QuestionAnswer
Why does my engine never shut
down above 40 mph (64 km/h)? The engine is required to turn on
above this speed to protect the
transaxle hardware.
Why does my engine stay ON
when it’s extremely cold outside? In order to ensure that the climate
control system can begin heating
the cabin and/or defrosting the
windshield as soon as a driver
requests it, the engine coolant
temperature has to be kept
sufficiently hot. Keeping the
engine on is required to maintain
the correct minimum temperature.
Why does my engine rev up so
high sometimes when I accelerate? Your vehicle’s engine and
transmission are designed to
deliver the power you need at the
most efficient engine speed. This
may be higher than expected
during heavy accelerations, and
may fluctuate during steady state
driving. These are characteristics
of the Atkinson engine cycle and
the eCVT transaxle technology
that help maximize your hybrid’s
fuel economy.
What does it mean when my
power assist gauge moves to the
right? To the left? Electricity is coming out of the
battery when the gauge moves to
the right. Electricity is going into
the battery when the gauge moves
to the left.
2008 Tribute Hybrid
(thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
11

QuestionAnswer
What is the fan noise and slight
tapping sound I hear from the rear
of my hybrid? The fan noise comes from two fans
located inside the high voltage
battery. These fans turn on when
the battery requires cooling air.
The fan speed, and associated
noise level, will change according
to the amount of cooling required
to maintain good performance.
How far can I go in Electric Drive
if I run out of gas? Running out of gas is not
recommended. However, you may
be able to go about one mile,
driving at 30 mph (48 km/h), if the
battery has a normal state of
charge.
What is the engine oil change
service interval? The engine oil should be changed
every 10,000 miles (16,000 km)
under normal operating conditions.
See the
Scheduled maintenance
guide chapter.
Can I put E10 or E85 in my
vehicle, and how will it affect my
fuel economy? Your hybrid vehicle can use E10
(10% ethanol, 90% gasoline) fuel,
but you may notice slightly
reduced fuel economy because
ethanol contains less energy per
gallon than gasoline. Your hybrid
vehicle is not designed to use E85
(85% ethanol).
How long will my high voltage
battery last? Does it need
maintenance? The high voltage battery system is
designed to last the life of the
vehicle and requires no
maintenance.
2008 Tribute Hybrid
(thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
12

QuestionAnswer
Can you charge the battery with a
plug into an A/C outlet? There are no provisions for
charging the high voltage battery
from a power supply external to
the vehicle.
What is the purpose of the ECON
button? ECON mode may provide
improved fuel economy by
preventing the gasoline engine
from running for the sole purpose
of providing air conditioning. When
the engine turns off, the A/C
compressor does not operate and
warm air may come out of the
vents. In ECON mode, A/C
operates as normal when the
gasoline engine is running.
Can I tow the hybrid behind my
motor home with all four wheels
down? Yes. Your hybrid vehicle can be
“flat-towed” without modification.
See the
Recreational Towing
section in the Tires, Wheels and
Loading chapter for more
information.
SPECIAL NOTICES
New Vehicle Limited Warranty
For a detailed description of what is covered and what is not covered by
your vehicle’s New Vehicle Limited Warranty, refer to the Warranty
Information Booklet that is provided to you along with your Owner’s
Manual.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
13

Special instructions
For your added safety, your vehicle is fitted with sophisticated electronic
controls.WARNING: Please read the section Airbag supplemental
restraint system (SRS) in theSeating and Safety Restraints
chapter. Failure to follow the specific warnings and instructions
could result in personal injury.
WARNING: Front seat mounted rear-facing child or infant seats
should NEVER be placed in front of an active passenger airbag.
Service Data Recording
Service data recorders in your vehicle are capable of collecting and
storing diagnostic information about your vehicle. This potentially
includes information about the performance or status of various systems
and modules in the vehicle, such as engine, throttle, steering or brake
systems. In order to properly diagnose and service your vehicle, Mazda
Motor Corporation, Mazda Canada, and service and repair facilities may
access vehicle diagnostic information through a direct connection to your
vehicle when diagnosing or servicing your vehicle.
Event Data Recording
Other modules in your vehicle — event data recorders — are capable of
collecting and storing data during a crash or near crash event. The
recorded information may assist in the investigation of such an event.
The modules may record information about both the vehicle and the
occupants, potentially including information such as:
• how various systems in your vehicle were operating;
• whether or not the driver and passenger seatbelts were buckled;
• how far (if at all) the driver was depressing the accelerator and/or the
brake pedal;
• how fast the vehicle was traveling; and
• where the driver was positioning the steering wheel.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
14

To access this information, special equipment must be directly connected
to the recording modules. Mazda Motor Corporation and Mazda Canada
do not access event data recorder information without obtaining consent,
unless pursuant to court order or where required by law enforcement,
other government authorities or other third parties acting with lawful
authority. Other parties may seek to access the information
independently of Mazda Motor Corporation and Mazda Canada.
Notice to owners of pickup trucks and utility type vehiclesWARNING: Utility vehicles have a significantly higher rollover
rate than other types of vehicles.
Before you drive your vehicle, please read this Owner’s Manual
carefully. Your vehicle is not a passenger car. As with other vehicles of
this type, failure to operate this vehicle correctly may result in loss of
vehicle control, vehicle rollover, personal injury or death.
Using your vehicle with a snowplow
Do not use this vehicle for snowplowing.
Your vehicle is not equipped with a snowplowing package.
Using your vehicle as an ambulance
Do not use this vehicle as an ambulance.
Your vehicle is not equipped with the Mazda Ambulance Preparation
Package.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
15

These are some of the symbols you may see on your vehicle.Vehicle Symbol Glossary
Safety Alert
See Owner’s Manual
Protecting the
EnvironmentFasten Seat Belt
Airbag - FrontAirbag - Side
Passenger Airbag OffChild Seat Lower
Anchor
Child Seat Tether
AnchorBrake System
Anti-Lock Brake SystemParking Brake System
Brake Fluid -
Non-Petroleum BasedParking Aid System
Stability Control SystemMaster Lighting Switch
Hazard Warning FlasherFog Lamps-Front
Fuse CompartmentFuel Pump Reset
Windshield Wash/WipeWindshield
Defrost/Demist
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
16

Vehicle Symbol Glossary
Rear Window
Defrost/Demist
Power Windows
Power Window LockoutPersonal Alarm System
Feature
Engine OilEngine Coolant
Engine Coolant
TemperatureDo Not Open When Hot
BatteryAvoid Smoking, Flames,
or Sparks
Battery AcidExplosive Gas
Fan WarningPower Steering Fluid
Maintain Correct Fluid
LevelMAX MIN
Service Engine Soon
Engine Air FilterSpeed Control
Passenger Compartment
Air FilterJack
Check Fuel CapLow Tire Pressure
Warning
INFORMATION ABOUT THIS GUIDE
The information found in this guide was accurate at the time of printing.
Mazda may change the contents without notice.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
17

Multi-function lever(pg. 58) Instrument cluster
(pg. 20)
Hazard flasher control(pg. 202)
Headlamp control
(pg. 47)
Parking brake release (pg. 189) Speed controls*
(pg. 69) Hood release
(pg. 249) Steering wheel controls*
(pg. 72)
* if equipped
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
18

Climate controls(pg. 42) Audio system
(pg. 27)
Auxiliary input jack (pg. 35)
Auxiliary power point (pg. 61)
*if equipped
2008 Tribute Hybrid(thv)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
19

WARNING LIGHTS AND CHIMES
Warning lights and gauges can alert you to a safety hazard or a vehicle
condition that may become serious enough to cause extensive repairs. A
warning light may illuminate when a problem exists with one of your
vehicle’s functions. Many lights will illuminate when you start your
vehicle to make sure the bulbs work. If any light remains on after
starting the vehicle, refer to the respective system warning light for
additional information.
Service engine soon:TheService
engine soon indicator light
illuminates when the ignition is first
turned to the ON position to check
the bulb and to indicate whether the vehicle is ready for
Inspection/Maintenance (I/M) testing. Normally, the Service engine soon
light will stay on until the engine is cranked, then turn itself off if no
malfunctions are present. However, if after 15 seconds the Service
engine soon light blinks eight times, it means that the vehicle is not
ready for I/M testing. See the Readiness for Inspection/Maintenance
(I/M) testing in theMaintenance and Specifications chapter.
Solid illumination after the engine is started indicates the On Board
Diagnostics System (OBD-II) has detected a malfunction. Refer to On
board diagnostics (OBD-II) in theMaintenance and Specifications
chapter. If the light is blinking, engine misfire is occurring which could
damage your catalytic converter. Drive in a moderate fashion (avoid
heavy acceleration and deceleration) and have your vehicle serviced
immediately by your authorized dealer.
