LEXUS NX300h 2021 Owners Manual
Manufacturer: LEXUS, Model Year: 2021, Model line: NX300h, Model: LEXUS NX300h 2021Pages: 484, PDF Size: 10.53 MB
Page 301 of 484

3015-3. Using the interior lights
LEXUS NX300h Owners Manual_USA_M78578_en
5
Interior features
5-3.Using the interior lights
Outer foot lights
Personal lights (P.303)
Front interi or light (P.303)
Rear interior light ( P.303)
Footwell lights
• When the power switch is in ON mode, the footwell lights will turn on. However, if the instrume nt panel light control switch is turned to minimum, the footwell
lights will turn off. ( P.88)
• When the shift lever is in a position other th an P, the brightness of the footwell light will
reduce intensity.
■Personal lights automatic on/off
●Illuminated entry system: The lights auto-
matically turn on/off according to power
switch mode, the presence of the elec-
tronic key, whether the doors are locked/
unlocked, and whether the doors are
opened/closed.
●If the interior lights remain on when the power switch is turned off, the lights will
go off automatically after 20 minutes.
■When front interior lights and personal
lights do not respond as normal
●When water, dirt, etc., have adhered to
the lens surface
●When operated with a wet hand
●When wearing gloves, etc.
Interior lights list
Location of the interior lights
A
B
C
D
E
Page 302 of 484

3025-3. Using the interior lights
LEXUS NX300h Owners Manual_USA_M78578_en
■Customization
Setting (e.g. the time elapsed before lights
turn off) can be changed. (Customizable
features: P.443)
■Front interior light
Turns the light on/off (touch the light)
The rear interior light also turns on/off.
However, when the rear interior light has
already been turned on , it will not be con-
trolled by front interior light operations.
Turns the door position on/off 1
On
The front and rear interior lights turn on/
off when a door is opened/closed.
2Off
■Rear interior light
Turns the light on/off
The rear interior light is also turned on/off
by the front interior light operations.
If the light is turned on by front interior light
operation, the rear interior light cannot
turn off by pressing the switch.
Turns the lights on/off (touch the lights)
NOTICE
■Removing light lenses
Never remove the lens for the front inte-
rior light and personal lights. Otherwise,
the lights will be damaged. If the lens
need to remove, contact your Lexus
dealer.
■To prevent 12-volt battery discharge
Do not leave the lights on longer than
necessary when the hy brid system is off.
Operating interior lights
Operating personal lights
Page 303 of 484

3035-3. Using the interior lights
LEXUS NX300h Owners Manual_USA_M78578_en
5
Interior features
Page 304 of 484

3045-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
5-4.Using the storage features
Glove box (P.306)
Bottle holders ( P.306)
Console box ( P.306)
Cup holders ( P.306)
Auxiliary box ( P.307)
List of storage features
Location of the storage features
A
B
C
D
E
WARNING
■Items that should not be left in the
vehicle
Do not leave glasses, lighters or spray
cans in the storage spaces, as this may
cause the following when cabin tempera-
ture becomes high:
●Glasses may be deformed by heat or
cracked if they come into contact with
other stored items.
●Lighters or spray ca ns may explode. If
they come into contact with other
stored items, the lighter may catch fire
or the spray can may release gas,
causing a fire hazard.
■When storage compartments are not
in use
When driving or when the glove box and
the console box are not in use, keep it
closed.
In the event of sudden braking or sudden
swerving, an accident may occur due to
an occupant being struck by an open lid
or the items stored inside.
Page 305 of 484

3055-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
5
Interior features
1Open (press the button)
2 Unlock with the mechanical key
3 Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail
lights are on.
1 Lift the lid while pushing the button
to release the lock. 2
Vehicles with wireless charger: Lift
the wireless charger.
■Console box tray (vehicles without wire-
less charger)
The tray slides forward/backward and can
be removed.
■Console box light
The console box light turns on when the tail
lights are on.
■Cup holders
Front
Rear Pull down the armrest and push the
release button.
Glove box
Console box
Cup holders/bottle holders
Page 306 of 484

3065-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
■Bottle holders
Front
Rear
■Cup holders/bottle holders
●When storing a bottle, close the cap.
●The bottle may not be stored depending
on its size or shape.
Remove the lid using the strap .
■Auxiliary box lid
●The removed auxiliary box lid can be
stored on the tray in the console box.
WARNING
■Items unsuitable for the cup hold-
ers/bottle holders
Do not place anything other than cups or
aluminum cans in the cup holders. Other
items may be thrown out of the holders in
the event of an accident or sudden brak-
ing, causing injury. If possible, cover hot
drinks to prevent burns.
NOTICE
■To prevent damage to the rear cup
holder
Stow the cup holder before stowing the
armrest.
■Bottle holders
Do not place open bottles or glass and
paper cups containing liquid in the bottle
holders. The contents may spill and
glasses may break.
Auxiliary box
A
Page 307 of 484

3075-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
5
Interior features
●The back side of the auxiliary box lid can
be used as a vanity mirror.
Raise the hook to use.
The cargo hooks are provided for securing
loose items.
Raise the hook to use.
The cargo net can be hanged, using the
hook.
Luggage compartment fea-
tures
Cargo hooks
WARNING
■When cargo hooks are not in use
To avoid injury, always return the hooks
to their stowed positions when not in use.
Cargo net hooks
Page 308 of 484

3085-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
Lift the deck board and attach the
hook. (P.309) The following item
can be stowed. First-aid kit and other items
Accessories
Warning reflector
*
*: The warning reflec
tor itself is not
included as an original equipment.
1 Open the back door.
2 Pull the lever upwards and open the
deck board.
WARNING
■When cargo net hooks are not in use
To avoid injury, always return the hooks
to their stowed positions when not in use.
Grocery bag hooks
NOTICE
■To prevent damage to the grocery
bag hooks
Do not hang any object heavier than 11 lb.
(5 kg) on the grocery bag hooks.
Deck under tray
Deck board
A
B
C
Page 309 of 484

3095-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
5
Interior features
3Lift the deck board and remove the
hook on the backside of the deck
board.
4 Use the hook to secure the deck
board as shown in the illustration.
■When attaching the side deck board
When attaching the side deck board, attach
it so that the “ FRONT” mark points to
the front side of the vehicle.
1 Unhook the cords.
2 Fold up the luggage cover.
WARNING
■If the deck boards are opened or
removed
Return them to their original positions
before driving. In the event of sudden
braking, an accident may occur due to an
occupant being struck by the deck
boards or the items stored in the deck
under tray.
Stowing the luggage cover
Page 310 of 484

3105-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
3Pull the lever upwards and open the
deck board.
4 Remove the luggage cover.
When the seatback for the rear seat is col-
lapsed to the rear, remove the cover after
the cover most upright position. ( P.133)
5 Stow the luggage cover in the deck
under tray while lifting the deck
board.
WARNING
■Luggage cover
●Do not place anything on the luggage
cover. In the event of sudden braking
or turning, the item may go flying and
strike an occupant. This could lead to
an unexpected accident, resulting in
death or serious injury.
●Do not allow children to climb on the
luggage cover. Climbing on the lug-
gage cover could result in damage to
the luggage cover, possibly causing
death or serious injury to the child.
