remote control MAZDA CX90 2024 Owners Manual

Steering Wheel Area Overview
ƒHigh Beam Control System (HBC) switch.......................................... page 5-142
„ Lighting control................................................................................. page 5-68
… Turn and lane-change signals............................................................. page 5-72
† Audio remote control switches........................................................... page 7-13
‡ INFO switch...................................................................................... page 5-28
ˆ Mazda Radar Cruise Control (MRC C) switches................................. page 5-167
‰ Cruising & Traffic Sup port (CTS) switches..........................................page 5-177
Š Cruise control switches................................................................... page 5-226
‹ Wiper and washer lever..................................................................... page 5-74
Name of Each Part
Steering Wheel Area Overview
1-2The equipment and installation position varies by vehicle
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Key
Sound function
The function that the sound notifies
you of unlocking/locking can be
turned on or off by changing the
setting in Mazda Connect. The volume
of the warning sound can also be
changed.
Auto re-lock function
All doors, the liftgate, and the fuel lid
are locked automatically if any of the
following operations are not
performed within about 60 seconds
after they are unlocked by pressing the
unlock button.
Open any door or liftgate.The vehicle power is switched to any
position other than off.
NOTE
The time until the door is automatically
locked can be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Power Saving Function
By turning on the power saving
function of the key, the advanced
keyless entry and the function to start
the hybrid system without removing
the key from a pocket or purse/case
are turned off, and the battery power
consumption of the key can be
reduced.
The remote control function is still
operational by pressing a button on
the key even while the power saving
function is turned on. However, the
remote operation indicator light does
not turn on or flash.
Turning on the power saving function
1. Press the lock button on the key 4
times within 3 seconds.
The key operation indicator light
turns on.
2. Press the lock button for 2 seconds or longer while the key operation
indicator light is turned on.
The hazard warning lights and a
warning sound operate 1 time, and
the power saving function is turned
on.
Turning off the power saving function
1. Press the lock button on the key 4 times within 3 seconds.
The key operation indicator light
turns on.
2. Press the lock button for 2 seconds or longer while the key operation
indicator light is turned on.
The hazard warning lights and a
warning sound operate 1 time, and
the power saving function is turned
off.
Opening/closing
Key
4-8
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Climate control timer
The climate control timer is a function
which operates the cooling or heating
system automatically according to a
preset time. The power consumption
of the air conditioner after starting to
drive the vehicle is reduced by
operating the air conditioner and
providing a comfortable temperature
in the cabin before driving.
Refer to Convenient Ways to Use the
Fully Automatic Air-Conditioning on
page 6-12.
Charge Connector Lock
The charge connector lock is a function
which locks the charge connector con-
nected to the vehicle so that it cannot
be pulled out. You can also select the
lock conditions for the charge connec-
tor according to locations and situa-
tions.
1. Select Settings from the homescreen on Mazda Connect.
2. Select EV Settings from the setting screen.
3. Select Charge Connector Lock from the selection screen.
4. Set the lock condition from the se- lection screen.
Available setting changes
Locked When Charging
Unlocks connector when charging is complete
or vehicle is unlocked.
Locked When Connected
Unlocks connector only when vehicle is un-
locked.
Available setting changes
Off
Charge connector remains unlocked at all
times.

Functions using a Smartphone
You can check the remaining high
voltage battery power, operate the
charging, and operate the air
conditioner remotely by a Smartphone
remote control operation using the
Connected Service. For details, consult
an Authorized Mazda Dealer.
Driving
Charging
5-121
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Fully AutomaticClimate Control
Cabin Preconditioning
Cabin preconditioning is a collective
term regarding use of the climate
control timer and the remote climate
control.
While the climate control timer or the
remote climate control is operating ,
you can check the setting status on
your Smartphone.
Climate Control Timer
By setting the departure time using
Mazda Connect, the climate control
system operates and adjusts the cabin
temperature by the departure time.
The departure time, day, set
temperature, and defroster operation/
non-operation can be personalized,
and 7 types of patterns can be
programmed in advance.
Remote Climate Control
Using your Smartphone, you can turn
on the climate control system remotely
before departing.
WARNING
Do not operate the cabin
preconditioning with people or pets
in the vehicle.
The cabin preconditioning may stop
automatically due to the vehicle
conditions and the surrounding
environment. If the climate control
system stops and the temperature
inside the vehicle increases or
decreases, it could cause a serious
medical condition such as heat
exhaustion and dehydration.
CAUTION
 If any of the following conditions is
met, the cabin preconditioning will
not operate. In addition, if the cabin
preconditioning is operating, it will
stop. However, if the liftgate is
opened while the cabin
preconditioning is operating, the
cabin preconditioning will not stop.
When the cabin preconditioning
does not operate or stops, the cabin
preconditioning cancel display is
indicated on the display.
 The high voltage battery or the
lead-acid battery charge is low
 The doors/liftgate are open
 The vehicle power is switched to a
position other than OFF
 There is a problem with the vehicle
 If any of the following conditions is
met, the climate control system will
not operate effectively and the cabin
temperature may not reach the set
temperature.
 Your power consumption is high
 Extremely high or low
temperatures
 The climate control system operates
so that it reaches the set temperature
at the departure time, and stops at
the departure time. The cabin
temperature may not reach the set
temperature if you get in the vehicle
earlier or later than the set departure
time.
 If you operate the cabin
preconditioning while charging the
vehicle, it could take more time to
charge the battery. In addition, when
it is extremely hot or cold, the power
consumption of the climate control
system is high, therefore the charge
amount may be less than the preset
charge amount.
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-12
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

During the cabin preconditioning
operation, the cooling fan, the
compressor, and the cabin fans
operate, but this does not indicate a
problem.
 The climate control system functions
you can use
differ depending on the
vehicle power position.
Function Vehicle power position
OFF ACC ON
(Hy- brid sys-
tem off) ON
(Hy- brid sys-
tem on)
Air circulation — — X X
Cooling/heating — — X
*1X
Climate Control
Timer X———
Remote climate
control X———
X: Available
—: Not available
*1 The cooling/heating function can
be used only while charging.
NOTE
The recommended set temperature
is 22 °C (72 °F). If you set an
extremely high or low temperature,
power consumption will increase
and the charging time will take
longer.
If you operate the cabin
preconditioning while the charge
connector is connected, you can
reduce the electric power
consumption of the high voltage
battery.
While the cabin preconditioning is
operating , the indicator light for the
climate control power switch turns
on.
The cabin preconditioning operates
for 20 minutes. If you set the
departure time using the climate
control timer, set it 20 minutes or
later from the current time and if you
want to make several settings, space
them out at intervals of 30 minutes
or longer.
How to set the Climate Control Timer
1. Select “Settings” from the Mazda Connect home screen.
2. Select “EV Settings”.
3. Select “Climate Control Timer”.
4. Select the item setting you would like to change from the displayed
content.
5. Switch the vehicle power OFF.
Climate Control Timer
Allows climate control to adjust cabin
temperature before driving.
Function Available setting changes
1 ---
Enable,
Disable
*1Edit,
Delete*2
2 ---
3 ---
4 ---
5 ---
6 ---
7 ---
*1 If an item selected using the cursor has been set, the item can be
enabled or disabled.
*2 Settings can be “Edit”/“Delete” bysliding an item selected using the
cursor to the right.
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-13
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Edit
The Climate Control Timer settings can
be edited.
FunctionAvailable setting
changes
Departure Time Time
(10-minute inter- vals)
Repeat
*1Monday ― Sun-
day
Te m p e ra t u r e 15.5
℃ (61 ℉) ―
28.5℃ (83 ℉)
Front Defroster Enable,
Disable
Rear Defroster Enable,
Disable
*1 If no [Repeat] day is set, the climate control timer operates only
1 time at the set hours.
NOTE
Enabling “Front Defroster” /“Rear
Defroster” will aid you in defrosting
and removing ice or snow from the
window glass. The recommended set
temperature when setting the
defroster is 22 °C (72 °F) or higher.
The defroster performance changes
according to the set temperature.
The climate control timer does not
work if the vehicle is left unattended
for a long period of time in an
environment where GPS signal
reception is difficult, such as in an
underground parking lot or indoors,
or if GPS signals are not received.
When GPS signals are received, the
climate control timer becomes
operational.
The climate control timer does not
operate while the remote climate
control is operating.
The climate control timer can be
stopped by a Smartphone remote
control operation using the
Connected Service.
For details, consult an Authorized
Mazda Dealer.
How to Set the Remote Climate
Control
To use the remote climate control, it is
necessary to subscribe to Connected
Service.
For details, consult an Authorized
Mazda Dealer.
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-14
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

7Other Equipment
Mazda Connect........................ 7-4Mazda Connect..................... 7-4
Warnings and Cautions for Using
the Mazda Connect............... 7-5
How to Use the Mazda
Connect................................ 7-6
How to Use the Commander
Switch...................................7-9
How to Use the Audio Remote
Control Switch.....................7-13
How to Use the Voice
Recognition Function........... 7-15
Connected Service (If
applicable).......................... 7-19
Appendix............................ 7-21
Storage Compartments............ 7-29 Warning and Cautions for Using
the Storage Compartments ..........
.......................................... 7-29
Cup Holders........................... 7-30 Warnings and Cautions for Using
the Cup Holders.................. 7-30
How to Use the Cup
Holders............................... 7-30
Bottle Holder..........................7-32 Warnings and Cautions for Using
the Bottle Holder................. 7-32
How to Use the Bottle
Holder................................ 7-32Glove Compartment................7-33How to Use the Glove
Compartment..................... 7-33
Center Console...................... 7-34 How to Use the Center
Console.............................. 7-34
Armrest Box........................... 7-35 How to Use the Armrest
Box..................................... 7-35
Overhead Console.................. 7-36 How to Use the Overhead
Console.............................. 7-36
Rear Coat Hooks..................... 7-37 Warning and Cautions for Using
the Rear Coat Hooks............ 7-37
How to Use the Rear Coat
Hooks................................. 7-37
Luggage Compartment............ 7-38 Luggage Compartment......... 7-38
How to Use the Luggage
Compartment..................... 7-38
Sunvisor.................................7-39 How to Use the Sunvisor...... 7-39
Vanity Mirror.......................... 7-40 How to Use the Vanity
Mirrors................................7-40
7-1
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautions for Using the Mazda Connect
WARNING
Always adjust Mazda Connect while the vehicle is stopped:
Do not adjust Mazda Connect with th e Commander switch while driving the
vehicle. Adjusting Mazda Connect with the Commander switch while driving the
vehicle is dangerous as it could distract your attention from the vehicle operation
which could lead to a serious accident.
Even if the audio remote control switches are equipped on the steering wheel, learn
to use the switches without looking down at them so that you can keep your
maximum attention on the road while driving the vehicle.
Do not allow the connection plug cord to get tangled with the selector lever:
Allowing the plug cord to become tangled with the selector lever is dangerous as it
could interfere with driving , resulting in an accident.
Do not adjust a mobile device or a similar product while driving the vehicle:
Adjusting a mobile device or a similar product while driving the vehicle is dangerous
as it could distract your attention from the vehicle operation which could lead to a
serious accident. Always adjust a mobile device or a similar product while the
vehicle is stopped.
CAUTION
For the purposes of safe driving , adjust the audio volume to a level that allows you
to hear sounds outside of the vehicle incl uding car horns and particularly emergency
vehicle sirens.
Other Equipment
Mazda Connect
7-5
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Audio Remote Control Switch
The audio remote control switch is on the left side of the steering wheel. You can
operate basic audio functions, pick up/hang up the phone, or activate voice
control using the switch.
The shape of the switches may differ depending on the specifications.

Volume adjustment button
/
Press the (+) or (-) button to adjust the volume.
If you adjust the volume during voice guidance, the volume of the voice guidance
will change.
If you adjust the volume during a hands-free call, the conversation volume will
change.

Seek Switch
(SEEK UP)/(SEEK DOWN)
Selecting a radio station
Radio stations saved to your Favorites can be selected by pressing the seek
switch while listening to FM/AM radio. The station will change to the previous or
next favorite station each time you press the seek switch. If you want to manually
tune to the next available station before or after the currently selected station, press
and hold the seek switch until it beeps and the tuner will select the next available
station.

Playback Control
Music and video files can be cued when listening to stored content via USB,
Bluetooth
®, and SiriusXM®*, audio, or video.
Other Equipment
Mazda Connect
*Some models.7-13
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Voice Recognition Function

The shape of the switches may differ depending on the specifications.

Talk/Pick-up button
When the button is pressed, the voice recognition top screen is displayed and the
voice recognition is activated.
(While voice guidance is being announced)
Press the button to skip the voice guidance.

Hang-up button
Press the button to end the voice recognition.

Voice recognition activation
When the talk/pick-up button on the audio remote control switch is pressed, top
screen of the voice recognition will be displayed.
NOTE
When an Apple CarPlay™ or Android Auto ™ compatible device is connected, the
Mazda Connect voice recognition system is disabled to allow the use of Siri® or
Android Auto™ voice recognition at an y time with the talk/pick-up button.
Commands usable at any time
“Help” - Can be used to check for usable voice commands.
“Back” - Returns to the previous screen. When a voice command is spoken while on
the telephone number input screen, the content that was previously input is deleted.
“Cancel”- The voice recognition is ended.
Other Equipment
Mazda Connect
7-15
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
