display MAZDA MODEL 3 4-DOOR 2014 Owner's Guide

4–98
When Driving
Mazda Radar Cruise Control (MRCC)
NOTE
 y When accelerating using the SET
switch while in headway control, the set
vehicle speed can be adjusted but
acceleration is not possible. If there is
no longer a vehicle ahead, acceleration
continues until reaching the set vehicle
speed. Check the set vehicle speed by
viewing the set vehicle speed display in
the active driving display.
 y When depressing the accelerator pedal,
the inter-vehicle distance display in
the display in the instrument cluster
changes to the white-line display.
 y The minimum settable speed is 30 km/h
(19 mph). If the set vehicle speed
reaches 30 km/h (19 mph) using the
switch operation, constant speed travel
is maintained at about 30 km/h (19
mph) even if the SET
switch is
pressed. The Mazda Radar Cruise
Control (MRCC) system is not
canceled.
To Deactivate
The Mazda Radar Cruise Control (MRCC)
is canceled when the OFF switch is
pressed.
When the system is temporarily
canceled
In the following cases, the Mazda Radar
Cruise Control (MRCC) system is
temporarily canceled and the “MRCC
Cancelled” indication is displayed in
the display in the instrument cluster.
The Mazda Radar Cruise Control
(MRCC) indicator light (green) turns off
simultaneously.
 y  The CANCEL switch is pressed. y The brake pedal is depressed. y The parking brake is applied. y The selector lever is shifted to park (P),
neutral (N) or reverse (R) (automatic
transaxle).
 y  The shift lever is in the reverse (R)
position (manual transaxle).
 y  In the following cases, the “MRCC
Cancelled” indication is displayed and
the beep sounds one time.
y The vehicle speed decreases to less than 25 km (16 mph).
y The DSC has operated.y The TCS has operated for a certain period of time.
y The Smart City Brake Support (SCBS) has operated.
y When traveling on a down slope for a long period of time.
y There is a problem with the system.y The engine stalls.
(Manual transaxle)
y The shift lever is shifted to neutral (N) for a certain period of time.
y The clutch is depressed for a certain period of time.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–99
When Driving
Mazda Radar Cruise Control (MRCC)
NOTE
 y The Mazda Radar Cruise Control
(MRCC) system may be canceled
during rain, fog, snow or other
inclement weather conditions, or the
front surface of the radiator grille is
dirty.
 y If the Mazda Radar Cruise Control
(MRCC) system has been temporarily
canceled, you can return to the
previously set vehicle speed by pressing
the RESUME switch after the following
conditions have been met.
 y All of the Mazda Radar Cruise
Control (MRCC) operation
conditions have been met.
 y A certain period of time has elapsed
since the system was automatically
canceled while driving for a long
time on a down slope.
 y If the SET / SET or RESUME switch
is pressed before a certain period of
time has elapsed since the system was
automatically canceled while driving
for a long time on a down slope,
“MRCC Not available” is displayed in
the display.
 y  If the OFF switch is pressed to cancel
the Mazda Radar Cruise Control
(MRCC), the system does not return
to the previously set speed even if the
RESUME switch is pressed.
Shift-up/Shift-down Request Display (Manual Transaxle)
The shift-up or shift-down request display
in the display of the instrument cluster
may be displayed while the Mazda
Radar Cruise Control (MRCC) system
is operating. When this occurs, shift
gears because the gear position is not
appropriate.
Request Indication on display
Shift up
Shift down
NOTE
 y  If the gears are not shifted up even
though the shift-up request indication
is displayed, load will be applied
to the engine and the Mazda Radar
Cruise Control (MRCC) system may
be automatically canceled or engine
damage could occur.
 y If the gears are not shifted down
even though the shift-down request
indication is displayed, the Mazda
Radar Cruise Control (MRCC) system
may be automatically canceled or
engine stalling could occur.
Radar Sensor Handling
The Mazda Radar Cruise Control (MRCC)
radar sensor is installed on the backside of
the radiator grille.
Refer to Radar Sensor on page 4-65 .
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–102
When Driving
Cruise Control
To Increase Cruising Speed
Follow either of these procedures.
To increase speed using cruise control
switch
Press the SET
switch and hold it. Your
vehicle will accelerate. Release the switch
at the speed you want.
Press the SET
switch and release it
immediately to adjust the preset speed.
Multiple operations will increase the
preset speed according to the number of
times it is operated.
Increasing speed with a single SET
switch operation
Meter display for vehicle speed indicated
in km/h: 1 km/h (0.6 mph)
Meter display for vehicle speed indicated
in mph: 1 mph (1.6 km/h)
To increase speed using accelerator
pedal
Depress the accelerator pedal to accelerate
to the desired speed. Press the SET
or
SET
switch and release it immediately.
NOTE
Accelerate if you want to speed up
temporarily when the cruise control is on.
Greater speed will not interfere with or
change the set speed. Take your foot off the
accelerator to return to the set speed.
To Decrease Cruising Speed
Press the SET switch and hold it. The
vehicle will gradually slow.
Release the switch at the speed you want.
Press the SET
switch and release it
immediately to adjust the preset speed.
Multiple operations will decrease the
preset speed according to the number of
times it is operated.
Decreasing speed with a single SET
switch operation
Meter display for vehicle speed indicated
in km/h: 1 km/h (0.6 mph)
Meter display for vehicle speed indicated
in mph: 1 mph (1.6 km/h)
To Resume Cruising Speed at More Than 25 km/h (16 mph)
If some other method besides the OFF
switch was used to cancel cruising speed
(such as applying the brake pedal) and the
system is still activated, the most recent
set speed will automatically resume when
the RESUME switch is pressed.
If vehicle speed is below 25 km/h (16
mph), increase the vehicle speed up to
25 km/h (16 mph) or more and press the
RESUME switch.
To Temporarily Cancel
To temporarily cancel the system, use one
of these methods:
 y  Slightly depress the brake pedal. y Depress the clutch pedal (Manual
transaxle only).
 y  Press the CANCEL switch.
If the RESUME switch is pressed when
the vehicle speed is 25 km/h (16 mph) or
higher, the system reverts to the previously
set speed.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–117
When Driving
Forward Obstruction Warning (FOW)
 y Although the objects which activate the system are 4-wheeled vehicles, the radar sensor
could detect the following objects, determine them to be an obstruction,\
and operate the
Forward Obstruction Warning (FOW) system.
 y Objects on the road at the entrance to a curve (including guardrails and snow banks). y A vehicle appears in the opposite lane while cornering or rounding a curve. y When crossing a narrow bridge. y When passing under a low gate or through a tunnel or narrow gate. y When entering an underground parking area. y Metal objects, bumps, or protruding objects on the road. y If you suddenly come close to a vehicle ahead. y When driving in areas where there is high grass or forage. y Two-wheeled vehicles such as motorbikes or bicycles. y Pedestrians or non-metallic objects such as standing trees.
 y When the system operates, the user is notifi ed by the fl ashing warning light and the active
driving display.
 y The indicator light turns on when the system has a malfunction. (page 4-22 )
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–118
When Driving
Forward Obstruction Warning (FOW)
Forward Obstruction Warning (FOW) Warning Light (Red)
If the Forward Obstruction Warning
(FOW) is operating, the warning light
fl ashes.
Collision Warning
If there is the possibility of a collision
with a vehicle or obstruction ahead, the
beep sounds continuously and a warning is
indicated in the display.
Stopping The Forward
Obstruction Warning (FOW)
System Operation
The Forward Obstruction Warning (FOW)
system can be deactivated.
Refer to Personalization Features on page
9-12 .
When the Forward Obstruction Warning
(FOW) system is turned off, the Forward
Obstruction Warning (FOW) OFF
indicator light turns on.
Radar Sensor Handling
The Forward Obstruction Warning (FOW)
radar sensor is installed on the backside of
the radiator grille.
Refer to Radar Sensor on page 4-65 .
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–122
When Driving
Lane Departure Warning System (LDWS)
When The System Operates
1. Press the LDWS switch. The LDWS goes on stand-by and the LDWS
warning light (amber) illuminates.
The lane indication (bordered line) is
indicated in the active driving display
(Type A instrument cluster
*1 ) or the
multi information display (Type B
instrument cluster
*1 ).
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
Indication on display
2. Drive the vehicle near the center of the lane and the LDWS indicator light
(green) illuminates in the instrument
cluster when all of the following
conditions are met.
y The vehicle is driven near the center of the lane with the white or yellow line
on the left and right sides, or on either
side.
y The vehicle speed is about 70 km/h (44 mph) or more
y The vehicle is driven on a straight road or road with gentle curves
 The lane indication is indicated in the active driving display (Type
A instrument cluster
*1 ) or the
multi information display (Type B
instrument cluster
*1 ).
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
Indication on display
NOTE
 y  The LDWS remains on stand-by until it
detects white or yellow lines on both the
left and right sides, or on either side.
 y When the system detects a white or
yellow line on one side only, the system
will operate the warning only when the
vehicle deviates to the side the white or
yellow line detected.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–123
When Driving
Lane Departure Warning System (LDWS)
Auto cancel
Under the following conditions, the
LDWS is automatically canceled and
kept on stand-by, and the LDWS warning
light (amber) in the instrument cluster
illuminates.
 y The system cannot detect white or
yellow lines.
 y  The vehicle speed is less than about 65
km/h (40 mph).
 y  The vehicle is making a sharp turn. y The vehicle is making a turn at an
inadequate speed.
 y  The temperature inside the camera is
high or low.
 y  The windshield around the camera is
foggy.
 y  The windshield around the camera is
blocked by an obstruction, causing poor
forward visibility.
The lane indication (bordered line) is
indicated in the active driving display
(Type A instrument cluster
*1 ) or the multi
information display (Type B instrument
cluster
*1 ).
The LDWS is automatically enabled when
the condition changes and the system is
operable.
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
Auto cancel of warning
Under the following conditions, the
LDWS determines that the driver is
making lane changes and the warning is
automatically canceled.
The LDWS is automatically enabled after
the operation.
 y The steering wheel is operated abruptly. y The brake pedal is depressed abruptly. y The accelerator pedal is depressed
abruptly.
 y  A turn signal lever is operated (after the
turn signal lever is returned, the LDWS
warning may not operate for about 3
seconds which is the period of time
required to make a lane correction).
NOTE
 y  After about 5 seconds have elapsed
with the turn signal lever left operating,
the LDWS warning may operate if the
vehicle is close to a white or yellow
line.
 y The sensitivity of the warning
(sensitivity with which the system
determines the driver's intentional lane
change) can be changed.
 Refer to Personalization Features on page 9-12 .
Canceling The System
To cancel the LDWS, press the LDWS
switch. The LDWS indicator light (Green/
Amber) in the instrument cluster turns off.
The lane indication displayed in the
active driving display (Type A instrument
cluster
*1 ) or the multi information display
(Type B instrument cluster *1 ) turns off.
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–124
When Driving
Lane Departure Warning System (LDWS)
LDWS Warning
If the system determines that the vehicle
may be deviating from its lane while the
system is operating, the LDWS warning
sounds and the LDWS indicator light
(green) fl ashes.
Refer to Lane Departure Warning System
(LDWS) Warning Sound on page 7-38 .
In the active driving display (Type
A instrument cluster
*1 ) or the multi
information display (Type B instrument
cluster
*1 ), the direction in which the
system determined that the vehicle may
be deviating from its lane is indicated.
Operate the steering wheel adequately and
drive in the center of the lane.
*1 To determine which instrument cluster is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
Indication on display
NOTE
 y  If the LDWS warning sound is set to
rumble, the sound will be heard from
the vehicle speaker on the side which
the system determined the vehicle may
be deviating from its lane.
 y The LDWS warning sound may not be
heard depending on the surrounding
conditions such as outside noise.
 y The warning timing with which the
system determines the vehicle may be
deviating from its lane can be changed.
 Refer to Personalization Features on page 9-12 .
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–126
When Driving
Rear View Monitor
Rear View Parking Camera Location
Rear View Parking Camera
4-Door 5-Door
Switching to the Rear View Monitor Display
Shift the shift lever to R with the ignition switched ON to switch the d\
isplay to the rear view
monitor display.
NOTE
When the shift lever is shifted from R to another shift lever position, the screen returns to the
previous display.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

4–127
When Driving
Rear View Monitor
Displayable Range on the Screen
The images on the screen may be different from the actual conditions.
(Screen display)(Actual view) Object
Trunk lid (4-door)/
garnish (5-door)
Bumper
NOTE
 y
 The displayable range varies depending on the vehicle and road conditions. y The displayable range is limited. Objects under the bumper or around the bumper ends
cannot be displayed.
 y The distance appearing in the displayed image is different from the actual distance
because the rear view parking camera is equipped with a specifi c lens.
 y Some optionally installed vehicle accessories may be picked up by the ca\
mera. Do not
install any optional parts that can interfere with the camera view, such as illuminating
parts or parts made of refl ective material.
 y It may be diffi cult to see the display under the following conditions, however, it does not
indicate a malfunction.
 y In darkened areas. y When the temperature around the lens is high/low. y When the camera is wet such as on a rainy day or during periods of high \
humidity. y When foreign material such as mud is stuck around the camera. y When the camera lens refl ects sunlight or headlight beams.
 y Image display may be delayed if the temperature around the camera is low.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
