6.(Without flat tire belt)
Store the damaged tire in the trunk/
luggage compartment.
(With flat tire belt)
Open the trunk/luggage compartment
mat.

Trunk/Luggage compartment mat
7. Remove the belt for securing the flat
tire.
8. Put the flat tire into the trunk/luggage
compartment on the left and toward the
back.

9. (Split-folding type seat)
Fold the rear seatback forward on the
right side of the rear seat.
10.(Split-folding type seat)
Unlock the rear seatback on the left
side and assure a clearance to pass the
belt.
(One-piece folding type seat)
Unlock the rear seatback and assure a
clearance to pass the belt.
11. Pass the belt through the rear seatback as shown in the figure.
After passing the be lt through, return
the rear seatback to the original
position.
(Split-folding type seat)

Belt
(One-piece folding type seat)

Belt
If Trouble Arises
Flat Tire
7-13
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

NOTE
Pass the belt underneath the seatbelts.

BeltSeat belt
12. Pass the buckle through the wheel as
shown in the figure and secure it so
that the buckle does not contact the
wheel.
(Aluminum wheel)

(Steel wheel)

13. Pass the belt through the buckle, thenpull the belt end to secure the flat tire.

14.(Split-folding type seat)
Return the rear seatback on the right
side of the rear seatback to its original
position.
15. Remove the tire blocks and store the tools and jack.
16. Check the inflation pressure. Refer to Tires on page 9-10.
17. Have the flat tire repaired or replaced
as soon as possible.
NOTE
Do not press the tire pressure monitoring
system set switch after installing the spare
tire. The switch is only to be pressed after
installing the repaired flat tire or installing
a replacement tire (page 4-23).
If Trouble Arises
Flat Tire
7-14
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

WA R N I N G
Do not drive with any tires that have
incorrect air pressure:
Driving on tires with incorrect air pressure
is dangerous. Tires with incorrect pressure
could affect handling and result in an
accident. When you check the regular tires'
air pressure, check the spare tire, too.
NOTE
To prevent the jack and tool from rattling,
store them properly.
If Trouble Arises
Flat Tire
7-15
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

SignalWarning
(Flashing)
Tire Pressure Moni-
toring System Warn-
ing Light
*
If the tire pressure m onitoring system has a malfunction, the t ire pressure warning light
flashes for about 1 minute when the ignition is switched ON and then continues illuminat-
ing. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.
WARNING
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, decrease vehicle speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, it is dangerous to drive the vehicle at high speeds, or
perform sudden maneuvering or braking. Vehicl e drivability could worsen and result in an
accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed to a
place where air may be added and the system monitored again by an Authorized Mazda
Dealer or a tire repair station.
Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have
the problem taken care of as soon as possible before it develops into a more serious situa‐
tion that could lead to tire failure and a dangerous accident.
(Red)
(Turns on)
KEY Warning Light If any malfunction occurs in the keyless entry system, it illum
inates continuously.
CAUTION
If the key warning indicator light illuminates or the push button start indicator light (am‐
ber) flashes, the engine may not start. If the en gine cannot be started, try starting it using
the emergency operation for starting the engine , and have the vehicle inspected at an Au‐
thorized Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4- 10.
Security Indicator
Light If the engine does not start with the correct key, and the secu
rity indicator light remains
illuminated or flashing, try the following:
Make sure the key is within the operational range for signal transmission. Switch the igni-
tion off, and then restart the e ngine. If the engine does not s tart after 3 or more tries, con-
tact an Authorized Mazda Dealer.
(Amber)
High Beam Control System (HBC)
Wa r n i n g L i g h t
*
The light remains turned on if th ere is a problem with the system. Have your vehicle in-
spected at an Authorized Mazda Dealer.
NOTE
If the windshield area in fr ont of the Forward Sensing Camera (FSC) is fogged or ob-
structed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-30*Some models.
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Taking Action
Take the appropriate action and verify that the warning light t
urns off.
SignalWarning Action to be taken
(Turns on)
Tire Pressure Monitoring
System
Wa r n i n g
Light
*
When the warning light illuminates, and the
warning beep sound is heard (about 3 seconds),
tire pressure is too low in one or more tires.
WA R N I N G
If the tire pressure monitoring system warning
light illuminates or flashes, or the tire pressure
warning beep sound is heard, decrease vehicle
speed immediately and avoid sudden maneuver‐
ing and braking:
If the tire pressure monitoring system warning
light illuminates or
flashes, or the tire pressure
warning beep sound is heard, it is dangerous to
drive the vehicle at high speeds, or perform sud‐
den maneuvering or braking. Vehicle drivability
could worsen and result in an accident.
To determine if you have a slow leak or a flat, pull
over to a safe position where you can check the
visual condition of the tire and determine if you
have enough air to proceed to a place where air
may be added and the sy stem monitored again
by an Authorized Mazda Dealer or a tire repair
station.
Do not ignore the TPMS Warning Light:
Ignoring the TPMS warn ing light is dangerous,
even if you know why it is illuminated. Have the
problem taken care of as soon as possible before
it develops into a more serious situation that
could lead to tire failure and a dangerous acci‐
dent. Inspect the tires and adjust to the specified in-
flation pressure (page 6-38).
NOTE
Perform tire pressure adjustment when the
tires are cold. Tire pressure will vary accord-
ing to the tire temperature, therefore let the ve-
hicle stand for 1 hour or only drive it 1.6 km (1
mile) or less before ad
justing the tire pres-
sures. When pressure is adjusted on hot tires to
the cold inflation pressure, the TPMS warning
light/beep may turn on af ter the tires cool and
pressure drops below specification.
Also, an illuminated TPMS warning light, re-
sulting from the tire air pressure dropping due
to cold ambient temper ature will remain illu-
minated even if the ambient temperature rises.
In this case, it will also be necessary to adjust
the tire air pressures. If the TPMS warning
light illuminates due to a drop in tire air pres-
sure, make sure to check and adjust the tire air
pressures.
Tires lose air naturally over time and the
TPMS cannot tell if the tires are getting too
soft over time or yo u have a flat. However,
when you find one low tir e in a set of four-that
is an indication of trouble; you should have
someone drive the vehicle slowly forward so
you can inspect any low tire for cuts and any
metal objects sticking through tread or side-
wall. Put a few drops of water in the valve
stem to see if it bubble s indicating a bad valve.
Leaks need to be addressed by more than sim-
ply reinflating the tire as leaks are dangerous
― take it to an Authorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-32*Some models.
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Key Left-in-luggage Compartment
Warning Beep (With the advanced
keyless function)
If the key is left in the luggage
compartment/trunk with all the doors
locked and the liftgate/trunk lid closed, a
beep will be heard outside for about 10
seconds to notify the driver that the key is
in the luggage compartment/trunk. In this
case, take out the key by pressing the
electric liftgate/trunk lid opener and
opening the liftgate/trunk lid. The key
taken out of the luggage compartment/
trunk may not operate because its
functions have been temporarily stopped.
To restore the key's functions, perform the
applicable procedure (page 3-8).
▼Key Left-in-vehicle Warning Beep
(With the advanced keyless
function)
If all the doors and luggage compartment/
trunk are locked using another key while
the key is left in the cabin, the beep which
sounds outside of the vehicle will be heard
for about 10 seconds
to notify the driver
that the key is in the cabin. In this case,
take out the key by opening the door. A
key taken out of the vehicle using this
method may not operate because its
functions have been temporarily stopped.
To restore the key's functions, perform the
applicable procedure (page 3-8).
▼ i-ELOOP Warning Beep*
The beep will activat
e if you attempt to
drive the vehicle under the following
conditions.
The i-ELOOP indicator light is flashing
green.
“i-ELOOP Charging” is indicated in the
center display (Type B audio).
The beep will stop when the vehicle is
stopped. Make sure the indicator light is
no longer illuminated and the message is
no longer displayed before driving the
vehicle.
▼ Tire Inflation Pressure Warning
Beep*
The warning beep sound will be heard for
about 3 seconds when there is any
abnormality in tire inflation pressures
(page 4-146).
▼Lane Departure Warning Sound
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
The volume of the Lane-keep Assist
System (LAS) & Lane Departure
Warning System (LDWS) warning sound
can be changed.
Refer to Personalization Features on
page 9-12.
The type of the Lane-keep Assist System
(LAS) & Lane Departure Warning
System (LDWS) warning sound can be
changed.
Refer to Personalization Features on
page 9-12.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-40*Some models.
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

WA R N I N G
Keep your vehicle's tires properly inflated and not overloaded:
Driving with improperly inflated or overload ed tires is dangerous. Excessive speed,
underinflation, or excessive loading, either separately or in combination, can cause heat
buildup and possible tire failure. The temperature grade for this tire is established for a tire
that is properly inflated and not overloaded.

These grades will be added to the sidewalls of passenger vehicl e tires over the next several
years according to a schedule established by the NHTSA and the tire manufacturers.

The grade of tires available as standard or optional equipment on Mazda vehicles may vary
with respect to grade.

ALL PASSENGER VEHICLE TIRES MUST CONFORM TO THESE GRADES AND TO
ALL OTHER FEDERAL TIRE-SAFETY REQUIREMENTS.
▼ UNIFORM TIRE QUALITY GRADING
Quality grades can be found where applicable on the tire sidewa
ll between tread shoulder
and maximum section width.
For example:
TREADWEAR 200 TRACTION AA TEMPERATURE A
UTQGS MARK (example)
Customer Information and Reporting Safety Defects
Uniform Tire Quality G rading System (UTQGS)
8-24
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Tire Labeling
Federal law requires tire manufacturers to place standardized information on the sidewall of
all tires. This inform ation identifies and describes the fundam ental characteristics of the tire
and also provides a tire identification number for safety standard certification and in case of
a recall.
▼ Information on Passenger Vehicle Tires
Please refer to the sample below.
1. TIN: U.S. DOT tire identification number
2. Passenger car tire
3. Nominal width of tire in millimeters
4. Ratio of height to width (aspect ratio)
5. Radial
6. Run-flat tire
7. Rim diameter code
8. Load index & speed symbol
9. Severe snow conditions
10. Tire ply composition and materials used
11. Max. load rating
12. Tread wear, traction and temperature grades
13. Max. permissible inflation pressure
14. SAFETY WARNING
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-25
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Letter RatingSpeed Rating
V 149 mph
W 168
* mph
Y 186
* mph
* For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR. For
tires with a maximum speed cap ability over 186 mph, tire manufa cturers always use the letters ZR.
MS or M/S: Mud and Snow
AT: All Terrain.
AS: All Season. The “M
S” or “M/S” indicates that the tire has some functional use in mud
and snow.
U.S. DOT Tire Identifi cation Number (TIN)
This begins with the letters “DOT” which indicates the tire mee ts all federal standards. The
next two numbers or letters are the plant code where it was man ufactured, and the last four
numbers represent the week and year the tire was manufactured. For example, the numbers
457 means the 45st week of 1997. After 2000 the numbers go to f our digits. For example,
the number 2102 means the 21th week of 2002. The other numbers are marketing codes
used at the manufacturer's discretion. This information is used to contact consumers if a tire
defect requires a recall.
Tire Ply Composition and Materials Used
The number of plies indicates the number of layers of rubber-co ated fabric in the tire. In
general, the greater the number of plies, the more weight a tir e can support. Tire
manufacturers also must indicate the tire materials, which incl ude steel, nylon, polyester,
and other.
Maximum Load Rating
This number indicates the maximum load in kilograms and pounds that can be carried by the
tire.
Maximum Permissible Inflation Pressure
This number is the greatest amoun t of air pressure that should ever be put in the tire under
normal driving conditions.
Tread Wear, Traction and Temperature Grades
Tr e a d w e a r : The tread wear grade is a comparative rating based on the wear rate of the tire
when tested under controlled con ditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-27
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Traction: The traction grades, from highe st to lowest are AA, A, B, and C. The grades
represent the tire's ability to stop on wet pavement as measure d under controlled conditions
on specified government test surfaces of asphalt and concrete. A tire marked C may have
poor traction performance.
Te m p e r a t u r e : The temperature grades are A (the highest), B and C, represent ing the tire's
resistance to the generation of heat and its ability to dissipa te heat when tested under
controlled conditions on a spec ified indoor laboratory test whe el.
Snow Tires
In some heavy snow areas, local governments may require true sn ow tires, those with very
deeply cut tread. These tires should only be used in pairs or p laced on all four wheels. Make
sure you purchase snow tires that are the same size and construction type as the other tires
on your vehicle.
SAFETY WARNING
The following safety warning a ppears on the tire's sidewall.
SERIOUS INJURY MAY RESULT FROM:
EXPLOSION OF TIRE/RIM ASSEMBLY DUE TO IMPROPER MOUNTING-MATCH
TIRE DIAMETER TO RIM D IAMETER; NEVER EXCEED 40 psi (275 kPa) TO SEAT
BEADS-ONLY SPECIALLY TRAINED PERSONS SHOULD MOUNT TIRES.
TIRE FAILURE DUE TO UNDER-INFLATION/OVERLOADING/
DAMAGE-FOLLOW OWNER'S MANUAL AND PLACARD IN
VEHICLE-FREQUENTLY CHECK INFLATION PRESSURE AND INSPECT FOR
DAMAGE.
▼ Information on Temporary Tires
Please refer to the sample below.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-28
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21
