MASERATI QUATTROPORTE 2019 Owners Manual

environment;
• never charge or recharge a battery
that has frozen;
• ensure that any sparks or open
flames are nowhere near the battery
while it is charging;
• before using a charger to charge or
maintain the battery charge status,
carefully follow the instructions
provided to ensure the charger is
connected to the battery safely and
correctly. Maintenance and Care
7
367

Maintenance and Care
368

8 – Features and Specifications Refillings ............................................. 370
Fuel Consumption ...................................... 374
Technical Data ......................................... 375
Tire Inflation Pressure ................................... 381
369

Refillings NOTE:
Maserati reserves the right to change or revise specifications without prior notification.
Refillings and Recommended Products Parts to be refilled Quantity Product Specifications
Fuel tank 21 Gallons/80 litres (including 4.2
Gallons/16 litres of reserve) Premium unleaded fuel with no less than 91 CLC or
AKI (95 RON/85 MON).
Engine (V8 Engine)
8.8 Quarts/8.3 litres (max) (Difference
among MIN and MAX level:
1.5 Quarts/1.4 litres) Synthetic multigrade lubricants SAE 5W-40 that meet
API SL/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati
5W-40 (1).
Engine (V6 Engine) 7.7 Quarts/7.3 litres (max) (Difference
among MIN and MAX level:
1.1 Quarts/1 litre) Synthetic multigrade lubricants SAE 10W-60 that
meet API SN/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati
10W-60 (2).
Engine (V6 Engine - AWD
version) 8.8 Quarts/8.3 litres (max) (Difference
among MIN and MAX level:
1.1 Quarts/1 litre)
Windshield washer fluid
tank 3.7 Quarts/3.5 litres Mix of water and detergent fluid, in the proportions
indicated on the product package. If the temperature
is below –4°F (–20°C), use pure detergent fluid.
Detergent fluid: Mix of CUNA NC 956-II surfactants
and alcohols.
Recommended fluid: WUERTH Windshield Washer
Fluid with antifreeze or AREXONS DP1.Features and Specifications
8
370

Parts to be refilled Quantity Product Specifications
Engine cooling circuit (V8
Engine) 15 Quarts/14.2 litres
(for dual-zone air conditioning
system)
15.85 Quarts/15 litres
(for four-zone air conditioning
system) Mixture of water and coolant, proportionally 50/50%.
Coolant: protective, antifreeze action and ethylene
glycol-based with organic inhibitors compatible with
regulations:
• ASTM D 3306, ASTM D 2570
• ASTM D 4340, ASTM D 2809
• SAE J 1034
• CUNA NC 956/16.
Recommended fluid: PETRONAS Paraflu Up 50/50.Engine cooling circuit (V6
Engine) 9.7 Quarts/9.2 litres
(for dual-zone air conditioning
system)
10.56 Quarts/10 litres
(for four-zone air conditioning
system)
Automatic transmission
cooling circuit 2.64 Quarts/2.5 litres
(3) Automatic
transmission 8 Quarts/7.6 litres First equipment oil: SHELL ATF L- 12108 or ZF
Lifeguard 8.
(3) Differential
1.4 Quarts/1.3 litres Synthetic Axle Lubricant SAE 75W-85 – FE Hypoid
Gear Lubricant.
(3) Front differential (V6
Engine - AWD version) 0.47 Quarts/0.45 litres First equipment oil: SHELL TF 0951B.
(3) Transfer case (V6
Engine - AWD version) 0.65 Quarts/0.62 litres First equipment oil: SHELL TF 0870.
Braking system
0.93 Quarts/0.88 litres +/- 4% Synthetic fluid: FMVSS 116 DOT 4, ISO 4925 Class 4,
ENSAYOS INTA-UNE 26-109-88, SAE J1703, SAE J1704,
CUNA NC 956-01.
Recommended fluid: PETRONAS Tutela TOP 4/S.Features and Specifications
8
371

Parts to be refilled Quantity Product Specifications
CAUTION!
For each oil refilling and/or replacement, please contact an Authorized Maserati Dealer .
Air conditioning system dual-zone: 24 oz +/-0.7 oz
680 g +/-20 g
four-zone: 30.7 oz +/-0.7 oz
870 g +/-20 g Coolant: r134a.
(1) In countries where it is not available, recommended oil “PENNZOIL Platinum 5W-40”.
(2) In countries where it is not available, recommended oil “PENNZOIL Platinum 10W-60”.
(3) No change and/or topping up expected in scheduled maintenance.
CAUTION!
To guarantee vehicle’s integrity and maintain performance level always use genuine parts approved and recommended by
Maserati.
WARNING!
California Proposition 65
Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including such
as, engine exhaust, carbon monoxide, phthalates and lead, that which are known to the State of California to cause
cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently
when servicing your vehicle. For more information go to: www.P65Warnings.ca.gov/passenger-
vehicleFeatures and Specifications
8
372

Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). Maserati only
recommends API Certified engine oils.
CAUTION!
Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Damage caused by use of
non-approved chemicals is not covered by the new Vehicle Limited Warranty.
Engine Oil Viscosity (SAE Grade) SAE 5W-40 (for V8 engine) and SAE 10W-60 (for V6 engine) engine oil is recommended for all operating temperatures.
The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil
filler cap location, refer to chapter “Maintenance Procedures” in section “Maintenance and Care”.
Lubricants that do not have both the engine oil certification mark and the correct SAE viscosity grade number should not
be used. Features and Specifications
8
373

Fuel Consumption NOTE:
• The technical data, values and specifications in this Owner’s Manual are provided as guidance only. The vehicle specific
data can deviate from the information provided, for example, as a result of optional or special equipment ordered with
the vehicle, vehicle loads, and country specific measurement methods.
• The specifications described below can change without prior notification.
The fuel consumption values shown (Miles Per Gallon - MPG) are established using EPA test guidelines.
Quattroporte GTS (V8 Engine) Quattroporte S (V6 Engine) Quattroporte SQ4 (V6 Engine -
AWD version)
City 18 MPG 19.3 MPG 19.4 MPG
Highway 30.3 MPG 32 MPG 32 MPG
Combined 22 MPG 23.4 MPG 23.6 MPG
CAUTION!
• Actual fuel economy results will vary for many reasons, including driving conditions and how you drive and maintain
your vehicle.
• The type of route, traffic and weather conditions, driving style, general condition of the vehicle, equipment/accessories in
the vehicle, use of the air conditioning system, vehicle load and other items or situations which may negatively affect the
vehicle aerodynamics or wind resistance lead to consumption ratios differing from the indicated ones.Features and Specifications
8
374

Technical Data NOTE:
The technical data, values and specifications in this Owner’s Manual are provided as guidance only. The vehicle specific
data can vary from the information provided, for example, as a result of optional or special equipment ordered with the
vehicle, vehicle loads, and country specific measurement methods.
Engine Data Quattroporte GTS Quattroporte S - Quattroporte
SQ4 (AWD version)
Cylinder number and position 8 - 90° V 6 - 60° V
Number of valves per cylinder 4 4
Bore x stroke 86.5 x 80.8 mm 86.5 x 84.5 mm
Total displacement 3,799 cm 3
2,979 cm 3
Compression ratio 9.5 : 1 9.7 : 1
Maximum power output (EC) 390 kW – 523 HP 316 kW – 424 HP
- corresponding RPM 6,700 RPM 5,750 RPM
Peak torque (EC) 480 ft-lb (650 N-m) 428 ft-lb (580 N-m)
- corresponding RPM 2,000 – 4,000 RPM 1,750 – 4,500 RPM
Overboost torque (EC) 524 ft-lb (710 N-m) 428 ft-lb (580 N-m)
- corresponding RPM 2,000 – 4,000 RPM 1,750 – 4,500 RPMFeatures and Specifications
8
375

Properties
Timing The timing system uses two overhead camshafts with timing variator.
Timing system control Timing chain.
Supply Over-supplied with turbocompressor and related intercooler for each bank.
Injection – Ignition High pressure 2900 PSI (200 bar) direct fuel injection system. Static ignition with digital
electronic control system included and controlled by a single microprocessor ECU.
Transmission ZF automatic transmission with 8 speeds, torque converter, lock-up clutch and anti-slip function.
Sequential and traditional control type.
Automatic transfer case (AWD version).
TRANSAXLE-type transmission.
Traction system equipped with rear self-locking differential.
Brakes Self-ventilating disc brakes on the four wheels.
The Electric Parking Brake (EPB) acts on the rear wheels.
Braking System
Performance Dual Cast Dual Cast
Front disc diameter 15 in (380 mm) 14.1 in (360 mm)
Rear disc diameter 13.6 in (345 mm) 13.6 in (345 mm)Features and Specifications
8
376
