7018-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL _U_OM48F85UNOTICE ■
When handling jumper cables
When connecting the jumper cables, ensure that they do not become entangled in the
cooling fans or belt. ■
To prevent damaging the vehicle
The exclusive jump starting te rminal is to be used when charging the 12-volt battery
from another vehicle in an emergency. It cannot be used to jump start another vehicle.

702 8-2. Steps to take in an emergency
RX450h_RX450hL _U_OM48F85U■
“Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
shown on the multi-information display
Stop the vehicle in a safe place and tu rn off the air conditioning system, and
then stop the hybrid system.
If you see steam: Carefully lift the hood after the steam subsides.
If you do not see steam: Carefully lift the hood.
After the hybrid system has
cooled down sufficiently, inspect
the hoses and radiator core (radi-
ator) for any leaks.
Radiator
Cooling fans If a large amount of coolant leaks,
immediately contact your Lexus
dealer.
The coolant level is satisfactory if
it is between the “FULL” and
“LOW” lines on the reservoir.
Reservoir
“FULL” line
“LOW” line
Radiator capIf your vehicle overheats The following may indicate that your vehicle is overheating. ●
The needle of the engine coolant temperature gauge ( → P. 96) enters the
red zone, or a loss of hybrid system power is experienced. (For example, the
vehicle speed does not increase.) ●
“Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” or
“Hybrid System Overheated Reduced Output Power” is shown on the
multi-information display. ●
Steam comes out from under the hood.
Correction procedures 1
2
3
1
2
4
1
2
3
4

7038-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL _U_OM48F85UAdd coolant if necessary. Water can be used in an emergency
if coolant is unavailable.
Start the hybrid system and turn the air conditioning system on to check
that the radiator cooling fans operate and to check for coolant leaks from
the radiator or hoses. The fans operate when the air conditioning system is turned on immediately after a
cold start. Confirm that the fans are operating by checking the fan sound and air
flow. If it is difficult to check these, tu rn the air conditioning system on and off
repeatedly. (The fans may not operate in freezing temperatures.)
If the fans are not operating:
Stop the hybrid system immediately and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer.
Check if “Engine Coolant Temp High Stop in a Safe Place See Owner’s
Manual” is shown on the multi-information display.
If the message does not disappear:
Stop the hybrid system and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer. 5
6
7
8

704 8-2. Steps to take in an emergency
RX450h_RX450hL _U_OM48F85U■
If “Hybrid System Overheated Reduced Output Power” is shown on the
multi-information display
Stop the vehicle in a safe place.
Stop the hybrid system an d carefully lift the hood.
After the hybrid system has
cooled down, inspect the hoses
and radiator core (radiator) for
any leaks.
Radiator
Cooling fans If a large amount of coolant leaks,
immediately contact your Lexus
dealer.
The coolant level is satisfactory if
it is between the “FULL” and
“LOW” lines on the reservoir.
Reservoir
“FULL” line
“LOW” line
Add coolant if necessary. Water can be used in an emergency
if coolant is unavailable. 1
2
3
1
2
4
1
2
3
5

7058-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL _U_OM48F85UStart the hybrid system and check if “Hybrid System Overheated Reduced
Output Power” is shown on the multi-information display.
If the message does not disappear:
Stop the hybrid system and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer. WARNING ■
To prevent an accident or injury when inspecting under the hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.●
If steam is seen coming from under the h ood, do not open the hood until the steam
has subsided. The engine compartment may be very hot. ●
After the hybrid system has been turned off, check that the “READY” indicator is off.
When the hybrid system is operating, the gasoline engine may automatically start, or
the cooling fans may suddenly operate even if the gasoline engine stops. Do not
touch or approach rotating parts such as th e fans, which may lead to fingers or cloth-
ing (especially a tie, a scarf or a muffler) getting caught, resulting in serious injury.●
Do not loosen the radiator cap and the coolant reservoir caps wh ile the hybrid system
and radiator are hot.
High temperature steam or coolant could spray out.
NOTICE ■
When adding engine/power control unit coolant
Add coolant slowly after the hybrid system has cooled down sufficiently. Adding cool
coolant to a hot hybrid system too quickly can cause damage to the hybrid system.■
To prevent damage to the cooling system
Observe the following precautions: ●
Avoid contaminating the coolant with foreig n matter (such as sand or dust etc.).●
Do not use any coolant additive. 6

706 8-2. Steps to take in an emergency
RX450h_RX450hL _U_OM48F85UStop the hybrid system. Shift the shif t lever to P and set the parking brake.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other materi al under the front wheels to help pro-
vide traction.
Restart the hybrid system.
Shift the shift lever to D or R and rele ase the parking brake. Then, while exer-
cising caution, depress the accelerator pedal. ■
When it is difficult to free the vehicle
If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes
stuck in mud, dirt or snow:
Press to turn off TRAC. 1
2
3
4
5

7078-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL _U_OM48F85UWARNING ■
When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding
area is clear to avoid striking other vehicl es, objects or people. The vehicle may also
lunge forward or lunge back suddenly as it becomes free. Use extreme caution. ■
When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an acci-
dent resulting in deat h or serious injury.
NOTICE ■
To avoid damage to the hybrid transmission and other components●
Avoid spinning the front wheels and depre ssing the accelerator pedal more than nec-
essary. ●
If the vehicle remains stuck even after th ese procedures are performed, the vehicle
may require towing to be freed.

708 8-2. Steps to take in an emergency
RX450h_RX450hL _U_OM48F85U

709
9Vehicle specifications
RX450h_RX450hL _U_OM48F85U 9-1. Specifications
Maintenance data
(fuel, oil level, etc.) ................... 710
Fuel information.......................... 720
Tire information .......................... 723
9-2. Customization
Customizable features ............ 736
9-3. Initialization
Items to initialize ......................... 749

710
RX450h_RX450hL _U_OM48F85U9-1. Specifications
* 1
:Unladen vehicle
* 2
: Vehicles with towing package
* 3
:RX450h
* 4
:RX450hLMaintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 192.5 in. (4890 mm)
* 3
196.9 in. (5000 mm)
* 4
Overall width 74.6 in. (1895 mm)
Overall height
* 1
67.7 in. (1720 mm)
Wheelbase 109.8 in. (2790 mm)
Tread Front 64.4 in. (1635 mm)
* 3
64.5 in. (1640 mm)
* 4
Rear 64.0 in. (1625 mm)
* 3
64.1 in. (1630 mm)
* 4
Vehicle capacity weight
(Occupants + luggage) 920 lb. (420 kg)
* 3
1070 lb. (490 kg)
* 4
Trailer Weight Rating
* 2
(Trailer weight + cargo we ight) 3500 lb. (1585 kg)
* 3
