7–31
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
Seat Belt
Warning Light
With warning light for front passenger's seat
The seat belt warning light illuminates if the driver or front passenger\
's seat is occupied and the
seat belt is not fastened with the ignition switched ON.
Without warning light for front passenger's seat
The seat belt warning light illuminates if the driver's seat is occupied\
and the seat belt is not
fastened with the ignition switched ON.
Seat belt reminder
NOTE
Consult an Authorized Mazda Dealer to deactivate or restore the belt reminder. Though the belt
reminder can be deactivated, doing so will defeat the purpose of the syst\
em to warn the driver and
the front passenger in the event that their seat belts are not fastened. For the safety of the driver
and front passenger, Mazda recommends not deactivating the belt reminder.
Front seat
If the vehicle is driven with the driver or front passenger's seat belt \
unfastened, the seat belt
warning light illuminates and a warning beep sounds.
NOTE
Some models do not have the seat belt reminder function for the front passenger's seat.
If the driver or front passenger's seat belt is unfastened (only when t\
he front passenger seat is
occupied) and the vehicle is driven at a speed faster than about 20 km/\
h (12 mph), the warning light
will fl ash and a beep sound will be heard. After a short time, the warning light stops fl ashing, but
remains illuminated, and the beep sound stops.
Until a seat belt is fastened or a given period of time has elapsed, the\
beep sound will not stop even
if the vehicle speed falls below 20 km/h (12 mph).
NOTE
yThe warning light fl ashes and a beep sound will be heard for about 6 seconds if the driver's seat
belt is not fastened when the ignition is switched ON.
y If a driver or front passenger's seat belt is unfastened after the beep sound turns off (\
warning light remains illuminated), and the vehicle speed exceeds 20 km/h (12 mph), \
the warning light fl ashes
and beep sound activates again.
yPlacing heavy items on the front passenger seat may cause the front passenger seat belt warning function to operate depending on the weight of the item.
yTo allow the front passenger seat weight sensor to function properly, do not place and sit on an additional seat cushion on the front passenger seat. The sensor may not function properly
because the additional seat cushion could cause sensor interference.
y When a small child sits on the front passenger seat, it is possible that the warning light will not operate.
Door-Ajar Warning Light The light turns on if any door is not closed
securely.
Close the door securely.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 502 of 586
*Some models.7–32
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
Low Washer
Fluid Level Warning Light This warning light indicates that little washer
fl
uid remains. Add washer fl
uid (page 6-31 ).
Tire
Pressure
Monitoring System
Warning Light
*
When the warning light illuminates, and the
warning beep sound is heard (about 3 seconds),
tire pressure is too low in one or more tires.
WARNING
If the tire pressure monitoring system
warning light illuminates or fl ashes, or the
tire pressure warning beep sound is heard,
decrease vehicle speed immediately and
avoid sudden maneuvering and braking: If the tire pressure monitoring system
warning light illuminates or fl ashes, or the
tire pressure warning beep sound is heard,
it is dangerous to drive the vehicle at high
speeds, or perform sudden maneuvering
or braking. Vehicle drivability could worsen
and result in an accident.
To determine if you have a slow leak or a
fl at, pull over to a safe position where you
can check the visual condition of the tire
and determine if you have enough air to
proceed to a place where air may be added
and the system monitored again by an
Authorized Mazda Dealer or a tire repair
station.
Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is
dangerous, even if you know why it is
illuminated. Have the problem taken care of
as soon as possible before it develops into
a more serious situation that could lead to
tire failure and a dangerous accident. Inspect the tires and adjust to the specifi
ed
infl ation pressure (page 6-41 ).
NOTE
yPerform tire pressure adjustment when the tires
are cold. Tire pressure will vary according
to the tire temperature, therefore let the
vehicle stand for 1 hour or only drive it 1.6
km (1 mile) or less before adjusting the tire
pressures. When pressure is adjusted on hot
tires to the cold infl ation pressure, the TPMS
warning light/beep may turn on after the tires
cool and pressure drops below specifi cation.
Also, an illuminated TPMS warning light,
resulting from the tire air pressure dropping
due to cold ambient temperature will remain
illuminated even if the ambient temperature
rises. In this case, it will also be necessary
to adjust the tire air pressures. If the TPMS
warning light illuminates due to a drop in tire
air pressure, make sure to check and adjust the
tire air pressures.
yTires lose air naturally over time and the TPMS cannot tell if the tires are getting too
soft over time or you have a fl at. However,
when you fi nd one low tire in a set of four-that
is an indication of trouble; you should have
someone drive the vehicle slowly forward
so you can inspect any low tire for cuts and
any metal objects sticking through tread or
sidewall. Put a few drops of water in the valve
stem to see if it bubbles indicating a bad
valve. Leaks need to be addressed by more
than simply reinfl ating the tire as leaks are
dangerous — take it to an Authorized Mazda
Dealer.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 503 of 586
*Some models.7–33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
(Amber)
Forward
Obstruction Warning/ Smart
City Brake Support(FOW/SCBS)
Indicator Light
*
The light turns on if the windshield and the radar
sensor are dirty or there is a malfunction in the
system. Verify the reason why the warning light is
illuminated on the audio display (page 7-24 ).
If the reason why the warning light is
illuminated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because of a
dirty radar sensor, clean the front emblem.
For any other reasons, have the vehicle
inspected at an Authorized Mazda Dealer.
KEY Warning Light
Take the appropriate action and verify that the warning light turns off.
Signal
Cause Action to be taken
(Red)
(Flashing) The advanced key battery is dead. Replace the battery (page 6-39 ).
The advanced key is not within the
operation range.
Bring the advanced key into the operation
range (page 3-7 ).
The advanced key is placed in areas inside
the cabin where it is diffi
cult for the key to
be detected.
A key from another manufacturer similar to
the advanced key is in the operation range. Take the key from another manufacturer
similar to the advanced key out of the
operation range.
Without the ignition switched off, the
advanced key is taken out of the cabin, and
then all the door are closed. Bring the advanced key back into the
cabin.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 504 of 586
*Some models.7–34
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated on Display *
If a message is displayed in the type B audio display, take appropriate action (in a calm
manner) according to the displayed message.
(Display example)
Stop Vehicle in Safe Place Immediately
If the following messages are displayed in the Type B audio display, a vehicle system may
be malfunctioning. Stop the vehicle in a safe place and contact an Authorized Mazda Dealer.
Display Indicated Condition
Displays if the engine coolant temperature has increased
excessively.
Displays if the charging system has a malfunction.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 505 of 586
7–35
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Make Sure the Message is No Longer Displayed
Displays in the following cases:
Display Indicated Condition/Action to be taken
Displays if i-ELOOP requires charging. Leave the engine
idling and wait until the message disappears.
NOTE
y If the vehicle is driven while the message is displayed, the
buzzer will sound.
y If you turn the steering wheel while the message is displayed, it will feel heavier than normal, but this does
not indicate an abnormality. The steering operation will
return to normal after the message has disappeared.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D / C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 506 of 586
7–36
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Warning Sound is Activated
