¾Do not mount any transceiver, microphones, speakers, or any other item in the deployment
path of the air bag system.
¾Do not fasten aerial lead to original vehicle wiring, fuel pipes or brake pipes. Avoid running
the aerial lead parallel with the wire harness to the best extent possible.
¾Keep the aerial and power leads at least 100 mm (3.9 in) from any electronic modules and
the air bags.
¾Avoid using the cigar lighter or accessory socket as a power source for the RF-transmitting
equipment.
Aerial positions:
: front right of roof
: front left of roof
: centre of roof
: both sides of liftgate (Hatchback)
) U H T X H Q F \ % D Q G 0 + ] 0 D [ L P X P R X W S X W S R Z H U : D W W D J H $ H U L D O 3 R V L W L R Q V
