SRS equip‐ment Types of collision
A severe frontal/near frontal collision A severe side colli‐
sion A roll-over/near
roll-over
*2A rear collision
Front seat
belt preten‐ sioner X
*1X*1X*1
No air bag and
front seat belt pre‐
tensioner will be
activated in a rear
collision.
Driver air
bag X――
Front pas‐ senger air bag X
*1――
Knee Airbag X
*1――
Side air bag ― X
*1 (impact side
only) ―
Curtain air bag ―X (impact side on‐
ly) X (both sides)
X: The SRS air bag equipment deploys in a collision.
―:The SRS air bag equipment does not deploy in a collision.
*1
(With Front Passenger Occupa nt Classification System)
The front passenger front and si de air bags, seat belt pretensioner and knee air bag are designed to deploy
depending on the condition of the total seated weight on the front passenger seat.
*2 (With Front Passenger Occupa nt Classification System)
In a roll-over accident, the seat belt pretensioners and the cu rtain air bags deploy.
NOTE
In a frontal offset collision, the equipped air bags and pretensioners may all deploy
depending on the direction, angle, and rate of impact.
Essential Safety Equipment
SRS Air Bags
2-69
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

▼Front Passenger Seat Weight
Sensors
Your vehicle is equipped with a front
passenger seat weight sensors as a part of
the supplemental restraint system. These
sensors are located under both of the front
passenger seat rails. These sensors
determine the total
seated weight on the
front passenger seat and monitor the seat
belt buckle for the front passenger seat.
The SAS unit is designed to prevent the
front passenger front and side air bags and
knee air bags, and seat belt pretensioner
system from deploying if the front
passenger air bag deactivation indicator
light illuminates.
To reduce the chance of injuries caused by
deployment of the fr ont passenger air bag,
the system deactivates the front passenger
front and side air bags and knee air bags,
and also the seat belt pretensioner system
when the front passenger air bag
deactivation indicator light illuminates.
Refer to the following table for the front
passenger air bag deactivation indicator
light illumination conditions.

This system shuts off the front passenger
front and side air bags and knee air bags,
and seat belt pretensioner system, so make
sure the front passenger air bag
deactivation indicator light illuminates
according to the following table.

The air bag/front seat belt pretensioner
system warning light flashes and the front
passenger air bag deactivation indicator
light illuminates if the sensors have a
possible malfunction. If this happens, the
front passenger front and side air bags and
knee air bags, and seat belt pretensioner
system will not deploy.
Front passenger air bag deactivation
indicator light
This indicator light illuminates to remind
you that the front passenger front and side
air bags and knee air bags, and seat belt
pretensioners will not deploy during a
collision.
If the front passenger weight sensors are
normal, the indicator light illuminates
when the ignition is switched ON. The
light turns off after a few seconds. Then,
the indicator light illuminates or is off
under the following conditions:
Essential Safety Equipment
SRS Air Bags
2-72
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Front passenger air bag deactivation in‐
dicator light on/off condition chart
Conditiondetected by the
front pas‐
senger oc‐ cupant
classifica‐
tion system Front pas‐
senger air
bag deacti‐
vation indi‐ cator light Front pas‐
senger
front and side andknee air bags Front
passenger seat beltpreten‐ sioner
system
Empty (Not
occupied) On Deactivated
Deactivat‐
ed
Child or
child-re‐
straint sys‐
tem
*1
On Deactivated Deactivat‐
ed
Adult
*2Off Ready Ready
*1 If a larger child sits on the front passenger seat, the sensors might detect the child as being an
adult depending on the child's physique.
*2 If a smaller adult sits on the front passenger seat,
the sensors might detect the person as being a
child depending on the person's physique.
The curtain air bag is ready for inflating regardless of
what the front passenger air bag deactivation
indicator light on/off condition chart indicates.

If the front passenger air bag deactivation
indicator light does not illuminate when
the ignition is switched ON and does not
illuminate as indicated in the front
passenger air bag deactivation indicator
light on/off condition chart, do not allow a
child to sit in the front passenger seat and
consult an Authorized Mazda Dealer as
soon as possible. The system may not
work properly in an accident.
WA R N I N G
Do not decrease the total seated weight on
the front passenger seat:
When an adult or large child sits on the
front passenger seat, decreasing the total
seated weight on the front passenger seat
required for air bag deployment is
dangerous. The front passenger seat
weight sensors will de tect the reduced total
seated weight condition and the front
passenger front and side air bags and knee
air bags, and the seat belt pretensioner
system will not deploy during an accident.
The front passenger will not have the
supplementary protection of the air bag,
which could result in serious injury.
Decreasing the total seated weight on the
front passenger seat could result in an air
bag not deploying under the following
conditions, for example:
Essential Safety Equipment
SRS Air Bags
2-73
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

A front passenger is seated as shown in
the following figure:A rear passenger pushes up on the front
passenger seat with their feet.
 Luggage or other items placed under the
front passenger seat or between the front
passenger seat and driver seat that push
up the front passenger seat bottom.
 Any accessories which might decrease
the total seated weight on the front
passenger seat are attached to the front
passenger seat.
The front passenger front and side air
bags and knee air bags, and the seat belt
pretensioner system will deactivate if the
front passenger air bag deactivation
indicator light illuminates.

Do not increase the total seated weight on
the front passenger seat:
When an infant or small child sits on the
front passenger seat, increasing the total
seated weight on th e front passenger seat
is dangerous. The front passenger seat
weight sensors will detect the increased
total seated weight, which could result in
the unexpected deployment of the front
passenger front and side air bags and knee
air bags, and seat belt pretensioner system
in an accident and may cause serious
injury. Increasing the total seated weight
on the front passenger seat could result in
the front passenger front and side air bags
and knee air bags, and seat belt
pretensioner system deployment in an
accident under the following conditions,
for example:
 Luggage or other items are placed on the
seat with the child in the child-restraint
system.
 A rear passenger or luggage push or pull
down on the front passenger seatback.
Essential Safety Equipment
SRS Air Bags
2-74
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

A rear passenger steps on the front
passenger seat rails with their feet.
 Luggage or other items are placed on the
seatback or hung on the head restraint.
 Heavy items are placed in the seatback
map pocket.
 The seat is washed.
 Liquids are spilled on the seat.
 The front passenger seat is moved
backward, pushing into luggage or other
items placed behind it.
 The front passenger seatback contacts
the rear seat.
 Luggage or other items are placed
between the front passenger seat and
driver seat.
 Any accessories which might increase the
total seated weight on the front
passenger seat are attached to the front
passenger seat.
CAUTION
To assure proper deployment of the front
air bag and to prevent damage to the
sensors in the front seat bottoms:
 Do not place sharp objects on the front
seat bottoms or leave heavy luggage
on them.
 Do not spill any liquids on the front
seats or under the front seats.
 To allow the sensors to function properly,
always perform the following:
 Adjust the front seats as far back as
possible and always sit upright against
the seatbacks with seat belts worn
properly.
If you place your child on the front
passenger seat, secure the
child-restraint system properly and
slide the front passenger seat as far
back as possible (page 2-47).
NOTE
The system requires about 10 seconds to
alternate between turning the front
passenger front and side air bags and
knee air bags, and seat belt pretensioner
system on or off.
The front passenger air bag deactivation
indicator light may illuminate
repeatedly if luggage or other items are
put on the front passenger seat, or if the
temperature of the vehicle's interior
changes suddenly.
The front passenger air bag deactivation
indicator light may illuminate for 10
seconds if the total seated weight on the
front passenger seat changes.
The air bag/front seat belt pretensioner
system warning light might illuminate if
the front passenger seat receives a
severe impact.
If the front passenger air bag
deactivation indicator light does not
illuminate after installing a
child-restraint system on the front
passenger seat, first, re-install your
child-restraint system according to the
procedure in this owner's manual. Then,
if the front passenger air bag
deactivation indicator light still does not
illuminate, install the child-restraint
system on the rear seat and consult an
Authorized Mazda Dealer as soon as
possible.
Essential Safety Equipment
SRS Air Bags
2-75
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

CAUTION
Before opening the liftgate/trunk lid,
remove any snow and ice accumulation
on it. Otherwise, the liftgate/trunk lid
could close under the weight of the snow
and ice resulting in injury.
 Be careful when opening/closing the
liftgate/trunk lid during strong winds. If a
strong gust blows against the liftgate/
trunk lid, it could close suddenly resulting
in injury.
 Fully open the liftgate/trunk lid and
make sure that it stays open. If the
liftgate/trunk lid is only opened partially,
it could slam shut by vibration or wind
gusts resulting in injury.
 When loading or unloading luggage in
the luggage compartment/trunk, turn off
the engine. Otherwise, you could get
burned by the heat of the exhaust gas.
 Be careful not to apply excessive force to
the damper stay on the liftgate such as
by putting your hand on the stay.
Otherwise, the damper stay may bend
and
affect the liftgate operation.
1. Damper stay

Do not modify or replace the liftgate
damper stay. Consult an Authorized
Mazda Dealer if a liftgate damper stay is
deformed or damaged for reasons such
as a collision or if there is some other
problem.
▼ Opening and Closing the Liftgate/
Trunk Lid
Opening the liftgate (5–door)
Using the electric liftgate opener
Unlock the doors and liftgate, then press
the electric liftgate opener on the liftgate
and raise it when the latch releases.

NOTE
(With the advanced keyless function)
A locked liftgate can also be opened
while the key is being carried.
When opening the liftgate with the doors
and the liftgate locked, it may require a
few seconds for the liftgate latch to
release after the elec
tric liftgate opener
is pressed.
Before Driving
Doors and Locks
3-19
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

The trunk lid can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the trunk lid can be
opened by pressing the electric trunk lid
opener. If the trunk lid cannot be opened
despite doing this procedure, press the
electric trunk lid opener to fully open
the trunk lid after pushing the trunk lid
completely closed.
If the vehicle battery is dead or there is
a malfunction in the electrical system
and the trunk lid cannot be unlocked,
the trunk lid can be opened by
performing the emergency procedure.
Refer to When Liftgate/Trunk Lid
Cannot be Opened on page 7-46.
Closing the liftgate/trunk lid
Lower the liftgate/trunk lid slowly using
the liftgate/trunk lid grip recess, then push
the liftgate/trunk lid closed using both
hands.
Do not slam it. Pull up on the liftgate/
trunk lid to make sure it is secure.
(5–door)

(4–door)

▼ Luggage Compartment
Luggage compartment cover (5-door)
WA R N I N G
Do not place anything on top of the cover:
Placing luggage or other cargo on top of
the luggage compartment cover is
dangerous. During sudden braking or a
collision, the cargo could become a
projectile that could hit and injure
someone. The vehicle has a light weight
luggage compartment cover to keep the
contents of your luggage area out of sight;
it will not retain heavy objects that are not
tied down in an accident such as a rollover.
Tie down all heavy objects, whether
luggage or cargo, using the tie down
hooks.
Make sure luggage and cargo are secured
before driving:
Not securing cargo while driving is
dangerous as it could move or be crushed
during sudden braking or a collision and
cause injury.
Before Driving
Doors and Locks
3-21
Mazda3_8HE9-EA-18K_Edition1
2018-10-17 19:05:10

Break-In Period
▼Break-In Period
No special break-in is necessary, but a few
precautions in the first 1,000 km (600
miles) may add to the performance,
economy, and life of the vehicle.
Do not race the engine.
Do not maintain one constant speed,
either slow or fast, for a long period of
time.
Do not drive constantly
at full-throttle or
high engine rpm for extended periods of
time.
Avoid unnecessary hard stops.
Avoid full-throttle starts.
Saving Fuel and Protection
of the Environment
▼Saving Fuel and Protection of the
Environment
How you operate your Mazda determines
how far it will travel on a tank of fuel. Use
these suggestions to help save fuel and
reduce CO
2.
Avoid long warm-ups. Once the engine
runs smoothly, begin driving.
Avoid fast starts.
Drive at lower speeds.
Anticipate when to apply the brakes
(avoid sudden braking).
Follow the maintenance schedule and
have an Authorized Mazda Dealer
perform inspections and servicing.
Refer to Scheduled Maintenance
(U.S.A. and Puerto Rico) on page 6-4.
Refer to Scheduled Maintenance
(Canada) on page 6-6.
Refer to Scheduled Maintenance
(Mexico) on page 6-8.
Use the air conditioner only when
necessary.
Slow down on rough roads.
Keep the tires properly inflated.
Do not carry unnecessary weight.
Do not rest your foot on the brake pedal
while driving.
Keep the wheels in correct alignment.
Keep windows closed at high speeds.
Slow down when driving in crosswinds
and headwinds.
Before Driving
Driving Tips
3-43
Mazda3_8HE9-EA-18K_Edition1
2018-10-17 19:05:10

Driving In Flooded Area
▼Driving In Flooded Area
WA R N I N G
Dry off brakes that have become wet by
driving slowly, releasing the accelerator
pedal and lightly applying the brakes
several times until the brake performance
returns to normal:
Driving with wet brakes is dangerous.
Increased stopping distance or the vehicle
pulling to one side when braking could
result in a serious accident. Light braking
will indicate whether the brakes have been
affected.
CAUTION
Do not drive the vehicle on flooded roads
as it could cause short circuiting of
electrical/electronic parts, or engine
damage or stalling from water absorption.
If the vehicle has been immersed in water,
consult an Authorized Mazda Dealer.
Overloading
▼ Overloading
WA R N I N G
Be careful not to overload your vehicle:
The gross axle weight rating (GAWR) and
the gross vehicle weight rating (GVWR) of
the vehicle are on the Motor Vehicle Safety
Standard Label on the driver's door frame.
Exceeding these ratings can cause an
accident or vehicle damage. You can
estimate the weight of the load by
weighing the items (or people) before
putting them in the vehicle.
Before Driving
Driving Tips
3-48
Mazda3_8HE9-EA-18K_Edition1
2018-10-17 19:05:10

Driving Tips
▼Driving Tips
WA R N I N G
Do not let the vehicle move in a direction
opposite to the direction selected by the
selector lever:
Do not let the vehicle move backward with
the selector lever in a forward position, or
do not let the vehicle move forward with
the selector lever in the reverse position.
Otherwise, the engine may stop, causing
the loss of the power brake and power
steering functions, and make it
difficult to
control the vehicle which could result in an
accident.
Passing
For extra power wh en passing another
vehicle or climbing steep grades, depress
the accelerator fully. The transmission will
shift to a lower gear, depending on vehicle
speed.
NOTE
The accelerator pedal may initially feel
heavy as it is being depressed, then feel
lighter as it is depressed further. This
change in pedal force aids the engine
control system in determining how much
the accelerator pedal has been
depressed for performing kickdown, and
functions to control whether or not
kickdown should be performed.
While the selector lever is in the M
position and the DSC is turned off,
manual shift mode does not switch to
automatic shift mode even if the
accelerator pedal is completely
depressed. Operate the selector lever.
Climbing steep gra des from a stop
To climb a steep grade from a stopped
position:
1. Depress the brake pedal.
2. Shift to D or M1, depending on the load weight and grade steepness.
3. Release the brake pedal while gradually accelerating.
Descending steep grades
When descending a steep grade, shift to
lower gears, depending on load weight and
grade steepness. Descend slowly, using the
brakes only occasionally to prevent them
from overheating.
When Driving
Automatic Transmission
4-42
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10
