed Bluetooth
* Settings”
screen.
Touch “On” or “Off”, and then
touch “Save”.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.
■ Editing the device name
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 6 7 8 )
Touch “Device Name” on the “Detailed Bluetooth
* Settings”
screen.
Input the device name, and touch “OK”.
Touch “Save” on the “Detailed Bluetooth
* Settings” screen.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
STEP 1
STEP 2
STEP 3
STEP 4

6803-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L21U_(U) ■ Editing the passcode
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 6 7 8 )
Touch “Passcode” on the “Detailed Bluetooth
* Settings” screen.
Input a passcode, and touch “OK”.
Touch “Save” on the “Detailed Bluetooth
* Settings” screen.
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.
■ Bluetooth ®
device connection status display settings
When “Bluetooth
* Power” is “On” and the “ENGINE START STOP”
switch is in ACCESSORY or IGNITION ON mode, the Bluetooth ®
phone and portable player’s conne ction status can be displayed.
( 
P. 6 7 9 )
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 6 7 8 )
Touch “Display Phone Status” or “Display Portable Player Status”
on the “Detailed Bluetooth
* Settings” screen.
Touch “On”, and then touch
“Save”.
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
STEP 4
STEP 1
STEP 2
STEP 3

7374-2. Maintenance
4
Maintenance and care
LX570_OM_OM60L21U_(U) ■
Repair and replacement
It is recommended that genuine Lexus parts be used for repair to ensure perfor-
mance of each system. If non-Lexus parts are used in replacement or if a repair
shop other than a Lexus dealer performs repairs, confirm the warranty coverage. ■
Reset the maintenance data
After the required maintenance is performed according to the maintenance sched-
ule, please reset the maintenance data.
To reset the data, follow th e procedures described below:
Switch the display to the trip me ter A when the engine is running.
(  P. 1 9 0 )
Turn the “ENGINE START STOP” switch OFF.
While pressing the trip meter reset button, set the “ENGINE START
STOP” switch to IGNITION ON mo de (but do not start the engine
because otherwise the reset mode will be canceled). Continue to press
and hold the button until the multi-in formation display indicates that the
reset is complete.■
Allow inspection and repairs to be performed by a Lexus dealer●
Lexus technicians are well-trained specialists and are kept up to date with the
latest service information. They are well informed about the operations of all
systems on your vehicle. ●
Keep a copy of the repair order. It proves that the maintenance that has been
performed is under warranty coverage. If any problem should arise while your
vehicle is under warranty, your Lexus de aler will promptly take care of it.STEP 1
STEP 2
STEP 3

7614-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L21U_(U) Washer fluid
If any washer does not work or the
warning message appears on the
multi-information display, the
washer tank may be empty. Add
washer fluid.
CAUTION■
When refilling the washer fluid
Do not refill the washer fluid when the engine is hot or running, as the washer fluid
contains alcohol and may catch fire if spilled on the engine etc.
NOTICE■
Do not use any fluid other than washer fluid
Do not use soapy water or engine antifreeze instead of washer fluid.
Doing so may cause streaking on the vehicle’s painted surfaces. ■
Diluting washer fluid
Dilute washer fluid with water as necessary.
Refer to the freezing temperatures listed on the label of the washer fluid bottle.

7644-3. Do-it-yourself maintenance
LX570_OM_OM60L21U_(U) ■ How to initialize the tire pressure warning system
Park the vehicle in safe plac e and turn the “ENGINE START
STOP” switch to OFF. While the vehicle is moving, initialization is not performed.
Adjust the tire inflation pressure to the specified co ld tire inflation
pressure level. (  P. 8 8 9 )Make sure to adjust the tire pressure to the specified cold tire inflation
pressure level. The tire pressure warning system will operate based on
this pressure level.
Turn the “ENGINE START STOP” switch to IGNITION ON
mode.
Push and hold the tire pressure
warning reset switch until the tire
pressure warning light blinks
slowly 3 times and a message
appears on the multi-information
display.
Wait for a few minutes with the IGNITION ON mode, and then
turn the “ENGINE START STOP” switch to OFF.
Registering ID codes
The tire pressure warning valve and transmitter is equipped with a unique
ID code. When replacing a tire pressu re warning valve and transmitter, it
is necessary to register the ID code of tire pressure warning valve and
transmitter. Have the ID code re gistered by your Lexus dealer.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

7674-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L21U_(U) ■
Initializing the tire pressure warning system
Initialize the tire pressure warning system with the tire inflation pressure adjusted to
the specified level. ■
If you push the tire pressure warning reset switch accidentally
If initialization is performed, adjust the ti re inflation pressure to the specified level
and initialize the tire pressure warning system again. ■
When the initialization of the tire pressure warning system has failed
Initialization can be completed in a few minutes. However, in the following cases,
the settings have not been recorded and the system will not operate properly. If
repeated attempts to record tire inflation pressure settings are unsuccessful, have
the vehicle inspected by your Lexus dealer. ●
When operating the tire pressure warnin g reset switch, the tire pressure warn-
ing light does not blink 3 times and the setting message does not appear on the
multi-information display. ●
After carrying out the initia lization procedure, the tire pressure warning light
blinks for 1 minute then stays on after driving for about 20 minutes.■
Routine tire inflation pressure checks
The tire pressure warning system does not replace routine tire inflation pressure
checks. Make sure to check tire inflation pressure as part of your routine of daily
vehicle checks.
