window MAZDA MODEL CX-7 2007 Quick Tips (in English)

DRIVER’S VIEW
Always check the Owner’s Manual for more operating information and safety features
1. Power window switches,
see Mirrors/Windows
2. Door locks,
see Locks
3. Mirror controls,
see Mirrors/Windows
4. Headlight leveling switch*, see Getting Started
5. Air vents
6. Turn signal/lighting
control lever,
see Getting Started
7. Audio control switches,see Getting Started
8. Horn/Air bag
To beep: Press
9. Cruise control, see Getting Started
10. Wiper/washer
control lever,
see Getting Started11. NAVI display*,
see Owner’s Manual
Audio system,
see Audio Systems
12. Information display,see Information Display
13. Hazard warning
switch/light
Push to activate/deactivate
14. Passenger air bag
off indicator,
see Getting Started
15. Bottle holder
CAUTION: Use plastic
bottles with caps, cups may
spill when door is closed
16. Climate control panel,
see Climate Controls
17. Accessory socket
18. Seat warmer*
Press: On/off
Driver’s
View
TRIPA773.7
67498
H140
8 7
6
5
4
3
2
1
0220
40 60 80 100120140160180
200
20120 100
80
60
40
20
0C
Fx1000km/minE
P
R
N
D
M
122225
242526
3
1515
27
19
541
18
21
18
A/C AMBCHPUSHAUTOPUSHOFFFRONTMODE
51214
16
17
22
108796
23
FM/AM SAT CD MEDIAPUSHPOWER/VOL
SCAN
AUDIOSEEK
TRACK NAVI
MENU
RET
DISP LOAD
EJECT
1113
17
20
19. Cup holder
20. Center console
21. Storage
22. Gearshift lever,
see Transaxle
23. Tilt steering wheel
release lever,
see Getting Started
24. Parking-brake
To engage: Push down
To release: Push down
slightly, then release
25. Hood release handle
Pull release handle to unlock
26. Traction Control System,
see Driving Tips
27. Fuel-filler lid release
To open: Pull lever upward
and release
*Denotes optional equipment

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Advanced
keyless entry/
start system*
Advanced key
must be carried
by driver to
operate properly
Refer to Owner’s Manual for
addi tional instructions
Tip: Do not use advanced key
with activated cell phone in
the same hand, advanced key
functions may become disabled
Advanced keyless
system customization
Your authorized Mazda Dealer can
customize your system if desired
with features such as auto-lock:
After exiting the vehicle after driving,
the car will automatically lock
For additional information
on customizable features,
see Owner’s Manual Passenger’s door request switch:
Press (
5) on passenger’s door; all doors
and liftgate unlock simultaneously
Liftgate request switch: Press ( 6)
on liftgate, doors and liftgate
will lock/unlock
Advanced key transmitter:
Press button ( 2) for driver’s
door; press again within 1 1/2
seconds to unlock other doors
and liftgate, hold to lower front
windows and open moonroof,
release to stop
Activating panic alarmPanic alarm: Press and hold
button ( 3) for more than 1 second;
horn sounds, hazard warning
lights flash; to stop, press any
remote button

compartments such as glove
box or in open liftgate/cargo
area, engine may not start or
warnings may activate
Turning off engine
Turn start knob to ACC position
to turn engine off, push in and
turn start knob to LOCK position
Tip: Vehicle battery may be
discharged if start knob is left
in ACC position
Always put vehicle in Park ( P), set
parking brake and turn start knob to
LOCK position when exiting vehicle
System operation warningsKEY indicator light flashes (green)
indicates advanced key transmitter
battery power is low
KEY indicator light illuminated
continuously (red) indicates system
malfunction, and auxiliary key
should be used, have vehicle
inspected at an Authorized Mazda
Dealer as soon as possible
Tip: When using advanced
keyless system, system will
beep as confirmation of
lock/unlock requests, system
will also beep if start knob is
left in ACC position, advanced
key has been left in vehicle or
if advanced key is removed from
vehicle while vehicle is running
For additional system operation
warnings, see Owner’s Manual
Replacing batterySee Owner’s Manual for
complete instructions
Cautions on useTo avoid damage to advanced
key, do not allow any severe
impacts or contact with liquids,
do not place heavy objects on
advanced key and do not leave
advanced key exposed to direct
sunlight or high temperatures,
See Owner’s Manual for all
cautions and warnings
Getting
Started
Getting
Started

12
4
3

*Denotes optional equipment
Starting enginePress start knob
( 7 ); when KEY
indicator (green)
illuminates on
instrument
cluster; turn start knob ( 7) to
START position to start engine
Tip: Engine will not start if
liftgate is open and advanced key
is placed in liftgate/cargo area
Auxiliary key operation
If advanced key cannot be used due
to a malfunction or dead battery,
use auxiliary key ( 4) to lock/unlock
doors and to start vehicle
To start vehicle: Remove start
knob cover ( 7) by pressing both
side release buttons ( 8) while
pulling; insert auxiliary key into
key cylinder and turn to start engine
Tip: Do not place advanced key
on or around dashboard, storage Locking doors
Driver’s/passenger’s door request
switch: Press (
5) once on either
door to lock other doors
Press and hold driver’s request
switch ( 5) to close windows and
moonroof, release to stop
Advanced key transmitter:
Press button ( 1); pressing again
within a few seconds causes doors
to relock and horn to beep
Unlocking doors/
opening liftgate
Driver’s door request switch: Press
( 5 ) to unlock driver’s door; press
again within 3 seconds to unlock
other doors and liftgate

LOCK ACC ON STARTPU SH
878
56

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Steering-
wheel
audio
controls
To increase/
decrease
volume:
Press (4)
Press ( 5) to either mute standard
Audio system or activate
Navigation Voice Command*
Press ( 6) to select AM, FM 1,
FM 2 and CD mode
Radio: Press ( 7) less than
one second to select next/previous
preset station, press ( 7)
more than one second until beep
sound is heard to seek next/
previous station
CD: Press ( 7) to select next
track, press ( 7) to repeat
current track

/
/
Getting
Started
Getting
Started
Tilt
steering-
wheel
release lever
Pull lever ( 8) down
to unlock column
and pull up to
lock column
WARNING: Do not adjust
steering-wheel while driving
because you may lose control
of the vehicle
AUTO* = With ignition switch
in ON position; headlights and
exterior lights automatically
turn ON/OFF depending on
surrounding darkness/lightness;
rotate knob ( 1) to third notch
To flash high beams: Pull back
slightly and release
Turn signals right/left: move
lever up/down
= Fog lights* on: Rotate ( 2);
functions only with low
beams on
Cruise
control
Operates
above
19 mph
Press ON/OFF
switch ( 1) to
enable/disable
To set speed: Press switch ( 2)
down and release
To increase set speed: Press
switch ( 2) up and release
at desired speed
To decrease set speed: Press
switch ( 2) down and release
at desired speed
To cancel: Tap brake or press
CANCEL switch ( 3)
Turn signal/lighting
control lever
OFF = Lights off
= Tail, parking and
dashboard lights on: Rotate
knob ( 1) to first notch
= Tail, parking,
dashboard and headlights on:
Rotate knob ( 1) to second notch
High beams on/off: Push
forward/pull back to detent
Rear window wiper/washer To activate rear interval wiper:
Rotate knob ( 4) up to INT
To activate rear normal speed
wiper: Rotate knob ( 4) up to ON
To activate rear washer: Rotate
knob ( 4) to and releaseWiper/washer control leverSingle wipe: Push lever up
Washer: Pull back, also operates wipers
Intermittent wiper: One click down
To change interval speed: Rotate
inner ring ( 3)
Normal wiper speed: Two clicks down
High-speed wiper: Three clicks down
*Denotes optional equipment
21
AUTO
R EA R
43
M IS TPU LL
8
31
ON OFF CANCEL
RES/ +
SET/–
256
VOL+ – MODE
47

LOCKS
Always check the Owner’s Manual for more operating information and safety features
Child-safety locks
Located at edge of rear doors
To activate: Pull tab (3) up;
door opens from outside only
To cancel: Push tab (3) down
WARNING: Since children
may access either rear door,
child-safety locks for both rear
doors should be activatedLiftgate
To open: Pull up on handle (4)
and raise
To close: Push liftgate down with
both hands until it securely locks;
do not slam liftgate
Liftgate request switch* (5)
operation, see Getting Started
Locks
Locks
Key
Operates ignition and all locks
Tip: Use key number plate
to purchase a new key;
store in safe place
separate from vehicle
Retractable type key
To fold/unfold press release
button (1)
Auxiliary key*See Getting Started
Manual door
locks
To lock: Press
front of button (1)
toward door handle
To unlock: Pull front
of button away
from door handle
Power door locks
To lock/unlock all doors and liftgate:
Press bottom/top of switch (2)
Using key to lock all doors: Rotate
key to clockwise position, continue
to hold key in lock position to
roll front windows up and close
moonroof, release to stop
Using key to unlock driver’s front
door: Rotate key to counterclockwise
position for more than one second
to unlock other doors and liftgate,
continue to hold key in unlock
position to roll front windows
down and open moonroofKeyless entry
system
Functions only
with ignition in
OFF position
To lock doors:
Press button (2);
pressing again within a few
seconds causes doors to relock
and horn to beep
To unlock: Press button (3)
for driver’s door; press again
within 3 seconds to unlock other
doors and liftgate, press and hold
to lower driver's and passenger
windows and open moonroof,
release to stop
Panic alarm: Press and hold
button (4) for more than 1
second; horn sounds, hazard
warning lights flash; to stop,
press any remote button
3
45
Advanced
keyless entry/
start system/
auxiliary key*
See Getting
Started
Illuminated entry system
Activates interior lights when dome
light switch set to DOOR position;
lights off after driver’s door is
locked or ignition in ON position
Immobilizer system
Prevents engine from running
unless coded key is used,
see Owner’s Manual
WARNING: Never leave a child
alone in vehicle and never
leave any key where a child can
find it, particularly advanced
keys which give easier
access to a curious child
1
234
*Denotes optional equipment
21

MIRRORS/WINDOWS
Always check the Owner’s Manual for more operating information and safety features
6. Moonroof slide switch*
Press rear of switch to
open moonroof
Press front of switch to close
Tip: With all doors closed,
moonroof and front windows
can be opened via Keyless
entry by pressing and holding
unlock button, or opened/
closed by turning and holding
driver’s door key toward
front/rear of vehicle
7. Cargo light
DOOR = Light on with any
door or liftgate open
OFF = Light always off
Driver/passenger
covered visor mirrors
To access mirror: Lower visor
Mirrors/
Windows
Interior
Lights
1. Map/reading light switch
Press on/off
2. Interior light switch
DOOR = Light on when door open
ON = Light always on
OFF = Light always off
3. Front interior light
4. Rear interior light
5. Moonroof tilt switch*
Press rear of switch to tilt
rear of Moonroof
Press front of switch to closePower window
switches
With ignition ON
All windows
controlled from
driver’s armrest;
passenger doors
have separate switches
Front window switches
One-touch down/up: Press/pull
AUTO switch (3) firmly and
release, window goes down/up
all the way, press/pull briefly
to stop, press/pull lightly and
hold for normal operation
Tip: During closing window
operation, window will stop
and open partway if object
blocks window operation
Power window lockout switch
Press button (5), only driver's
window operates; press again
for normal operationRear window switches
Push/pull (4) to open/close
Power window
initialization procedure
If battery is disconnected or power
window fuse is replaced, the auto
open/close and anti-pinch features
will not function
Resetting procedure:
1. Turn ignition switch to “ON”
position
2. Press power window switch
down to fully open window,
then pull switch up to close
window completely, continue
holding switch up for at least
3 seconds, then release switch
3. Move to front passenger
door and repeat Step 2 for
front passenger window
4. After windows have been
initialized turn ignition to
“LOCK”, then back to “ON” Dual power mirrors
Ignition switch must be in ACC
or ON position
Switch is on driver’s door
To adjust left/right mirror:
Press selector switch (1) left/right,
press switch (2) in direction of
desired movement
Tip: To lock mirrors in place,
move selector switch (1) to
center position
LR
2
1AUT
O
AUT
O5
34
O
F
FD
O
OR
TIL
TSLI
DE
121
3356
O
NO
F
FD
O
O
R
2
4
OFFDOO
R7
*Denotes optional equipment

CLIMATE CONTROLS
Always check the Owner’s Manual for more operating information and safety features
1. Air flow selections= air to dash
= air to dash and floor
= air to floor
= air to floor and windshield
= air to windshield (defrost)(Manual Climate Control) 6. Air intake control
Press switch to alternate
between recirculated (Indicator
light on) or outside (Indicator
light off) air mode
= recirculate inside air;
use for maximum cooling
WARNING: Do not use position in cold
weather, windows may
fog and hamper vision

Automatic operation
Press AUTO ( 10) for automatic
operation; rotate outer dial to set
temperature, refer to information
display for air flow selection, see
Owner's Manual
Tip: Automatic climate control
display viewed via information
display, see below
2. Fan control Rotate knob clockwise/
counterclockwise to increase/
decrease fan speed
3. Temperature control Cooler/warmer = rotate knob
counterclockwise/clockwise
4. A/C = air conditioner
Press to turn on/off
5. Rear window defogger Press on/off; shuts off with
ignition or automatically after
15 minutes of operation; also
operates heated outside mirrors*
7. AMB*Press AMB button ( 7) to display
ambient temperature, press again
to switch display to temperature
set for air conditioner
Tip: To change from
Fahrenheit to Centigrade or
vice versa: Press AMB button
(7) for 3 seconds or more
8. Windshield defroster switch
Press: Fresh air position is
automatically selected, A/C
automatically turns ON
9. OFF Press to turn system OFF

Control positions for
maximum defrost
Fan to maximum, temperature
to maximum hot, selected
Tip: To help prevent
windshield fogging in
humid weather, select
before starting engine
To prevent moisture buildup,
never drive with system off
Objects placed under the
front seats may interfere
with air flow to the rear

Information DisplayInformation display ( 1) has
the following functions: Clock,
audio display, automatic climate
control display* and ambient/cabin
temperature display* (AMB)Tip: Manual climate
control not viewable via
information display
Climate
Controls
Information Display

04 13
2
321
645
A/CA/C AMB
CHPUSHAUTOPUSHOFFFRONTMOD
E
4657910
2381
Manual A/C Automatic A/C*
*Denotes optional equipment
88:88 FM1 88.9 88.8CHDISC IN MD W ST RPT RDM AUTO-M8AMB FOAUTOA/C ECO1
