run flat MAZDA MODEL 6 2019 (in English) User Guide

SignalWarning Action to be taken
Door-Ajar/Trunk
lid-Ajar Warning Indi‐ cation/Warning Light The light turns on if any door/trunk lid is
not closed securely.
Close the door/tr
unk lid securely.

Tire Pressure Monitoring Syste m Warning Light (Turns on)
Take the appropriate action and verify that the warning light t urns off.
Wa r n i n g
When the warning light illuminates, and the warning beep sound is heard when tire pressure is too low in one or
more tires.
WA R N I N G
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, decrease vehicle speed immediately and avoid sudden maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, it is dangerous to drive the vehicle at high speeds, or perform sudden maneuvering or braking. Vehicle
drivability could worsen an d result in an accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can check the visual condition
of the tire and determine if you have enough air to proceed to a place where air may be added and the system
monitored again by an Authorized Mazda Dealer or a tire repair station.
Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is da ngerous, even if you know why it is illuminated. Have the problem taken
care of as soon as possible before it develops into a more serious situation that could lead to tire failure and a
dangerous accident.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-35
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Request Switch Inoperable Warning
Beep (With the advanced keyless
function)
If the request switch is pressed with the
door open or ajar, or the ignition is not
switched OFF with a key being carried, a
beep will be heard outside for about 2
seconds to notify the driver that the door
or trunk lid cannot be locked.
▼Key Left-in-trunk Compartment
Warning Beep (With the advanced
keyless function)
If the key is left in the trunk with all the
doors locked and the trunk lid closed, a
beep will be heard outside for about 10
seconds to notify the driver that the key is
in the trunk. In this case, take out the key
by pressing the electric trunk lid opener
and opening the trunk lid. The key taken
out of the trunk may not operate because
its functions have been temporarily
stopped. To restore the key's functions,
perform the applicable procedure (page
3-7).
▼Key Left-in-vehicle Warning Beep
(With the advanced keyless
function)
If all the doors and trunk are locked using
another key while the key is left in the
cabin, the beep which sounds outside of
the vehicle will be heard for about 10
seconds to notify the driver that the key is
in the cabin. In this case, take out the key
by opening the door. A key taken out of
the vehicle using this method may not
operate because its functions have been
temporarily stopped. To restore the key's
functions, perform the applicable
procedure (page 3-7).
▼ Power Steering Warning Buzzer
If the power steer
ing system has a
malfunction, the power steering
malfunction indication/malfunction
indicator light turns on or flashes and the
buzzer operates at the same time.
Refer to Stop Vehicle in Safe Place
Immediately on page 7-23.
▼ Electric Parking Brake (EPB)
Warning Beep
The warning buzzer is activated under the
following conditions:
The vehicle is driven with the parking
brake applied.
The Electric Parking Brake (EPB)
switch is pulled while the vehicle is
driven.
▼Tire Inflation Pressure Warning
Beep
The warning beep sound will be heard for
about 3 seconds if the tire pressures
decrease.
Refer to Tire Pressure Monitoring System
on page 4-220.
▼AUTOHOLD Warning Beep
Warning light flashes/m
essage is displayed
and beep sound is activated
simultaneously for about 5 seconds when
using AUTOHOLD function or when
AUTOHOLD switch is operated.
Because a problem with AUTOHOLD
function has occurred, AUTOHOLD
function does not operate even if
AUTOHOLD switch is operated.

If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-44
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Tire Labeling
Federal law requires tire manufacturers to place standardized information on the sidewall of
all tires. This information identifies and describes the fundam ental characteristics of the tire
and also provides a tire identification number for safety stand ard certification and in case of
a recall.
▼ Information on Passenger Vehicle Tires
Please refer to the sample below.
1. TIN: U.S. DOT tire identification number
2. Passenger car tire
3. Nominal width of tire in millimeters
4. Ratio of height to width (aspect ratio)
5. Radial
6. Run-flat tire
7. Rim diameter code
8. Load index & speed symbol
9. Severe snow conditions
10. Tire ply composition and materials used
11. Max. load rating
12. Tread wear, traction and temperature grades
13. Max. permissible inflation pressure
14. SAFETY WARNING
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-26
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

▼Safety Practices
The way you drive has a great deal to do with your tire mileage
and safety. So cultivate
good driving habits for your own benefit.
Observe posted speed limits and d rive at speeds that are safe for the existing weather
conditions
Avoid fast starts, stops and turns
Avoid potholes and objects on the road
Do not run over curbs or hit the tire against the curb when parking
CAUTION
If you feel a sudden vibration or ride distur bance while driving or you suspect your tire or
vehicle has been damaged, immediately reduce your speed. Drive with caution until you can
safely pull off the road. Stop and inspect the ti re for damage. If the tire is under-inflated or
damaged, deflate it, remove the tire and rim and rep lace it with your spare tire. If you cannot
detect a cause, have the vehicle towed to the nearest vehicle or tire dealer to have the vehicle
inspected.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-36
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Smart Brake Support (SBS)............ 4-174Collision warning...................... 4-176
Stopping the Smart Brake Support
(SBS) system operation............. 4-176
Smart City Brake Support
(SCBS)............................................ 4-171 Collision warning...................... 4-173
Smart City Brake Support (SCBS)
Indicator Light (Red).................4-173
Stopping the Smart City Brake
Support (SCBS) System
Operation................................... 4-174
Spare Tire............................................ 7-5
Specifications...................................... 9-4
SRS Air Bags Front passenger occupant
classification system.................... 2-67
How the SRS air bags work........ 2-60
Limitations to SRS air bag.......... 2-65
Monitoring................................... 2-71
SRS air bag deployment
criteria.......................................... 2-64
Supplemental restraint system
components.................................. 2-58
Starting the Engine..............................4-5
Steering Wheel
Heated steering wh eel................. 2-21
Horn............................................. 4-85
Storage Compartments ...................... 5-92
Armrest box................................. 5-93
Center console............................. 5-93
Glove compartment..................... 5-93
Overhead console........................ 5-92
Rear coat hooks........................... 5-94
Sunshade............................................3-34
Sunvisors........................................... 5-83
T
Theft-Deterrent System ..................... 3-37
Three-flash Turn Signal.................... 4-79
Tiedown
Hook............................................ 7-21
Tires................................................... 6-39 Flat tire.......................................... 7-3
Replacing a tire........................... 6-40
Replacing a wheel....................... 6-42
Snow tires.................................... 3-42
Specifications.................................9-8
Temporary spare tire....................6-41
Tire chains................................... 3-42
Tire inflation pressure................. 6-39
Tire rotation................................. 6-40
Uniform tire quality grading system
(UTQGS)..................................... 8-24
Tire Inflation Pressure Warning
Beep...................................................7-44
Tire Information................................ 8-26
Tire Pressure Monitoring System.... 4-220
To w i n g
Recreational towing.....................3-47
Trailer towing.............................. 3-47
Towing Description........................... 7-20
Traction Control System (TCS)...... 4-106
TCS/DSC indicator light........... 4-106
Traffic Sign Recognition System
(TSR)............................................... 4-128
Trouble Battery runs out........................... 7-14
Emergency starting...................... 7-17
Emergency towing....................... 7-20
Flat tire.......................................... 7-3
Overheating................................. 7-18
Parking in an emergency............... 7-2
Warning/indicator lights and warning
sounds............. ............................. 7-23
When trunk lid cannot be
opened..........................................7-47
Trunk Lid............ .............................. 3-16
Inside trunk release lever............ 3-18
When trunk lid cannot be
opened..........................................7-47
10-9
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Turn and Lane-Change Signals......... 4-79
Turn Signals...................................... 4-79
U
USB Power Outlet............................ 5-89
V
Vanity Mirrors................................... 5-83
Vehicle Information Labels................. 9-2
W
Warning Sound is Activated............. 7-42Air bag/seat belt pr etensioner system
warning beep............................... 7-42
AUTOHOLD Warning Beep....... 7-44
Blind Spot Monitoring (BSM)
warning beep............................... 7-45
Collision warning...... .................. 7-46
Electric Parking Brake (EPB)
Warning Beep.............................. 7-44
Excessive speed warning.............7-46
Ignition not switched off (STOP)
warning beep............................... 7-43
Key left-in-trunk warning beep (With
the advanced keyless function).... 7-44
Key left-in-vehicle warning beep
(With the advanced keyless
function).......................................7-44
Key removed from vehicle warning
beep..............................................7-43
Lane Departure Warning sound... 7-45
Lights-on reminder...................... 7-42
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) system
warnings.......................................7-45
Power steering warning buzzer....7-44
Request switch inoperable warning
beep (With the advanced keyless
function).......................................7-44
Seat belt warning beep................ 7-42
Tire inflation pressure warning
beep..............................................7-44
Warning/Buzzer................................. 7-23
Warranty............................................ 8-17
Weights................................................ 9-6
Windows Power windows........................... 3-29
Windshield Washer........................... 4-83
Windshield Wipers............................ 4-80
Windshield Wiper De-icer................ 4-84
Winter Driving.................................. 3-41
Wiper
Replacing windshield wiper
blades........................................... 6-30
0-9
360°View Monitor...........................4-177Front wide view.........................4-191
How to use the system.............. 4-183
Margin of error be tween road surface
on screen and actual road
surface........................................4-200
Rear wide view..........................4-198
Side view................................... 4-192
Top view/Front view................. 4-187
Top view/Rear view.................. 4-194
Types of images displayed on the
screen......................................... 4-181
10-10
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
