Page 261 of 777

260 4-3. Operating the lights and wipers
RX350/RX350L_U (U.S.A.) or (Canada)
Turns the fog lights off
Turns the fog lights on
■
Fog lights can be used when
The headlights are on in low beam.Fog light switch The fog lights secure excellent visibility in difficult driving conditions, such as
in rain and fog.
Operating instructions 1
2
Page 262 of 777

2614-3. Operating the lights and wipers
4
Driving
RX350/RX350L_U Operating the lever operates th e wipers or washer as follows.
Intermittent windshield wipe rs with interval adjuster
Wiper intervals can be adjusted when intermittent operation is selected.
The interval of intermittent operat ion varies according to vehicle speed.
(U.S.A.) or (Canada)
Off
(U.S.A.) or (Canada)
Intermittent operationThe intermittent wind shield wiper oper-
ates more frequently as vehicle speed
becomes higher.
(U.S.A.) or (Canada)
Low speed operation
(U.S.A.) or (Canada)
High speed operation
(U.S.A.) or (Canada)
Temporary operation
Increases the intermittent windshield
wiper frequency
Decreases the intermittent wind-
shield wiper frequencyWindshield wipers and washer Operating the wiper lever 1
2
3
4
5
6
7
Page 263 of 777

262 4-3. Operating the lights and wipers
RX350/RX350L_U Washer/wiper dual opera-
tionPulling the lever op erates the wipers
and washer.
The wipers will automatically operate a
couple of times afte r the washer squirts.
Vehicles with headlight cleaners:
When the engine switch is in IGNI-
TION ON mode and the headlights are
on, if the lever is pulled, the headlight
cleaners will operate once. After this,
the headlight cleaners will operate
every 5th time the lever is pulled.
Rain-sensing windshield wipers
When “AUTO” is selected, the wipers will operate automatically when the sensor
detects falling rain. The system automatically adjusts wiper timing in accordance
with rain volume and vehicle speed.
The sensor sensitivity can be adju sted when “AUTO” is selected.
(U.S.A.) or (Canada)
Off
Rain-sensing operation
(U.S.A.) or (Canada)
Low speed operation
(U.S.A.) or (Canada)
High speed operation
(U.S.A.) or (Canada)
Temporary operation
Increases the sensitivity
Decreases the sensitivity 8
1
2
3
4
5
6
7
Page 264 of 777

2634-3. Operating the lights and wipers
4
Driving
RX350/RX350L_U Washer/wiper dual opera-
tionPulling the lever op erates the wipers
and washer.
The wipers will automatically operate a
couple of times afte r the washer squirts.
Vehicles with headlight cleaners:
When the engine switch is in IGNI-
TION ON mode and the headlights are
on, if the lever is pulled, the headlight
cleaners will operate once. After this,
the headlight cleaners will operate
every 5th time the lever is pulled. ■
The windshield wipers and washer can be operated when
The engine switch is in IGNITION ON mode. ■
Dripping prevention wiper sweep (vehicle s with rain-sensing windshield wipers)
After washing and wiping operation several times, the wipers operate one more time
after a short delay to prevent dripping. However, this function will not operate while driv-
ing. ■
Effects of vehicle speed on wiper operation
Vehicle speed affects the Intermittent wiper interval. ■
Raindrop sensor (vehicles with rain-sensing windshield wipers)
●
If the wiper switch is turned to the “AUTO” position while the engine switch is in IGNI-
TION ON mode, the wipers will operate once to show that AUTO mode is activated.●
When the sensor sensitivity ring is turned toward high while in “AUTO” position, the
wipers will operate once to indicate that the sensor sensitivity is enhanced. ●
If the temperature of the raindrop sensor is 194 F (90 C) or higher, or 5 F (-15 C) or
lower, automatic operation may not occur. In this case, operate the wipers in any mode
other than AUTO mode. ■
If no windshield washer fluid sprays
Check that the washer nozzles are not blocked, if there is washer fluid in the washer fluid
tank. 8
●
The raindrop sensor judges the amount of
raindrops.
An optical sensor is ad opted. It may not oper-
ate properly when sunlight from the rising or
setting of the sun inte rmittently strikes the
windshield, or if bugs, etc. are present on the
windshield.
Page 265 of 777

264 4-3. Operating the lights and wipers
RX350/RX350L_U ■
Front door opening linked windshield wiper stop function (vehicles with rain-sensing
windshield wipers)
When “AUTO” is selected and the windshield wipers are operating, if a front door is
opened, the operation of the windshield wipers will be stopped to prevent anyone near
the vehicle from being sprayed by water from the wipers, provided the vehicle is stopped
with the parking brake applied or the shift lever in P. When the front door is closed, wiper
operation will resume. ■
Customization
Some functions can be customized. ( P. 722)
WARNING ■
Caution regarding the use of windshield wi pers in AUTO mode (vehicles with rain-
sensing windshield wipers)
The windshield wipers may operate unexpectedly if the sensor is touched or the wind-
shield is subject to vibration in AUTO mode. Take care that your fingers, etc. do not
become caught in the windshield wipers. ■
Caution regarding the use of washer fluid
When it is cold, do not use the washer fl uid until the windshield becomes warm. The
fluid may freeze on the windshield and cause lo w visibility. This may lead to an accident,
resulting in death or serious injury.
NOTICE ■
When the windshield is dry
Do not use the wipers, as they may damage the windshield. ■
When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may overheat. ■
When a nozzle becomes blocked
In this case, contact your Lexus dealer.
Do not try to clear it with a pin or other object. The nozz le will be damaged.
Page 266 of 777

2654-3. Operating the lights and wipers
4
Driving
RX350/RX350L_U When the windshield wipers are not bein g used, they retract to below the hood.
To enable the windshield wi pers to be lifted when park ing in cold conditions or
when replacing a windshield wiper insert, change the rest position of the wind-
shield wipers to the service position using the wiper lever.■
Raising the wipers to the service position
Within approximately 40 seconds of
turning the engine switch off, move
the wiper lever to the
(U.S.A.) or (Canada) posi-
tion and hold it for approximately 2
seconds or more. The wipers will move to the service
position.
■
Lifting the windshield wipers
While holding the hook portion of
the wiper arm, lift the windshield
wiper from the windshield.Changing the windshield wiper rest position/Lifting the windshield wip-
ers
Hook portion
Page 267 of 777

266 4-3. Operating the lights and wipers
RX350/RX350L_U ■
Lowering the windshield wipers to the retracted position
With the windshield wipers placed on the windshield, turn the engine switch to IGNI-
TION ON mode and then move the wiper le ver to an operating position. When the
wiper switch is turned off, the windshield wipers will stop at the retracted position.
NOTICE ■
When lifting the windshield wipers ●
Do not lift the windshield wipers when they are in the retracted position below the
hood. Otherwise, they may contact the hood, possibly resulting in damage to a wind-
shield wiper and/or the hood.
●
Do not operate the wiper lever when the windshield wipers are lifted. Otherwise, the
windshield wipers may contact the hood, po ssibly resulting in damage to the wind-
shield wipers and/or hood. ●
Do not lift a windshield wiper by the wiper
blade. Otherwise, the wiper blade may be
deformed.
Page 268 of 777

2674-3. Operating the lights and wipers
4
Driving
RX350/RX350L_U Operating the switch operates the rear wiper as follows:
(U.S.A.) or (Canada)
Off
(U.S.A.) or (Canada)
Intermittent operation
(U.S.A.) or (Canada)
Normal operation
Washer/wiper dual opera-
tionPushing the lever operates the wiper
and washer.
The wiper will automatically operate a
couple of times afte r the washer squirts.Rear window wiper and washer Operating the wiper lever 1
2
3
4
Page 269 of 777

268 4-3. Operating the lights and wipers
RX350/RX350L_U ■
The rear window wiper and washer can be operated when
The engine switch is in IGNITION ON mode. ■
If no washer fluid sprays
Check that the washer nozzle is not blocked if there is washer fluid in the washer fluid
tank.
NOTICE ■
When the rear window is dry
Do not use the wiper, as it may damage the rear window. ■
When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may overheat. ■
When a nozzle becomes blocked
In this case, contact your Lexus dealer.
Do not try to clear it with a pin or other object. The nozz le will be damaged.
Page 270 of 777

269
4
Driving
RX350/RX350L_U 4-4. Refueling
●
Close all the doors and windows, and turn the engine switch off.●
Confirm the type of fuel. ■
Fuel types
P. 706 ■
Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehi cle has a fuel tank opening that only accom-
modates the specia l nozzle on unleaded fuel pumps.
Opening the fuel tank cap Perform the following steps to open the fuel tank cap:
Before refueling the vehicle
