Page 511 of 524
9–7
Specifi cations
Specifi cations
Weights
U.S.A. and Canada
Item Weight
Manual transaxle Automatic transaxle
GVWR (Gross Vehicle Weight Rating) 1,772 kg (3,907 lbs) 1,815 kg (4,001 lbs)
GAWR (Gross Axle Weight Rating) Front
925 kg (2,039 lbs) 975 kg (2,149 lbs)
Rear 855 kg (1,885 lbs) 848 kg (1,870 lbs)
Mexico
Item Weight
Manual transaxle Automatic transaxle
GVW (Gross Vehicle Weight) Total
1,815 kg (4,001 lbs) 1,835 kg (4,045 lbs)
Front 920 kg (2,028 lbs) 940 kg (2,072 lbs)
Rear 895 kg (1,973 lbs) 895 kg (1,973 lbs)
GAW (Permissible axle load) Front
945 kg (2,083 lbs) 965 kg (2,127 lbs)
Rear 945 kg (2,083 lbs) 945 kg (2,083 lbs)
Air Conditioner
The type of refrigerant used is indicated on a label attached to the ins\
ide of the engine
compartment. Check the label before recharging the refrigerant. Refer to Climate Control
System on page 5-2 .
Item Classifi cation
Refrigerant Type HFC134a (R-134a)
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 512 of 524
*Some models.9–8
Specifi cations
Specifi cations
Light Bulbs
Exterior light
Light bulb Category
Wattage ECE R (SAE)
Headlights High beam 65
HB3 (9005)
Low beam 55 H11 (H11)
Daytime running lights 65 HB3 (9005)
Parking lights (Front side-marker lights) 5 WY5W (—)
Front turn signal lights 21 WY21W (7443NA)
Fog lights
* 55 H11 (H11)
Side turn signal lights * LED *1 — (—)
High-mount brake light LED *1 — (—)
Rear turn signal lights 21 WY21W (7443NA)
Brake lights/Taillights/Rear side-marker light 21/5 W21/5W (7443)
Reverse lights 4-Door
18 W16W (921)
5-Door 21 W21W (7440)
License plate lights 5 W5W (—)
*1 LED is the abbreviation for Light Emitting Diode.
Interior light
Light bulb Category
Wattage ECE R
Trunk light (4-Door) 3 —
Luggage compartment light (5-Door) 5 —
Overhead lights (Front)/Map lights
* 8 —
Overhead light (Front) * 10 —
Overhead light (Rear) * 10 —
Vanity mirror lights * 2 —
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 513 of 524
9–9
Specifi cations
Specifi cations
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fi tted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and infl ation pressure.
Refer to Tire Infl ation Pressure on page 6-41 .
After adjusting the tire pressure, initialization of the tire pressure m\
onitoring system is
necessary to make the system operates normally.
Refer to Tire Pressure Monitoring System Initialization on page 4-64
Standard tire
Tire size Infl
ation pressure
Front Rear
P205/60R16 91H 250 kPa (2.5 bar, 36 psi) 250 kPa (2.5 bar, 36 psi)
Temporary spare tire
Tire size Infl ation pressure
T125/70D16 96M 420 kPa (60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108—147 N·m (12—14 kgf·m, 80—108 ft·lbf)
Fuses
Refer to Fuses on page 6-57 .
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 514 of 524
9–10
Specifi cations
Personalization Features
Personalization Features
The following personalization feature is available. This setting can only be changed by an
Authorized Mazda Dealer.
Items in which the feature setting can be changed differ depending on the market and
specifi cation.
Item Feature Factory Setting Available Settings
Daytime running
lights The function of the daytime running lights can
be changed.
On
On/Off
The following personalization features can be changed by the vehicle own\
er.
Items in which the feature setting can be changed differ depending on the market and
specifi cation.
Item Feature Factory Setting Available Settings
Power door lock Changes the auto lock/unlock function setting
for all the doors according to the vehicle speed,
the vehicle power supply condition, and the
selector lever position.
Refer to Auto Lock/Unlock Function on page
3-16 .
Refer to Settings on page 5-53 . Lock: When
Driving Unlock: IGN Off Lock: Shifting from
Park Unlock: In Park/ Lock: Shifting from Park/
Lock: When Driving Unlock: IGN Off/
Lock: When Driving/ Off
Keyless entry
system The method for unlocking the doors using the
transmitter can be changed.
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-53 .
Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice: All Doors
The time required for the doors to relock
automatically after unlocking with the
transmitter can be changed.
Refer to Settings on page 5-53 . 60 seconds
90 seconds/
60 seconds/
30 seconds
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 515 of 524
9–11
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Advanced keyless
entry system The volume of the answer-back beep during
advanced keyless entry system operation can
be changed.
Refer to Locking, Unlocking with Request
Switch (With the advanced keyless function)
on page 3-12 .
Refer to Settings on page 5-53 .
Medium
High/
Medium/ Low/ Off
The function to automatically lock the doors
when leaving the vehicle while carrying the
key can be changed.
Refer to Settings on page 5-53 . Off
On/Off
The method for unlocking the doors using the
request switch/transmitter can be changed.
Refer to Locking, Unlocking with Request
Switch (With the advanced keyless function)
on page 3-12 .
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-53 . Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice: All Doors
The time required for the doors to relock
automatically after unlocking with the request
switch/transmitter can be changed.
Refer to Settings on page 5-53 . 60 seconds
90 seconds/
60 seconds/
30 seconds
Illumination entry The time required for the interior lamp to turn
off automatically can be changed (prevents
battery depletion when a door is open/ajar).
Refer to Settings on page 5-53 .
30 minutes
60 minutes/
30 minutes/
10 minutes
The time required for the interior lamp to turn
off automatically after all doors are closed can
be changed.
Refer to Settings on page 5-53 . 15 seconds 60 seconds/
30 seconds/
15 seconds/
7.5 seconds
Three-fl ash turn
signal The three-time fl
ash function can be changed.
Refer to Settings on page 5-53 . On
On/Off
Auto-wiper control The auto-wiper control function can be
changed.
Refer to Settings on page 5-53 . On
On/Off
Auto headlight off
*1 The time required for headlights to turn off
after ignition is switched off can be changed.
Refer to Settings on page 5-53 . 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off
*2
Auto-light control The headlight illumination on/off timing based
on surrounding lightness/darkness can be
changed.
Refer to Settings on page 5-53 . Medium Light/
Medium Light/ Medium/
Medium Dark/ Dark
Turn indicator The turn indicator beep volume level can be
changed.
Refer to Settings on page 5-53 . High
High/Low
Lights-on reminder
*3 The volume of the lights-on reminder warning
alarm can be changed.
Refer to Settings on page 5-53 . Off
High/Low/Off
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 516 of 524
9–12
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Blind Spot
Monitoring (BSM)
system The volume of the BSM warning beep can be
changed.
*4
Refer to Settings on page 5-53 .
High High/
Low/ Off
Display The distance unit can be changed.
Refer to Settings on page 5-53 .
Miles or Km Miles/Km
The display language can be changed.
Refer to Settings on page 5-53 . English, French,
or Spanish English/
French/
Spanish
The temperature unit can be changed.
Refer to Settings on page 5-53 . F° or C°
F°/C°
Fuel Economy
Monitor Setting can be changed so that the ending
screen of the Fuel Economy Monitor is
displayed.
Refer to Fuel Economy Monitor on page 4-54 .
OFF
ON/OFF
Fuel economy
resetting procedure Setting can be changed so that the fuel
economy reset is linked with the trip meter
reset.
Refer to Fuel Economy Monitor on page 4-54 .
OFF
ON/OFF
*1 If the setting is changed to Off, the following operation is performed according to the headlight switc\
h position:
y At position: Headlights turn off immediately after the ignition is switched off. y At any position other than : Headlights do not turn off after the ignition is switched off.
*2 When set to Off, the lights-on reminder is operable.
*3 The setting of the lights-on reminder can be changed with the time setti\
ng of auto headlight off function set to Off. Refer to Lights-On Reminder on page 7-34 .
*4 Only the volume of the warning beep during Blind Spot Monitoring (BSM)\
operation can be changed. The volume of the warning beep during Rear Cross Traffi c Alert (RCTA) operation cannot be changed.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 517 of 524
10–1
10Index
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 518 of 524
10–2
Index
A
Accessory Socket .............................. 5-132
Add-On Non-Genuine Parts and
Accessories ......................................... 8-18
Advanced Key Advanced keyless entry system ...... 3-9
Operational range .......................... 3-10
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ......................... 7-34
Air Bag Systems ................................. 2-40
Ambient Temperature Display ............ 4-13
Antilock Brake System (ABS) ............ 4-50
Audio Control Switch Adjusting the Volume .................... 5-56
Mute Switch .................................. 5-56
Seek Switch ................................... 5-56
Audio System ...................................... 5-16 AUX/USB/iPod mode ................... 5-57
Antenna ......................................... 5-16
Audio Control Switch ................... 5-55
Audio Set (Type A) ....................... 5-25
Audio Set (Type B) ....................... 5-36
Operating Tips for Audio System ... 5-17
Satellite Radio ............................... 5-45
Automatic Transaxle ........................... 4-24 Active Adaptive Shift (AAS) ........ 4-26
Driving tips.................................... 4-32
Manual shift mode......................... 4-27
Shift-lock system ........................... 4-26
Shift position indication ................ 4-25
Warning light ................................. 4-25
B
Battery ................................................. 6-36 Maintenance .................................. 6-38
Specifi cations .................................. 9-4
Battery runs out ................................... 7-15 Jump-Starting ................................ 7-15
Blind Spot Monitoring (BSM) System ... 4-65
BSM OFF switch........................... 4-71
BSM warning light ........................ 4-70
Blind Spot Monitoring (BSM) ...... 4-66
Care of radar sensors ..................... 4-71
Blind Spot Monitoring (BSM) System
warning beep ....................................... 7-36
Blind Spot Monitoring (BSM) system
Rear Cross Traffi c Alert (RCTA) ... 4-68
Bluetooth® ........................................... 5-73
Bluetooth® Audio (Type A) ......... 5-111
Bluetooth® Audio (Type B) ......... 5-113
Bluetooth® Hands-Free (Type A) ... 5-93
Bluetooth® Hands-Free (Type B) ... 5-99
Troubleshooting .......................... 5-126
Body Lubrication ................................ 6-32
Bottle Holder ..................................... 5-135
Brakes Brakes assist .................................. 4-48
Foot brake...................................... 4-46
Pad wear indicator ......................... 4-47
Parking brake ................................ 4-47
Warning light ................................. 4-47
Break-In .............................................. 3-45
C
Capacities .............................................. 9-5
Carbon Monoxide ............................... 3-29
Cell Phones ......................................... 8-19
Center Console .................................. 5-136
Child Restraint Child-restraint precautions ............ 2-22
Installing child-restraint systems... 2-28
LATCH child-restraint systems ..... 2-36
Child Safety Locks for Rear Doors ..... 3-20
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 519 of 524
10–3
Index
Climate Control System ........................ 5-2 Automatic Climate Control ............. 5-9
Dual-Zone Automatic Climate
Control........................................... 5-12
Gas specifi cations ............................ 9-7
Manual Climate Control .................. 5-5
Operating Tips ................................. 5-2
Vent Operation ................................ 5-3
Clock ................................................... 5-28
Cruise Control ..................................... 4-57 Cruise Control Switch ................... 4-57
Cruise Control Set Vehicle Speed
Display ................................................ 4-14
Cup Holder ........................................ 5-134
Customer Assistance ............................. 8-2
D
Dashboard Illumination ...................... 4-12
Daytime Running Lights ..................... 4-37
Defogger Rear window ................................. 4-43
Mirror ............................................ 4-44
Dimensions ........................................... 9-5
Door Locks .......................................... 3-11
Driving In Flooded Area ..................... 3-49
Driving Tips Automatic transaxle ...................... 4-32
Break-in ......................................... 3-45
Driving in fl ooded area.................. 3-49
Driving on uneven road ................. 3-51
Floor mat ....................................... 3-46
Hazardous driving ......................... 3-46
Money-saving suggestions ............ 3-45
Overloading ................................... 3-50
Rocking the vehicle ....................... 3-47
Winter driving ............................... 3-47
Driving on Uneven Road .................... 3-51
Dynamic Stability Control (DSC) ....... 4-52 DSC OFF Indicator Light.............. 4-53
DSC OFF Switch........................... 4-53
TCS/DSC Indicator Light ............. 4-52
E
Emergency Starting Push-Starting ................................. 7-18
Starting a Flooded Engine ............. 7-18
Emergency Towing Tiedown Hooks ............................. 7-22
Towing Description ....................... 7-21
Emission Control System .................... 3-28
Ending Screen Display ........................ 4-55
Engine Coolant .......................................... 6-29
Engine Compartment Overview .... 6-26
Exhaust gas.................................... 3-29
Hood release .................................. 6-24
Oil .................................................. 6-27
Starting ............................................ 4-3
Essential information ............................ 6-2
Event Data Recorder ........................... 8-20
Exhaust Gas ........................................ 3-29
Exterior Care ....................................... 6-63
Aluminum Wheel Maintenance .... 6-68
Bright-Metal Maintenance ............ 6-67
Maintaining the Finish .................. 6-65
Plastic Part Maintenance ............... 6-68
F
Flasher Hazard warning ............................. 4-45
Headlights ..................................... 4-33
Flat Tire ................................................. 7-3 Mounting the Spare Tire................ 7-11
Removing a Flat Tire ....................... 7-7
Floor Mat ............................................ 3-46
Fluid
Brake/Clutch ................................. 6-31
Washer ........................................... 6-31
Fluids Classifi cation ................................... 9-4
Fog Lights ........................................... 4-37
Foot Brake ........................................... 4-46
Front Seat .............................................. 2-5
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 520 of 524
10–4
Index
Fuel Filler lid and cap............................ 3-30
Gauge ............................................ 4-12
Requirements................................. 3-27
Tank capacity .................................. 9-5
Fuel Consumption Display ................. 4-55
Fuel Economy Monitor ....................... 4-54 Ending screen display ................... 4-55
Fuel consumption display ............. 4-55
G
Gauges ................................................... 4-9
Glove Compartment .......................... 5-136
H
Hazard Warning Flasher ...................... 4-45
Hazardous Driving .............................. 3-46
Head Restraint ..................................... 2-10
Headlights Control........................................... 4-33
Flashing ......................................... 4-36
High-low beam .............................. 4-36
Hill Launch Assist (HLA) ................... 4-48
Hood Release ...................................... 6-24
Horn .................................................... 4-44
I
If a Warning Light Turns On or
Flashes................................................. 7-24
Ignition Switch .............................................. 4-2
Ignition not switched off (STOP) warning
beep ..................................................... 7-35
Immobilizer System ............................ 3-41
Indicator Lights ................................... 4-19
BSM OFF ...................................... 4-71
Low engine coolant temperature ... 4-20
Wrench .......................................... 4-20
Inside Trunk Release Lever ................ 3-25
Inspecting Brake/Clutch Fluid Level ... 6-31 Inspecting Coolant Level .................... 6-29
Inspecting Engine Oil Level ............... 6-28
Inspecting Washer Fluid Level............ 6-31
Interior Care ........................................ 6-69
Cleaning the Lap/Shoulder Belt
Webbing ........................................ 6-71
Cleaning the Upholstery and Interior
Trim ............................................... 6-69
Cleaning the Window Interiors ..... 6-71
Dashboard Precautions .................. 6-69
Interior Lights ................................... 5-130 Luggage Compartment Light ...... 5-130
Map Lights .................................. 5-130
Overhead Lights .......................... 5-130
J
Jack ....................................................... 7-4
Jump-Starting ...................................... 7-15
K
Key removed from vehicle warning
beep ..................................................... 7-35
Key Suspend Function .......................... 3-8
Key left-in-luggage compartment warning
beep (With the advanced keyless
function) .............................................. 7-35
Key left-in-vehicle warning beep (With
the advanced keyless function) ........... 7-36
Keyless Entry System ........................... 3-3
Keys ...................................................... 3-2 Key suspend function ...................... 3-8
Transmitter ...................................... 3-4
L
Label Information ................................. 9-2
Lane-Change Signals .......................... 4-38
Liftgate ................................................ 3-20
Light Bulbs Replacement .................................. 6-45
Specifi cations .................................. 9-8
. B [ E B @ % $ & " " @ & E J U J P O J O E C
