126Battery SaverWhen the ignition is turned off, the vehicle will
turn off battery voltage to the courtesy lamps after
10 minutes and the demand lamps after 30
minutes.
This will prevent draining of the battery if those
lights have been left on inadvertently or if a door is
not completely closed. Battery voltage to these
lamps will be restored when the keyless entry
keypad is used, the remote entry transmitter is
used, any door is opened, the trunk is opened, or
the ignition key is turned to the ON position.Perimeter Anti-Theft SystemWhen armed, this system helps to protect your
vehicle against break-ins or theft.
When an unauthorized entry occurs, the system
triggers and will:q
flash the headlamps, parking lamps, and alarm
indicator light
q
honk the horn
q
prevent the engine from starting
NOTE: The factory installed Remote Entry System
has a PANIC feature that also honks the vehicle
horn and flashes the interior/exterior lamps when
the PANIC button on the remote entry transmitter
is pushed.The PANIC alarm and the Anti-Theft
alarm are two separate features.Both the
anti-theft alarm and the PANIC feature can be
active at the same time.
To tell the difference between a PANIC alarm and
a triggered Anti-Theft alarm:
q
only the Anti-Theft alarm will cause the alarm
indicator light (located in the center of the
instrument cluster) to flash on and off.
q
only the Anti-Theft alarm will prevent the
engine from starting.
For more information on the PANIC alarm, see
Remote Entry Systemin the Index.
File:05fncf8.ex
Update:Thu Jun 27 10:02:20 1996

253
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) TestingIn some localities it may become a legal
requirement to pass an Inspection/Maintenance
(I/M) test of the On-Board Diagnostic (OBD) II
system. If the vehicle's powertrain system or its
battery has just been serviced, the OBD II system is
reset to a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional mixed city and highway driving is
required to complete the check of the OBD II
system.
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below:q
At least twenty minutes driving in stop and go,
city type traffic with at least four idle periods.
q
At least ten minutes of driving on an
expressway or highway.Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not be
turned off during these driving modes.
Lights and Bulb ReplacementIt is a good idea to check the operation of the
following lights frequently:q
headlamps
q
high-mount brakelamp
q
tail lamps
q
brakelamps
q
hazard flasher
q
turn signals
q
license plate lamps
File:11fnmc8.ex
Update:Thu Jun 20 14:28:32 1996

254
Thealignmen tof you rheadlamp sshoul dbe
WARNING
Handl ea haloge nheadlam pbulb

255
Headlamp bulb removalRemoving the high beam headlamp bulb1. Make sure that the headlamp switch is in the
OFF position.
2. Lift the hood, remove the sight shield above
the headlamp and find the bulb in the
headlamp socket.3. Remove the high beam dust cap by rotating
counterclockwise 1/4 turn. Pull back to
exposes wiring and connector.
4. Remove the bulb connector by pulling rearward
to free it from the lamp assembly.
5. Remove the electrical connector by pulling off
the bulb base.
Installing the high beam headlamp bulb1. Push the electrical connector into the rear of
the plastic base of the bulb until it snaps,
locking it into position.
2. Insert the glass envelope of the bulb into the
lamp assembly socket while aligning the locking
tabs.
3. Rotate the bulb 1/4 turn to lock.
File:11fnmc8.ex
Update:Thu Jun 20 14:28:32 1996

2564. Replace the high beam dust cap by aligning
tabs and rotating clockwise 1/4 turn.
5. Replace the sight shield.Aiming HeadlampsYour vehicle is equipped with a Vehicle Headlamp
Aim Device (VHAD) on each headlamp body. Each
headlamp may be properly aimed in the horizontal
direction (left/right) and the vertical position
(up/down).
NOTE:A non-zero bubble reading does not
necessarily indicate out-of-aim headlamps. If your
vehicle is not positioned on a level surface, the
slope will be included in the level indicator.
Therefore, vertical headlamp adjustment should be
performed only when beam direction appears to be
incorrect or a level surface can be verified.Tools required: One 6mm socket and ratchet.
The Horizontal aim must be adjusted first.
NOTE:The following procedure assumes that the
vehicle's front structure is in factory alignment
condition. If the vehicle has been in an accident
requiring the front end of the vehicle to be
repaired, the horizontal indicator should be
recalibrated by the servicing facility.
File:11fnmc8.ex
Update:Thu Jun 20 14:28:32 1996

257
Before adjusting your headlamps, you must make
sure that the air suspension has been adjusted to
the proper ride height. In order to do this:
1. Position the vehicle on a level surface.
2. Make sure the air suspension switch in the
luggage compartment is in the ON position.
3. Turn the ignition key to the ON position.
4. Open and close the driver's door to allow the
air suspension to fully level.
File:11fnmc8.ex
Update:Thu Jun 20 14:28:32 1996

296Anti-theft system
arming the system.......... 127
description............. 127
disarming an untriggered system.... 128
disarming a triggered system...... 128
triggering.............. 128
Appeals (see Dispute settlement board) . . 272
Assistance (see Customer assistance) . . . 271
Audio system (see Electronic
sound system)............ 49
Autolamp system (see Headlamps).... 78
Automatic transmission
driving an automatic overdrive..... 177
fluid, adding............. 235
fluid, checking............ 235
fluid, refill capacities......... 264
fluid, specification.......... 265
Axle
lubricant specifications........ 265
refill capacities............ 264
B
Basic vehicle warranty........... 3
Battery................ 236
acid, treating emergencies....... 237
battery saver............. 126
charging system warning light..... 13
disconnecting............ 212
how to service............ 236
jumping a disabled battery....... 209
maintenance-free........... 236
proper disposal, recycling....... 237
replacement, specifications....... 263
servicing.............. 236
when storing your vehicle....... 268
Brake fluid............... 225
brake warning light.......... 10
checking and adding......... 225
description............. 225
specifications............ 265
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996

297
Brakes
adjustment............. 171
anti-lock.............. 171
anti-lock brake system (ABS)
warning light........... 11
applying the brakes.......... 171
brake warning light.......... 10
fluid, checking and adding....... 225
fluid, refill capacities......225, 264
fluid, specifications.......... 265
front disc.............. 171
if brakes do not grip well....... 171
master cylinder........... 225
new brake linings........... 5
noise................ 171
parking brake and auto-release..... 172
servicing.............. 225
trailer............... 187
when storing your vehicle....... 268Break-in period.............. 5
Brights (high beams).......... 14
Bulbs, replacing............ 253
halogen............... 254
headlamps.............. 254
C
Canada, customer assistance....... 276
Canada, warranty information....... 3
Canadian Motor Vehicle Arbitration Plan
(CAMVAP).............. 277
Capacities for refilling fluids....... 264
Carbon monoxide in exhaust....... 169
Car seats for children
(see Child safety seats)........ 151
Catalytic converter........... 250
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996

298Chains, tires.............. 242
Changing a tire............ 201
Charging system warning light...... 13
Child safety restraints.......... 150
child safety belts........... 163
child safety seats........... 151
Child safety seats............ 151
and air bags............. 151
attaching with tether straps...... 162
automatic locking mode (retractor) 143, 151
in front seat............. 151
in rear outboard seat......... 151
in rear seat............. 151
tether anchorage hardware . . . 162, 163
Chime
headlamps on............ 15
key in ignition............ 84
safety belt.............. 44Cleaning your vehicle.......... 260
chrome and aluminum parts...... 260
exterior............... 260
exterior lamps............ 261
fabric................ 262
headlamps.............. 261
instrument panel......... 7,261
interior............... 262
interior lamps............ 262
mirrors............... 100
plastic parts............. 261
polishing.............. 260
rustproofing............. 261
safety belts............. 261
tail lamps.............. 261
upholstery and interior trim...... 262
washing............... 260
waxing............... 260
wheels............... 262
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996

303
G
Gas cap (see Fuel cap)......... 243
Gas mileage (see Fuel economy) . . . 25, 248
Gasoline (see Fuel)........... 243
Gauges
engine coolant temperature gauge . . . 17
fuel gauge.............. 19
odometer.............. 16
speedometer............. 16
tachometer............. 17
GAWR (Gross Axle Weight Rating)
calculating............. 183
definition.............. 182
driving with a heavy load....... 182
location............... 182Gearshift
automatic operation.......... 177
locking the gearshift......... 83
positions.............. 177
shifting the gears........... 177
GVWR (Gross Vehicle Weight Rating) . . . 182
calculating.............. 183
definition.............. 182
driving with a heavy load....... 182
location............... 182
H
Hazard flashers............. 89
Headlamps
aiming............... 256
autolamp system........... 80
checking alignment.......... 253
cleaning............... 261
daytime running lights........ 78
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996
