weight MAZDA MODEL 3 HATCHBACK 2019 (in English) Owner's Guide

Payload is the combination weight of
cargo and passengers that the vehicle is
designed to carry. The maximum payload
for your vehicle can be found on the Tire
and Load Information label on the driver's
door frame or door pillar. Look for “THE
COMBINATION WEIGHT OF
OCCUPANTS AND CARGO SHOULD
NEVER EXCEED XXX kg or XXX lbs”
for your maximum payload. The payload
listed on the tire label is the maximum
payload for the vehicle as built by the
assembly plant. If any aftermarket or
dealer installed equipment has been
installed on the vehicle, the weight of the
equipment must be subtracted from the
payload listed on the tire label in order to
be accurate.

SAMPLE

CARGO
Cargo Weight includes all weight added
to the Base Curb Weight, including cargo
and optional equipment.

The cargo weight limit decreases
depending on the number of vehicle
occupants. The cargo weight limit can be
calculated by subtracting the total weight
of the vehicle occupants from the
“combination weight of occupants and
cargo should never exceed” value on the
tire label.

Examples: Based on a single occupant
weight of 68 kg (150 lbs), and a value of
385 kg (849 lbs) for the “combination
weight of occupants and cargo should
never exceed”:
The cargo weight limit with one occupant
is 385 kg (849 lbs) － 68 kg (150 lbs) =
317 kg (699 lbs)
The cargo weight limit with two occupants
is 385 kg (849 lbs) － (68 × 2) kg ( (150 ×
2) lbs) = 249 kg (549 lbs)
If the weight of the occupant increases, the
cargo weight limit decreases by that much.

GAW (Gross Axle Weight) is the total
weight placed on each axle (front and
rear) - including vehicle curb weight and
all payload.

GAWR (Gross Axle Weight Rating) is
the maximum allowable weight that can be
carried by a single a xle (front or rear).
These numbers are shown on the Safety
Compliance Certificat ion Label located
on the driver's door frame or door
pillar. The total l oad on each axle must
never exceed its GAWR.

GVW
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-31
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

GVW (Gross Vehicle Weight) is the
Vehicle Curb Weight + cargo +
passengers.

GVWR (Gross Vehicle Weight Rating)
is the maximum allowable weight of the
fully loaded vehicle (including all options,
equipment, passengers and cargo). The
GVWR is shown on the Safety
Compliance Certificat ion Label located
on the driver's door frame or door
pillar. The GVW must never exceed the
GVWR.

SAMPLE
WA R N I N G
Never Exceed Axle Weight Rating Limits:
Exceeding the Safety Certification Label
axle weight rating limits is dangerous and
could result in death or serious injury as a
result of substandard vehicle handling,
performance, engine, transmission and/or
structural damage, serious damage to the
vehicle, or loss of control.
Always keep the vehicle within the axle
weight rating limits.

GCW
GCW (Gross Combination Weight) is
the weight of the loaded vehicle (GVW).

GCWR (Gross Comb ination Weight
Rating) is the maximum allowable weight
of the vehicle - including all cargo and
passengers - that the vehicle can handle
without risking damage. The GCW must
never exceed the GCWR.

WA R N I N G
Never Exceed GVWR or GAWR
Specifications:
Exceeding the GVWR or the GAWR specified
on the certification label is dangerous.
Exceeding any vehicle rating limitation
could result in a serious accident, injury, or
damage to the vehicle.
Do not use replacement tires with lower
load carrying capacities than the originals
because they may lower the vehicle's
GVWR and GAWR limitations. Replacement
tires with a higher limit than the originals
do not increase the GVWR and GAWR
limitations.
Never exceed the GVWR or the GAWR
specified on the certification label.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-32
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Steps for Determining theCorrect Load Limit
▼Steps for Determining the Correct
Load Limit
Steps for Determin
ing Correct Load
Limit-
(1) Locate the statement “The combined
weight of occupants and cargo should
never exceed XXX kg or XXX lbs.”
on your vehicle's placard.
(2) Determine the combined weight of the driver and passengers that will be
riding in your vehicle.
(3) Subtract the combined weight of the driver and passengers from XXX kg
or XXX lbs.
(4) The resulting figure equals the
available amount of cargo and
luggage load capacity. For example, if
the “XXX” amount equals 1400 lbs.
and there will be five 150 lb
passengers in your vehicle, the
amount of available cargo and
luggage load capacity is 650 lbs.
(1400 － 750 (5 × 150) = 650 lbs.)
(5) Determine the c ombined weight of
luggage and cargo being loaded on the
vehicle. That weight may not safely
exceed the available cargo and
luggage load capacity calculated in
Step 4.
(6) If your vehicle will be towing a trailer,
load from your trailer will be
transferred to your vehicle. Consult
this manual to det ermine how this
reduces the available cargo and
luggage load capacity of your vehicle.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-33
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

▼Dimensions
4-Door
Item
Vehicle specification
Overall length 4,662 mm (183.5 in)
Overall width 1,797 mm (70.7 in)
Overall height 1,445 mm (56.9 in)
Front tread 1,568 mm (61.7 in)
Rear tread 2WD
1,581 mm (62.2 in)
AWD 1,580 mm (62.2 in)
Wheelbase 2,726 mm (107.3 in)
5-Door
ItemVehicle specification
Overall length 4,459 mm (175.6 in)
Overall width 1,797 mm (70.7 in)
Overall height 1,440 mm (56.7 in)
Front tread 1,568 mm (61.7 in)
Rear tread 2WD
1,581 mm (62.2 in)
AWD 1,580 mm (62.2 in)
Wheelbase 2,726 mm (107.3 in)
▼We i g h t s
U.S.A. and Canada
SKYACTIV-G 2.0
(4-Door)
Item We i gh t
Manual transmission Automatic transmission
GVWR (Gross Vehicle Weight
Rating) 1,804 kg (3,977 lbs)
1,825 kg (4,023 lbs)
GAWR (Gross Axle
Weight Rating) Front
966 kg (2,130 lbs) 989 kg (2,180 lbs)
Rear 843 kg (1,858 lbs) 841 kg (1,854 lbs)
(5-Door)
Item We i gh t
Manual transmission Automatic transmission
GVWR (Gross Vehicle Weight
Rating) 1,810 kg (3,990 lbs)
1,833 kg (4,041 lbs)
Specifications
Specifications
9-6
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

ItemWe i g h t
Manual transmission Automatic transmission
GAWR (Gross Axle
Weight Rating) Front
965 kg (2,127 lbs) 989 kg (2,180 lbs)
Rear 848 kg (1,870 lbs) 847 kg (1,867 lbs)
SKYACTIV-G 2.5
(4-Door)
Item We i g h t
With Cylinder Deactivation Without Cylinder De‐
activation
2WD AWD
GVWR (Gross Vehicle Weight
Rating) 1,850 kg (4,079 lbs) 1,910 kg (4,211 lbs) 1,800 kg (3,968 lbs)
GAWR (Gross Axle
Weight Rating) Front 1,016 kg (2,240 lbs) 1,030 kg (2,271 lbs) 982 kg (2,165 lbs)
Rear 839 kg (1,850 lbs) 885 kg (1,951 lbs) 823 kg (1,814 lbs)
(5-Door)
Item We i g h t
2WD AW D
Manual transmission Automatic transmission
GVWR (Gross Vehicle Weight
Rating) 1,822 kg (4,017 lbs) 1,849 kg (4,076 lbs) 1,915 kg (4,222 lbs)
GAWR (Gross Axle
Weight Rating) Front 987 kg (2,176 lbs) 1,016 kg (2,240 lbs) 1,046 kg (2,306 lbs)
Rear 838 kg (1,847 lbs) 836 kg (1,843 lbs) 872 kg (1,922 lbs)
Mexico
SKYACTIV-G 2.0
(4-Door)
Item
We i g h t
Manual transmission Automatic transmission
GVW (Gross Vehicle Weight) 1,849 kg (4,076 lbs)1,870 kg (4,123 lbs)
(5-Door)
Item We i g h t
Manual transmission Automatic transmission
GVW (Gross Vehicle Weight) 1,847 kg (4,072 lbs)1,870 kg (4,123 lbs)
Specifications
Specifications
9-7
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

SKYACTIV-G 2.5
(4-Door)
ItemWe i gh t
Manual transmission Automatic transmission
GVW (Gross Vehicle Weight) 1,861 kg (4,103 lbs)1,870 kg (4,123 lbs)
(5-Door)
Item We i gh t
Manual transmission Automatic transmission
GVW (Gross Vehicle Weight) 1,848 kg (4,074 lbs)1,870 kg (4,123 lbs)
▼Air Conditioner*
The type of refrigerant used is indicated on a label attached t
o the inside of the engine com‐
partment. Check the label befo re recharging the refrigerant.
Refer to Operating Tips on page 5-2.
Item Specification
Refrigerant Type HFC134a (R-134a)
▼Light Bulbs
Exterior light
Light bulb Category
Wattage UN-R*1 (SAE)
Headlights LED
*2― (―)
Daytime running lights LED
*2― (―)
Parking lights LED type
LED
*2― (―)
Bulb type 5 WY5W (―)
Front turn signal lights LED
*2― (―)
Front side-marker lights LED type
LED
*2― (―)
Bulb type 5 WY5W (―)
Side turn signal lights
*LED*2― (―)
High-mount brake light LED
*2― (―)
Rear turn signal lights LED
*2― (―)
Rear side-marker lights LED
*2― (―)
Brake lights LED
*2― (―)
Taillights LED
*2― (―)
Reverse lights LED
*2― (―)
License plate lights LED
*2― (―)
Specifications
Specifications
9-8*Some models.
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Index
Front passenger's seat.................. 2-13
Front seat....................................... 2-5
Head restraint.............................. 2-17
Rear seat...................................... 2-14
Seat warmer................................. 2-20
Seat Belt System............................... 2-26 Automatic locking....................... 2-25
Emergency locking...................... 2-25
Extender....................................... 2-30
Pregnant women.......................... 2-25
Seat belt precautions................... 2-23
Seat Belt Warning Beep.................... 7-41
Security System
Immobilizer system..................... 3-39
Theft-deterrent system.................3-41
Smart Brake Support (S BS)............ 4-153
Collision warning.... .................. 4-155
Stopping the Smart Brake Support
(SBS) system operation............. 4-155
Smart Brake Support [Rear Crossing]
(SBS-RC)........................................ 4-160 Collision warning.... .................. 4-163
Stopping the Smart Brake Support
[Rear Crossing] (SBS-RC) system
operation.................................... 4-164
Smart Brake Support [Rear] (SBS-
R)..................................................... 4-156 Collision warning.... .................. 4-159
Stopping the Smart Brake Support
[Rear] (SBS-R) system
operation.................................... 4-159
Spare Tire............................................ 7-5
Spare Tire and Tool Storage............... 7-3
Specifications Air conditioner......... ..................... 9-8
Capacities.......................................9-5
Dimensions.................................... 9-6
Electrical system............................9-4
Engine............................................ 9-4
Light bulbs.....................................9-8
Lubricant quality........................... 9-4Tires............................................... 9-9
Weights.......................................... 9-6
SRS Air Bags Driver and front passenger occupant
classification system.................... 2-71
How the SRS air bags work........ 2-64
Limitations to SRS air bag.......... 2-70
Monitoring................................... 2-76
SRS air bag deployment
criteria.......................................... 2-68
Supplemental restraint system
components.................................. 2-62
Supplemental restraint system (SRS)
precautions................................... 2-55
Starting the Engine..............................4-5
Steering Wheel
Heated steering wheel................. 2-21
Horn............................................. 4-56
Storage Compartments...................... 5-40
Center console............................. 5-41
Glove compartment..................... 5-41
Overhead console........................ 5-41
Storage pocket............................. 5-41
Storage Pocket...................................5-41
Sunshade............................................3-38
Sunvisors........................................... 5-33
T
Theft-Deterrent System..................... 3-41
Three-flash Turn Signal.................... 4-49
Tiedown Hook...................................7-23
Tires................................................... 6-30 Replacing a tire........................... 6-32
Replacing a wheel....................... 6-33
Snow tires.................................... 3-46
Specifications.................................9-9
Temporary spare tire....................6-32
Tire chains................................... 3-47
Tire inflation pressure................. 6-30
Tire rotation................................. 6-31
10-8
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Index
Mazda Radar Cruise Control
(MRCC) system warnings........... 7-44
Seat belt warning beep................ 7-41
Touch sensor inoperable warning
beep (With the advanced keyless
function).......................................7-43
Warranty............................................ 8-14
Weights................................................ 9-6
Windows Power windows........................... 3-33
Windshield Washer........................... 4-53
Windshield Wipers............................ 4-50
Windshield Wipers Operate at High
Speed................................................. 7-49
Windshield Wiper De-icer................ 4-55
Winter Driving.................................. 3-46
Wiper Replacing Rear Window Wiper Blade
(5-Door)....................................... 6-24Replacing windshield wiper
blades........................................... 6-21
0-9
360°View Monitor...........................4-164How to use the system.............. 4-173
Margin of error be tween road surface
on screen and actual road
surface........................................4-192
Side view................................... 4-182
Top view/front view.................. 4-177
Top view/front wide view......... 4-180
Top view/rear view.................... 4-185
Top view/rear wide v iew........... 4-190
Types of images displayed on the
screen......................................... 4-168
10-10
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10
