Page 126 of 585
*Some models.4–1
4When Driving
Information concerning safe driving and stopping.
Start/Stop Engine ................................ 4-4
Ignition Switch ............................... 4-4
Starting the Engine ......................... 4-5
Turning the Engine Off ................ 4-10
Instrument Cluster and Display ...... 4-12
Meters and Gauges ....................... 4-12
Active Driving Display
* ............... 4-19
Warning/Indicator Lights ............. 4-21
Transaxle ............................................ 4-27
Manual Transaxle Operation ........ 4-27
Automatic Transaxle Controls ...... 4-30
Switches and Controls ...................... 4-41
Lighting Control ........................... 4-41
High Beam Control System
(HBC)
* ......................................... 4-48
Fog Lights* ................................... 4-51
Turn and Lane-Change Signals ...... 4-51
Windshield Wipers and Washer ...... 4-52
Rear Window Wiper and
Washer
* ........................................ 4-56
Rear Window Defroster ............... 4-56
Horn ............................................. 4-58
Hazard Warning Flasher ............... 4-58
HomeLink Wireless Control
System
* ......................................... 4-59
Forward Sensing Camera ................. 4-63
Forward Sensing Camera
* ............ 4-63
Radar Sensor ..................................... 4-65
Radar Sensor ................................ 4-65 Brake .................................................. 4-68
Brake System ............................... 4-68
Hill Launch Assist (HLA) ............ 4-70
Smart City Brake Support
(SCBS)
* ........................................ 4-72
ABS/TCS/DSC ................................... 4-79
Antilock Brake System (ABS) ...... 4-79
Traction Control System (TCS) ...... 4-80
Dynamic Stability Control
(DSC) ........................................... 4-81
i-ELOOP ............................................ 4-83
i-ELOOP
* ..................................... 4-83
Fuel Economy Monitor ..................... 4-86
Fuel Economy Monitor
* ............... 4-86
Drive Selection ................................... 4-88
Drive Selection
* ........................... 4-88
Power Steering................................... 4-90
Power Steering ............................. 4-90
Mazda Radar Cruise Control
(MRCC) ............................................. 4-91
Mazda Radar Cruise Control
(MRCC) ....................................... 4-91
Cruise Control ................................. 4-100
Cruise Control
* ........................... 4-100
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 141 of 585
*Some models.4–16
When Driving
Instrument Cluster and Display
Dashboard Illumination
Rotate the knob to adjust the brightness
of the instrument cluster and other
illuminations in the dashboard.
NOTE
y The brightness of dashboard
illuminations can be adjusted when
the headlights and Parking lights are
turned on.
y When the dashboard illumination
brightness cannot be adjusted any
more, a beep sound will be heard.
Dim
Bright
Canceling the illumination dimmer
When the headlight switch is in the
or
position, the illumination of the
instrument cluster dims.
When driving on snowy or foggy roads,
or in other situations when the instrument
cluster's visibility is reduced due to glare
from surrounding brightness, cancel the
illumination dimmer and increase the
illumination intensity.
To cancel the illumination dimmer, rotate
the knob clockwise fully. You will hear a
beep sound and the illumination dimmer
will be canceled.
NOTE
y This symbol () indicates the knob to
adjust the brightness of the dashboard
illumination.
y If the dashboard illumination knob is
kept at the illumination dimmer cancel
position, the instrument cluster will not
dim when the headlight switch is turned
to the
or position again. Rotate
the dashboard illumination knob
counterclockwise to activate the
illumination dimmer.
Outside Temperature Display *
When the ignition is switched ON, the
outside temperature is displayed.
NOTE
y Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and
vehicle conditions:
y Signifi cantly cold or hot
temperatures.
y Sudden changes in outside
temperature.
y The vehicle is parked.
y The vehicle is driven at low speeds.
The outside temperature unit can be
switched between Celsius and Fahrenheit
using the following procedure.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 174 of 585
4–49
When Driving
Switches and Controls
NOTE
The timing in which the system switches the headlights changes under the following
conditions. If the system does not switch the headlights appropriately, manually switch
between high and low beams according to the visibility as well as road and traffi c
conditions.
y When there are sources of light in the area such as street lamps, illuminated signboards,
and traffi c signals.
y When there are refl ective objects in the surrounding area such as refl ective plates and
signs.
y When visibility is reduced under rain, snow and foggy conditions.
y When driving on roads with sharp curves or hilly terrain.
y When the headlights/rear lamps of vehicles in front of you or in the opposite lane are dim
or not illuminated.
y When there is suffi cient darkness such as at dawn or dusk.
y When the luggage compartment is loaded with heavy objects or the rear passenger seats
are occupied.
y When visibility is reduced due to a vehicle in front of you spraying water from its tires
onto your windshield.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 176 of 585
*Some models.4–51
When Driving
Switches and Controls
Fog Lights *
Use this switch to turn on the fog lights.
The fog lights will improve visibility at
night and during foggy conditions.
To turn the fog lights on, rotate the fog
light switch to the
position.
Fog light switch
The headlight switch must be in the
position before turning on the fog lights.
The fog light indicator light in the
instrument cluster illuminates while the
fog light are on.
To turn the fog lights off, rotate the fog
light switch to the
position or turn the
headlight switch to the
or
position.
NOTE
y The fog lights will turn off when the
headlights are set at high beams.
y (With auto-light control)
If the fog light switch is in the
position and the headlight switch is in
the
position, the fog lights will
turn on when the headlights, the
exterior lights and dashboard
illumination turn on.
Turn and Lane-Change
Signals
The ignition must be switched ON to use
the turn and lane-change signals.
Turn Signals
Move the signal lever down (for a left
turn) or up (for a right turn) to the stop
position. The signal will self-cancel after
the turn is completed.
If the indicator light continues to fl ash
after a turn, manually return the lever to its
original position.
Right turn
Left turn Right lane change
Left lane changeOFF
The turn signal indicators (green) in the
instrument cluster fl ash according to the
operation of the turn signal lever to show
which signal is working.
Right turn
Left turn Right lane change
Left lane changeOFF
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 181 of 585
*Some models.4–56
When Driving
Switches and Controls
Rear Window Wiper and
Washer
*
The ignition must be switched ON to use
the wiper.
Rear Window Wiper
Turn the wiper on by turning the rear
wiper/washer switch.
Switch
Position Wiper operation
INT Intermittent
ON Normal
Rear Window Washer
To spray washer fl uid, turn the rear wiper/
washer switch to the
position. After the
switch is released, the washer will stop.
If the washer does not work, inspect the
fl uid level (page 6-31 ). If the fl uid level is
normal and the washer still does not work,
consult an Authorized Mazda Dealer.
Rear Window Defroster
The rear window defroster clears fog from
the rear window.
The ignition must be switched ON to use
the defroster.
Press the switch to turn on the rear
window defroster. The rear window
defroster operates for about 15 minutes
and then turns off automatically.
The indicator light illuminates when the
defroster is operating.
To turn off the rear window defroster
before the 15 minutes has elapsed, press
the switch again.
Manual Climate Control
Indicator light
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 189 of 585
4–64
When Driving
Forward Sensing Camera
CAUTION
Heed the following cautions to assure the correct operation of the Forward Sensing
Camera (FSC).
¾ Do not remove the Forward Sensing Camera (FSC) cover.
¾ Do not place objects on the dashboard which refl ect light.
¾ Do not apply accessories, stickers or fi lm to the windshield near the Forward Sensing
Camera (FSC). If there are objects in front of the Forward Sensing Camera (FSC) lens,
even a transparent sticker, they will cause the system to not operate correctly.
¾ Always keep the windshield glass around the camera clean by removing dirt or
fogging. Use the windshield defroster to remove fogging on the windshield.
¾ When cleaning the windshield, do not allow glass cleaners or similar cleaning agent
to get on the Forward Sensing Camera (FSC) lens. In addition, do not touch the
Forward Sensing Camera (FSC) lens.
¾ Consult an Authorized Mazda Dealer regarding cleaning the interior side of the
windshield around the Forward Sensing Camera (FSC).
¾ Be careful not to scratch the Forward Sensing Camera (FSC) lens or allow it to get
dirty. Also, do no take the camera apart. Otherwise, it could result in damage or
malfunction.
¾ Consult an Authorized Mazda Dealer before performing repairs around the Forward
Sensing Camera (FSC).
¾ The Forward Sensing Camera (FSC) is installed to the windshield. Consult an
Authorized Mazda Dealer for windshield repair and replacement.
¾ When performing repairs around the rearview mirror, consult an Authorized Mazda
Dealer.
¾ Consult an Authorized Mazda Dealer regarding cleaning of the Forward Sensing
Camera (FSC) lens.
¾ Do not hit or apply strong force to the Forward Sensing Camera (FSC) or the area
around it. If strong force is applied, stop using the Lane Departure Warning System
(LDWS) and the High Beam Control System (HBC), and consult an Authorized Mazda
Dealer.
¾ The direction in which the Forward Sensing Camera (FSC) is pointed has been fi nely
adjusted. Do not change the installation position of the Forward Sensing Camera
(FSC) or remove it. Otherwise, it could result in damage or malfunction.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 199 of 585
4–74
When Driving
Brake
CAUTION
¾ When driving off -road in areas where there is grass or forage, it is recommended that the
Smart City Brake Support (SCBS) system be turned off .
¾ Always use tires for all wheels that are of the specifi ed size, and the same manufacturer,
brand, and tread pattern. In addition, do not use tires with signifi cantly diff erent wear
patterns on the same vehicle as the Smart City Brake Support (SCBS) system may not
operate normally.
¾ The laser sensor includes a function for detecting a soiled windshield and informing the
driver, however, depending on the conditions, it may not detect plastic shopping bags, ice
or snow on the windshield. In such cases, the system cannot accurately determine a vehicle
or obstruction ahead and may not be able to operate normally. Always drive carefully and
pay attention to the road ahead.
NOTE
y The Smart City Brake Support (SCBS) system will operate under the following
conditions.
y The engine is running.
y The Smart City Brake Support (SCBS) indicator light does not illuminate.
y The vehicle speed is between about 4 to 30 km/h (2 to 18 mph).
y The Smart City Brake Support (SCBS) system is not turned off.
y The DSC operation is not turned off using the DSC OFF switch.
y The DSC is not malfunctioning.
y The driver is not deliberately performing driving operations (accelerator pedal,
steering wheel, and braking operations).
y The Smart City Brake Support (SCBS) detects a vehicle ahead by emitting a near-infrared
laser beam and receiving the beam refl ected off the refl ector of the vehicle ahead, and
then using it for the measurement. Consequently, the Smart City Brake Support (SCBS)
may not operate under the following conditions:
y Refl ection of the laser is poor due to the shape of the vehicle ahead.
y The vehicle ahead is signifi cantly dirty.
y Under bad weather condition, such as rain, fog and snow.
y The window washer is being used or the windshield wipers are not used when it's
raining.
y The windshield is dirty.
y The steering wheel is turned completely left or right, or the vehicle is accelerated
rapidly and comes close to the vehicle ahead.
y Trucks with low loading platforms, vehicles traveling at extremely low speeds, and
vehicles with a high profi le.
y Vehicles with certain shapes such as a vehicle carrier.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 244 of 585
*Some models.4–119
When Driving
Lane Departure Warning System (LDWS)
Lane Departure Warning System (LDWS) *
The LDWS notifi es the driver that the vehicle may be deviating from its lane.
The system detects the white or yellow lines on the traffi c lane using the Forward Sensing
Camera (FSC). If it determines that the vehicle may be deviating from its lane, it notifi es
the driver by fl ashing the LDWS indicator light (green) and operating the LDWS warning
sound.
Refer to Forward Sensing Camera on page 4-63 .
Use the LDWS when you drive the vehicle on roads with white or yellow lines.
Forward Sensing Camera (FSC)
LDWS warning light (Amber)/
LDWS indicator light (Green)
The warning light fl ashes when the system has a malfunction.
Refer to Warning Lights on page 4-22 .
WARNING
Do not use the LDWS under the following conditions:
The system may not operate adequately according to the actual driving conditions,
resulting in an accident.
¾ Driving on roads with tight curves.
¾ Driving under bad weather conditions (rain, fog, and snow).
The functions of the LDWS have limitations:
Always stay on course using the steering wheel and drive with care. The system is not
designed to compensate for a driver’s lack of cautions and if you rely too much on the
LDWS it could lead to an accident. The driver is responsible for assuring lane changes and
other maneuvers. Always pay attention to the direction in which the vehicle is traveling
and the vehicle’s surroundings.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 246 of 585
4–121
When Driving
Lane Departure Warning System (LDWS)
y Under the following conditions, the LDWS may not be able to detect white or yellow lines
correctly and the LDWS may not operate correctly.
y If an object placed on the dashboard is refl ected in the windshield and picked up by the
camera.
y Heavy luggage is loaded in the luggage compartment or on the rear seat and the
vehicle is inclined.
y The tire pressures are not adjusted to the specifi ed pressure.
y When the vehicle is driven on the entry and exit to or from the rest area or tollgate of a
highway.
y The white or yellow lines are less visible because of dirt or paint fl aking.
y The vehicle in front of your vehicle is running near a white or yellow line and the line
is less visible.
y A white or yellow line is less visible because of bad weather (rain, fog, or snow).
y The vehicle is driven on a temporary lane or section with a closed lane due to
construction.
y A misleading line is picked up on the road such as a temporary line for construction,
or because of shade, lingering snow, or grooves fi lled with water.
y The surrounding brightness suddenly changes such as when entering or exiting a
tunnel.
y The illumination of the headlights is weakened because of dirt or the optical axis is
deviated.
y The windshield is dirty or foggy.
y Back-light is refl ecting from the road surface.
y The road surface is wet and shiny after rain, or there are puddles on the road.
y The shade of a guardrail parallel to a white or yellow line is on the road.
y The width of a lane is excessively narrow or wide.
y The road is excessively uneven.
y The vehicle is shaken after hitting a road bump.
y There are two or more adjacent white or yellow lines.
y There are various road markings or lane markings of various shapes near an
intersection.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 248 of 585
4–123
When Driving
Lane Departure Warning System (LDWS)
Auto cancel
Under the following conditions, the
LDWS is automatically canceled and
kept on stand-by, and the LDWS warning
light (amber) in the instrument cluster
illuminates.
y The system cannot detect white or
yellow lines.
y The vehicle speed is less than about 65
km/h (40 mph).
y The vehicle is making a sharp turn.
y The vehicle is making a turn at an
inadequate speed.
y The temperature inside the camera is
high or low.
y The windshield around the camera is
foggy.
y The windshield around the camera is
blocked by an obstruction, causing poor
forward visibility.
The lane indication (bordered line) is
indicated in the active driving display
(Type A instrument cluster
*1 ) or the multi
information display (Type B instrument
cluster
*1 ).
The LDWS is automatically enabled when
the condition changes and the system is
operable.
*1 To determine which instrument cluster
is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
Auto cancel of warning
Under the following conditions, the
LDWS determines that the driver is
making lane changes and the warning is
automatically canceled.
The LDWS is automatically enabled after
the operation.
y The steering wheel is operated abruptly.
y The brake pedal is depressed abruptly.
y The accelerator pedal is depressed
abruptly.
y A turn signal lever is operated (after the
turn signal lever is returned, the LDWS
warning may not operate for about 3
seconds which is the period of time
required to make a lane correction).
NOTE
y After about 5 seconds have elapsed
with the turn signal lever left operating,
the LDWS warning may operate if the
vehicle is close to a white or yellow
line.
y The sensitivity of the warning
(sensitivity with which the system
determines the driver's intentional lane
change) can be changed.
Refer to Personalization Features on
page 9-12 .
Canceling The System
To cancel the LDWS, press the LDWS
switch. The LDWS indicator light (Green/
Amber) in the instrument cluster turns off.
The lane indication displayed in the
active driving display (Type A instrument
cluster
*1 ) or the multi information display
(Type B instrument cluster *1 ) turns off.
*1 To determine which instrument cluster
is equipped on your Mazda, Refer to
Meters and Gauges on page 4-12 .
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
