Vent Operation (Rear)
▼Adjusting the Vents
Directing airflow
You can direct air flow by moving the adjustment knob.
NOTE
When using the air conditioner, mist may come out from the vents. This is not a sign of
trouble but a result of humi
d air being suddenly cooled.
knob
Interior Features
Climate Control System
5-12
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Selecting the Airflow Mode
Dashboard Vents
Dashboard and Floor Vents Floor Vents
Interior Features
Climate Control System
5-13
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

Rear Air Conditioner
Climate control system information is displayed on the display.
Mode selector switch
Airflow display
AUTO switchTemperature setting display
REAR switch
Mode selector display
OFF switch
AU TO SYNC
Temperature control switch
Fan control switch
Interior Features
Climate Control System
5-14
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Control Switches
Rear switch
Press the rear switch to operate the rear air
conditioner.
The indicator illuminates to indicate that
the rear air conditioner is operating.
AUTO switch
By pressing the AUTO switch the
following functions will be automatically
controlled in accord
ance with the set
temperature:
•Airflow temperature
•Amount of airflow
•Selection of airflow mode
OFF switch
Pressing the OFF sw itch shuts off the
climate control system.
Temperature control switch
This switch controls temperature. Press
for hot and for cold.
Fan control switch
The fan has five speeds. The selected
speed will be displayed.
Mode selector switch
The desired airflow mode can be selected.
Refer to Selecting the Airflow Mode on
page 5-13.
▼ Operation of Automatic Air
Conditioner
Operation from front seats
1. Turn the front air conditioner on.
2. Press the rear switch. The rear air
conditioner operates.
3. Selection of the airflow mode, airflow
amount and temperature will be
automatically controlled to the same
temperature setting as the front air
conditioner for the driver's side.
NOTE
•If the AUTO switch is pressed while
the front A/C switch is off, the rear
air conditioner operates only to
circulate air.
•Setting the temperature to the
maximum high or low will not
provide the desired temperature at a
faster rate.
•When selecting heat, the system will
restrict airflow until it has warmed
to prevent cold air from blowing out
of the vents.
•When the rear air conditioner is
controlled to the same temperature
setting as the front air conditioner
for the driver's side, “SYNC” is
displayed on the rear screen.
Operation from rear seats
1. Turn the front air conditioner on.
2. Press the AUTO switch. The selection of the airflow mode and airflow
amount will be automatically
controlled.
3. Use the temperature control switch to
set the desired temperature.
Interior Features
Climate Control System
5-15
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

NOTE
•If the AUTO switch is pressed while
the front A/C switch is off, the rear
air conditioner operates only to
circulate air.
•Setting the temperature to the
maximum high or low will not
provide the desired temperature at a
faster rate.
•When selecting heat, the system will
restrict airflow until it has warmed
to prevent cold air from blowing out
of the vents.
•When the rear air conditioner is
operated automatically, “AUTO” is
displayed on the rear screen.
•When the rear air conditioner is
controlled to the same temperature
setting as the front air conditioner
for the driver's side, “SYNC” is
displayed on the rear screen.
To turn off the system, press the OFF
switch.
Interior Features
Climate Control System
5-16
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Voice Recognition
▼Basic Operation Method
Activating Voice Recognition
Press the talk button.
Ending Voice Recognition
Use one of the following methods:
•Press the hang-up button.
•Say, “Cancel”.
•Operate the commander switch or the
center display (only when vehicle is
stopped).
Skipping Voice Guidance (for faster
operation)
Press and release the talk button.
Troubleshooting for Voice Recognition
If you do not understand an operation
method while in the voice recognition
mode, say “Tutorial” or “Help”.
Commands useable anytime during
voice recognition
“Go Back” and “Cancel” are commands
which can be used at anytime during voice
recognition.
Returning to previous operation
To return to the previous operation, say,
“Go Back” while in voice recognition
mode.
Cancel
To put the Bluetooth
® Hands-Free system
in standby mode, say, “Cancel” while in
voice recognition mode.
To prevent a deterioration in the voice
recognition rate and voice quality, the
following points should be observed:
•The voice recognition cannot be
performed while voi ce guidance or the
beep sound is operating. Wait until
the voice guidance or the beep sound
is finished before saying your
commands.
•Phone related commands are available
only when your phone is connected via
Bluetooth
®. Make sure your phone is
connected via Bluetooth
® before you
operate phone related voice commands.
•Music play commands, such as Play
Artist and Play Album can be used only
in USB audio mode.
•Do not speak too sl owly or loudly (no
loud voice).
•Speak clearly, without pausing between
words or numbers.
•Dialects or different wording other than
hands-free prompts cannot be
recognized by voice recognition. Speak
in the wording specified by the voice
commands.
•It is not necessary to face the
microphone or approach it. Speak the
voice commands while maintaining a
safe driving position.
•Close the windows and/or the moonroof
to reduce loud noises from outside the
vehicle, or turn dow n the airflow of the
climate control system while Bluetooth
®
Hands-Free is being used.
•Make sure the vents are not directing air
up towards the microphone.
Interior Features
Audio Set
5-72
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

NOTE
Tires degrade over time, even when they
are not being used on the road. It is
recommended that tires generally be
replaced when they are 6 years or older.
Heat caused by hot climates or frequent
high loading conditions can accelerate the
aging process. You should replace the
spare tire when you replace the other road
tires due to the aging of the spare tire. The
period in which the tire was manufactured
(both week and year) is indicated by a
4-digit number.
Refer to Tire Labeling on page 8-26.
▼Replacing a Wheel
WA R N I N G
Always use wheels of the correct size on
your vehicle:
Using a wrong-sized wheel is dangerous.
Braking and handling could be affected,
leading to loss of control and an accident.
CAUTION
A wrong-sized wheel may adversely
affect:
 Tire fit
 Wheel and bearing life
 Ground clearance
 Snow-chain clearance
 Speedometer calibration
 Headlight aim
 Bumper height
 Tire Pressure Monitoring System
*
NOTE
•When replacing a wheel, make sure the
new one is the same as the original
factory wheel in diameter, rim width,
and offset (inset/outset).
•For details, contact an Authorized
Mazda Dealer.

Proper tire balancing provides the best
riding comfort and helps reduce tread
wear. Out-of-balance tires can cause
vibration and uneven wear, such as
cupping and flat spots.
Maintenance and Care
Owner Maintenance
6-44*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Uniform Tire Quality Grading System (UTQGS)
This information relates to the tire grading system developed by the U.S. National Highway
Traffic Safety Administration fo r grading tires by tread wear, traction, and temperature
performance.
▼ Tr e a d We a r
The tread wear grade is a compara
tive rating based on the wear rate of the tire when tested
under controlled conditions on a specified government test cour se.
For example, a tire graded 150 would wear one-and-a-half times as well on the government
course as a tire graded 100.

The relative performance of tires depends upon the actual condi tions of their use, however,
and may depart significantly from the norm because of variations in driving habits, service
practices and differences in road characteristics and climate.
▼ Traction-AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B, and
C. These grades represent the
tire's ability to stop on wet pavement as measured under contro lled conditions on specified
government test surfaces of asphalt and concrete. A tire marked C may have poor traction
performance.
WA R N I N G
The traction grade assigned to th is tire is based on braking (straight ahead) traction tests and
does not include acceleration cornering (t urning), hydroplaning, or peak traction
characteristics.
▼ Temperature-A, B, C
The temperature grades A (the highest), B, and C, represent the
tire's resistance to the
generation of heat and its ability to dissipate heat when teste d under controlled conditions
on a specified indoor laboratory test wheel.
Sustained high temperature can cause the material of the tire t o degenerate and reduce tire
life, and excessive temperatures can lead to sudden tire failure.

Grade C corresponds to a level of performance which all passeng er vehicle tires must meet
under the Federal Motor Vehicle S afety Standard No. 109. Grades B and A represent higher
levels of performance on the laboratory test wheel than the min imum required by law.
Customer Information and Reporting Safety Defects
Uniform Tire Quality Grading System (UTQGS)
8-24
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼We i g h t s
U.S.A. and Canada
Item We i g h t
2WD AWD
GVWR (Gross Vehicle Weight Rating) 2,568 kg (5,661 lbs) 2,638 kg (5,816 lbs)
GAWR (Gross Axle Weight Rating) Front 1,217 kg (2,683 lbs) 1,241 kg (2,736 lbs)
Rear 1,386 kg (3,056 lbs) 1,433 kg (3,159 lbs)
Mexico
Item We i g h t
2WD AWD
GVW (Gross Vehicle Weight) Total 2,495 kg (5,500 lbs) 2,565 kg (5,655 lbs)
Front 1,180 kg (2,601 lbs) 1,200 kg (2,646 lbs)
Rear 1,315 kg (2,899 lbs) 1,365 kg (3,009 lbs)
GAW (Permissible axle load) Front 1,200 kg (2,646 lbs) 1,225 kg (2,701 lbs)
Rear 1,370 kg (3,020 lbs) 1,420 kg (3,131 lbs)
▼
Air Conditioner
The type of refrigerant used is indicated on a label attached t
o the inside of the engine com-
partment. Check the la bel before recharging the refrigerant. Re fer to Climate Control Sys-
tem on page 5-4.
Item Classification
Refrigerant Type HFC134a (R-134a)
Specifications
Specifications
9-6
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Index
Pad wear indicator....................... 4-69
Warning light............................... 4-69
Break-In Period.......... ....................... 3-48
C
Capacities............................................ 9-5
Carbon Monoxide............................. 3-31
Cell Phones....................................... 8-21
Center Console................................ 5-100
Child Restraint Categories of child-restraint
systems.........................................2-35
Child-restraint precautions.......... 2-30
Child-restraint system
installation................................... 2-35
Child-restraint system suitability for
various seat positions table..........2-38
Installing child-restraint
systems.........................................2-42
LATCH child-restraint systems... 2-52
Child Safety Locks fo r Rear Doors... 3-21
Climate Control System...................... 5-4 Front Air Conditioner....................5-7
Gas specifications.......................... 9-6
Operating tips................................ 5-4
Rear Air Conditioner... ................ 5-14
Vent Operation (Front).................. 5-5
Vent operation (Rear).................. 5-12
Collision warning.............................. 7-51
Coming Home Light......................... 4-52
Cruise Control................................. 4-155 Cruise control switc h.................4-155
Cruise main indication (white)/cruise
set indication (green)................. 4-156
Cruise Control Set Vehicle Speed
Display.............................................. 4-18
Cup Holder........................................ 5-97
Customer Assistance.... ....................... 8-2
D
Dashboard Illumination. ....................4-16
Daytime Running Lights................... 4-53
Defogger Mirror...........................................4-60
Rear window........... .................... 4-59
Dimensions.......................................... 9-5
Distance Recognition Support System
(DRSS)............................................ 4-104 Indication on display................. 4-104
Door Locks........................................3-12
Drive Selection..................................4-79
Driving In Flooded Ar ea...................3-53
Driving on Uneven Road.................. 3-54
Driving Tips
Automatic transaxle.....................4-48
Break-in period............................ 3-48
Driving in flooded a rea............... 3-53
Driving on uneven road...............3-54
Floor mat..................................... 3-50
Hazardous driving.. ..................... 3-49
Overloading............. .................... 3-53
Rocking the vehicle. .................... 3-50
Saving fuel and protection of the
environment................................. 3-48
Turbocharged vehicles.................3-55
Winter driving............................. 3-51
Dynamic Stability Control (DSC)..... 4-75 TCS/DSC indicator light............. 4-75
E
Electric parking brake (EPB)............ 4-67
Electric Parking Brake (EPB) Warning
Beep...................................................7-50
Emergency Starting
Push-starting................................ 7-24
Starting a flooded engine............ 7-24
Emergency Towing Towing description...................... 7-27
10-3
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
