When Driving
Instrument Cluster and Display
Ty p e B

*1The range varies depending on the type
of gauge. *
1Striped zone
*
1Red zone
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
Fuel Gauge
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Type A/Type B
Full
1/4 Full
Type C
Full1/4 Full
If the low fuel warning light illuminates or
the fuel level is very low, refuel as soon as
possible.
Refer to Warning/Indicator Lights on page
4-21 .
NOTE
 y  After refueling, it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve since
the fuel moves in the tank.
 y The display indicating a quarter or less
remaining fuel has more segments to
show the remaining fuel level in greater
detail.
 y The direction of the arrow ()
indicates that the fuel-fi ller lid is on the
left side of the vehicle.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.4–16
When Driving
Instrument Cluster and Display
Dashboard Illumination
Rotate the knob to adjust the brightness
of the instrument cluster and other
illuminations in the dashboard.
NOTE
 y The brightness of dashboard
illuminations can be adjusted when
the headlights and Parking lights are
turned on.
 y When the dashboard illumination
brightness cannot be adjusted any
more, a beep sound will be heard.
Dim
Bright
Canceling the illumination dimmer
When the headlight switch is in the
or
position, the illumination of the
instrument cluster dims.
When driving on snowy or foggy roads,
or in other situations when the instrument
cluster's visibility is reduced due to glare
from surrounding brightness, cancel the
illumination dimmer and increase the
illumination intensity.
To cancel the illumination dimmer, rotate
the knob clockwise fully. You will hear a
beep sound and the illumination dimmer
will be canceled.
NOTE
 y  This symbol () indicates the knob to
adjust the brightness of the dashboard
illumination.
 y  If the dashboard illumination knob is
kept at the illumination dimmer cancel
position, the instrument cluster will not
dim when the headlight switch is turned
to the
or position again. Rotate
the dashboard illumination knob
counterclockwise to activate the
illumination dimmer.
Outside Temperature Display *
When the ignition is switched ON, the
outside temperature is displayed.
NOTE
 y  Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and
vehicle conditions:
 y Signifi cantly cold or hot
temperatures.
 y Sudden changes in outside
temperature.
 y The vehicle is parked. y The vehicle is driven at low speeds.
The outside temperature unit can be
switched between Celsius and Fahrenheit
using the following procedure.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.4–17
When Driving
Instrument Cluster and Display
1. Press the INFO button with the ignition switched off and continue pressing the
INFO button for 5 seconds or longer
while switching the ignition ON. The
outside temperature display fl ashes.
2. Press the up
or down part of the
INFO switch to change the outside
temperature unit.
3. Press and hold the INFO button for 3 seconds or longer while the outside
temperature display is fl ashing. The
outside temperature display illuminates.
Cruise Control Set Vehicle Speed Display*
The vehicle speed preset using the cruise
control is displayed.
Trip Computer and INFO Switch *
The following information can be selected
by pressing the up
or down part of the
INFO switch with the ignition switched
ON.
 y  Approximate distance you can travel on
the available fuel
 y  Average fuel economy y Current fuel economy y Average vehicle speed
If you have any problems with your trip
computer, consult an Authorized Mazda
Dealer.
Distance-to-empty mode
This mode displays the approximate
distance you can travel on the remaining
fuel based on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.
NOTE
 y  Even though the distance-to-empty
display may indicate a suffi cient
amount of remaining driving distance
before refueling is required, refuel
as soon as possible if the fuel level is
very low or the low fuel warning light
illuminates.
 y  The display may not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
 y The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
(indicating the remaining fuel supply)
disappear.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–18
When Driving
Instrument Cluster and Display
Average fuel economy mode
This mode displays the average fuel
economy by calculating the total fuel
consumption and the total traveled
distance since purchasing the vehicle, re-
connecting the battery after disconnection,
or resetting the data. The average fuel
economy is calculated and displayed every
minute.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - L/100
km (- - - mpg) will be displayed for about
1 minute before the fuel economy is
recalculated and displayed.
Current fuel economy mode
This mode displays the current fuel
economy by calculating the amount of fuel
consumption and the distance traveled.
Current fuel economy will be calculated
and displayed every 2 seconds.
When you've slowed to about 5 km/h (3
mph), - - - L/100 km (- - - mpg) will be
displayed.
Average vehicle speed mode
This mode displays the average vehicle
speed by calculating the distance and the
time traveled since connecting the battery
or resetting the data.
Average vehicle speed will be calculated
and displayed every 10 seconds.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - km/h
(- - - mph) will be displayed for about
1 minute before the vehicle speed is
recalculated and displayed.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.4–19
When Driving
Instrument Cluster and Display
Active Driving Display *
Optical receiver
Mirror
Combiner
WARNING
Adjust the brightness or the display position while paying attention to s\
afe driving:
If you do not pay attention to your driving while trying to make the adjustments, it could
lead to an unexpected accident.
CAUTION


4–20
When Driving
Instrument Cluster and Display
The active driving display indicates the following information:
 y Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control (MRCC) on page 4-91 . y Lane Departure Warning System (LDWS) Operation Conditions and Warnings Refer to Lane Departure Warning System (LDWS) on page 4-119 . y Smart City Brake Support (SCBS) Operation Conditions and Warnings Refer to Smart City Brake Support (SCBS) on page 4-72 . y Forward Obstruction Warning (FOW) Operation Conditions and Warnings Refer to Forward Obstruction Warning (FOW) on page 4-116 . y Vehicle Speed Setting Using Cruise Control Refer to Cruise Control on page 4-100 . y Turn-by-Turn (TBT) (Direction and Distance) and Lane Guidance y Vehicle Speed
Each setting/adjustment for the active driving display can be performed \
on the Type B audio
display.
1. Select the (
) icon on the home screen and display the Settings screen.
2. Select the AD-Disp tab.
3. Select the desired item and perform the setting/adjustment.
yHeight : Active driving display positionyBrightness Control : Method for adjusting screen brightness (Automatically/Manually)yCalibration : Brightness initialization setting (when selecting automatic adjustment\
)yBrightness : Brightness adjustment (when selecting manual adjustment)yNavigation : On/OffyActive Driving Display : On/OffyReset
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–21
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifi cations.
Warning/Indicator lights will appear in any of the highlighted areas
Type A
Type B
Type C
Center of Dashboard (Digital Speed Meter Type)
(Analog Speed Meter Type (With Tachometer))
(Analog Speed Meter Type (Without Tachometer))
Instrument Cluster
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.4–22
When Driving
Instrument Cluster and Display
Warning Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Warning Lights Page
Master Warning Light *1 7-24
Brake System Warning Light *1*2 7-24
ABS Warning Light *1 7-24
Charging System Warning Light *1 7-24
Engine Oil Warning Light *1 7-24
Check Engine Light *1 7-24
(Red) High Engine Coolant Temperature Warning Light
*1
7-24
* Automatic Transaxle Warning Light *1 7-24
Power Steering Malfunction Indicator Light *1 7-24
Air Bag/Front Seat Belt Pretensioner System Warning Light *1 7-24
Low Fuel Warning Light 7-24
Check Fuel Cap Warning Light *1 7-24
Seat Belt Warning Light 7-24
Door-Ajar Warning Light 7-24
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.4–23
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light 7-24
(Red)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Warning Light *1 4-78 ,
4-118
(Amber)
* Lane Departure Warning System (LDWS) Warning Light *1*3 7-24
(Amber)
* High Beam Control System (HBC) Warning Light *1 7-24
(Amber)
* Mazda Radar Cruise Control (MRCC) Warning Light *1 7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
*3 The light turns on when the system on stand-by. The light fl ashes when the system has a malfunction.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.4–24
When Driving
Instrument Cluster and Display
Indicator Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Indicator Lights Page
* BSM OFF Indicator Light 4-114
(Green)
* Lane Departure Warning System (LDWS) Indicator Light 4-122
(Green) KEY Indicator Light 3-9
(Green)
* High Beam Control System (HBC) Indicator Light
4-50
Wrench Warning Indicator Light *1 4-26
TCS/DSC Indicator Light *1 4-80 ,
4-81
DSC OFF Indicator Light *1 4-82
* AFS OFF Indicator Light *1 4-46
(Amber)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Indicator Light *1 4-78
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS) OFF
Indicator Light *1 4-78
* i-ELOOP Indicator Light 4-85
(Blue) Low Engine Coolant Temperature Indicator Light 4-26
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
