Rocking the Vehicle
WA R N I N G
Do not spin the wheels at more than 56
km/h (35 mph), and do not allow anyone
to stand behind a wheel when pushing the
vehicle:
When the vehicle is stuck, spinning the
wheels at high speed is dangerous. The
spinning tire could overheat and explode.
This could cause serious injuries.
CAUTION
Too much rocking may cause engine
overheating, transaxle failure, and tire
damage.
If you must rock the vehicle to free it from
snow, sand or mud, depress the accelerator
slightly and slowly move the selector lever
from D to R position.
Winter Driving
Carry emergency gear, including tire
chains, window scraper, flares, a small
shovel, jumper cables, and a small bag of
sand or salt.
Ask an Authorized Mazda Dealer to check
the following:
Have the proper ratio of antifreeze in the
radiator.
Refer to Engine Coolant on page 6-26.
Inspect the battery and its cables. Cold
reduces battery capacity.
Use an engine oil appropriate for the
lowest ambient temperatures that the
vehicle will be driven in (page 6-22).
Inspect the ignition system for damage
and loose connections.
Use washer fluid made with
antifreeze―but do not use engine
coolant antifreeze for washer fluid (page
6-29).
NOTE
Remove snow before driving. Snow left
on the windshield is dangerous as it
could obstruct vision.
Do not apply excessive force to a
window scraper when removing ice or
frozen snow on the mirror glass and
windshield.
Never use warm or hot water for
removing snow or ice from windows and
mirrors as it could result in the glass
cracking.
Before Driving
Driving Tips
3-46
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Interior Care
WARNING
Do not spray water into the vehicle cabin:
Spraying water into the vehicle cabin is
dangerous as electrical devices such as the
audio and switches could get wet resulting
in a malfunction or vehicle fire.
NOTE
Do not wipe the interior using alcohol,
chlorine bleach, or organic solvents
such as thinner, benzene, and gasoline.
Otherwise, it may cause discoloration or
stains.
Rubbing hard with a stiff brush or cloth
may cause damage.
If the vehicle interior becomes soiled by
any of the follo wing, wipe it off
immediately using a soft cloth.
Leaving it uncleaned could cause
discoloration, stains , cracks, or peeling of
the coating, and it will make it hard to
wipe off later.
Beverage or fragrance
Grease or oil
Soiling
▼ Seat Belt Maintenance
1. Clean the soiled area by lightly
dabbing it with a soft cloth soaked in a
mild detergent (approx. 5%) diluted
with water.
2. Wipe off the remaining detergent using
a cloth soaked in clean water and
wrung out well.
3. Before retracting seat belts which havebeen pulled out for cleaning, dry them
off thoroughly and make sure there is
no remaining moisture on them.
WA R N I N G
If a seat belt appears frayed or has
abrasions, have it replaced by an
Authorized Mazda Dealer:
If a seat belt is used under such a condition,
it cannot function at its full capacity which
could result in serious injury or death.
Use a mild detergent to remove soiling
from a seat belt:
If organic solvents are used for cleaning the
seat belts or they become stained or
bleached, there is the possibility of them
becoming weakened and as a result, they
may not function at their full capacity
which could cause serious injury or death.
NOTE
Clean seat belts diligently if they get dirty.
Leaving them uncleaned will make it
difficult to clean them later, and it may
affect the smooth retracting of the seat
belt.
▼Vinyl Upholstery Maintenance
Remove dust and dirt from the vinyl
upholstery using a brush or vacuum.
Remove soiling from
vinyl upholstery
using a leather and vinyl upholstery
cleaner.
Maintenance and Care
Appearance Care
6-65
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

CAUTION
When cleaning the iridium plugs, do not use a wire brush. The
fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-22.
Coolant FL-22 type
Automatic transaxle fluid Mazda Genuine ATF FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil SKYACTIV-G
2.5
With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil filter replacement 4.3 L (4.5 US qt, 3.8 Imp qt)
SKYACTIV-G
2.5T With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replacement 4.6 L (4.9 US qt, 4.0 Imp qt)
SKYACTIV-D
2.2 With oil filter replacement
5.1 L (5.4 US qt, 4.5 Imp qt)
Without oil filter replacement 4.8 L (5.1 US qt, 4.2 Imp qt)
Coolant U.S.A. and
Canada SKYACTIV-G 2.5
7.0 L (7.4 US qt, 6.2 Imp qt)/7.1 L (7.5 US qt, 6 .2
Imp qt)
SKYACTIV-G 2.5T 8.3 L (8.8 US qt, 7.3 Imp qt)
SKYACTIV-D 2.2 8.6 L (9.1 US qt, 7.6 Imp qt)
Mexico SKYACTIV-G 2.5
7.1 L (7.5 US qt, 6.2 Imp qt)
SKYACTIV-G 2.5T 8.2 L (8.7 US qt, 7.2 Imp qt)
Automatic
transaxle
fluid SKYACTIV-G 2.5
7.8 L (8.2 US qt, 6.9 Imp qt)/8.0 L (8.5 US qt, 7.0
Imp qt)
SKYACTIV-G 2.5T, SKYACTIV-D 2.2 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Specifications
Specifications
9-5
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

ItemCapacity
Fuel tank FWD
62.0 L (16.4 US gal, 13.6 Imp gal)
AWD 52.0 L (13.7 US gal, 11.4 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼Dimensions
Item
Vehicle specification
Overall length Without license plate holder
4,865 mm (191.5 in)
With license plate holder 4,895 mm (192.7 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,450 mm (57.1 in)
Front tread 17 inch wheel vehicle
1,585 mm (62.4 in)
19 inch wheel vehicle 1,595 mm (62.8 in)
Rear tread 17 inch wheel vehicle
1,575 mm (62.0 in)
19 inch wheel vehicle 1,585 mm (62.4 in)
Wheelbase 2,830 mm (111.4 in)
▼We i g h t s
U.S.A. and Canada
SKYACTIV-G 2.5
Item
Weight
GVWR (Gross Vehicle Weight Rating) 2,029 kg (4,473 lbs)
GAWR (Gross Axle Weight Rating) Front
1,078 kg (2,377 lbs)
Rear 957 kg (2,110 lbs)
SKYACTIV-G 2.5T
Item Weight
GVWR (Gross Vehicle Weight Rating) 2,065 kg (4,552 lbs)
GAWR (Gross Axle Weight Rating) Front
1,107 kg (2,440 lbs)
Rear 963 kg (2,123 lbs)
SKYACTIV-D 2.2
Item Weight
GVWR (Gross Vehicle Weight Rating) 2,185 kg (4,817 lbs)
GAWR (Gross Axle Weight Rating) Front
1,166 kg (2,571 lbs)
Rear 1,024 kg (2,258 lbs)
Specifications
Specifications
9-6
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Index
Aluminum wheel maintenance.... 6-64
Bright-metal maintenance........... 6-63
Maintaining the finish................. 6-60
Plastic part maintenance.............. 6-64
F
Flasher Hazard warning........................... 4-91
Headlights.................................... 4-78
Flat Tire............................................... 7-3 Mounting the spare tire............... 7-12
Removing a flat tire...................... 7-8
Floor Mat.......................................... 3-45
Fluid Brake............................................6-28
Washer......................................... 6-29
Fluids Classification................................. 9-5
Foot Brake.......................................4-100
Forward Sensing Camera (FSC)..... 4-215
Fuel Filler lid and cap......................... 3-27
Requirements (SKYACTIV-D
2.2)............................................... 3-22
Requirements (SKYACTIV-G 2.5,
SKYACTIV-G 2.5T)....................3-21
Tank capacity.................................9-5
Fuses.................................................. 6-52 Panel description......................... 6-55
Replacement................................ 6-52
G
Gauges............................................... 4-13
Glove Compartment.......................... 5-37
H
Hazardous Driving............................ 3-45
Hazard Warning Flasher....................4-91
HeadlightsComing home light......................4-82
Control......................................... 4-78
Flashing....................................... 4-82
Headlight flashing....................... 4-82
High-low beam............................ 4-82
Leaving home light..................... 4-83
Leveling....................................... 4-83
Head Restraint................................... 2-17
High Beam Control System
(HBC).............................................. 4-123 High Beam Control System (HBC)
indicator light (green)................4-124
Hill Launch Assist (HLA).......... .... 4-109
HomeLink Wireless Control System
(Type A)............................................ 4-92
HomeLink Wireless Control System
(Type B)............................................ 4-95
Hood Release............. ....................... 6-18
Horn...................................................4-91
I
If a Warning Light Turns On or
Flashes............................................... 7-25
If the Active Driving Display Does Not
Operate.............................................. 7-51
Ignition Switch............................................ 4-4
Ignition Not Switched Off (STOP)
Warning Beep.................................... 7-46
Illuminated Entry System................. 5-32
Immobilizer System..... ..................... 3-40
Inside Trunk Release Lever.............. 3-20
Inspecting Brake Fluid Level............ 6-28
Inspecting Coolant Level.................. 6-26
Inspecting Engine Oil Level............. 6-25
Inspecting Washer Fluid Level......... 6-29
Instrument Cluster............................. 4-13 Instrument Cluster (Type A)........4-14
Instrument Cluster (Type B)........ 4-33
Instrument Cluster (Type C)........ 4-51
Instrument Cluster (Type A)............. 4-14
