height MAZDA MODEL CX-5 2017 (in English) Owner's Manual

8–29
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
T
Indicates a tire that may be installed on cars, SUVs, minivans and light\
trucks as designated
by the Tire and Rim Association (T&RA).
11 5
“115” is the nominal width of the tire in millimeters. This three-digit number gives the width
in millimeters of the tire from sidewall edge to sidewall edge. In gener\
al, the larger the
number, the wider the tire.
70
“70” is the aspect ratio. This two-digit number indicates the tire's ratio of height to width.
D
“D” is the tire construction symbol. D indicates “diagonal ply \
construction”.
16
“16” is the wheel rim diameter in inches.
90
“90” is the Load Index. This two-or three-digit number indicates how much weight each tire
can support.
M
“M” is the speed rating. The speed rating denotes the maximum speed for which the use of
the tire is rated.

Letter Rating Speed Rating
M 81 mph

CX-5_8FN1-EA-16L_Edition1.indb 292016/12/12 10:07:33

9–6
Specifi cations
Specifi cations
Dimensions
Item Vehicle specifi cation
Overall length 4,550 mm (179.1 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,675 mm (65.9 in)
Front tread 17 inch styled steel wheel vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel vehicle 1,596 mm (62.8 in)
Rear tread 17 inch styled steel wheel vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel vehicle 1,596 mm (62.8 in)
Wheelbase 2,698 mm (106.2 in)

Weights
U.S.A. and Canada
SKYACTIV-G 2.0
Item Indication on display
GVWR (Gross Vehicle Weight Rating) 1,944 kg (4,286 lbs)
GAWR (Gross Axle Weight Rating) Front
981 kg (2,163 lbs)
Rear 966 kg (2,130 lbs)

SKYACTIV-G 2.5
Item Indication on display
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,048 kg (4,515 lbs) 2,106 kg (4,643 lbs)
GAWR (Gross Axle Weight Rating) Front
1,057 kg (2,330 lbs) 1,075 kg (2,370 lbs)
Rear 994 kg (2,191 lbs) 1,034 kg (2,280 lbs)

CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:07:39

9–16
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings
Change
Method


Fuel Economy Monitor (page 4-86 )
Ending display Display/non-display Off On/Off B —


Fuel economy
resetting procedure Linkage/non-linkage with fuel economy reset
and trip meter A reset
Off On/Off B —


Active Driving Display (page 4-28 )
Display Setting can be changed so that the Active
Driving Display is not displayed.
On On/Off C —


The display height (up/down position) can
be changed. 0 13 steps up/
down from
initial setting
(total: 27 steps) C —


The method for adjusting the display
brightness (automatically/manually) can be
changed. AUTO
AUTO/
MANUAL C —


The standard brightness while automatic
adjustment is selected can be changed using
the brightness adjustment. 0 2 steps up/
down from
initial setting
(total: 5 steps) C —


The standard brightness while manual
adjustment is selected can be changed using
the brightness adjustment. 0 20 steps up/
down from
initial setting
(total: 41 steps) C —


The display angle can be changed. 0 3steps up/down
from initial setting
(total: 7steps) C —


Navigation
guidance Display/non-display
On On/Off C —


Street Information Display/non-display On-Demand Off/Always/
On-Demand C —


*1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitoring (BSM)\
operation can be changed. The volume of the warning beep during Rear Cross Traf fi c Alert (RCTA) operation cannot be changed.
*3 This system functions only when the navigation system is functioning.
*4 If the auto-wiper control is set to Off, the wiper lever
position is set to intermittent operation.
*5 If the setting is changed to Off, the following operation is performed according to the headlight switc\
h position:
 At position: Headlights turn off immediately after the ignition is switched off.
 At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-51 .
*6 When set to Off, the lights-on reminder is operable.
*7 The lights-on reminder settings can be changed at anytime, however, the lights-on reminder only operates when
the auto headlight function is set to Off. Refer to Lights-On Reminder on page 7-39 .
CX-5_8FN1-EA-16L_Edition1.indb 162016/12/12 10:07:41
