Front Cabin Overview
ƒHead restraint................................................................................... page 3-48
„ Front seat......................................................................................... page 3-30
… Seat belt........................................................................................... page 3-25
† Bottle holder.....................................................................................page 7-32
‡ Vanity mirror..................................................................................... page 7-40
ˆ Sunvisor........................................................................................... page 7-39
‰ Overhead light (front)........................................................................ page 7-42
Š Map lights........................................................................................ page 7-43
‹ Overhead console............................................................................. page 7-36
ΠPanorama sunroof switch/Moonroof switch............................... page 4-32, 4-36
Rearview mirror................................................................................ page 5-11
Ž Wireless Charger (Qi)........................................................................ page 7-56
Mazda intelligent Drive Select (Mi-Dr ive) switch................................. page 5-96
CHARGE Mode switch.......................................................................page 5-23
‘ Selector lever.................................................................................... page 5-47
’ Commander switch............................................................................. page 7-9
“ Hill descent control switch................................................................. page 5-93
” 360° View Monitor switch............................................................... page 5-212
• Electric Parking Brake (EPB) switch...................................................... page 5-58
– AUTOHOLD switch........................................................................... page 5-64
Center console................................................................................. page 7-34
Name of Each Part
Front Cabin Overview
The equipment and installation position varies by vehicle1-5
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04 ㉑

Rear Exterior Overview
ƒRear window wiper blade.............. .................................................... page 9-23
„ Electric liftgate opener....................................................................... page 4-18
… Liftgate............................................................................................. page 4-17
† Charging port lid.............................................................................page 5-116
‡ Outside mirror.................................................................................... page 5-8
Name of Each Part
Rear Exterior Overview
The equipment and installation position varies by vehicle1-9
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

5Driving
Mirrors.................................... 5-8Warnings and Cautions for Using
the Mirrors............................ 5-8
How to Use the Outside
Mirrors..................................5-9
Convenient Ways to Use the
Outside Mirrors................... 5-10
Warnings and Cautions for the
Rearview Mirror................... 5-11
How to Use the Rearview
Mirror................................. 5-11
Convenient Ways to Use the
Rearview Mirror................... 5-12
Power Switch..........................5-13 Power Switch....................... 5-13
Warning and Cautions for Using
the Power Switch................. 5-13
How to Use the Power
Switch.................................5-14
e-SKYACTIV PHEV...................5-16 e-SKYACTIV PHEV............... 5-16
e-SKYACTIV PHEV
Overview............................ 5-17
Warning and Cautions for Using
the e-SKYACTIV PHEV.......... 5-19
How to Use the e-SKYACTIV
PHEV.................................. 5-23
Convenient Ways to Use the e-
SKYACTIV PHEV...................5-25
Instrument Cluster.................. 5-27 Instrument Cluster............... 5-27How to Use the Instrument
Cluster................................ 5-28
Convenient Ways to Use the
Instrument Cluster............... 5-31
Speedometer.......................5-31
Tachometer......................... 5-32
Odometer/Trip Meter.......... 5-32
How to Use the Odometer/Trip
Meter................................. 5-33
High Voltage Battery Temperature
Gauge................................. 5-33
Engine Coolant Temperature
Gauge................................. 5-34
High Voltage Battery Power
Gauge................................. 5-34
Fuel Gauge.......................... 5-35
Dashboard Illumination........5-35
How to Use the Dashboard
Illumination.........................5-36
Outside Temperature
Display................................5-37
Maximum Driving Distance
Display................................5-37
Average Electrical Power
Consumption Rate Display ..........
.......................................... 5-38
How to Use the Average Electrical
Power Consumption Rate
Display................................5-38
Average Fuel Economy
Display................................5-39
How to Use the Average Fuel
Economy Display................. 5-39
Instantaneous Electrical Power
Consumption Rate Display ..........
.......................................... 5-40
5-1
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautionsfor Using the Mirrors
WARNING
Be sure to look over your shoulder
before changing lanes.
Changing lanes without taking into
account the actual distance of a vehicle
in the convex mirror is dangerous. You
could have a serious accident. What
you see in the convex mirror is closer
than it appears.
Always return the outside mirrors to
the driving position before you start
driving.
Driving with the outside mirrors folded
in is dangerous. Your rear view will be
restricted, which could lead to an
unexpected accident.

(Vehicles with electric retractable
mirrors)
Do not touch the outside mirrors
while they are folding in and out.
Touching an outside mirror while it is
folding in or out is dangerous. Your
hands could get caught which could
cause an injury or the door mirror
could be damaged.
Use the switch to set the outside
mirrors.
Setting the outside mirrors manually is
dangerous. The outside mirrors will not
lock into place, which could obstruct
visibility.
Always operate the electric retractable
mirrors with the vehicle parked in a
safe place.
Operating the electric retractable
mirrors while driving is dangerous.
Wind pressure could damage the
outside mirrors, making it impossible
to return them to the driving position
and to see behind you.
Do not adjust the outside mirrors
while driving the vehicle.
Adjusting the outside mirrors while
driving the vehicle is dangerous as
doing so could distract your attention
from the road ahead and lead to an
accident.
CAUTION
(Vehicles with electric retractable
mirrors)
Operate the folding switch to fold in or
out the outside mirrors. If you unfold
the outside mirrors manually, they will
not be in a secured position and you
will be unable to check the view to the
rear of the vehicle.
Driving
Mirrors
5-8
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Outside Mirrors
Driving Position Memory*
The angle of the outside mirrors can be
programmed to the Driving Position
Memory.
Refer to Driving Position Memory on
page 3-33.
Auto fold function
*
When locking/unlocking the doors
while the vehicle power is switched
OFF, the outside mirrors automatically
fold in and out.
When the outside mirrors are folded in
and the vehicle power is switched ON,
or the hybrid system is started, the
outside mirrors fold out automatically.
Turn the auto fold function on using
the center display.
Refer to Settings section in the Mazda
Connect Owner's Manual or consult
an Authorized Mazda Dealer.
Operation function after hybrid
system is stopped
The angle of the outside mirrors can be
adjusted and they can be folded in and
out for about 40 seconds after the
vehicle power is switched from ON to
OFF.
Auto tilt-down outside mirror
function for reversing *
The outside mirrors can be set to tilt
downwards automatically when
reversing the vehicle. When the vehicle
is finished reversing , the outside
mirrors return to their original angle.
1. Press the select switch on the side of the door mirror to be tilted
down.
Turn on the indicator light of the
select switch.
2. Shift the selector lever to the Rposition.
The outside mirror on the side
where you pressed the select switch
will tilt downward.
NOTE
When any of the following condition is
met, the outer mirrors return to their
normal positions.
The vehicle power is switched to a
position other than ON.
The shift selector lever is shifted to a
position other than R.
The select switch is pressed again.
Automatic glare prevention function
*
In conjunction with the glare
prevention function of the auto-type
rearview mirror, only the driver's side
outside mirror reduces the light from
the headlights of on-coming vehicles.
Operation Function After Vehicle
power is Switched OFF
The outside mirrors can be operated
for about 40 seconds after the vehicle
power is switched from ON to off with
all doors closed. If any door is opened,
the outside mirrors will stop operating.
Driving
Mirrors
5-10*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautions
for the Rearview Mirror
WARNING
Do not stack luggage higher than the
seatback.
Loading luggage higher than the
seatback is dangerous. The rearview
mirror visibility may be obstructed,
which may result in a collision with
another vehicle when changing lanes.
How to Use the Rearview Mirror
Move and adjust the rearview mirror
body.
Driving
Mirrors
5-11
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Rearview Mirror
Glare prevention function
Prevents glare from the headlights of
rear on-coming vehicles.
Manual type
Push the day/night lever forward for
day driving. Pull it back to reduce glare
of headlights from vehicles at the rear.
Automatic type
Automatically operates when the
vehicle power is switched ON and the
selector lever is in a position other
than R.
Driving
Mirrors
5-12
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Do not apply accessories, stickers, or
film to the windshield near the
Forward Sensing Camera (FSC). If the
area in front of the Forward Sensing
Camera (FSC) lens is obstructed, it
will cause the system to not operate
correctly even if it is transparent.
 Always keep the windshield glass
around the Forward Sensing Camera
(FSC) clean by removing dirt or
fogging. If the windshield is fogged,
press the windshield defroster
switch.
 The Forward Sensing Camera (FSC)
includes a function for detecting a
soiled windshield and informing the
driver, however, depending on the
conditions, it may not detect plastic
shopping bags, water or snow on the
windshield. In such cases, the system
cannot accurately determine a
vehicle or obstruction in front and
may not be able to operate normally.
Always drive carefully and pay
attention to the road ahead.
 When cleaning the windshield, do
not allow glass cleaners or similar
cleaning fluids to get on the Forward
Sensing Camera (FSC) lens. In
addition, do not touch the Forward
Sensing Camera (FSC) lens.
 Consult an Authorized Mazda Dealer
regarding cleaning the interior side of
the windshield around the Forward
Sensing Camera (FSC).
 If there are cracks or damage caused
by flying gravel or debris on the
windshield, always have the
windshield replaced. Consult an
Authorized Mazda Dealer before
replacing the windshield.
 Consult an Authorized Mazda Dealer
before doing repairs around the
Forward Sensing Camera (FSC).When doing repairs around the
rearview mirror, consult an
Authorized Mazda Dealer.
 Always use tires of the specified size
and the same manufacturer, brand,
and tread pattern on all 4 wheels. In
addition, do not use tires with
significantly different wear patterns
or tire pressures on the same vehicle
(including temporary spare tire).
NOTE
If the Forward Sensing Camera (FSC)
does not function normally due to
fog or the vehicle being driven
towards the sun, the functions
related to the Forward Sensing
Camera (FSC) are temporarily
stopped. In this case, the following
warning indications turn on.
However, this does not indicate a
problem.
HBC warning indicationi-ACTIVSENSE warning indicationSBS OFF indicationIf the Forward Sensing Camera (FSC)
does not function normally due to
high temperatures, the functions
related to the Forward Sensing
Camera (FSC) are temporarily
stopped. In this case, the following
warning indications turn on.
However, this does not indicate a
problem. Cool down the area
around the Forward Sensing Camera
(FSC) such as by turning on the air
conditioner.
HBC warning indicationi-ACTIVSENSE warning indicationSBS OFF indication
Driving
Forward Sensing Camera (FSC)
5-128
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

CAUTION
Handle the cameras appropriately. If the cameras are handled incorrectly, images
may not be displayed normally.
Refer to Cameras on page 5-137.
 Do not use the 360° view monitor in th e following locations or conditions.
 Bumpy roads
 The vehicle is on a road incline.
 Icy or snow-covered roads
 Tire chains or a temporary spare tire is installed.
 The doors are not fully closed.
 The outside mirrors are retracted.
 If the doors are not completely closed, images and guide lines may not be
displayed correctly.
 Heed the following cautions to assure that the 360° view monitor operates
normally.
 Do not modify the suspensions.
 Always use wheels of the specified size for the front and rear wheels. Consult an
Authorized Mazda Dealer for tire replacement.
 When the center display is cold, images may leave trails or the display might be
darker than usual, making it difficult to check the vehicle surroundings. Always
confirm the safety around the vehicle visually when driving.
 Recognizing images at night may be
difficult because there are no lights in the
shooting range of the side camera. Always confirm the safety around the vehicle
visually when driving.
 The method for parking/stopping the vehicle using the 360° View Monitor
differs
depending on the road conditions and ve hicle conditions. In addition, when and
how much you turn the steering wheel will differ depending on the situation,
therefore always check the vehicle surroundings directly with your eyes while using
the system.
Driving
360° View Monitor
5-211
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Sunvisor
When blocking light from the front
When blocking light from the side
Unhook the sunvisor and swing it to
the side.
The visor extender extends the
sunvisor's range of sun shading.
To u s e , p u l l i t o u t .
CAUTION
When moving the sunvisor, retract the
visor extender to its original position.
Otherwise, the visor extender could hit
the rearview mirror.
Other Equipment
Sunvisor
7-39
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
