If the Active Driving
Display Does Not Operate
If the active driving display does not
operate, switch the ignition off and then
restart the engine. If the active driving
display does not operate even with the
engine restarted, have the vehicle
inspected at an Authorized Mazda Dealer.
If Trouble Arises
Active Driving Displa y Does Not Operate
7-53
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

Personalization Features
The following personalization features can be set or changed by the customer or an Author-
ized Mazda Dealer. Consult an Auth orized Mazda Dealer for details.
Additionally, some of the personalization features can be changed by the customer depend-
ing on the feature.
Personalization features and settings which can be changed differ depending on the market
and specification.
Personalization features which can be changed may change without notice depending on
software updates.
Settings Change Method
Settings can be changed by operating the center display screen.
A: Refer to Settings on page 5-78.
B: Refer to Fuel Economy Monitor on page 4-106.
C: Refer to Active Driving Display on page 4-56.
Settings can be changed by operating the vehicle switches.
D: Refer to Auto Lock/Unlock Function on page 3-17.
E: Refer to Transmitter on page 3-5.
F: Refer to Locking, Unlockin g with Request Switch (With the advanced keyless function)
on page 3-14.
Settings can be changed by an Authorized Mazda Dealer.
Item FeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Safety
Advanced Smart
City Brake Sup-
port (Advanced
SCBS) (page
4-167)
Smart City
Brake Support
(SCBS) (page
4-170)
Smart Brake
Support (SBS)
(page 4-173) The system can be changed so that Advanced
Smart City Brake Support (Advanced SCBS)/
Smart City Brake Support (SCBS)/Smart Brake
Support (SBS) does not operate.
*1
On On/Off A
―
The distance at which the collision warning ac-
tivates can be changed. Med. Near/Med./Far A
―
The volume of the collision warning can be
changed. High High/Low/Off A
―
Lane-keep As-
sist System
(LAS) & Lane
Departure Warn-The system can be changed so that the steering
wheel assist does not operate.
On On/Off A―
Specifications
Personalization Features
9-9
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Distance Recog-
nition Support
System (DRSS)
(page 4-133) The system can be changed so that Distance
Recognition Support Syst
em (DRSS) does not
operate.*1On On/Off A ―
The distance at which the vehicle ahead and
your vehicle indicated in the display flashes in
white can be changed. Near Far/Med./Near A
―
Traffic Sign
Recognition
System (TSR)
*3
(page 4-127)The Traffic Sign Recognition System (TSR)
can be set to inoperable.
*1On On/Off A
―
The warning pattern of the excessive speed
warning can be changed. OffOff/
Vi s u a l /
Audio & Visual A
―
The activation timing for the excessive speed
warning can be changed.00/5/10 A
―
360° View Mon-
itor (page 4-175) Setting can be changed so that the 360° view
monitor is automatically displayed when the
ignition is switched to ON.
Off On/Off A
―Setting can be changed so that the display of
the estimated forward line of progress is not
displayed. On On/Off A
―
Setting can be changed so that the top view/
front view displayed while the vehicle is mov-
ing in the forward direction after reversing is
not displayed. On On/Off A
―
Parking sensor
system (page
4-234)Display*4/non-display
On On/Off A
―
Ve h i c l e
Door locks
(page 3-17)Operation condition of
auto lock/unlock func-
tion Lock: When
Driving Un- lock: IGN Off Lock: Out of
Park Unlock: In Park/
Lock: Shifting Out of Park/
Lock: When
Driving Unlock: In Park/
Lock: When
Driving Unlock: IGN Off/
Lock: When Driving/ Off AD
Specifications
Personalization Features
9-11
CX-9_8HT8-EA-19I_Edition2_old
2019-9-24 13:14:55

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Auto-light con-
trol (page 4-68) Timing by which lights turn on Medium High/
Med. High/ Medium/
Med. Low/ Low A
―
High Beam Con-
trol System
(HBC) (page
4-118) Operational/non-operational
*1On On/Off A
―
Adaptive Front
Lighting System
(AFS) (page
4-117)Operational/non-operational
*1On On/Off A
―
Lights-on re-
minder*8 (page
7-47) Warning beep volume High High/Low/Off A
―
Coming home
light (page 4-71)Time until headlights turn off 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off A
―
Leaving home
light (page 4-71) Operational/non-operational On On/Off A
―
Turn indicator
(page 4-73)Beep volume High High/Low A
―
Three-flash turn
signal (page
4-74)Operational/non-operational On On/Off A
―
Ambient Light-
ing (page 5-94)Ambient lights brightness*9MediumBright/
Medium/ Dim/
Off
*10
A ―
Rear window
defogger (page
4-78) The operation time for the rear window defog-
ger can be changed.
15 minutes15 minutes/
Continuous
*11――
System
Language Language indicated in display US EnglishDepends on
market
*12A ―
Temperature Temperature unit in dicated in display °F °F/°C A ―
Distance Distance unit indicated in display mi or km mi/km A―
Specifications
Personalization Features
9-13
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Fuel Economy Monitor (page 4-106)
Ending display Display/non-display Off On/Off B ―
Fuel economy
resetting proce-
dure
*
Linkage/non-linkage with fuel economy reset
and trip meter A resetOff On/Off B
―
Active driving display (page 4-56)
Display Setting can be changed so that the Active Driv-
ing Display is not displayed.
On On/Off C
―
The display height (up/down position) can be
changed. 013 steps up/
down from ini-
tial setting (total: 27 steps) C
―
The method for adjusti ng the display bright-
ness (automatically/manually) can be changed. Auto Auto/Man. C
―
The standard brightness with the automatic
brightness adjustment can be changed. 02 steps up/down
from initial set- ting (total: 5
steps) C
―
The standard brightness with the manual
brightness adjustment can be changed. 020 steps up/
down from ini-
tial setting (total: 41 steps) C
―
The display angle can be changed. 03steps up/down
from initial set- ting (total:7steps) C
―
The street name display tim ing can be changed. On-Dem. On-Dem./At
Maneuver/Off C
―
Display/non-display of the navigation guidance On On/Off C ―
*1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda
recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation can be changed. Thevolume of the warning beep during Rear Cross Traffic Alert (RCTA) operation cannot be changed.
*3 This system functions only when the navigation system is functioning.*4 When the ultrasonic sensors detect an obstruction, the co ntents indicated on the center display switches to the
360°View Monitor. (Vehicles with 360°View Monitor)
*5 If the auto-wiper control is set to Off, the wiper lever position is set to intermittent operation.*6 If the setting is changed to Off, the following oper ation is performed according to the headlight switch
position:
At position: Headlights turn off immediately after the ignition is switched off.
Specifications
Personalization Features
9-14*Some models.
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55

At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-68.
*7 When set to 0 seconds, the lights-on reminder is operable.*8 The lights-on reminder settings can be changed at a nytime, however, the lights-on reminder only operates
when the auto headlight function is set to Of f. Refer to Lights-On Reminder on page 7-47.
*9 Change the ambient light illumination level with the parking lights or headlights turned on.*10 When set to OFF, the ambient lights remain turned off regardless of whether or not the parking lights or
headlights are on or off. However, they will turn on or off in conjunction with the illuminated entry system.
*11 The operation may stop in 15 minutes due to the effect of the outside temperature even if the operation time ofthe rear window defogger has been changed to Continuous.
*12 Available only in display from the center display.
Specifications
Personalization Features
9-15
CX-9_8HT8-EA-19I_Edition2_old 2019-9-24 13:14:55
