set clock MAZDA MODEL 3 5-DOOR 2016 User Guide

5–55
Interior Features
Audio System
Settings
NOTE
Depending on the grade and specification, the screen display may differ.
Select the
icon on the home screen and display the Settings screen.
Switch the tab and select the setting item you want to change.
You can customize settings in the setup display as follows:
Ta bItem Function
AD-Disp Height
Brightness Control
Other Refer to Active Driving Display on page
4-18.
Display Refer to Volume/Display/Sound Controls on page 5-42.
Safety Smart City Brake Support
Blind Spot Monitoring Volume
Other Refer to Personalization Features on page
9-12.
Sound Refer to Volume/Display/Sound Controls on page 5-42.
Clock Adjust Time
Displays the currently set time is displayed.
Press
to advance the hour/minute, and select
to move the hour/minute back.
AM/PM can only be selected with the 12-hour
clock display.
GPS Sync Synchronizes with GPS when turned on.
When turned off, the time can be changed from
“Adjust Time”.
Time Format Changes the display between 12 and 24-hour
clock time.
Time Zone Select When it's not synchronized with GPS, select
the region you want to specify.
Daylight Savings Time Turns the daylight saving time setting on/off.
When ON, the time advances 1 hour. When
OFF, it returns to normal time.
Vehicle Rain Sensing Wiper
Door Locks
Other Refer to Personalization Features on page
9-12.
Devices Bluetooth
®Refer to Bluetooth® Preparation (Type B) on
page 5-94.
Mazda3_8FA4-EA-15G_Edition3.indb 552015/12/04 19:24:09

5–88
Interior Features
Bluetooth®
4. Rotate the audio control dial and select
the name of the paired device you
would like to delete.

Device name 1
Device name 2
Device name 3
Device name 4
Device name 5
Device name 6
Device name 7
NOTE
Only the names of paired devices can be
displayed. If only one device is paired,
only the name for this device is displayed.
5. If a selection other than “GO BACK”
is made and the audio control dial is
pressed, “SURE ? NO” is displayed.
6. Rotate the audio control dial clockwise
and switch the display to “SURE ?
YES”.
NOTE
The display changes as follows depending
on whether the audio control dial is
rotated clockwise or counterclockwise.
-Clockwise: “SURE ? YES” displayed
-Counterclockwise: “SURE ? NO”
displayed
7. Press the audio control dial to delete
the selected device.
NOTE
Select “GO BACK” and press the audio
control dial to return to the “PAIR
DELETE” display.
8. “PAIR DELETED” is displayed for
three seconds after the deletion is
completed, and then it returns to the
normal display.
NOTE
If an error occurs while trying to delete
the paired device, “Err” flashes in the
display for three seconds and the display
returns to “LINK DELETE”.
Bluetooth
® audio device information
display
1. Using the audio control dial, select the
pair device information display mode
“DEVICE INFO” in the “BT SETUP”
mode. (Refer to “Bluetooth
® audio
device set-up” for details.)
2. Press the audio control dial to
determine the mode.
3. The name of the Bluetooth® unit device
is displayed.
4. Rotate the audio control dial to select
the information for the Bluetooth® unit
which you would like to view.

Device name
BT address
NOTE
When “GO BACK” is selected and the
audio control dial is pressed, the display
returns to “DEVICE INFO”.
Mazda3_8FA4-EA-15G_Edition1.indb 882015/05/11 14:01:48

7–6
If Trouble Arises
Flat Tire
To remove the spare tire
1. Lift the trunk/luggage compartment
mat.

Trunk/Luggage compartment mat
2. Turn the spare tire hold-down bolt
counterclockwise.

Spare tire hold-down bolt
To secure the spare tire
Store the spare tire in the reverse order
of removal. After storing, verify that the
spare tire is stored securely.
Changing a Flat Tire
NOTE
If the following occurs while driving, it
could indicate a flat tire.
 Steering becomes difficult. The vehicle begins to vibrate
excessively. The vehicle pulls in one direction.
If you have a flat tire, drive slowly to a
level spot that is well off the road and out
of the way of traffic to change the tire.
Stopping in traffic or on the shoulder of a
busy road is dangerous.
WARNING
Be sure to follow the directions for
changing a tire:
Changing a tire is dangerous if not
done properly. The vehicle can slip off
the jack and seriously injure someone.
No person should place any portion
of their body under a vehicle that is
supported by a jack.
Never allow anyone inside a vehicle
supported by a jack: Allowing someone to remain in
a vehicle supported by a jack is
dangerous. The occupant could cause
the vehicle to fall resulting in serious
injury.
NOTE
Make sure the jack is well lubricated
before using it.
1. Park on a level surface of f the right-of-
way and firmly set the parking brake.
2. Put a vehicle with an automatic
transaxle in Park (P), a manual
transaxle in Reverse (R) or 1, and turn
off the engine.
Mazda3_8FA4-EA-15G_Edition1.indb 62015/05/11 14:02:35

10–3
Index
Climate Control System ........................5-2
Automatic Climate Control
.............5-9
Dual-Zone Automatic Climate
Control ........................................... 5-12
Gas specifications
............................9-9
Manual Climate Control
..................5-5
Operating Tips
.................................5-2
Vent Operation
................................5-3
Clock
...................................................5-28
Collision warning
................................7-38
Control Status Display
........................4-70
Cruise Control
...................................4-119
Cruise Control Switch
.................4-119
Cruise Control Set Vehicle Speed
Display
................................................4-16
Cup Holder
........................................5-138
Customer Assistance
.............................8-2
D
Dashboard Illumination ......................4-15
Daytime Running Lights
.....................4-45
Defogger Mirror
............................................4-53
Rear window
.................................4-52
Dimensions
...........................................9-6
Direct Mode Automatictransaxle
.......................4-38
Door Locks
..........................................3-11
Drive selection
....................................4-71
Driving In Flooded Area
.....................3-48
Driving Tips Automatic transaxle
......................4-39
Break-in period .............................. 3-44
Driving in flooded area ..................3-48
Driving on uneven road
.................3-50
Floor mat
.......................................3-45
Hazardous driving
.........................3-45
Overloading
...................................3-49
Rocking the vehicle
.......................3-46
Winter driving
...............................3-46
Driving on Uneven Road
....................3-50 Dynamic Stability Control (DSC)
.......4-64
DSC OFF Indicator Light ..............4-65
DSC OFF Switch ...........................4-65
TCS/DSC Indicator Light
.............4-64
E
Emergency Starting Push-Starting
.................................7-18
Starting a Flooded Engine
.............7-18
Emergency Towing Tiedown Hooks
.............................7-22
Towing Description
.......................7-21
Emission Control System
....................3-27
Ending Screen Display
........................4-70
Engine Coolant
..........................................6-30
Engine Compartment Overview
....6-26
Exhaust gas .................................... 3-28
Hood release
..................................6-24
Oil
..................................................6-27
Starting
............................................4-5
Essential information
............................6-2
Event Data Recorder
...........................8-20
Exhaust Gas
........................................3-28
Exterior Care
.......................................6-68
Aluminum Wheel Maintenance
....6-73
Bright-Metal Maintenance
............6-72
Maintaining the Finish
..................6-70
Plastic Part Maintenance
...............6-73
F
Flasher Hazard warning
.............................4-54
Headlights
.....................................4-40
Flat Tire
.................................................7-3
Mounting the Spare Tire ................7-10
Removing a Flat Tire
.......................7-7
Floor Mat
............................................3-45
Fluid Brake/Clutch
.................................6-32
Washer
...........................................6-32
Mazda3_8FA4-EA-15G_Edition1.indb 32015/05/11 14:03:02
