Water Marks
Occurrence
Rain, fog, dew, and even tap water can
contain harmful minerals such as salt and
lime. If moisture containing these minerals
settles on the vehicle and evaporates, the
minerals will concentrate and harden to
form white rings. The rings can damage
your vehicle's finish.
Prevention
It is necessary to wash and wax your
vehicle to preserve it s finish according to
the instructions in this section. These steps
should be taken immediately after you find
water marks on your vehicle's finish.
Paint Chipping
Occurrence
Paint chipping occurs when gravel thrown
in the air by another vehicle's tires hits
your vehicle.
How to avoid paint chipping
Keeping a safe distance between you and
the vehicle ahead reduces the chances of
having your paint chipped by flying
gravel.
NOTE
The paint chipping zone varies with the
speed of the vehicle. For example, when
traveling at 90 km/h (56 mph), the paint
chipping zone is 50 m (164 ft).
In low temperatures a vehicle's finish
hardens. This increases the chance of
paint chipping.
Chipped paint can lead to rust forming
on your Mazda. Before this happens,
repair the damage by using Mazda
touch-up paint according to the
instructions in this section. Failure to
repair the affected area could lead to
serious rusting and expensive repairs.

Follow all label and container directions
when using a chemical cleaner or polish.
Read all warnings and cautions.
▼ Maintaining the Finish
Wa s h i n g
CAUTION

When the wiper lever is in the
position and the ignition is switched ON,
the wipers may move automatically in
the following cases:
 If the windshield above the rain sensor
is touched or wiped with a cloth.
 If the windshield is struck with a hand
or other object from either outside or
inside the vehicle.
Keep hands and scrapers clear of the
windshield when the wiper lever is in the
position and the ignition is
switched ON as fingers could be pinched
or the wipers and wiper blades damaged
when the wipers activate automatically.
If you are going to clean the windshield,
be sure the wipers are turned off
completely (when it is most likely that the
engine is left running) this is particularly
important when clearing ice and snow.
Maintenance and Care
Appearance Care
6-59
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

SignalWarning
(Red)
(Turns on)
KEY Warning
Light
*
If any malfunction occurs in the keyless entry system, it illuminates continuously.
CAUTION
If the key warning indicator light illuminates or the push button start indicator light (amber)
flashes, the engine may not start. If the engine cannot be started, try starting it using the
emergency operation for starting the engine, and have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-10.
(Amber)
High Beam Control System (HBC)
Warning Indication/
Warning Light
*
The light remains turned on if th ere is a problem with the system. Have your vehicle in‐
spected at an Authorized Mazda Dealer.
NOTE
If the Forward Sensing Camera (FSC) field of view is impaired during bad weather condi ‐
tions (such as rain, fog, and snow) and when the windshield is dirty, the warning indica ‐
tion/warning light for the High Beam Control System (HBC) may display/turn on. Howev ‐
er, this does not indicate a problem.
Blind Spot Monitor‐ ing (BSM) Warning
Indication
*
The Warning indication turns on if there is any malfunction in the Blind Spot Monitoring
(BSM). Have your vehicle inspect ed by an Authorized Mazda Dealer.
NOTE
If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause. How ever, it does not indicate a malfunction.
Blind Spot Monitor‐
ing (BSM) OFF In‐
dicator Light
*
A problem in the system may be i ndicated under the following conditions.
Have your vehicle inspected a t an Authorized Mazda Dealer.
The light does not turn on when the ignition is switched ON.The light remains on even when the Blind Spot Monitoring (BSM) system can be oper‐
ated.
It turns on while driving the vehicle.
NOTE
If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause (The Blin d Spot Monitoring (BSM) OFF indicator light
in the instrument cluster illuminates). However, it does not indicate a malfunction.
(Amber)
Mazda Radar Cruise Control with Stop & Go function
(MRCC with Stop & Go function)
Warning Indication
*
The message is displayed when the system has a malfunction. Have your vehicle inspect‐
ed at an Authorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-31
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

SignalWarning
Lane-keep Assist
System (LAS) &
Lane Departure
Wa r n i n g S y s t e m
(LDWS) Warning
Indication
*
The message is displayed when the system has a malfunction. Have your vehicle inspect‐
ed at an Authorized Mazda Dealer.
The system does not operate when the warning message is displayed.
CAUTION
Always use tires for all wheels that are of the specified size, and the same manufacture,
brand, and tread pattern. In addition, do no t use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the system may not operate
normally.
 When an emergency spare tire is used, the system may not operate normally.
LED Headlight
Warning Light This light illuminates if there
is a malfunction in the LED hea dlight. Have your vehicle
inspected by an Authorized Mazda Dealer.
▼ Taking Action
Take the appropriate action and verify that the warning light t
urns off.
SignalWarning Action to be taken
(Amber)
Smart Brake Support/
Smart City Brake Sup‐ port (SBS/SCBS)
Warning Indication/
Wa r n i n g L i g h t
*
The light turns on if the windshield or the
radar sensor are dirty, or there is a malfunc‐
tion in the system. Verify the reason why the warning light is
illuminated on the center display.
If the reason why the warning light is illu‐
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em‐
blem.
For any other reasons, have the vehicle in‐
spected at an Authorized Mazda Dealer.
Low Fuel Warning In‐
dication/Warning Light The light turns on when
the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).NOTE
The light illumination timing may vary be ‐
cause fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture. Add fuel.
Check Fuel Cap Warn‐
ing Indication/Warning Light If the check fuel cap warning light illumi‐
nates while driving, the fuel-filler cap may
not be installed properly.
Stop the engine and reinstall the fuel-filler
cap.
Refer to Refueling on page 3-30.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-32*Some models.
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

SignalWarning Action to be taken
Engine Oil Level
Warning Light This warning light indicates that the engine
oil level is around the MIN mark (page
6-26).
Add 1 L (0.3 US gal, 0.2 Imp gal) of en‐
gine oil (page 6-24).
Seat Belt Warning
Light (Front seat) Except Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not
fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than abo ut 20 km/h (12 mph),
the warning light flash es. After a short time,
the warning light stops flashing, but re‐
mains illuminated.
NOTE
The warning light flashes for about 6
seconds if the driver's seat belt is not fas ‐
tened when the ignition is switched ON.
To allow the front passenger occupant
classification sensor to function properly,
do not place and sit on an additional seat
cushion on the front passenger's seat.
The sensor may not function properly be ‐
cause the additional seat cushion could
cause sensor interference.
If a small child is seated on the front pas‐
senger's seat, the warning light may not
operate. Fasten the seat belts.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-33
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

SignalWarning Action to be taken
Seat Belt Warning
Light (Front seat) Mexico
The seat belt warning light turns on if the
driver or front passeng
er's seat is occupied
and the seat belt is not fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than abo ut 20 km/h (12 mph),
the warning light flash es. After a short time,
the warning light stops flashing, but re‐
mains illuminated. If a seat belt remains un‐
fastened, the warning light flashes again for
a given period of time.
NOTE
Placing heavy items on the front pas ‐
senger's seat may cause the front pas ‐
senger's seat belt warning function to op ‐
erate depending on the weight of the
item.
To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function prop erly because the
additional seat cushion could cause sen ‐
sor interference.
If a small child is seated on the front pas ‐
senger's seat, the warning light may not
operate. Fasten the seat belts.
(Red)
Seat Belt Warning Light (Rear seat) If the rear seat belts are not fastened while
the ignition is switched ON , the driver and
the passenger are alerted by the warning
light.
The warning light operates even if there is
no passenger on the rear seat.
NOTE
If a rear seat belt is not fastened by a cer
‐
tain period of time after the engine has
been started, the warning light turns off. Fasten the seat belts.
Low Washer Fluid
Level Warning Indica‐
tion/Warning Light
*
This warning light indicates that little wash‐
er fluid remains. Add washer fluid (page 6-29).
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-34*Some models.
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).
NOTE
To allow the front passenger occupant
classification sensor to function
properly, do not place and sit on an
additional seat cushion on the front
passenger's seat. The sensor may not
function properly because the additional
seat cushion could cause sensor
interference.
If a small child is seated on the front
passenger's seat, the warning beep may
not operate.
Mexico
If the vehicle speed exceeds about 20
km/h (12 mph) with the driver or front
passenger's seat belt unfastened, a warning
beep sounds continuously. If the seat belt
remains unfastened, the beep sound stops
once and then continues for about 90
seconds. The beep stops after the driver or
front passenger's seat belt is fastened.
Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).
NOTE
Placing heavy items on the front
passenger's seat may cause the front
passenger's seat belt warning function
to operate depending on the weight of
the item.
To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause
sensor interference.
If a small child is seated on the front
passenger's seat, the warning beep may
not operate.
Rear seat
The warning beep only sounds if a seat
belt is unfastened after being fastened.
▼ Ignition Not Switched Off (STOP)
Warning Beep
If the driver's door is opened with the
ignition switched to ACC, a beep will be
heard continuously in the cabin to notify
the driver that the
ignition has not been
switched OFF (STOP). Under this
condition, the keyles s entry system will
not operate, the vehicle cannot be locked,
and the battery voltage will be depleted.
▼ Key Removed from Vehicle Warning
Beep
Vehicles with advanced keyless function
If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, the beep which
sounds outside of the vehicle will be heard
6 times, the beep which sounds inside the
vehicle will be
heard 6 times.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-43
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Reversing
The Blind Spot Monitoring (BSM)
warning sound is activated if there is a
possibility of collision with a vehicle
approaching from behind and from the
rear on the left and right sides of the
vehicle.
▼Lane Departure Warning Sound*
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
The volume of the Lane-keep Assist
System (LAS) & Lane Departure
Warning System (LDWS) warning sound
can be changed.
Refer to Personalization Features on
page 9-12.
The type of the Lane-keep Assist System
(LAS) & Lane Departure Warning
System (LDWS) warning sound can be
changed.
Refer to Personalization Features on
page 9-12.
▼ Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) System
Wa r n i n g s
*
The Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) system warnings notify the
driver of system problems and precautions
on use when required. Check after hearing
a warning beep sound.
Warning beep What to check
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system is operating,
a single beep sound is
heard when “Front Ra‐
dar Sensor Blocked” is
displayed in the mul‐
ti-information display. Cancel the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system if the radar
sensor (front) becomes
dirty. Clean the area
around the radar sensor
(front).
The beep sounds inter‐
mittently while the vehi‐
cle is being driven. The distance between
your vehicle and the ve‐
hicle ahead is too close.
Verify the safety of the
surrounding area and re‐
duce vehicle speed.
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system is operating,
a single beep sound is
heard when “ Front Ra‐
dar Sensor System Mal‐
function” is displayed in
the multi-information
display. A malfunction in the
system may be indicated.
Check the center display
to verify th
e problem
and then have your vehi‐
cle inspected by an Au‐
thorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-46*Some models.
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

ItemFeatureFactory
Setting Available Settings Settings
Change
Method
Distance Recognition
Support System (DRSS)
(page 4-134) The system can be changed so that Dis‐
tance Recognition Support System
(DRSS) does not operate.*1On On/Off A ―
The distance at which the vehicle ahead
and your vehicle indi
cated in the display
flashes in white can be changed. Near Far/Med./Near A ―
Traffic Sign Recogni‐
tion System (TSR)*3
(page 4-128)The Traffic Sign R
ecognition System
(TSR) can be set to inoperable.
*1On On/Off A ―
The warning pattern of the excessive
speed warning can be changed. OffOff/
Vi s ua l /
Audio & Visual A―
The activation timing for the excessive
speed warning can be changed.00/5/10
A―
360° View Monitor
(page 4-176) Setting can be changed so that the 360°
view monitor is automatically displayed
when the ignition is switched to ON.
Off On/Off A ―Setting can be changed so that the dis‐
play of the estimated forward line of
progress is not displayed.
On On/Off A ―
Setting can be changed so that the top
view/front view disp
layed while the vehi‐
cle is moving in the f orward direction af‐
ter reversing is not displayed. On On/Off A ―
Parking sensor system
(page 4-233)
Display*4/non-display
On On/Off A ―
Ve h i c l e
Door locks (page 3-16)Operation condition of
auto lock/unlock
function Lock:
When
Driving
Unlock:
IGN Off Lock: Out of Park
Unlock: In Park/
Lock: Shifting Out of Park/
Lock: When Driving Unlock: In Park/
Lock: When Driving Unlock: IGN Off/
Lock: When Driving/ Off AD
Specifications
Personalization Features
9-14
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

ItemFeatureFactory
Setting Available Settings Settings
Change
Method
Active Driving Display (page 4-56)
Display Setting can be changed so that the Active
Driving Display is not displayed.
On On/Off C ―
The display height (up/down position)
can be changed.
013 steps up/down
from initial setting (total: 27 steps) C―
The method for adju
sting the display
brightness (automatically/manually) can
be changed. Auto Auto/Man. C ―
The standard brightness while automatic
adjustment is selected can be changed us‐
ing the brightness adjustment.
02 steps up/down from
initial setting (total: 5 steps) C―
The standard brightness while manual
adjustment is selected can be changed us‐
ing the brightness adjustment. 020 steps up/down
from initial setting (total: 41 steps) C―
The display angle can be changed.
03steps up/down from
initial setting (total: 7steps) C―
Navigation guidance Display/non-display
On On/Off C ―
*1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda
recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation ca n be changed. The
volume of the warning beep during Rear Cross Traffic Alert (RCT A) operation cannot be changed.
*3 This system functions only when the navigation system is funct ioning.*4 When the ultrasonic sensors detect an obstruction, the contents indicated on the center display switches to the
360°View Monitor. (Vehicles with 360°View Monitor)
*5 If the auto-wiper control is s et to Off, the wiper lever position is set to intermittent operation.*6 If the setting is changed to Of f, the following operation is performed according to the headlight switch
position:
At position: Headlights turn off i mmediately after the ignition i s switched off.At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-71.
*7 When set to Off, the light s-on reminder is operable.*8 The lights-on reminder settings c an be changed at anytime, however, the lights-on reminder only operates
when the auto headlight function is set to Off. Refer to Lights-On Reminder on page 7-42.
*9 Change the ambient light illumi nation level with the parking lights or headlights turned on.*10 When set to OFF, the ambient lights remain turned off regardless of whether or not the parking lights or
headlights are on or off. Howev er, they will turn on or off in conjunction with the illuminated entry system.
*11 The operation may stop in 15 mi nutes due to the effect of the outside temperature even if the operation time of
the rear window defogger has been changed to Continuous.
*12 Available only in display from the center display.
Specifications
Personalization Features
9-17
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Index
Warning Indication/Warning
Lights........................................... 4-38
Warning (Display Indication)...... 4-37
Instrument Cluster (Type C)............. 4-44
Cruise Control Set Vehicle Speed
Display......................................... 4-50
Dashboard Illuminati on............... 4-48
Engine Coolant Temperature
Gauge........................................... 4-47
Fuel Gauge.................................. 4-47
Indication/Indi cator Lights.......... 4-53
Multi-information Display (Type
C)................................................. 4-45
Odometer..................................... 4-46
Outside Temperature Display...... 4-48
Speedometer................................ 4-44
Tachometer.................................. 4-44
Trip Computer............................. 4-49
Trip Meter....................................4-46
Warning Indication/Warning
Lights........................................... 4-51
Interior Care...................................... 6-64
Active driving display
maintenance................................. 6-66
Cleaning the floor mats............... 6-66
Cleaning the window interiors.....6-66
Instrument panel top (Soft pad)
maintenance................................. 6-66
Leather upholstery
maintenance................................. 6-65
Panel maintenance....................... 6-66
Plastic part maintenance.............. 6-65
Seat belt maintenance..................6-64
Upholstery maintena nce.............. 6-65
Vinyl upholstery maintenance..... 6-65
Interior Lights................................... 5-95 Luggage compartment light.........5-95
Map lights....................................5-95
Overhead lights............................5-95
i-ACTIVSENSE.............................. 4-116
Active safety technology........... 4-116Adaptive Front Lighting System
(AFS)......................................... 4-119
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-167
Blind Spot Monitoring (BSM) ............
................................................... 4-123
Camera and sensors................... 4-117
Distance Recognition Support System
(DRSS).......................................4-134
Forward Sensing Camera
(FSC)......................................... 4-203
High Beam Control System
(HBC)........................................ 4-120
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-156
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-142
Pre-crash safety technology....... 4-117
Radar sensors (rear)................... 4-211
Radar sensor (front)...................4-208
Rear Cross Traffic Alert
(RCTA)...................................... 4-138
Smart Brake Suppor t (SBS)...... 4-173
Smart City Brake Support
(SCBS)....................................... 4-170
Traffic Sign Recognition System
(TSR)......................................... 4-128
360°View Monitor..................... 4-176
i-ACTIV AWD Operation............... 4-113
J
Jack...................................................... 7-4
Jump-Starting.................................... 7-14
K
Keyless Entry System......................... 3-3
Keys.....................................................3-2 Key suspend function.................... 3-8
10-6
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47
