LINCOLN NAVIGATOR 2004 Owners Manual

When backing down a ramp during boat launching or retrieval:
• do not allow the static water level to rise above the bottom edge of
the rear bumper.
• do not allow waves to break higher than 15 cm (6 inches) above the
bottom edge of the rear bumper.
Exceeding these limits may allow water to enter vehicle components:
• causing internal damage to the components.
• affecting driveability, emissions and reliability.
Replace the rear axle lubricant any time the axle has been submerged in
water. Rear axle lubricant quantities are not to be checked or changed
unless a leak is suspected or repair required.
RECREATIONAL TOWING (ALL WHEELS ON THE GROUND)
An example of recreational towing would be towing your vehicle behind
a motorhome. Follow these guidelines if you have the need for
recreational towing your vehicle with all four wheels on the ground.
These guidelines are designed to ensure that your transmission is not
damaged.
2WD vehicles (with automatic transmissions):
• Place the transmission in N (Neutral)
• Maximum speed is 56 km (35 mph)
• Maximum distance is 80 km (50 miles)
If a distance of 80 km (50 miles) or a speed of 56 km (35 mph) must be
exceeded, the drive shaft will have to be removed before the vehicle is
towed.
Ford recommends the driveshaft be removed/installed only by a qualified
technician. See your local dealer for driveshaft removal/installation.
Improper removal/installation of the driveshaft can cause
transmission fluid loss, damage to the driveshaft and internal
transmission components.
Vehicles equipped with Control Trac four-wheel drive system:
Vehicles equipped with the Control Trac four-wheel drive system cannot
be towed with any wheels on the ground. See your local dealer if you
must flat-tow a vehicle equipped with the Control Trac four-wheel drive
system.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Driving
261

GETTING ROADSIDE ASSISTANCE
To fully assist you should you have a vehicle concern, Ford Motor
Company offers a complimentary roadside assistance program. This
program is separate from the New Vehicle Limited Warranty. The service
is available:
• 24 – hours, seven days a week
• for the New Vehicle Limited Warranty period of three years or 60,000
km (36,000 miles), whichever occurs first on Ford and Mercury
vehicles, and four years or 80,000 km (50,000 miles) on Lincoln
vehicles.
Roadside assistance will cover:
• changing a flat tire
• jump-starts
• lock-out assistance
• limited fuel delivery
• towing of your disabled vehicle to the nearest Ford Motor Company
dealership, or your selling dealer if within 56.3 km (35 miles) of the
nearest Ford Motor Company dealership (one tow per disablement).
Even non-warranty related tows, like accidents or getting stuck in the
mud or snow, are covered (some exclusions apply, such as impound
towing or repossession).
Canadian customers refer to your Owner Information Guide for
information on:
• coverage period
• exact fuel amounts
• towing of your disabled vehicle
• emergency travel expense reimbursement
• travel planning benefits
USING ROADSIDE ASSISTANCE
Complete the roadside assistance identification card and place it in your
wallet for quick reference. In the United States, this card is found in the
Owner Guide portfolio in the glove compartment in Ford vehicles and is
mailed to you if you own a Mercury or Lincoln. In Canada, the card is
found in the Owner Information Guide in the glove compartment.
U.S. Ford or Mercury vehicle customers who require roadside assistance,
call 1 – 800 – 241 – 3673; Lincoln vehicle customers call 1 – 800 – 521 – 4140.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
Roadside Emergencies
262

Canadian customers who require roadside assistance, call
1 – 800 – 665 – 2006.
If you need to arrange roadside assistance for yourself, Ford Motor
Company will reimburse a reasonable amount. To obtain reimbursement
information, U.S. Ford or Mercury vehicles customers call
1-800-241-3673; Lincoln vehicle customers call 1 – 800 – 521 – 4140.
Canadian customers who need to obtain reimbursement information, call
1 – 800 – 665 – 2006.
ROADSIDE COVERAGE BEYOND BASIC WARRANTY
In the United States, you may purchase additional roadside assistance
coverage beyond this period through the Ford Auto Club by contacting
your Ford or Lincoln Mercury dealer.
Similarly in Canada, for uninterrupted Roadside Assistance coverage, you
may purchase extended coverage prior to your Basic Warranty ’ s Roadside
Assistance expiring. For more information and enrollment, contact
1 – 877 – 294 – 2582 or visit our website at www.ford.ca.
HAZARD FLASHER
Use only in an emergency to warn traffic of vehicle breakdown,
approaching danger, etc. The hazard flashers can be operated when the
ignition is off.
• The hazard lights control is
located on top of the steering
column.
• Depress hazard lights control to
activate all hazard flashers
simultaneously.
• Depress control again to turn the
flashers off.
FUEL PUMP SHUT-OFF SWITCH FUEL
RESET
The fuel pump shut-off switch is a device intended to stop the electric
fuel pump when your vehicle has been involved in a substantial jolt.
After a collision, if the engine cranks but does not start, the fuel pump
shut-off switch may have been activated.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
263

The fuel pump shut-off switch is
located in the left rear quarter trim
panel, near the liftgate. The switch
is located behind two access panels;
the second panel has a tab that
needs to be pushed down to remove
the access panel door.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
264

The fuel pump shut-off switch has a
red reset button on top of it and is
located beneath the air suspension
switch (if equipped). If the vehicle
is not equipped with air suspension,
the fuel pump shut-off switch ’ s red
reset button will still be visible
behind this access panel.
Use the following procedure to reset the fuel pump shut-off switch.
1. Turn the ignition to the OFF position.
2. Check the fuel system for leaks.
3. If no fuel leak is apparent, reset the fuel pump shut-off switch by
pushing in on the reset button.
4. Turn the ignition to the ON position. Pause for a few seconds and
return the key to the OFF position.
5. Make a further check for leaks in the fuel system.
FUSES AND RELAYS
Fuses
If electrical components in the
vehicle are not working, a fuse may
have blown. Blown fuses are
identified by a broken wire within
the fuse. Check the appropriate
fuses before replacing any electrical
components. 15
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
265

Note: Always replace a fuse with one that has the specified amperage
rating. Using a fuse with a higher amperage rating can cause severe wire
damage and could start a fire.
Standard fuse amperage rating and color
COLOR
Fuse
rating Mini
fuses Standard
fuses Maxi
fuses Cartridge
maxi
fuses Fuse link
cartridge
2A Grey Grey ———
3A Violet Violet ———
4A Pink Pink ———
5A Tan Tan ———
7.5A Brown Brown ———
10A Red Red ———
15A Blue Blue ———
20A Yellow Yellow Yellow Blue Blue
25A Natural Natural ———
30A Green Green Green Pink Pink
40A —— Orange Green Green
50A —— Red Red Red
60A —— Blue — Yellow
70A —— Ta n — Brown
80A —— Natural — Black
Passenger compartment fuse panel / power distribution box
The fuse panel is located under the right-hand side of the instrument
panel.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
266

To remove the trim panel for access
to the fuse box, pull the panel
toward you and swing it out away
from the side and remove it. To
reinstall it, line up the tabs with the
grooves on the panel, then push it
shut.
To remove the fuse box cover, place
a finger behind the PULL tab and
your thumb above the PULL tab as
shown in the illustration, then pull
the cover off.
To reinstall the fuse box cover, place the top part of the cover on the
fuse panel, then push the bottom part of the cover until you hear it click
shut. Gently pull on the cover to make sure it is seated properly.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
267

The fuses are coded as follows.
Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
1 10A* Run/Accessory - Instrument cluster, Front
wiper motor, Rear wiper motor, Tire
Pressure Monitor System (TPMS) module
2 20A* Brake On/Off (stoplamp) switch, Turn
signal/Hazard flasher, AdvanceTrac

stoplamps relay, Stoplamps, Center
High-Mounted Stoplamp (CHMSL), Turn
signal lamps
3 7.5A* Power mirror switch, Memory module (logic
power), Driver seat switch (memory)
4 15A* Rear seat audio controls, Navigation module,
DVD player
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
268

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
5 7.5A* Brake On/Off (stoplamp) switch, Powertrain
Control Module (PCM) (keep alive power),
EATC control head, Body Security Module
(BSM) (keep alive power), Speed control
deactivation switch, Speed control servo,
SecuriLock LED, 3rd row seat relay coils,
Power liftgate module, Clock, Brake Shift
Interlock (BSI) solenoid
6 15A* Headlamp switch (parklamps and switch
backlighting feed), Parklamps, License
lamps, Foglamp relay coil, Trailer tow
electric brake controller (illumination), BSM
(autolamp parklamps), Floor console gear
selector lighting, Switch backlighting
module, Foglamp indicator
7 7.5A* Radio (Start signal)
8 10A* Rear window defroster switch, Heated
outside mirrors, Rear window defroster
indicator (climate control head)
9 — Not used
10 20A* Trailer tow back-up lamps relay, Trailer tow
7 – wire connector (back-up lamps), Trailer
tow parklamps relay, Trailer tow 7 – and
4 – wire connectors (parklamps)
11 10A* A/C compressor clutch relay, A/C
compressor clutch solenoid, Air suspension
compressor relay, 4x4 Integrated Wheel
Ends (IWE) solenoid
12 10A* Speed control relay, Speed control servo
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
269

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
13 10A* Rear window defroster relay coil, A/C
refrigerant containment switch, A/C
compressor thermistor, DEATC control
head, DEATC solenoids, DEATC blower
controller, Trailer tow battery charge relay
coil
14 10A* Daytime Running Lamps (DRL) ignition
relay coil, Digital Transmission Range Sensor
(DTRS back-up lamps), Trailer tow back-up
lamps relay coil, Elctrochromatic mirror
15 5A* AdvanceTrac
switch, Instrument cluster
(Run/Start feed)
16 10A* ABS/AdvanceTrac
module (Run/Start
feed)
17 15A* Foglamps
18 10A* Auxiliary A/C temperature blend door
actuator, Auxiliary A/C front auxiliary
control, Park brake release relay coils, Turn
signal flasher, Electrochromatic mirror,
Auxiliary mode motor, Climate controlled
seat modules
19 10A* Restraints Control Module (RCM)
20 30A* 4x4 module, Air suspension module (air
spring solenoids and height sensors)
21 15A* Instrument cluster (B+), Interior (courtesy)
lamps, TPMS module, Park brake release
relays, Park brake release motor, Puddle
lamps (outside mirrors)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Roadside Emergencies
270
