display LINCOLN NAVIGATOR 2004 Owner's Guide

If the avoid point is enlarged to an
avoid area, it will appear on the
screen as a shaded box.
Way point symbol — Indicates the
location of a way point (locations
you wish to visit in route to your
ultimate destination) on the map.
Home position symbol —
Indicates the location on the map,
currently stored as the home
position.
Stored location symbol —
Indicates the location of a memory
point. This is the default symbol
used when the point is stored. (If
desired, an icon of your own choice can be selected from the 15 icons
available.) Refer to Choosing from the icon list.
GPS symbol — Indicates that
insufficient GPS satellite signals are
being received for accurate map
positioning. The symbol is not
displayed under normal operation.
Speaker icon symbol — Press to
turn voice guidance on/off.
Navigation menu
To access the Navigation Menu,
press NAV MENU at the bottom of
the map screen.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Entertainment Systems
65

Once pressed, the Navigation Menu
will display showing the following
options:
• Route Options/Preferences
• Navigation Set Up
• Display Options
• Stored Locations
• On Route Scroll
• Voice Guidance/Volume
Depending upon whether or not a route is active will determine if route
options/route preferences is contained on the Navigation Menu.
Route options (destination entered)
Once in navigation mode and a
route is currently active, press
“ Chng. route ” to access the ROUTE
OPTIONS screen. Choose from the
following selections:
• Detour : Press to select a detour
around the current route. Refer
to Detour options later in this
chapter for further information.
• Route Preferences : When
creating a destination, select from: Minimize Time/Distance, Use Major
Roads, Use Toll Roads, Use Ferries.
• Display Whole Route : Will enter MAP mode and display your entire
chosen route.
Note: Route preference appears on the Nav menu when no destination
is entered.
While driving under route guidance, only follow an instruction
when it is safe to do so as the system cannot be aware of
changing conditions. Use voice guidance as much as possible, and only
view the display when driving conditions permit.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Entertainment Systems
66

Ensure that you follow highway code restrictions and do not
take any risks. For example, if you are unable to make a U-turn,
continue on your journey. The navigation system will recalculate your
route to get you back to an appropriate road to your destination.
Route preferences
After entering a destination, the
Route options will appear on the
screen showing what is currently
selected. You may choose to
activate/deactivate selections which
the system will factor in when
calculating your route. Those
options are:
• Minimize Time/Distance
• Use Major Roads
• Use Toll Roads
• Use Ferries
Navigation set up
The Navigation Set up screen will
allow you to make adjustments to
the navigation displays.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Entertainment Systems
67

Calibration
This feature is helpful if the car has
been towed, or if you notice it is not
registering at the correct vehicle
location on the map.
Press “ Position ” to reposition the
vehicle location. Press the screen to
scroll the map to the desired
location and press OK to confirm.
Press “ Distance ” to calibrate by
distance and improve the navigation
accuracy. It is recommended to
activate this function after every tire replacement. When the button is
highlighted, calibration is in process and will turn off automatically when
complete.
DVD map version
Displays the version of the inserted
navigation DVD. Refer to Ordering
additional map DVDs for further
information.
Display Options
The Display Options screen will
allow you make adjustments to the
navigation display screen. You can
choose from:
• Map Mode (Dual or Full)
• Guidance Mode (Arrows or Turn
list)
• Guidance Display (On or Off)
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Entertainment Systems
69

Initial map display
After pressing AGREE to the initial
WARNING screen, you will move
into the initial map screen which
shows the current vehicle location.
Pressing the globe icon will take you
to the user settings — audible
feedback, navigation units, language
and clock.
Note: There may be a slight time
delay between the soft key and the
hard key functions.
Route options
Once in navigation mode and a
route is currently active, the ROUTE
OPTIONS screen will appear and
allow you to choose from the
following selections:
• Detour — Press to select a detour around the current route.
• Route Preferences — When creating a destination, select from:
Minimize Time/Distance, Use Major Roads, Use Toll Roads, Use
Ferries.
• Display Whole Route: Will enter MAP mode and display your entire
chosen route.
• Destination Entry : Allows you to enter a new destination or select
from entries in: Address book, Points of Interest, Previous
Destinations, and Intersections.
While driving under route guidance, only follow an instruction
when it is safe to do so as the system cannot be aware of
changing conditions. Use voice guidance as much as possible, and only
view the display when driving conditions permit.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Entertainment Systems
72

Search area
The mapped areas covered by your
map DVD are reflected in the
Search Area map that is displayed
on the Destination Entry screen.
Your navigation system uses a
regional search area. This area is
the area from which navigational
directions will be used. To check
your area or reset, press CHANGE under the search area listing. The
map will open and allow you to select another regional area. Ensure that
your search area is correct prior to setting your destination.
Points of interest (POI)
Select “ Point of Interest ” from the
Destination Entry Menu. In this next
menu, you will have the following
options:
• By Name — Enter POI name on
the keyboard. Touch “ List ” to
display the list of matching points
of interest. If there are too many
matches being listed, try entering
the town name first.
• By Category — Press “ Category ” . Scroll down the list to select the
category, then sub-category desired. Once you have selected a
category, your entry of the POI will be restricted to that category.
Previous destination
Press “ Previous Destination ” on the
Destination Entry Menu.
• Select (touch) the desired item
from the list of destinations
previously reached. The item
details will be listed.
• Confirm destination details.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Entertainment Systems
74

Deleting previous destination
• Press “ Delete ” . The list of
previous destinations is displayed
showing “ Delete Previous
Destination ” at the top of the
screen.
• Select (touch) the entry to be
deleted. The item details will be
listed.
• Press YES to confirm the
deletion.
• Press DELETE ALL to delete all previous destinations.
Memory point
Your navigation system allows you to
save special destinations you may
wish to again visit. Select “ Memory
Point ” from the Destination Entry
Menu.
• Select the desired item from the
list of stored memory points.
• Confirm destination details.
Note: The list can be sorted by date, name or icon by pressing the
appropriate button. STORE MEMORY POINT
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Entertainment Systems
75

Choosing from the icon list
After choosing ICON to edit, 15
normal and three audible icons will
be displayed. Press the icon you
wish to use.
The normal icons will be displayed
on the map to indicate the map
location identified with that icon.
The audible icon will sound a
distinctive chime when the vehicle
is approaching the memory point
associated with that icon.
Deleting a memory point
• In the Memory Point Menu, press
DELETE.
• Select the entry to be deleted.
• The system will ask you to
confirm deletion. Press YES to
confirm.
The screen will briefly show
“ Memory Point Deleted ” .
Deleting all memory points
• In the Memory Point Menu, press
DELETE ALL.
• The system will ask you to confirm deletion. Press YES to confirm.
The screen will briefly show “ All Memory Points Deleted ” .
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Entertainment Systems
77

Freeway Entrance/Exit
Select “ Freeway Entrance/Exit ”
from the second page of the
Destination Entry menu. Follow
these steps:
1. Enter freeway name — Enter
the freeway name using the
keyboard. Press “ List ” to select a
freeway from those displayed.
To enter numbers in the freeway
name, press “ Sym ” .
2. Select entrance/exit — Press
“ Entrance ” if you wish to join the
freeway at this junction. Press
“ Exit ” if you wish to leave the
freeway at this junction.
3. Select Junction — The screen
will display a list of junctions on the
freeway. They can be listed either
by distance, (from the current
vehicle location), by pressing the
“ Dist ” button or alphabetically by
pressing the “ A-Z ” button. Select the desired entrance or exit.
The destination details are displayed for confirmation.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Entertainment Systems
80

Special memory points
There are five possible memory
points that you can set.
To set a memory point:
• Press MAP.
• Press “ Nav Menu ” .
• Press “ Stored locations ” .
• Press “ Special Memory Point ” .
• Select “ Add ” and input destination.
• Press OK to confirm.
To delete a memory point:
• Press “ Delete ” . The list will display.
• Select the special memory point to delete.
• Press “ Del. all ” to delete all entered special memory points.
• Press “ Ye s ” to confirm.
Once all five special memory points are entered, the “ Add ” control will
read as “ Full ” . You must delete points before more can be added.
Destination and way points
The Store Dest. & Way Point menu
is used after a destination or way
point has been entered for the first
time using the Destination Entry
menu. You can store and delete
destinations and way points
(locations you wish to visit in route
to your ultimate destination). You
can also select the order in which
you visit them.
