MAZDA MODEL CX-3 2021 Owners Manual

▼Operating Tips for USB device
This unit plays audio files as follows:
Extension Playback with this unit
.mp3 MP3
.wma WMA
.aac
*1AAC
.m4a
.wav
*1WAV
.ogg
*1OGG
CAUTION
Do not use an audio file extension on files
other than audio files. In addition, do not
change the audio file extension. Otherwise,
the unit will not recognize the file correctly
resulting in noise or a malfunction.
NOTE
Playback may not be possible depending
on the type and condition of the USB
flash memory even if the audio file
complies with the standard.
A copyright protected WMA/AAC file
cannot be played in this unit.
(Type B)
If a file name in th e USB memory is too
long, it could cause operation problems
such as not being able to playback the
song.
(Recommended: Within 80 characters)
The order of the music data stored in the
device may differ from the playback
order.
To prevent loss or damage of stored
data, we recommend that you always
back up your data.
(Vehicles without USB port indicated
with
)
If a device exceeds the maximum
electric current value of 1,000 mA, it
may not operate or recharge when
connected.
(Vehicles with USB port indicated with
)
If the current consumption of the
connected device exceeds the following
current value, it may not operate or
recharge.
Apple device is connected : 2,100 mA
Device compatible with BC1.2 is
connected : 1,500 mA
Device other than the above is
connected : 500 mA
Do not pull out the USB device while in
the USB mode (only pull it out while in
FM/AM radio mode).
The device will not operate if the data is
password protected.
MP3/WMA/AAC/OGG files written under
specifications other than the indicated
specification may not play normally or
files/folder names may not display
correctly.
*1 Type B
▼ Operating Tips for iPod
This unit supports playback of music files
recorded to an iPod.

 iPod is a trademark of Apple Inc.,
registered in the U.S. and other
countries.
The iPod may not be compatible
depending on the model or OS version. In
this case, an error message is displayed.
Interior Features
Appendix
5-139
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

CAUTION
Remove the iPod when it is not in use.
Because the iPod is not designed to
withstand excessive changes in
temperature inside the cabin, it could be
damaged or the battery may deteriorate
due to the excessive temperature or
humidity inside the cabin if it is left in the
vehicle.
 If data in the iPod is lost while it is
connected to the unit, Mazda cannot
guarantee recovery of any lost data.
 If the iPod battery is deteriorated, the
iPod may not recharge and playback
may not be possible when it is connected
to the unit.
 For details on using the iPod, refer to the
iPod instruction manual.
 When connecting the iPod to a USB port,
all commands are made from the audio
unit. iPod control is not possible.
NOTE
The audio unit cannot display images or
videos stored in an iPod.
▼ Agreements and disclaimers related
to Apple CarPlay™
This unit is compatible with Apple
CarPlay™ which can operate an iPhone
®
using the vehicle's audio device.

 iPhone, Siri and Apple Music are
registered trademarks of Apple Inc.
 Apple CarPlay is trademarks of Apple
Inc.
 iOS is a trademark or registered
trademark of Cisco in the U.S. and other
countries and is used under license.
May not be compatible depending on the
model or OS version.
CAUTION

For the purposes of safety, do not
operate your iPhone
® while driving.
 Disconnect the iPhone
® when it is not in
use. If the device is left in the cabin, it
could be damaged or the battery may
deteriorate due to the excessive
temperature or humidity inside the
cabin.
 If the iPhone
® battery has deteriorated, it
may not recharge or play audio even if it
is connected to this unit.
 Before use, carefully read the user
instructions for the iPhone
®.
NOTE
To prevent loss or damage of stored data,
we recommend that you always back up
your data.
▼ Operating Tips for Android™
Requires the Android Auto app on Google
Play and an Android compatible
smartphone running Android™ 5.0
Lollipop or higher.
CAUTION

For the purposes of safety, do not
operate your Android™ Smartphone
while driving.
 Disconnect the Android™ Smartphone
when it is not in use. If the device is left in
the cabin, it could be damaged or the
battery may weaken due to the excessive
temperature or humidity inside the
cabin.
Interior Features
Appendix
5-140
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

If the Android™ Smartphone battery has
deteriorated, it may not recharge or play
audio even if it is connected to this unit.
 Before use, carefully read the user
instructions for the Android™
Smartphone.
NOTE
To prevent loss or damage of stored data,
we recommend that you always back up
your data.
 Google, Android, Android Auto and
other related marks are trademarks of
Google LLC.
Interior Features
Appendix
5-141
CX-3_8JL1-EA-20G_Edition1_old
2020-5-22 15:31:00

Sunvisors
When you need a sunvisor, lower it for use
in front or swing it to the side.
Sunvisor
▼ Side Extension Sunvisors*
The visor extender extends the sunvisor's
range of sun shading.
To use, pull it out.
CAUTION
When moving the sunvisor, retract the visor
extender to its original position. Otherwise,
the visor extender could hit the rearview
mirror.
▼Va n i t y M i r r o r s
To use the vanity mirror, lower the
sunvisor.
Interior Lights
NOTE
Do not leave the lights on for long periods
while the engine is turned off. Otherwise,
the battery power could be depleted.
Overhead Lights
Switch Posi
‐
tion Overhead Lights
Light off
Light is on when any door is openLight is on or off when the illumi
‐
nated entry system is on
Light on

Front
Rear
NOTE
The rear overhead light also turn on and
off when the front o verhead light switch is
operated.
Interior Features
Interior Equipment
5-142*Some models.
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Map Lights
When the overhead light switch is in the
door or off position, press the lens to
illuminate the map lights, and then press
the lens again to turn them off.

NOTE
The map lights will not turn off even if the
lens is pressed in the following cases:
The overhead light switch is in the ON
position.
The overhead light switch is in the door
position with the door open.
The illuminated entry system is on.
Luggage Compartment Lights

Switch Posi ‐
tion Luggage Compartment Light
Light off
Light on when the liftgate is open
▼
Illuminated Entry System
The overhead lights turn on when any of
the following operations is done with the
overhead light switch in the DOOR
position.
The driver's door is unlocked with the
ignition is switched OFF.
The ignition is swit
ched OFF with all
doors closed.
NOTE
The illumination tim e differs depending
on the operation.
Battery saver
If an interior light is left on with the
ignition switched OFF, the light is
turned off automatically after about 30
minutes to prevent battery depletion.
The operation of the illuminated entry
system can be changed.
Refer to Personalization Features on
page 9-9.
Interior Features
Interior Equipment
5-143
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Accessory Socket
Only use genuine Mazda accessories or
the equivalent requiring no greater than
120 W (DC 12 V, 10 A).
The ignition must be switched to ACC or
ON.

CAUTION
To prevent accessory socket damage or
electrical failure, pay attention to the
following:
 Do not use accessories that require
more than 120 W (DC 12 V, 10 A).
 Do not use accessories that are not
genuine Mazda accessories or the
equivalent.
 Close the cover when the accessory
socket is not in use to prevent foreign
objects and liquids from getting into
the accessory socket.
 Correctly insert the plug into the
accessory socket.
 Do not insert the cigarette lighter into
the accessory socket.
 Noise may occur on the audio playback
depending on the device connected to
the accessory socket.
Depending on the device connected to
the accessory socket, the vehicle's
electrical system may be
affected, which
could cause the warning light to
illuminate. Disconnect the connected
device and make sure that the problem is
resolved. If the problem is resolved,
disconnect the device from the socket
and switch the ignition off. If the problem
is not resolved, consult an Authorized
Mazda Dealer.
NOTE
To prevent discharging of the battery, do
not use the socket for lo ng periods with the
engine off or idling.
Interior Features
Interior Equipment
5-144
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Cup Holder
WARNING
Never use a cup holder to hold hot liquids
while the vehicle is moving:
Using a cup holder to hold hot liquids while
the vehicle is moving is dangerous. If the
contents spill, you could be scalded.
▼Front
There are two cup holders.
Front
Rear
How to use the cup holder
Front
Press the button on the divider. The flap
pops up to hold the drink cup in place
firmly.
Rear
Pull up the armrest and press the button on
the divider. The flap pops up to hold the
drink cup in place firmly.
Flaps
Buttons
NOTE
(Rear)
If the divider was removed, return it to
its original position.
Refer to Center Console on page 5-148.
The base plate lowers at the same time
the flap pops up. Use it to hold small
drink cups. When placing tall bottles
such as PET drink bottles, retract the
flap and the base plate.
To retract the front/rear flaps and rear
base plate
Front
To retract the flap, press down the flap.
Interior Features
Interior Equipment
5-145
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Rear
To retract the base plate, insert a finger
into the notch of the base plate and pull it
up.
▼Rear*
The rear cup holder is on the rear center
armrest.
To use the rear seat cup holders, pull open
the lids.
Lids
CAUTION

Be careful not to pinch your hand or
finger when closing the cover. Otherwise,
you could pinch and injure your fingers
or hand.
 When putting a PET bottle or a tall drink
cup in the cup holder, make sure it is held
securely. Depending on the height and
shape of the drink cup or bottle, it may
not remain held in the cup holder while
you are driving the vehicle.
 Do not close the lid or store the armrest
with small items left in the cup holder.
Otherwise, the items could be damaged.
NOTE
If it is difficult to remove a PET bottle
from the cup holder, press the flap with
your fingers to make it easier to pull out.
Flaps
Flaps
Interior Features
Interior Equipment
5-146*Some models.
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00

Bottle Holder
Bottle holders are on the inside of the
doors.
Front
Bottle holder
Rear
Bottle holder
CAUTION
Do not use the bottle holders for containers
without caps. The contents may spill when
opening/closing the door or while driving
the vehicle.
Storage Compartments
WA R N I N G
Keep storage boxes closed when driving:
Driving with the storage boxes open is
dangerous. To reduce the possibility of
injury in an accident or a sudden stop, keep
the storage boxes closed when driving.
When loading cargo, make sure that it is
completely secured:
If the cargo is not completely secured, it
may move or collapse while driving or
during sudden braking, resulting in injury
or an accident.
Do not put articles in storage spaces with
no lid:
Putting articles in storage spaces with no
lid is dangerous as they could be thrown
around the cabin if the vehicle is suddenly
accelerated and cause injury depending on
how the article is stored.
CAUTION
Do not leave lighters or eyeglasses in the
storage boxes while parked under the sun.
A lighter could explode or the plastic
material in eyeglasses could deform and
crack from high temperature.
▼ Overhead Console*
This console box is designed to store
eyeglasses or other accessories.
Interior Features
Interior Equipment
*Some models.5-147
CX-3_8JL1-EA-20G_Edition1_old
2020-5-22 15:31:00

Push and release to open.
▼Glove Compartment
To open the glove compartment, pull the
latch toward you.
To close the glove compartment, firmly
press in the center of the glove
compartment lid.
▼Center Console
The rear divider can be removed and
stored.
Removing the divider provides a console
box with a wider space.
1. Pull out the divider.
Divider
(rear)
2. Insert the divider into the armrest from
the top with the flap side of the divider
facing the underside of the armrest,
and press it in until a click sound is
heard.
NOTE
To use the divider, install it in the
reverse order of removal.
Flap side
▼ Cargo Securing Loops
Use the loops in the
luggage compartment
to secure cargo with a rope or net. The
tensile strength of the loops is 196 N (20
Interior Features
Interior Equipment
5-148
CX-3_8JL1-EA-20G_Edition1_old 2020-5-22 15:31:00
