▼Sensor Detection Range
The sensors detect obstructions within the following range.

Front sensor detection range
Front corner sensor detection range Rear sensor detection range
Rear corner sensor detection range
B
A
D
C A: About 55 cm (About 21.7 in)
B: About 55 cm (About 21.7 in)
C: About 100 cm (About 39.3 in)
D: About 150 cm (About 59.1 in)
Viewing distance display
Display
Distance between vehicle and obstruction
Front Sensor/Front Corner Sensor Rear Sensor/Rear Corner Sensor
Green
Front sensor:
Approx. 100―60 cm (39.3―23.6 in) Rear sensor:
Approx. 150―60 cm (59.0―23.6 in)
When Driving
Parking Sensor System
4-233
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

DisplayDistance between vehicle and obstruction
Front Sensor/Front Corner Sensor Rear Sensor/Rear Corner Sensor
Yellow
Front sensor:
Approx. 60―45 cm (23.6―17.7 in) Front corner sensor:
Approx. 55―38 cm (21.7―15.0 in) Rear sensor:
Approx. 60―45 cm (23.6―17.7 in) Rear corner sensor:
Approx. 55―38 cm (21.7―15.0 in)
Amber
Front sensor:
Approx. 45―35 cm (17.7―13.7 in)
Front corner sensor:
Approx. 38―25 cm (15.0―9.8 in) Rear sensor:
Approx. 45―35 cm (17.7―13.7 in)
Rear corner sensor:
Approx. 38―25 cm (15.0―9.8 in)
Red
Front sensor:
Within approx. 35 cm (13.7 in)
Front corner sensor:
Within approx. 25 cm (9.8 in) Rear sensor:
Within approx. 35 cm (13.7 in)
Rear corner sensor:
Within approx. 25 cm (9.8 in)
When Driving
Parking Sensor System
4-234
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

▼Park Assist Sensor
System Operation
When the parking sensor switch is pressed with the ignition switched ON, the buzzer sounds
and the indicator light turns on.
When the ignition is switched ON with the parking sensor activa ted, the indicator light turns
on.
Press the switch again to stop the operation.
Indicator light
Operation conditions
The parking sensor system can be used when all of the following conditions are met:
The ignition is switched ON.
The parking sensor switch is turned on.
NOTE
The detection indicator and buzzer of the front sensors/front corner sensors do not
operate when the selector lever is in the P position.
The detection indicator and buzzer sound do not activate when the parking brake is
applied.
▼Obstruction Detection Indication
The position of a sensor which has detected an obstruction is i
ndicated. The gauge
illuminates in different areas depending on the distance to an obstruction detected by the
sensor.
When Driving
Parking Sensor System
4-235
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.

Rear sensor
Left front
corner sensor
Left rear
corner sensor
Right front
corner sensor
Right rear
corner sensor
Front sensor
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalization Features on page 9-12.
System problem notification
If a problem occurs, the driver is notified of the problem by t
he following indications.
Detection IndicatorSolution
Disconnection
The system may have a malfunction. Have the
vehicle inspected at an Authorized Mazda Deal‐
er as soon as possible.
System mal‐ function
The system may have a malfunction. Have the
vehicle inspected at an Authorized Mazda Deal‐
er as soon as possible.
When Driving
Parking Sensor System
4-236
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Detection IndicatorSolution
Frost/soiling
Foreign matter may be on the sensor area corre‐
sponding to the obstruction detection indication
shown. If the system doe s not recover, have the
vehicle inspected at an Authorized Mazda Deal‐
er.
▼ Parking Sensor Warning Beep
The beeper sounds as follows while the system is operating.
Front Sensor, Rear Sensor
Distance Detec‐
tion area Distance between vehicle and obstruction
Beeper sound*1Front SensorRear Sensor
Farthest distance Approx. 100―60 cm (39.3―23.6
in)
Approx. 150―60 cm (59.0―23.6in)
Slow intermittent
sound
Far distance Approx. 60―45 cm (23.6―17.7
in)
Approx. 60―45 cm (23.6―17.7in)
Medium intermit‐
tent sound
Middle distance Approx. 45―35 cm (17.7―13.7
in)
Approx. 45―35 cm (17.7―13.7in)
Fast intermittent
sound
When Driving
Parking Sensor System
4-237
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Distance Detec‐tion area Distance between vehicle and obstruction
Beeper sound*1Front SensorRear Sensor
Close distance Within approx. 35 cm (13.7 in)
Within approx. 35 cm (13.7 in)
Continuous sound
*1 The rate at which the interm
ittent sound beeps increases as the vehicle approaches the obstruction.
Front Corner Sensor, Rear Corner Sensor
Distance Detection areaDistance between vehicle and obstruction
Beeper sound*1Front/Rear Corner Sensor
Far distance Approx. 55―38 cm (21.7―15.0 in)
Medium intermittent sound
Middle distance Approx. 38―25 cm (15.0―9.8 in)
Fast intermittent sound
Close distance Within approx. 25 cm (9.8 in)
Continuous sound
*1 The rate at which the interm
ittent sound beeps increases as the vehicle approaches the obstruction.
NOTE
If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped
(except for the close-distance zone). If the same obstruction is detected in another zone, the
corresponding beep sound is heard.
When Driving
Parking Sensor System
4-238
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

▼When Warning Indicator/Beep is Activated
The system notifies th
e driver of an abnormality by activating the beep sound and the
indicator light.
Indicator/Beep How to check
The indicator light flashes when
the parking sensor switch is
pressed at a vehicle speed of 10
km/h (6 mph) or less. The system may have a malfuncti
on. Have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.
The beep sound is not heard. The system may have a malfuncti
on. Have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.
The intermittent sound of the
buzzer is heard 5 times. Remove any foreign material from the sensor area. If the system does not re‐
cover, have the vehicle inspected
at an Authorized Mazda Dealer.
A certain obstruc tion detection
indicator is con tinuously dis‐
played. Refer to Obstruction Detection Indication on page 4-235.
When Driving
Parking Sensor System
4-239
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

When selecting heat, the system will
restrict airflow until it has warmed to
prevent cold air from blowing out of the
vents.
▼Windshield Defrosting and
Defogging
Press the windshield
defroster switch.
In this position, the outside air position is
automatically selected, and the air
conditioner automatically turns on. The air
conditioner will direct ly dehumidify the
air to the front windshield and side
windows on page 5-6.
Airflow amount wil l be increased.
WA R N I N G
Set the temperature control to the hot or
warm position when defogging (
position):
Using the
position with the temperature
control set to the cold position is
dangerous as it will cause the outside of the
windshield to fog up. Your vision will be
hampered, which could lead to a serious
accident.
NOTE
Use the temperature control dial to
increase the air flow temperature and
defog the windshie ld more quickly.
▼Sunlight/Interior Temperature
Sensor
Sunlight sensor
Do not place objects on the sunlight
sensor. Otherwise, the interior temperature
may not adjust correctly.
Sunlight sensor
Interior temperature sensor
Do not cover the interior temperature
sensor. Otherwise, the interior temperature
may not adjust correctly.
Interior temperature sensor
Interior Features
Climate Control System
5-14
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

Volume/Display/Sound Controls
Commander switchAudio control switch
Volume switch
Volume dial
▼Volume adjustment
Turn the commander switch volume dial.
The volume switch on the steering switch
can also be pressed.
NOTE
Press the volume dial to switch the audio
MUTE on and off.
▼Display setting
Select the icon on the home screen to
display the Settings screen.
Select the
tab to select the item you
would like to change.
Display OFF/Clock
The center display can be turned off.
Select
to turn the display off.
When
is
selected the center di splay turns off and
the clock is displayed.
The center display can be turned back on
as follows:
Touch the center display.
Operate the commander switch.
Daytime/nighttime (System) screen
setting
The daytime or nighttime screen can be
selected.
:
(With auto-light control)
Switches screen automatically according
to parking lights illumination condition.
However, when the li ght sensor detects
that the surrounding area is bright such as
when the parking lights are turned on in
the daytime, the screen is switched to the
daytime screen
*1
(Without auto-light control)
Switches screen automatically according
to parking lights illumination condition.
*1
: Daytime screen setting
: Nighttime screen setting
*1 The display is constantly on daytime screen when the il lumination dimmer
is cancelled.
Brightness adjustment
Adjust the center display brightness using
the slider.
Interior Features
Audio Set
5-24
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Wiper Blades
CAUTION
Hot waxes applied by automatic car
washers have been known to
affect the
wiper's ability to clean windows.
 To prevent damage to the wiper blades,
do not use gasoline, kerosene, paint
thinner, or other solvents on or near
them.
 When the wiper lever is in the AUTO
position and the ignition is switched ON,
the wipers may move automatically in
the following cases:
 If the windshield above the rain sensor
is touched.
 If the windshield above the rain sensor
is wiped with a cloth.
 If the windshield is struck with a hand
or other object.
 If the rain sensor is struck with a hand
or other object from inside the vehicle.
Be careful not to pinch hands or fingers
as it may cause injury, or damage the
wipers. When washing or servicing the
vehicle, make sure the wiper lever is in
the OFF position.
Contamination of either the windshield or
the blades with foreign matter can reduce
wiper effectiveness. Common sources are
insects, tree sap, and hot wax treatments
used by some commercial car washes.

If the blades are not wiping properly, clean
the window and blades with a good
cleaner or mild detergent; then rinse
thoroughly with clean water. Repeat if
necessary.
▼ Replacing Windshield Wiper Blades
When the wipers no longer clean well, the
blades are probably worn or cracked.
Replace them.
CAUTION

To prevent damage to the wiper arms
and other components, do not try to
sweep the wiper arm by hand.
 Do not bend the blade rubber
unnecessarily when replacing it.
Otherwise, the metal stiffener in the
blade may deform and the windshield
wiper operation may be adversely
affected.
NOTE
When raising both windshield wiper arms,
raise the driver's side wiper arm first.
When lowering the wiper arms, slowly
lower the wiper arm from the passenger's
side first while supporting it with your
hand. Forcefully lowering the wiper arms
could damage the wiper arm and blade,
and may scratch or crack the windshield.
1. Raise the wiper arm.
CAUTION
To prevent damage to the windshield
let the wiper arm down easily, do not
let it slap down on the windshield.
Maintenance and Care
Owner Maintenance
6-31
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47
