Page 112 of 664
3–32
Before Driving
Fuel and Emission
Engine Exhaust (Carbon monoxide)
WARNING
Do not drive your vehicle if you smell exhaust gas inside the vehicle: Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is
colorless, odorless, and poisonous. When inhaled, it can cause loss of consciousness and
death. If you smell exhaust gas inside the vehicle, keep all windows fully open and contact
an Authorized Mazda Dealer immediately.
Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust
gas, which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur.
Open the windows or adjust the heating or cooling system to draw fresh air when
idling the engine: Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and
the engine running for a long time even in an open area, exhaust gas, which contains
poisonous carbon monoxide, could enter the cabin. Loss of consciousness or even death
could occur.
Clear snow from underneath and around your v ehicle, particularly the tail pipe, before
starting the engine: Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust
pipe could be blocked by the snow, allowing exhaust gas to enter the cabin. Because
exhaust gas contains poisonous carbon monoxide, it could cause loss of consciousness or
even death to occupants in the cabin.
CX-5_8FN1-EA-16L_Edition1.indb 322016/12/12 10:05:33
Page 115 of 664
3–35
Before Driving
Steering Wheel
*Some models.
Steering Wheel
WARNING
Never adjust the steering wheel while
the vehicle is moving: Adjusting the steering wheel while
the vehicle is moving is dangerous.
Moving it can very easily cause the
driver to abruptly turn to the left or
right. This can lead to loss of control or
an accident.
Steering Wheel Adjustment
To change the angle or length of the
steering wheel:
1. Stop the vehicle, and then pull down the lock release lever under the steering
column.
Lock release lever
2. Tilt the steering wheel and/or adjust the steering column length to the desired
positions, then push the lever up to lock
the column.
3. Attempt to push the steering wheel up and down to make sure it's locked
before driving.
Heated Steering Wheel *
The grips on the left and right of the
steering wheel can be warmed up.
Heated steering
wheel switchHeating area
The ignition must be switched ON.
Press the switch to turn on the heated
steering wheel. The heated steering wheel
operates for about 30 minutes and then
turns off automatically.
The indicator light illuminates when the
heater is operating.
To turn off the heated steering wheel
before the 30 minutes has elapsed, press
the switch again.
CAUTION
The following types of persons should
be careful not to touch the steering
wheel. Otherwise, it could cause a low-
temperature burn.
Infants, small children, elderly people, and physically challenged
people
People with delicate skin People who are excessively fatigued People who are intoxicated People who have taken sleep-inducing medicine such as sleeping
pills or cold medicine
CX-5_8FN1-EA-16L_Edition1.indb 352016/12/12 10:05:34
Page 131 of 664
3–51
Before Driving
Driving Tips
Floor Mat
We recommend the use of Genuine
Mazda fl oor mats.
WARNING
Make sure the fl oor mats are hooked on
the retention pins to prevent them from
bunching up under the foot pedals: Using a fl oor mat that is not secured is
dangerous as it will interfere with the
accelerator and brake pedal operation,
which could result in an accident.
Do not install two fl oor mats, one on top
of the other, on the driver's side: Installing two fl oor mats, one on top
of the other, on the driver's side is
dangerous as the retention pins can
only keep one fl oor mat from sliding
forward.
Loose fl oor mat(s) will interfere with
the foot pedal and could result in an
accident.
If using an all-weather mat for winter
use always remove the original fl oor
mat.
When setting a fl oor mat, position the fl oor
mat so that its grommets are inserted over
the pointed end of the retention posts.
Rocking the Vehicle
WARNING
Do not spin the wheels at more than
56 km/h (35 mph), and do not allow
anyone to stand behind a wheel when
pushing the vehicle: When the vehicle is stuck, spinning the
wheels at high speed is dangerous.
The spinning tire could overheat and
explode. This could cause serious
injuries.
CAUTION
Too much rocking may cause engine
overheating, transaxle failure, and tire
damage.
If you must rock the vehicle to free it from
snow, sand or mud, depress the accelerator
slightly and slowly move the shift lever
from 1 (D) to R.
CX-5_8FN1-EA-16L_Edition1.indb 512016/12/12 10:05:37
Page 142 of 664
![MAZDA MODEL CX-5 2017 Owners Manual (in English) 3–62
Before Driving
Towing
Passing
Plan well ahead to pass other vehicles, and provide plenty of room befor\
e changing lanes.
Crosswinds from passing vehicles, especially larger ones, and th](/img/28/13793/w960_13793-141.png "MAZDA MODEL CX-5 2017 Owners Manual (in English) 3–62
Before Driving
Towing
Passing
Plan well ahead to pass other vehicles, and provide plenty of room befor\
e changing lanes.
Crosswinds from passing vehicles, especially larger ones, and th")
3–62
Before Driving
Towing
Passing
Plan well ahead to pass other vehicles, and provide plenty of room befor\
e changing lanes.
Crosswinds from passing vehicles, especially larger ones, and the effects of rough roads will
affect handling.
If swaying occurs, fi rmly grip the steering wheel and reduce speed immediately, but
gradually.
Steer straight ahead. If no extreme correction of steering or braking is\
made, the
combination of less speed and fi rm steering will result in stability.
Backing up
Backing a vehicle with a trailer requires practice and patience. Back sl\
owly, and have a
helper outside at the rear of the trailer to reduce the risk of an accid\
ent.
To turn the trailer, place your hand at the bottom of the steering wheel and turn it in the\
direction you want the trailer to go. Make only slight movements to prev\
ent sharp or
prolonged turning.
Ascending a hill
Shift into a lower gear to reduce the possibility of overloading or over\
heating the engine, or
both.
Descending a hill
Shift into a lower gear and use engine compression as a braking effect.
WARNING
Always use lower gears to reduce speed: Holding the brake pedal down too long or too frequently is dangerous as it could cause
the brakes to overheat and lose power, resulting in loss of control and a serious accident.
Use lower gears to help reduce speed. Pull off the road and allow brakes to cool down
whenever braking performance feels reduced.
Overheated engine
The extra weight of the trailer may strain the engine on hot days and on\
long or steep
upgrades.
If the temperature gauge indicates overheating, turn off the air conditioner, drive safely
to the side of the road, park off the right-of-way and wait for engine to cool. Refer to
Overheating on page 7-18 .
CX-5_8FN1-EA-16L_Edition1.indb 622016/12/12 10:05:39
Page 159 of 664
4–15
When Driving
Instrument Cluster and Display
Engine Coolant Temperature Gauge (Without Multi-information
Display)
Displays the engine coolant temperature.
The white gauge indicates that the engine
coolant temperature is low, and the red
gauge indicates that the engine coolant
temperature is high and overheating.
CAUTION
If the engine coolant temperature
gauge indicator fl ashes, there is a
possibility of overheating. Park the
vehicle in a safe place immediately
and take appropriate measures. If the
vehicle continues to be driven, it could
cause damage to the engine.
Refer to Overheating on page 7-18 .
NOTE
The temperature unit (Centigrade/
Fahrenheit) of the engine coolant gauge
display changes in conjunction with
the temperature unit of the outside
temperature display.
Refer to Personalization Features on page 9-11 .
During normal driving, the engine
coolant temperature stabilizes at
100 °C (210 °F) or less, and the gauge
indicates a range lower than 100 °C
(210 °F).
If the engine load increases and the
engine coolant temperature exceeds
100 °C (210 °F), the gauge indicates the
engine coolant temperature.
Fuel Gauge (Without Multi-information Display)
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Full
1/4 Full
Empty
If the low fuel warning light illuminates or
the fuel level is very low, refuel as soon as
possible.
Refer to Warning Indication/Warning
Lights on page 4-33 .
CX-5_8FN1-EA-16L_Edition1.indb 152016/12/12 10:05:42
Page 167 of 664
4–23
When Driving
Instrument Cluster and Display
Engine Coolant Temperature Gauge
Displays the engine coolant temperature.
The blue gauge indicates that the engine
coolant temperature is low, and the red
gauge indicates that the engine coolant
temperature is high and overheating.
CAUTION
If the high engine coolant temperature
warning light (red) turns on, there is
a possibility of overheating. Park the
vehicle in a safe place immediately
and take appropriate measures. If the
vehicle continues to be driven, it could
cause damage to the engine.
Refer to Overheating on page 7-18 .
NOTE
The temperature unit (Centigrade/
Fahrenheit) of the engine coolant gauge
display changes in conjunction with
the temperature unit of the outside
temperature display.
Refer to Personalization Features on page 9-11 .
During normal driving, the engine
coolant temperature stabilizes at
100 °C (210 °F) or less, and the gauge
indicates a range lower than 100 °C
(210 °F).
If the engine load increases and the
engine coolant temperature exceeds
100 °C (210 °F), the gauge indicates the
engine coolant temperature.
Fuel Gauge
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Full
1/4 Full
Empty
If the fuel level is low, (
) and ( ) turn an
amber color. Refuel as soon as possible.
Refer to Taking Action on page 7-31 .
NOTE
After refueling, it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve since
the fuel moves in the tank.
The display indicating a quarter or less
remaining fuel has more segments to
show the remaining fuel level in greater
detail.
The direction of the arrow ( )
indicates that the fuel- fi ller lid is on the
left side of the vehicle.
CX-5_8FN1-EA-16L_Edition1.indb 232016/12/12 10:05:44
Page 194 of 664
4–50
When Driving
Automatic Transaxle
Driving Tips
WARNING
Do not let the vehicle move in a
direction opposite to the direction
selected by the selector lever: Do not let the vehicle move backward
with the selector lever in a forward
position, or do not let the vehicle
move forward with the selector lever
in the reverse position. Otherwise, the
engine may stop, causing the loss of
the power brake and power steering
functions, and make it diffi cult to
control the vehicle which could result
in an accident.
Passing
For extra power when passing another
vehicle or climbing steep grades, depress
the accelerator fully. The transaxle will
shift to a lower gear, depending on vehicle
speed.
NOTE
The accelerator pedal may initially feel
heavy as it is being depressed, then feel
lighter as it is depressed further. This
change in pedal force aids the engine
control system in determining how
much the accelerator pedal has been
depressed for performing kickdown,
and functions to control whether or not
kickdown should be performed.
While the selector lever is in the M
position and the TCS is turned off,
manual shift mode does not switch
to automatic shift mode even if the
accelerator pedal is completely
depressed. Operate the selector lever.
Climbing steep grades from a stop
To climb a steep grade from a stopped
position:
1. Depress the brake pedal.
2. Shift to D or M1, depending on the load weight and grade steepness.
3. Release the brake pedal while gradually accelerating.
Descending steep grades
When descending a steep grade, shift to
lower gears, depending on load weight and
grade steepness. Descend slowly, using the
brakes only occasionally to prevent them
from overheating.
CX-5_8FN1-EA-16L_Edition1.indb 502016/12/12 10:05:53
Page 213 of 664
4–69
When Driving
Switches and Controls
Gate operator/Canadian Programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
— which may not be long enough for
HomeLink to pick up the signal during
programming. Similar to this Canadian
law, some U.S. gate operators are designed
to “time-out” in the same manner.
If you live in Canada or you are having
diffi culties programming a gate operator
by using the “Programming” procedures
(regardless of where you live), replace
“Programming HomeLink” step 3 with
the following:
NOTE
If programming a garage door opener or
gate operator, it is advised to unplug the
device during the “cycling” process to
prevent possible overheating.
Continue to press and hold the HomeLink
button while you press and release
— every two seconds (“cycle”) your
hand-held transmitter until the frequency
signal has successfully been accepted by
HomeLink. (The indicator light will fl ash
slowly and then rapidly.)
Proceed with “Programming” step 4 to
complete.
Operating the HomeLink System
Press the programmed HomeLink button
to operate a programmed device. The
code will continue being transmitted for a
maximum of 20 seconds.
Reprogramming the HomeLink system
To program a device to HomeLink using
a HomeLink button previously trained,
follow these steps:
1. Press and hold the desired HomeLink
button. DO NOT release the button.
2. The indicator light will begin to fl ash
after 20 seconds. Without releasing
the HomeLink button, proceed with
“Programming” - step 1.
Erasing Programmed HomeLink Buttons
To erase the existing programming from
all three operating channels, press and
hold the two outside buttons (
, ) on
the auto-dimming mirror until the
HomeLink indicator light begins to fl ash
after approximately 10 seconds.
Verify that the programming has been
erased when you resell the vehicle.
CX-5_8FN1-EA-16L_Edition1.indb 692016/12/12 10:05:59
Page 215 of 664
4–71
When Driving
Brake
CAUTION
Do not drive with your foot held on the clutch pedal or brake pedal, or hold
the clutch pedal depressed halfway
unnecessarily. Doing so could result in
the following:
The clutch and brake parts will wear out more quickly.
The brakes can overheat and adversely aff ect brake performance.
Always depress the brake pedal with
the right foot. Applying the brakes with
the unaccustomed left foot could slow
your reaction time to an emergency
situation resulting in insuffi cient braking
operation.
Wear shoes appropriate for driving in order to avoid your shoe contacting
the brake pedal when depressing the
accelerator pedal.
Electric Parking Brake (EPB)
The electric parking brake (EPB)
equipment applies the parking brake
using an electric motor. When the
electric parking brake (EPB) is applied,
the electric parking brake (EPB) switch
indicator light turns on.
Indicator light
WARNING
Do not drive the vehicle with the electric
parking brake (EPB) applied: If the vehicle is driven with the parking
brake applied, the brake parts may
generate heat and the brake system
may not operate, leading to an
accident.
Before driving, release the electric
parking brake (EPB) and verify that the
electric parking brake (EPB) indicator
light is turned off .
NOTE
The electric parking brake (EPB)
cannot be applied or released while the
vehicle battery is dead.
If the electric parking brake (EPB) is
repeatedly applied and released it may
stop operating to prevent overheating
of the motor. If this occurs, wait approx.
1 minute before operating the electric
parking brake (EPB) switch again.
CX-5_8FN1-EA-16L_Edition1.indb 712016/12/12 10:05:59
Page 233 of 664
4–89
When Driving
i-ACTIV AWD
*Some models.
i-ACTIV AWD Operation *
AWD provides excellent drivability on
snow-covered and ice-packed roads, sand
and mud, as well as on steep slopes and
other slippery surfaces.
A system malfunction or operation
conditions are indicated by a warning.
Refer to Warning Indication/Warning
Lights on page 4-33 .
WARNING
Never spin a wheel that is off the
ground: Spinning a wheel that is off the ground
as a result of the vehicle being stuck
or in a ditch is dangerous. The drive
assembly could be seriously damaged
which could lead to an accident or
could even lead to overheating, oil
leakage, and a fi re.
AWD Driving
WARNING
Avoid sharp turns, excessive speed and
abrupt maneuvers when driving this
vehicle: Sharp turns, excessive speed and
abrupt maneuvering of this vehicle
is dangerous as it could result in the
increased risk of loss of vehicle control,
vehicle roll-over, personal injury or
death.
This vehicle has a higher center of
gravity. Vehicles with a higher center
of gravity such as utility and AWD
vehicles handle diff erently than
vehicles with a lower center of gravity.
Utility and AWD vehicles are not
designed for cornering at high speeds
any more than low profi le sports cars
are designed to perform satisfactorily
under off -road conditions. In addition,
utility vehicles have a signifi cantly
higher rollover rate than other types of
vehicles.
Drive carefully when the vehicle is
loaded by lowering vehicle speed and
applying the brakes earlier: Abrupt maneuvering and sudden
braking when driving a loaded vehicle
is dangerous as the driving behavior of
a vehicle with a high center of gravity
is diff erent when it is loaded compared
to when it is not, and could result in the
loss of vehicle control and an accident.
CX-5_8FN1-EA-16L_Edition1.indb 892016/12/12 10:06:04
