640 7-3. Do-it-yourself maintenance
RX350/RX350L_U ■
Back-up lights
Open the back door and remove
the cover. Using a flathead screwdriver, remove
the cover.
To prevent scratching to the vehicle,
wrap the tip of the flathead screw-
driver with a cloth, etc.
Turn the bulb base counterclock-
wise and remove it.
Remove the light bulb.
Install a new light bulb and then
install the bulb base to the light
unit by inserting it and turning it
clockwise. After installing th e bulb base, wiggle
it lightly to make sure it is securely
installed and turn on the back-up
lights to visually check that there is no
light leaking from between the bulb
base and light unit. 1
2
3
4

6417-3. Do-it-yourself maintenance
7
Maintenance and care
RX350/RX350L_U Install the cover. Align the tabs of the cover with the
grooves and install the cover.
■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your Lexus
dealer. ●
Headlight low beams ●
Headlight high beams ●
Front turn signal lights (vehic les with triple-beam headlights)●
Parking lights and daytime running lights ●
Fog lights ●
Cornering lights (if equipped) ●
Front side marker lights (vehicles with triple-beam headlights) ●
Side turn signal lights ●
Stop/tail lights ●
Rear turn signal light (vehicles with triple-beam headlights) ●
Rear side marker lights ●
High mounted stoplight ●
License plate lights ●
Outer foot lights 5

642 7-3. Do-it-yourself maintenance
RX350/RX350L_U ■
LED lights
The headlight low beams, headlight high beams, front turn signal lights (vehicles with tri-
ple-beam headlights), parking lights and da ytime running lights, fog lights, cornering
lights (if equipped), front side marker lights (vehicles with triple-b eam headlights), side
turn signal lights, stop/tail lights, rear turn signal light (vehicles with triple-beam head-
lights), rear side marker lights, high mounted stoplight, license plate lights, and outer foot
lights consist of a number of LEDs. If any of the LEDs has burned out, take your vehicle to
your Lexus dealer to have the light replaced. ■
Condensation build-up on the inside of a lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:●
Large drops of water have built up on the inside of a lens. ●
Water has built up inside a headlight. ■
When replacing light bulbs
 P. 626
WARNING ■
To prevent injury
Before performing any light bulb replacement procedure, be sure to turn the engine
switch off. Failure to do so may result in burns from hot components or a part of your
body may get caught on an operating co mponent, possibly causing serious injury.■
Replacing light bulbs ●
Turn off the lights. Do not attempt to replac e the bulb immediately after turning off the
lights.
The bulbs become very hot and may cause burns. ●
Do not touch the glass portion of the light bu lb with bare hands. When it is unavoid-
able to hold the glass portion, use and hold with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is sc ratched or dropped, it may blow out or crack.●
Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or water entering th e headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.●
Do not attempt to repair or disassemble th e light bulbs, connector s, electric circuits
or component parts.
Doing so may result in death or se rious injury due to electric shock.■
To prevent damage or fire ●
Make sure bulbs are fully seated and locked. ●
Check the wattage of the bulb before installing to prevent heat damage.

643
8When trouble arises
RX350/RX350L_U 8-1. Essential information
Emergency flashers .................. 644
If your vehicle has
to be stopped in
an emergency .......................... 645
8-2. Steps to take in
an emergency
If your vehicle needs
to be towed................................ 646
If you think something is
wrong ........................................... 652
Fuel pump shut off
system .......................................... 653
If a warning light turns on
or a warning buzzer
sounds.......................................... 654
If a warning message is
displayed...................................... 661
If you have a flat tire .................. 666
If the engine will not start ........ 682
If the electronic key does
not operate properly .............684
If the vehicle battery is
discharged ................................. 687
If your vehicle overheats ......... 692
If the vehicle becomes
stuck ............................................. 695

644
RX350/RX350L_U 8-1. Essential information
Press the switch. All the turn signal lights will flash. To turn
them off, press the switch once again.
■
Emergency flashers
If the emergency flashers are used for a long time while the engine is not operating, the
battery may discharge.
Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has
to be stopped on the road due to a breakdown, etc.

6458-1. Essential information
8
When trouble arises
RX350/RX350L_U Steadily step on the brake pedal with both feet and firmly depress it.Do not pump the brake pedal repeatedly as this will increase the effort required to
slow the vehicle.
Shift the shift lever to N. 
If the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the engine. 
If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed as
much as possible.
To stop the engine, press and hold
the engine switch for 2 consecutive
seconds or more, or press it briefly 3
times or more in succession.
Stop the vehicle in a safe place by the road.If your vehicle has to be stopped in an emergencyOnly in an emergency, such as if it becomes impossible to stop the vehicle in
the normal way, stop the vehicl e using the following procedure:1
2
3
4
3
Press and hold for 2 seconds or more,
or press briefly 3 times or more4
WARNING ■
If the engine has to be turned off while driving
Power assist for the brakes and steering wheel will be lost, making the brake pedal
harder to depress and the steering wheel heav ier to turn. Decelerate as much as possi-
ble before turning off the engine. 5

646
RX350/RX350L_U 8-2. Steps to take in an emergency
The following may indicate a problem wi th your transmission. Contact your
Lexus dealer or commercial to wing service before towing.●
The engine is running but the vehicle dose not move. ●
The vehicle makes an abnormal sound.
Do not tow with a sling-type truck to
prevent body damage.If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or commercial towing se rvice, using a wheel-lift type truck or
flatbed truck.
Use a safety chain system for all towing, and abide by all state/provincial and
local laws.
2WD models: If towing your vehicle with a wheel-lift type truck from the front,
the vehicle’s rear wheels and axles must be in good conditions. (  P. 647, 650)
If they are damaged, use a towing dolly or flatbed truck.
AWD models: If towing your vehicle with a wheel-lift type truck, use a towing
dolly. (  P. 647, 650)
Situations when it is necessary to contact dealers before towing
Towing with a sling-type truck

6478-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U Towing with a wheel-lift type truck 
From the front (2WD models) 
From the front (AWD models)
Release the parking brake. Use a towing dolly under the rear
wheels.
From the rear
Use a towing dolly under the front
wheels.

648 8-2. Steps to take in an emergency
RX350/RX350L_U If your vehicle is transported by a flat-
bed truck, it should be tied down at the
locations shown in the illustration.
If you use chains or cables to tie down
your vehicle, the angles shaded in black
must be 45  .
Do not overly tighten the tie downs or
the vehicle may be damaged.
If a tow truck is not available in an em ergency, your vehicle may be temporarily
towed using cables or chains secured to the emergency towing eyelets. This
should only be attempted on hard surf aced roads for at most 50 miles (80 km)
at under 18 mph (30 km/h).
A driver must be in the vehicle to st eer and operate the brakes. The vehicle’s
wheels, drive train, axles, steering an d brakes must be in good condition.Using a flatbed truck Front
Emergency towing (vehicles with towing eyelets)

6498-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U Take out the towing eyelet. (  P. 667)
Remove the eyelet cover.
Insert the towing eyelet into the hole
and tighten partially by hand.
Tighten down the towing eyelet
securely using a wheel nut wrench
or hard metal bar.
Securely attach cables or chains to the towing eyelet.
Take care not to damage the vehicle body.
Enter the vehicle being towed and start the engine.
If the engine does not start, turn th e engine switch to IGNITION ON mode.
Shift the shift lever to N and release the parking brake.
When the shift lever cannot be shifted:  P. 239, 244Emergency towing procedure (vehicles with a towing eyelet) 1
2
3
4
5
6
7
