display MAZDA MODEL CX-5 2017 Owners Manual (in English)

4–17 8
When Driving
Rear View Monitor
Displayable Range on the Screen
The images on the screen may be different from the actual conditions.

(Screen display) Garnish
Bumper
(Actual view)
Object

NOTE
  The displayable range varies depending on the vehicle and road conditions.  The displayable range is limited. Objects under the bumper or around the bumper ends
cannot be displayed.
  The distance appearing in the displayed image is different from the actual distance
because the rear view parking camera is equipped with a speci fi c lens.
   Some optionally installed vehicle accessories may be picked up by the ca\
mera. Do not
install any optional parts that can interfere with the camera view, such as illuminating
parts or parts made of refl ective material.
  It may be dif fi cult to see the display under the following conditions, however, it does not
indicate a malfunction.
   In darkened areas.  When the temperature around the lens is high/low.  When the camera is wet such as on a rainy day or during periods of high \
humidity.  When foreign material such as mud is stuck around the camera.  When the camera lens refl ects sunlight or headlight beams.   Image display may be delayed if the temperature around the camera is low.
CX-5_8FN1-EA-16L_Edition1.indb 1782016/12/12 10:06:20

4–17 9
When Driving
Rear View Monitor
Viewing the Display
Guide lines which indicate the width of the vehicle (yellow) are displ\
ayed on the screen as a
reference to the approximate width of the vehicle in comparison to the w\
idth of the parking
space you are about to back into.
Use this display view for parking your vehicle in a parking space or gar\
age.

b
a

a) Vehicle width guide lines (yellow)
These guide lines serve as a reference to the approximate width of the v\
ehicle.
b) Distance guide lines.
These guide lines indicate the approximate distance to a point measured \
from the vehicle's rear (from the end of the bumper).
 The red and yellow lines indicate the points about 50 cm (19 in) for t\
he red line and 100 cm (39.3 in) for the yellow lines from the rear bumper (at the ce\
nter point of each
of the lines).

CAUTION
The guide lines on the screen are fi xed lines. They are not synced to the driver's turning
of the steering wheel. Always be careful and check the area to the vehicle's rear and the
surrounding area directly with your eyes while backing up.

CX-5_8FN1-EA-16L_Edition1.indb 1792016/12/12 10:06:20

4–18 0
When Driving
Rear View Monitor
Rear View Monitor Operation
The operation of the rear view monitor when reversing the vehicle varies\
depending on
the traffi c, road, and vehicle conditions. The amount of steering and the timing also varies
depending on conditions, so con fi rm the surrounding conditions directly with your eyes and
steer the vehicle in accordance with the conditions.
Be well aware of the above cautions prior to using the rear view monitor\
.
NOTE
Images displayed on the monitor from the rear view parking camera are reversed images
(mirror images).

1. Shift the shift lever/selector lever to R to switch the display to the r\
ear view monitor display.
2. Confi rming the surrounding conditions, reverse the vehicle.


(Display condition) (Vehicle condition)

3. After your vehicle begins entering the parking space, continue backing u\
p slowly so that the distance between the vehicle width lines and the sides of the parkin\
g space on the left
and right are roughly equal.
4. Continue to adjust the steering wheel until the vehicle width guide line\
s are parallel to the left and right sides of the parking space.
CX-5_8FN1-EA-16L_Edition1.indb 1802016/12/12 10:06:21

4–181
When Driving
Rear View Monitor
5. Once they are parallel, straighten the wheels and back your vehicle slow\
ly into the parking space. Continue checking the vehicle's surroundings and then sto\
p the vehicle in
the best possible position.


(Display condition) (Vehicle condition)

6. When the shift lever/selector lever is shifted from R to another shift l\
ever/selector lever position, the screen returns to the previous display.
CX-5_8FN1-EA-16L_Edition1.indb 1812016/12/12 10:06:21

4–182
When Driving
Rear View Monitor
NOTE
  If the parking space has division lines, straighten the wheels when the \
vehicle width guide
lines are parallel to them.
  Because there may be a difference between the displayed image, such as indicated below,
and the actual conditions when parking, always verify the safety at the \
rear of the vehicle
and the surrounding area directly with your eyes.
  In the image of the parking space (or garage) displayed on the screen, the back end
and distance guide lines may appear aligned in the monitor, but they may not actually
be aligned on the ground.
  When parking in a space with a division line on only one side of the par\
king space, the
division line and the vehicle width guide line appear aligned in the mon\
itor, but they
may not actually be aligned on the ground.



CX-5_8FN1-EA-16L_Edition1.indb 1822016/12/12 10:06:21

4–183
When Driving
Rear View Monitor
Variance Between Actual Road Conditions and Displayed Image
Some variance occurs between the actual road and the displayed road. Suc\
h variance in
distance perspective could lead to an accident. Note the following condi\
tions that may cause
a variance in distance perspective.
When the vehicle is tilted due to the weight of passengers and load
When the vehicle rear is lowered, the object displayed on the screen app\
ears farther than the
actual distance.
Variance
Object

When there is a steep grade behind the vehicle
When there is a steep upgrade (downgrade) behind the vehicle, the obje\
ct displayed on the
screen appears farther (downgrade: closer) than the actual distance.

A
AB
B
Appears
farther than
actual
distance
Appears
farther than
actual
distance
Object at actual
position
Object at actual position
Object on screen
A: Distance between the vehicle and object displayed on the screen.
B: Actual distance between the vehicle and object. Object on screen

CX-5_8FN1-EA-16L_Edition1.indb 1832016/12/12 10:06:21

4–184
When Driving
Rear View Monitor
Three-dimensional object on vehicle rear
Because the distance guide lines are displayed based on a fl at surface, the distance to the
three-dimensional object displayed on the screen is different from the actual distance.

A
A
C B
CB
(Actual distance) B>C=A
Sensed distance on screen A>B>C (Screen display)
(Actual condition)

Picture Quality Adjustment
WARNING
Always adjust the picture quality of the rear view monitor while the vehicle is stopped: Do not adjust the picture quality of the rear view monitor while driving the vehicle.
Adjusting the picture quality of the rear view monitor such as brightness, contrast, color,
and tint while driving the vehicle is dangerous as it could distract your attention from the
vehicle operation which could lead to an accident.

Picture quality adjustment must be done while the shift lever/selector l\
ever is in reverse (R).
There are four settings which can be adjusted including, brightness, con\
trast, tint, and color.
When adjusting, pay suf fi cient attention to the vehicle surroundings.

1. Select the icon on the screen to display the tabs.
2. Select the desired tab item.
3. Adjust the brightness, contrast, tint, and color using the slider.
If you need to reset, press the reset button.
4. Select the
icon on the screen to close the tab.

CX-5_8FN1-EA-16L_Edition1.indb 1842016/12/12 10:06:21

5–1*Some models.
5Interior Features
Use of various features for ride comfort, including air-conditioning and audio system.

Climate Control System...................... 5-4
Operating Tips ................................ 5-4
Vent Operation ............................... 5-5
Manual Type .................................. 5-7
Fully Automatic Type ................... 5-11

Before Using the Audio System ........ 5-15 Audio Control Switch .................. 5-15
AUX/USB .................................... 5-16
Antenna ........................................ 5-18

Audio Set
[Type A (non-touchscreen)] .............. 5-20 Power/Volume/Sound Controls .... 5-20
Clock ............................................ 5-22
Operating the Radio ..................... 5-24
How to use AUX mode ................ 5-26
How to use USB mode ................. 5-28
How to use iPod mode ................. 5-32
Error Indications .......................... 5-34
Bluetooth
® .................................... 5-35
Bluetooth® Preparation ................. 5-38
Available Language ...................... 5-48
Security Setting ............................ 5-49
Bluetooth
® Audio ......................... 5-50
Bluetooth® Hands-Free ................ 5-53
Voice Recognition ........................ 5-60
Voice Recognition Learning Function
(Speaker Enrollment) ................... 5-62
Troubleshooting ........................... 5-65
Audio Set
[Type B (touchscreen)] ...................... 5-69
Basic Operation Method .............. 5-69
Home screen ................................. 5-73
Volume/Display/
Sound Controls ............................. 5-74
Operating the Radio ..................... 5-76
Operating the Satellite Radio
* ...... 5-80
How to use AUX mode ................ 5-84
How to use USB mode ................. 5-85
Bluetooth
® .................................... 5-90
Bluetooth® Preparation ................. 5-94
Available Language ...................... 5-97
Bluetooth
® Audio ......................... 5-97
How to Use Pandora® ................. 5-102
How to Use Aha™ ....................... 5-105
How to Use Stitcher™ Radio ...... 5-109
Bluetooth® Hands-Free .............. 5-111
Voice Recognition ...................... 5-121
Settings ....................................... 5-124
Applications ............................... 5-126
Troubleshooting ......................... 5-127

Appendix .......................................... 5-132 Things You Need to Know ......... 5-132

CX-5_8FN1-EA-16L_Edition1.indb 12016/12/12 10:06:22

5–11
Interior Features
Climate Control System
Fully Automatic Type
Climate control information is displayed on the display.
Airflow display
Temperature setting display (driver’s side)
Mode selector
display
A/C mode display
Air intake selector
(outside air position)
Driver temperature control dial
AUTO switch Mode selector switch
Fan control switch OFF switchWindshield defroster switch
Rear window defogger switch
Passenger temperature
control dial
DUAL switch
A/C switch
Temperature setting display
(Passenger’s side)
Air intake selector
(recirculated air position)

Control Switches
AUTO switch
By pressing the AUTO switch the
following functions will be automatically
controlled in accordance with the selected
set temperature:
 
 Airfl ow temperature  Amount of airfl ow  Selection of air fl ow mode   Outside/Recirculated air selection Air conditioner operation
NOTE
AUTO switch indicator light   When on, it indicates auto operation,
and the system will function
automatically.
  If any of the following switches are
operated while in auto control, the
AUTO switch indicator turns off.
  Mode selector switch  Fan control switch  Windshield defroster switch The functions for switches other than
those operated continue to operate in
auto control.


OFF switch
Pressing the OFF switch shuts off the
climate control system.
CX-5_8FN1-EA-16L_Edition1.indb 112016/12/12 10:06:24

5–12
Interior Features
Climate Control System
Temperature control dial
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
  When the DUAL switch is off: Turn the driver temperature control dial
to control the temperature throughout
the entire cabin.
  When the DUAL switch is on: Turn the driver or front passenger
temperature control dial to
independently control the temperature
on each side of the cabin.

NOTE
  The climate control system changes to
the individual operation mode ( DUAL
switch indicator light illuminated) by
turning the front passenger temperature
control dial even when the DUAL switch
is off, which allows individual control
of the set temperature for the driver and
front passenger.
  The temperature units for the
temperature setting display can be
changed in conjunction with the
temperature units for the outside
temperature display.
 (Type A instrument cluster) Refer to Outside Temperature Display on page 4-24 .
 (Type B instrument cluster) Refer to Outside Temperature Display on page 4-17 .

Fan control switch
The fan has seven speeds. The selected
speed will be displayed.
Mode selector switch
The desired air fl ow mode can be selected
(page 5-6 ).
NOTE
   With the air fl ow mode set to the
position and the temperature control
dial set at a medium temperature,
heated air is directed to the feet and air
at a comparably lower temperature will
fl ow through the central, left and right
vents.
   To set the air vent to , press the
windshield defroster switch.
   In the or position, the air
conditioner is automatically turned on
and the outside air position is
automatically selected to defrost the
windshield. In the
or position, the
outside air position cannot be changed
to the recirculated air position.

A/C switch
Pressing the A/C switch while the AUTO
switch is turned on will turn off the air-
conditioning (cooling/dehumidifying
functions).
The on/off of the air-conditioning switches
each time the A/C switch is pressed.
NOTE
   The air conditioner operates when the
A/C switch is pressed while the air
conditioner is turned off.
  The air conditioner may not function
when the outside temperature
approaches 0 °C (32 °F).

CX-5_8FN1-EA-16L_Edition1.indb 122016/12/12 10:06:25
